Transition Networks
CPSMC13xx-100
13-Slot PointSystem™ Chassis
User’s Guide
Revision D
CPSMC1300-100
CPSMC1310-100
CPSMC1320-100

2
CPSMC13xx-100 PointSystem™ Chassis
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Compliance Information
UL Listed
C-UL Listed (Canada)
CISPR22/EN55022 Class A + EN55024
CE Mark
FCC Regulations
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case
the user will be required to correct the interference at the user’s own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on the radio
interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la Class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des
Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses Gerätes
Rundfunkstörungen auftreten. In diesem Fäll ist der Benutzer für Gegenmaßnahmen verantwortlich.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de créer des interférences
radioélectriques, il appartiendra alors à l’utilsateur de prende les measures spécifiques appropriées
Trademark Notice
All trademarks and registered trademarks are the property of their respective owners.
Copyright Restrictions
© 2001-2005 Transition Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any means – graphic, electronic,
or mechanical – without written permission from Transition Networks.
Printed in the U.S.A. 33208.D

3
CPSMC13xx-100 PointSystem™ Chassis
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.2 Unpacking the CPSMC13xx-100 Equipment . . . . . . . . . . . . . . . . . . . . . .5
2 Slide-in-Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.1 Media Converter Slide-in-Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.1.1 Chassis Face Plates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.1.2 Calculating Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.1.3 Installing Media Converter Slide-in-Modules . . . . . . . . . . . . . . . . . . . . .7
2.1.4 Replacing Media Converter Slide-in-Modules . . . . . . . . . . . . . . . . . . . . .8
2.2 Management Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.2.1 Three Types of Management Modules . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.2.2 Installing the Management Modules . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.2.3 Replacing the Management Modules . . . . . . . . . . . . . . . . . . . . . . . . . .11
3 Powering the CPSMC13xx-100 . . . . . . . . . . . . . . . . . . . . . . .12
3.1 CPSMP-120 Power Supply Module (AC) . . . . . . . . . . . . . . . . . . . . . . . .12
3.2 CPSMP-130 Power Supply Module (48-VDC) . . . . . . . . . . . . . . . . . . . .14
3.3 CPSMP-140 Power Supply Module (24-VDC) . . . . . . . . . . . . . . . . . . . .16
3.4 Optional Dual Power Supply Modules . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.5 Power Supply Module Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3.5.1 Installing the Power Supply Module . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3.5.2 Replacing the Power Supply Module . . . . . . . . . . . . . . . . . . . . . . . . . .20
3.5.3 Replacing the Power Supply Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
4 CPSMC13xx-100 Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
4.1 Installing the CPSMC13xx-100 Chassis . . . . . . . . . . . . . . . . . . . . . . . . .23
4.1.1 Table Top Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
4.1.2 Standard 19-inch Rack Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
4.1.3 Grounding Lugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
4.2 Cascade Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
4.3 Connecting the Slide-in-Modules to the Network . . . . . . . . . . . . . . . . .28
4.4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
5 Network Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
5.1 Hardware Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

