Transition Bicycle Company CARBON COVERT 26 User manual

FRAME MANUAL
MODEL: CARBON COVERT 26
VERSION: V2
DATE: 2014
BICYCLE COMPANY

Congratulations on the purchase of your Transition frame. This
manual will give you helpful information on how to develop a
long and lasting relationship with your bike. Read every word
of this manual because we may quiz you on it later.
Frame Specications
REAR TRAVEL: 160mm (6.3”)
REAR SHOCK: 216mm x 63.5mm (8.5” x 2.5”)
(22.2mm x 8mm eyelets)
FRAME MATERIAL: Monocoque Carbon Fiber Front
Triangle, Carbon Seatstay,
Alloy Chainstay
SIZES: Small, Medium, Large
COLORS: Black, Green, Orange
WARRANTY: 2 year defect warranty
Lifetime crash replacement
Build Specications
SEATPOST/CLAMP: 31.6mm Seatpost/34.9mm Clamp
HEADTUBE: 44mm/56mm Zero Stack
BOTTOM BRACKET: 73mm Press Fit 30
REAR DROPOUT: 142 x 12mm Shimano Standard
135 x 10mm (optional)
HANGER PART NO: 12mm: 93.1245
10mm: 93.1036
FRONT DERAILLEUR: Low Direct Mount
(S3 SRAM / E2 Shimano)
CHAINGUIDE: ISCG 05 - 2.5mm Offset
REAR BRAKE: 160mm IS
REAR AXLE: Shimano AX-55 E-Thru Axle QR
Geometry SM MD LG
Reach 383 409 435
Stack 580 593 607
Top Tube (Effective) 552 584 615
Seat Tube (Center to Top) 407 445 483
Head Tube Angle 66.9° 66.9° 66.9°
Seat Tube Angle * 73.9° 73.6°73.4°
Chainstay Length 430 430 430
Bottom Bracket Height 346 346 346
Bottom Bracket Drop -4 -4 -4
Wheelbase 1103 1135 1167
Head Tube Length 110 125 140
Geometry based on 537.9mm axle to crown fork with 37mm offset and 2.9mm lower
headset stack. Length Measurements are in Millimeters.
* Measured at these saddle heights: (620mm SM, 680mm MD, 740mm LG)
Shock/Suspension Setup
Your frame comes equipped with a custom tuned rear
shock designed to work in conjunction with the frame’s
leverage curve. Adjustments like rebound, compression
and sag are all personal preference settings that should
be adjusted to your personal riding style and preferences.
Consult your shock manual for information about how to
adjust your rear shock.
CHAINSTAY
WHEELBASE
BB DROP
HEADTUBE ANGLE
STACK
REACH
EFFECTIVE TOP TUBE
EFFECTIVE
SEAT TUBE
ANGLE
SEAT TUBE LENGTH

Cable Routing
Your Transition frame has cable routing for the following
components.
1. Stealth Adjustable Seatpost
2. Standard Adjustable Seatpost
3. Front Derailleur Bottom Pull
4. Rear Derailleur*
5. Rear Brake
*Front derailleur mount includes a guide for rear derailleur cable and
cable stop for Shimano front derailleurs. A cable stop for SRAM rear
derailleurs is located on the chainstay yoke.
Maintenance
It is crucial to the longevity of your Transition frame that you
properly maintain and inspect it. We recommend that all
service be done by a qualied Transition Bikes dealer.
Before you begin any ride it is very important to inspect
your entire frame for any cracks, loose pivots or bolts, and
properly functioning bearings. In addition to inspecting your
frame, checking your entire bike to make sure it is working
properly must happen before every ride. This includes but is
not limited to checking tire pressure, ensuring the wheels are
secure to the frame and fork, all components and brake bolts
are tight and pedals are secure. Also, a quick check of your
brake pads and brakes to insure they are working properly
and ready to ride. If you are unsure of what you need to
check on your bike to make sure it is safe, please bring your
bike to a bicycle shop to have them inspect and maintain it
before you begin a ride.
Bearings
Take apart all the linkage and rocker arms to inspect the
bearings to see if they are rotating smoothly. If they do
not feel smooth or are seized up, you should replace the
affected bearings. Always replace bearings in pairs.
Rocker Arm Pivot Bearings Qty: 4 - 6901
Bottom Bracket Pivot Bearings Qty: 2 - 6902
Dropout Seat Stay Pivot Qty: 2 - 6900
Torque Settings
Torque ratings for the hardware used on this product are
listed below. Damage caused by over/under torquing will not
be covered by the warranty on this product.
• All Pivot Bolts 150 in/lbs (16.9 N·m)
• Sleeved 2 piece Shock Mounting Bolt 125 in/lbs (14 N·m)
• Main Rocker Arm Shock Mounting Bolt 200 in/lbs (22.5 N·m)
• Dropout Bolt 75 in/lbs ( 8.4 N·m)

Warranty
Your Transition Frame is covered under a 2 year warranty
period against any manufacturing defects or aws. This
does not cover normal wear and tear of the frame, misuse
or crashing. This warranty only applies to the original owner
of the frame 2 years from the date of purchase.
Transition Bikes also offers a lifetime crash replacement of
the frame for the original owner. In the event your frame is
broken due to a crash or rider negligence, Transition Bikes
will offer a replacement frame at a discounted price.
Register Your Frame
To be eligible for your warranty or crash replacement you
must register your frame with Transition Bikes and maintain
a proof of purchase from the location you purchased the
frame. Transition Bikes and your bike shop do not keep
records of your serial number unless you register it with us
on our site. Visit: www.transitionbikes.com/Register.cfm to
register your frame.
Warning!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Riding mountain bikes is an extremely dangerous activity.
The rider of any Transition Bikes frame assumes all the
risk when they ride their Transition Bike. Transition Bikes
assumes no liability in the event of a crash or broken frame.
It is up to the rider and bike shop to properly maintain and
inspect the frame for any aws or cracks before every ride.
It is the riders responsibility to ride within their limits and not
push the frame beyond it’s intended use.
