Vision Team clip-on s-bend User manual

Vision

TeamClip

OnHandlebar InstallationInstructions

Published Dec, 2016.ZS192.v0 ©Full SpeedAhead

Introduction

CongratulationsonyourVisionproduct.Pleaseread theseinstructionsandfollowthemforcorrectuse. Failuretofollow

thewarnings andinstructionscouldresultin damagetoproductnotcoveredunderwarranty,damagetobicycle; or

causeanaccident resultingininjury ordeath.Sincespecifictoolsandexperiencearenecessary forproperinstallation,it

isrecommendedthattheproductbeinstalledby aqualifiedbicycletechnician.FSA& Vision assumesnoresponsibility

for damages or injuryrelated toimproperly installed components.

Warranty

FullSpeedAhead(FSA)warrantsallFSA,Vision,MetropolisandRPMproductstobefree fromdefectsin materialsor

workmanshipforaperiodoftwoyears afteroriginalpurchaseunless otherwisestatedin thefull warrantypolicy.The

warrantyisnon-transferableandvalidto theoriginalpurchaserof theproductonly.Anyattempttomodifytheproductin

anywaysuchasdrilling,grinding,andpaintingwillvoidthewarranty.Formoreinformation onwarrantypolicyand

instructionsforcompletingawarrantyclaim, checkouttheFull WarrantyPolicyfoundatourwebsite:

http://www.visiontechusa.com/support/warranty-policy/

Always useacalibratedtorquewrenchtotightenallscrews andbolts when assemblingand adjustingthe

visionhandlebar tothebicycle. Failureto useacalibrated torquewrenchcan causedamagetothehandlebar making it

unsafetoride, andisnotcoveredunderwarranty.Checkboltandscrewtorquebeforeeachridetoensuretheyhavenot

loosened duringuse.

Periodicallyinspectyouraerboarsforanycracks,chips,scratches,andanyothervisibledamage. Inthe

event ofanaccidentdonotridethebicycleuntilthehandlebars havebeeninspectedby anexperiencedmechanicasthe

aerobars maybedamagedorweakenedevenif novisibledamageisapparent.Ifthereisanyvisibledamage, the

aerobars shouldnotbeusedanyfurther and replaced.

Specification

Theseinstructionsarefor theinstallationandadjustmentofthefollowing VisionBrand components only:

ItemNumber / ModelName HB-RO-a410/SB /TeamClip-on Bar-Close(1-Piece)

HB-RO-a420/JB/TeamClip-on Bar-Open(2-Piece)

Components

Follow theassembly order intheillustration:

Handlebar

②ClampBolts(16 mm)x4

③Lower Clamp x2

④Upper Clamp x2

⑤ArmrestMount(L & R)x2

⑥AeroExtension(L& R)x2

⑦AeroExtensionBolts(35 mm)x2

⑧ArmrestPlates(L &R)x2

⑨Washer x4

⑩ArmrestPlatesFixingBolts (10mm) x4

AdhesiveVelcroStripsx2

⑫ArmrestPadx2

⑬AeroExtensionFrontPlugx2

⑭AeroExtensionRear Plug x2

Clip-On Aerobarinstallation

1. Visionclip-on barclamps are 31.8mm diameter.Ensurehandlebariscompatiblewithclip-on aerobars andis 31.8mm diameter.FSAreccommends usingcarboninstallationcompoundbetween clampsurfacesandhandlebar,

especiallyonclip-on compatiblecarbon handlebars.DO NOTapply greasetoany oftheclamping surfaces.

Installingclip-onaerobars onanon-compatiblehandlebar cancausedamagetothehandlebarand mayresultinaccident,injury or death.

2. InstallUpper and Lower Clamps ③,on④thehandlebar .Movetheclamp platestothedesired width.Alternately tightenClampBoltsto60 kgf.cm / 6Nm / 53 in.lbs.②

Toensureclamping securityandsafety,installclip-onbarsonly ontheroundcenter section ofhandlebar.Donotinstallclip-onbar onanytapered or shaped sectionofhandlebar.

Installing clip-onbar inany locationother than theround center sectionmay causeslippageor damagetohandlebaror aerobar resulting inloss ofcontrol,accident,injury or death.

3. InstallAeroExtensions intoUpper Clamp⑥④and ArmrestMount.Setto desired length.Alternatelytighten⑤AeroExtensionBoltsto⑦60 kgf.cm / 6Nm / 53 in.lbs.

4.ChoosethedesiredarmrestpositionandattachtheArmrestPlate ⑧toArmrestmount ⑤.Install ArmrestPlateFixingBoltsand Washers andtighten t⑩⑨o60 kgf.cm /6Nm / 53 in.lbs.

Alwaysuseacalibrated torquewrenchtotightenarmrestfixingbolts.

Always installthearmrestbolts withwashers.Installingarmrestboltswithout washers can causearmreststocrackandfail unexpectedly whileriding resulting inloss ofcontrolofbicycle.

5. Removetheadhesivevelcrostrips fromarmrestpads ⑫andattachtothe top surfaceofleft and rightarmrestplates.

6. Press AeroExtensionFront and RearPlugs ⑬, ⑭intoaeroextension.

UseonlysuppliedVisionboltsforinstallation.Usingboltsother thanoriginalsuppliedboltsmaycausedamagetoextensionbarthreadsresulting inarmrestplateposition deflectionwhileriding,resulting inloss of