4
CPSMC13xx-100 PointSystem™ Chassis
introduction
1 Introduction
1.1 Description
The Transition Networks CPSMC13xx-100 13-Slot PointSystem™ chassis is a 19-
inch, rack-mountable chassis for selected Transition Networks media converter
slide-in-modules. The CPSMC13xx-100 chassis allows the network administrator to
connect various copper and fiber-optic network media over protocols that include
Ethernet, Fast Ethernet, DS3/E3, and OC-12 and many others. The chassis provides
installation space for up to 13 single-slot media converter slide-in-modules in the
front of the unit.
The CPSMC13xx-100 also comes equipped with an AC or DC power supply
installed in the front of the chassis. An extra installation space is available for an
optional redundant AC or DC power supply.
With installed PointSystem™ management module(s) (P/N CPSMM-120, -200, or
-210), the CPSMC13xx-100 can be managed and monitored via:
• An SNMP application such as Transition Networks FocalPoint™ management
software installed at a remote Network Management Station (NMS).
• A remote Web browser.
• A command-line interface (CLI) at an attached terminal.
• A command-line-interface (CLI) at a remote Telnet connection.
The management modules also make it possible to control up to eight (8) cascaded
chassis fully populated with installed media converter slide-in-modules.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CFMFF100
10BASE-2
CECF100 CFMFF100
050½
Link Alert
ED
CETCF100 CFETF100
CFETF110
CFMFF100
LA PWR
RXF
RXC
LNK
COL
SPD PWR
FRX
CRX
FLNK
CLNK
SPD PWR
FRX
CRX
FLNK
CLNK
10/100TX
RX
TX
10/100SX
100BASE-TX
RX
TX
100BASE-FX
Link Alert
ED
050½
LA PWR
RXF
RXC
LNK
COL
LKS
PWR
LKM
10BASE-2
10BASE-FL
10BASE-T
LKS
PWR
LKM
LKS
PWR
LKM
Multimode
Singlemode
TX
RX
TX
RX
Multimode
Singlemode
TX
RX
TX
RX
Multimode
Singlemode
TX
RX
TX
RX
TERM
INIT
RX
TX
LNK
PWR
CPSMM120
SERIAL
10BASE-T
R
E
S
E
T
I
0
Management
Module
Installed
Slide-in-Module Open Slot
Power Supply Module
(AC module is pictured)
Extra Installation
S
p
ace

5
CPSMC13xx-100 PointSystem™ Chassis
introduction
1.2 Unpacking the CPSMC13xx-100 Equipment
Use the following list to verify the shipment:
Item Part Number
13-Slot chassis with AC Power Supply CPSMC1300-100
13-Slot chassis with 48-VDC Power Supply CPSMC1310-100
13-Slot chassis with 24-VDC Power Supply CPSMC1320-100
PointSystem™ chassis face plates (10) CPSFP-200
Power Cord (varies by country)
User’s Guide 33208
The following items are optional accessories for the CPSMC13xx-100 13-Slot
PointSystem™ chassis:
Item Part Number
Redundant AC Power Supply 120/240 VAC CPSMP-120 (optional)
Redundant 48-VDC Power Supply CPSMP-130 (optional)
Redundant 24-VDC Power Supply CPSMP-140 (optional)
Single-Slot Master Management Module CPSMM-120 (optional)
Dual-Slot Master Management Module CPSMM-200 (optional)
FocalPoint™ Software Disk 7223
(included with the Master Management Modules)
Expansion Management Module CPSMM-210 (optional)
Management Module Cascade Connector 6026 (optional)
23-inch Rack Mount Ears CPSRE-230 (optional)
Selectable Media Converter Slide-in-Module(s) (various P/N) - (optional)
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600

6
CPSMC13xx-100 PointSystem ™ Chassis
slide-in-modules
2 Slide-in-Modules
2.1 Media Converter Slide-in-Modules
Transition Networks media converter slide-in-modules, installed in slots at the front
of the chassis, allow the network administrator to connect various copper and fiber-
optic network media over protocols that include Ethernet, Fast Ethernet, DS3/E3,
and OC-12 as well as many others (see www.transition.com for a complete listing).
NOTE: Refer to the specific user’s guide that comes with each media converter
slide-in-module for cable, connector, and LED indicator information.
2.1.1 Chassis Face Plates
CAUTION: Slots in the CPSMC13xx-100 chassis without a slide-in-module
installed MUST have a protective chassis face plate (P/N CPSFP-200) covering the
empty slot for Class A compliance.
Install a chassis face plate over any unused chassis slot by aligning the hole in the
face plate with the threaded hole in the chassis. Secure the face place with the
enclosed bolt.
2.1.2 Calculating the Power Consumption
CAUTION: Before installing the media converter, refer to the power consumption
data for each individual media converter (provided in the user’s guide shipped with
each media converter). The combined power consumption of all devices must not
exceed the available power supply. Failure to observe this caution could result in
diminishing system reliability.
In other words, the combined power requirements of the CPSMC13xx-100 chassis
plus all slide-in-modules must be less than the available power.
In addition, the maximum power delivery capacity for each chassis slot is 12 Watts,
with an aggregate chassis maximum of 6 Watts per slot. For example, a 12-Watt
slide-in-module media converter would require the power of two slots. Therefore,
only six (6) 12-Watt converters could be installed into the CPSMC13xx-100 chassis.
Six (6) slots must remain unused and the remaining slot can accommodate a slide-
in-module up to 6 Watts.
Contact Transition Networks Tech Support to ensure the power requirements for
your specific application do not exceed the available power.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
I
0
Chassis Face Plate

7
CPSMC13xx-100 PointSystem ™ Chassis
slide-in-modules
2.1.3 Installing the Media Converter Slide-in-Modules
CAUTION: Wear a grounding device and observe electrostatic discharge
precautions when installing the slide-in-module(s). Failure to observe this caution
could result in damage to, and subsequent failure of, the slide-in-module(s).
NOTE: The slide-in-modules can be installed in any installation slot, in any order.
To install the slide-in-module into the CPSMC13xx-100 chassis:
1. If a chassis face plate (P/N CPSFP-200) is covering the installation slot, remove
the face plate from the installation slot by removing the one (1) screw that
secures the plate to the front of the chassis.
NOTE: If the slide-in-module requires two slots, remove the face plates from
two (2) adjacent installation slots.
2. Align the slide-in-module with the chassis installation slot so that the panel
fastener screw is at the top of the module.
3. Carefully slide the slide-in-module into the installation slot, while aligning the
module’s circuit board with the installation guides.
NOTE: Ensure that the slide-in-module is firmly seated inside the chassis.
4. Push in and rotate the attached panel fastener screw clockwise to secure the
slide-in-module to the chassis.
5. Repeat steps 1 through 4 for any additional slide-in-module(s).
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CFMFF100
10BASE-2
CECF100 CFMFF100
050½
Link Alert
ED
CETCF100 CFETF100
CFETF110
CFMFF100
LA PWR
RXF
RXC
LNK
COL
SPD PWR
FRX
CRX
FLNK
CLNK
SPD PWR
FRX
CRX
FLNK
CLNK
10/100TX
RX
TX
10/100SX
100BASE-TX
RX
TX
100BASE-FX
Link Alert
ED
050½
LA PWR
RXF
RXC
LNK
COL
LKS
PWR
LKM
10BASE-2
10BASE-FL
10BASE-T
LKS
PWR
LKM
LKS
PWR
LKM
Multimode
Singlemode
TX
RX
TX
RX
Multimode
Singlemode
TX
RX
TX
RX
Multimode
Singlemode
TX
RX
TX
RX
I
0
TERM
INIT
RX
TX
LNK
PWR
CPSMM120
SERIAL
10BASE-T
R
E
S
E
T
I
0
CFMFF100
Multimode
Singlemode
TX
RX
TX
RX
LKF
PWR
RXF
RXC LKC
RX
TX
10BASE-T
10BASE-FL
Panel Fastener Scre
w

8
CPSMC13xx-100 PointSystem ™ Chassis
slide-in-modules
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
2.1.4 Replacing the Media Converter Slide-in-Modules
CAUTION: Wear a grounding device and observe electrostatic discharge
precautions when replacing the slide-in-module(s). Failure to observe this caution
could result in damage to, and subsequent failure of, the slide-in-module(s).
NOTE: The media converter slide-in-modules can be hot-swapped.
To replace a media converter slide-in-module:
1. Remove the slide-in-module to be replaced by loosening the panel fastener
screw that secures it to the chassis front. Slide the module from the chassis.
2. Align the replacement slide-in-module with the chassis installation slot so that
the panel fastener screw is at the top.
3. Carefully slide the replacement slide-in-module into the installation slot, while
aligning the module’s circuit board with the installation guides.
NOTE: Ensure that the slide-in-module is firmly seated inside the chassis.
4. Rotate the attached panel fastener screw clockwise to secure the slide-in-
module to the chassis.
CFMFF100
10BASE-2
CECF100 CFMFF100
050½
Link Alert
ED
CETCF100 CFETF100
CFETF110
CFMFF100
LA PWR
RXF
RXC
LNK
COL
SPD PWR
FRX
CRX
FLNK
CLNK
SPD PWR
FRX
CRX
FLNK
CLNK
10/100TX
RX
TX
10/100SX
100BASE-TX
RX
TX
100BASE-FX
Link Alert
ED
050½
LA PWR
RXF
RXC
LNK
COL
LKS
PWR
LKM
10BASE-2
10BASE-FL
10BASE-T
LKS
PWR
LKM
LKS
PWR
LKM
Multimode
Singlemode
TX
RX
TX
RX
Multimode
Singlemode
TX
RX
TX
RX
Multimode
Singlemode
TX
RX
TX
RX
I
0
TERM
INIT
RX
TX
LNK
PWR
CPSMM120
SERIAL
10BASE-T
R
E
S
E
T
I
0
CFMFF100
Multimode
Singlemode
TX
RX
TX
RX
LKF
PWR
RXF
RXC LKC
RX
TX
10BASE-T
10BASE-FL
Panel Fastener Scre
w

9
CPSMC13xx-100 PointSystem ™ Chassis
slide-in-modules
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
2.2 Management Modules
Optional network management is provided by SNMP software embedded in
Transition Networks
PointSystem
™
management module(s) that can be installed in
the CPSMC13xx-100 chassis.
Transition Networks provides two such modules:
• CPSMM-120 Single-Slot Master Management Module.
• CPSMM-200 Dual-Slot Master Management Module.
Along with an additional expansion module:
• CPSMM-210 Single Slot Expansion Management Module.
2.2.1 Three Types of Management Modules
CPSMM-120 Single-Slot Master Management Module
The optional CPSMM-120 Single-Slot Master Management Module can
be installed to enable network management of a single CPSMC13xx-
100 chassis.
Refer to the CPSMM-120 user’s guide for more information on the
CPSMM-120 Single-Slot Master Management Module.
CPSMM-200 Dual-Slot Master Management Module
The optional CPSMM-200 Dual-Slot Master Management
Module can also be installed in the CPSMC13xx-100 chassis to
enable network management.
This module has all of the features of the CPSMM-120 plus a pair
of cascade ports, which allow multiple PointSystem™ chassis to
be connected.
Note also that this module requires two adjacent slots in the
chassis for installation.
Refer to the CPSMM-200/-210 user’s guide for more information
on the CPSMM-200 Dual-Slot Master Management Module.
CPSMM-210 Single-Slot Expansion Management Module
The CPSMM-210 is used with the CPSMM-200 to connect up to eight (8)
PointSystem™ chassis into one manageable stack.
Refer to the CPSMM-200/-210 user’s guide for more information on the
CPSMM-210 Single-Slot Expansion Management Module.
NOTE: See section 4.2 Cascade Option for details on connecting
multiple chassis.
10BASE-T
RX
TX
LNK
PWR
RESET
SERIAL
CPSMM120
10BASE-T IN
CPSMM200
OUT
RX
TX
LNK
PWR
RESET
DB-9
RESET
CPSMM210
Power
IN OUT

10
CPSMC13xx-100 PointSystem ™ Chassis
slide-in-modules
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
2.2.2 Installing the Management Modules
CAUTION: Wear a grounding device and observe electrostatic discharge
precautions when installing the management module into the CPSMC13xx-100
chassis. Failure to observe this caution could result in damage to, and subsequent
failure of, the management module.
NOTE: Transition Networks recommends installing the management module into
the left-most installation slot to keep the management module cables separate from
the media converter cables.
To install a management module into the CPSMC13xx-100 chassis:
1a. CPSMM-200 Dual-Slot Master Management Module:
If chassis face plates are covering the installation slots, remove the face plates
from the two (2) installation slots at the far-left position of the chassis.
1b. CPSMM-120 Single-Slot Master Management Module OR
CPSMM-210 Single-Slot Expansion Management Module:
If chassis face plates are covering the installation slots, remove the face plate
from the one (1) installation slot at the far-left position of the chassis.
2. Align the management module with the chassis installation slot so that the panel
fastener screw is at the top of the module.
3. Carefully slide the management module into the installation slot, while aligning
the module’s circuit board with the installation guides.
NOTE: Ensure that management module is firmly seated inside the chassis.
4. Rotate the attached panel fastener screw clockwise to secure the management
module to the chassis.
I
0
TERM
INIT
RX
TX
LNK
PWR
CPSMM120
SERIAL
10BASE-T
R
E
S
E
T
I
0
MCCM10
MGMT MASTER
DB-9
12C 12C-1TERM INIT
RX
TX
LNK
PWR
RESET
DB-9
Panel Fastener Screw
I
0
TERM
INIT
RX
TX
LNK
PWR
CPSMM120
SERIAL
10BASE-T
R
E
S
E
T
I
0
RX
TX
LNK
PWR
RESET
Panel Fastener Screw

11
CPSMC13xx-100 PointSystem ™ Chassis
slide-in-modules
2.2.3 Replacing the Management Modules
CAUTION: Wear a grounding device and observe electrostatic discharge
precautions when replacing the management module(s). Failure to observe this
caution could result in damage to, and subsequent failure of, the management
module(s).
NOTE: The management modules can be replaced while the chassis remains
powered. However, you must configure a new IP address for the replacement
management module. For more information, see the FocalPoint™ 2.0 user’s guide
on the enclosed application CD or on-line at www.transition.com.
To replace a management module in the CPSMC13xx-100 chassis:
1. Remove the management module to be replaced by loosening the panel
fastener screw that secures the module to the chassis front. Slide the module
from the chassis.
2. Align the replacement module with the installation slot so that the panel
fastener screw is at the top.
3. Carefully slide the replacement management module into the installation slot,
while aligning the module’s circuit board with the installation guides.
NOTE: Ensure that the management module is firmly seated inside the chassis.
4. Rotate the attached panel fastener screw clockwise to secure the module to the
chassis.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
I
0
TERM
INIT
RX
TX
LNK
PWR
CPSMM120
SERIAL
10BASE-T
R
E
S
E
T
I
0
MCCM10
MGMT MASTER
DB-9
12C 12C-1TERM INIT
RX
TX
LNK
PWR
RESET
DB-9
Panel Fastener Screw

12
CPSMC13xx-100 PointSystem ™ Chassis
power supply
3 Powering the CPSMC13xx-100
3.1 CPSMP-120 Power Supply Module (AC)
The CPSMC1300-100 PointSystem™ chassis is equipped with an AC power supply
module (P/N CPSMP-120) installed in the front of the chassis. The power supply
module supplies power to the chassis, installed media converter slide-in-modules,
and management modules.
The components of the CPSMP-120 AC power supply module include:
• An AC power cord that distributes power from an external outlet to an AC
power connector on the power supply module.
• An On/Off switch that, when set to “I”, allows the module to supply power to
the chassis and any installed modules.
•Apower LED indicator.
• An fuse installed in a fuse holder.
Optional Redundant AC Power Supply Module
An extra installation space is available in the front of the chassis for installing an
optional redundant AC power supply module (P/N CPSMP-120). See section 3.5.1
Installing the Power Supply Module for instructions on installation.
Instant Fail-Over
The Instant Fail-Over feature ensures uninterrupted power to the chassis. If one of
the power supply modules loses power, the chassis mother board automatically
switches to the other power supply.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Power LED
AC Power Connector
On/Off Switch
Fuse Holder
AC Power Cord
I
0
I
0
Redundant Power Supply Installation Space

13
power supply
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CPSMC13xx-100 PointSystem™ Chassis
Powering the AC Power Supply Module
To power the CPSMC1300-100 chassis through the CPSMP-120 AC power supply
module:
1. Set the On/Off switch to “0”.
2. Connect the female end of power cord to the power receptacle on the power
supply module.
3. Plug the end of the power cord into the correct voltage AC rack or wall socket.
4. Set the On/Off switch to “I”.
5. Verify that the chassis is powered by observing the illuminated power LED.
Power LED
AC Power Connector
On/Off Switch
AC Power Cord
I
0
I
0

14
CPSMC13xx-100 PointSystem ™ Chassis
power supply
3.2 CPSMP-130 Power Supply Module (48-VDC)
The CPSMC1310-100 chassis is equipped with a 48-VDC power supply module
(P/N CPSMP-130) installed in the front of the chassis. The power supply module
supplies power to the chassis, installed media converter slide-in-modules, and
management modules.
The components of the CPSMP-130 48-VDC power supply module include:
• A set of three (3) external power connectors that distribute power from an
external 48-VDC outlet to a chassis ground connector, a positive (+) connector,
and a negative (-) connector on the power supply module.
• An On/Off switch that, when set to “I”, allows the module to supply power to
the chassis, and any installed modules.
•Apower LED indicator.
•Afuse installed on the power supply module’s circuit board.
Optional Redundant 48-VDC Power Supply Module
An extra installation space is available in the front of the chassis for installing an
optional redundant 48-VDC power supply module (P/N CPSMP-130). See section
3.5.1 Installing the Power Supply Module for instructions on installation.
Instant Fail-Over
The Instant Fail-Over feature ensures uninterrupted power to the chassis. If one of
the power supply modules loses power, the chassis mother board automatically
switches to the other power supply.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Power LED
External Power Connectors
On/Off Switch
Fuse (on the circuit board)
I
0
-+
Redundant Power Supply Installation Space

15
power supply
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CPSMC13xx-100 PointSystem™ Chassis
Read and follow all warning notices & instructions marked on the product or included in the manual.
CAUTION: All installation and service must be performed by qualified service personnel.
CAUTION: Ensure that the external power source is NOT powered and that the On/Off switch is set
to “0” when connecting the 48-VDC power supply module. Failure to observe this caution could result
in damage to, and subsequent failure of, the power supply module.
Powering the 48-VDC Power Supply Module
• This product is intended to be used in a restricted access location. Proper
earthing (grounding) is required to ensure safe operation. Grounding terminals
are provided (section 4.1.3) for proper grounding of the device as per customer
installation requirements and local electrical codes. Prior to installation, use a
voltmeter/ohmmeter to check the wiring for the presence of earth ground.
• A readily accessible disconnect device as part of the building installation shall
be incorporated into the fixed wiring. The disconnect device (a 48 VDC, 15 or
20A circuit breaker or switch) must be included in the ungrounded supply
conductor. Overcurrent protection must be a 48 VDC, 15 or 20A fuse or circuit
breaker.
To power the CPSMC1310-100 chassis through the CPSMP-130 48-VDC power
supply module:
1. Set the On/Off switch to “0”.
2. Connect the +48-VDC terminal to the chassis external power connector marked
“+”. Turn the terminal screw clockwise to secure.
3. Connect the -48-VDC terminal to the chassis external power connector marked
“-”. Turn the terminal screw clockwise to secure.
4. Connect the ground terminal to the chassis external power connector marked
“chassis ground”. Turn the terminal screw clockwise to secure.
5. Set the On/Off switch to “I”.
6. Verify that chassis is powered by observing the illuminated power LED.
I
0
-+
I
0
-+
+
GND
–
Power LED
External Power Connectors
On/Off
Switch
Panel Fastener Screw

16
CPSMC13xx-100 PointSystem ™ Chassis
power supply
3.3 CPSMP-140 Power Supply Module (24-VDC)
The CPSMC1320-100 chassis is equipped with a 24-VDC power supply module
(P/N CPSMP-140) installed in the front of the chassis. The power supply module
supplies power to the chassis, installed media converter slide-in-modules, and
management modules.
The components of the CPSMP-140 24-VDC power supply module include:
• A set of three (3) external power connectors that distribute power from an
external 24-VDC outlet to a chassis ground connector, a positive (+) connector,
and a negative (-) connector on the power supply module.
• An On/Off switch that, when set to “I”, allows the module to supply power to
the chassis, and any installed modules.
•Apower LED indicator.
•Afuse installed on the power supply module’s circuit board.
Optional Redundant 24-VDC Power Supply Module
An extra installation space is available in the front of the chassis for installing an
optional redundant 24-VDC power supply module (P/N CPSMP-140). See section
3.5.1 Installing the Power Supply Module for instructions on installation.
Instant Fail-Over
The Instant Fail-Over feature ensures uninterrupted power to the chassis. If one of
the power supply modules loses power, the chassis mother board automatically
switches to the other power supply.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Power LED
External Power Connectors
On/Off Switch
Fuse (on the circuit board)
I
0
-+
Redundant Power Supply Installation Space

17
CPSMC13xx-100 PointSystem ™ Chassis
power supply
Read and follow all warning notices & instructions marked on the product or included in the manual.
CAUTION: All installation and service must be performed by qualified service personnel.
CAUTION: Ensure that the external power source is NOT powered and that the On/Off switch is set
to “0” when connecting the 24-VDC power supply module. Failure to observe this caution could result
in damage to, and subsequent failure of, the power supply module.
Powering the 24-VDC Power Supply Module
• This product is intended to be used in a restricted access location. Proper
earthing (grounding) is required to ensure safe operation. Grounding terminals
are provided (section 4.1.3) for proper grounding of the device as per customer
installation requirements and local electrical codes. Prior to installation, use a
voltmeter/ohmmeter to check the wiring for the presence of earth ground.
• A readily accessible disconnect device as part of the building installation shall
be incorporated into the fixed wiring. The disconnect device (a 24 VDC, 15 or
20A circuit breaker or switch) must be included in the ungrounded supply
conductor. Overcurrent protection must be a 24 VDC, 15 or 20A fuse or circuit
breaker.
To power the CPSMC1320-100 chassis through the CPSMP-140 24-VDC power
supply module:
1. Set the On/Off switch to “0”.
2. Connect the +24-VDC terminal to the chassis external power connector marked
“+”. Turn the terminal screw clockwise to secure.
3. Connect the -24-VDC terminal to the chassis external power connector marked
“-”. Turn the terminal screw clockwise to secure.
4. Connect the ground terminal to the chassis external power connector marked
“chassis ground”. Turn the terminal screw clockwise to secure.
5. Set the On/Off switch to “I”.
6. Verify that chassis is powered by observing the illuminated power LED.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
I
0
-+
I
0
-+
+
GND
–
Power LED
External Power Connectors
On/Off
Switch
Panel Fastener Screw

18
CPSMC13xx-100 PointSystem ™ Chassis
power supply
3.4 Optional Dual Power Supply modules
Alternatively, two different types of power supplies may be installed in any of the
CPSMC13xx-100 chassis, where one power supply is the primary and the other is
the back up.
The drawing above shows one AC power supply and one DC power supply.
However, the CPSMC13xx-100 chassis can accommodate any combination of AC,
48-VDC and 24-VDC power supplies. See section 3.5 Power Supply Module
Maintenance for instructions on installation.
Instant Fail-Over
The Instant Fail-Over feature ensures uninterrupted power to the chassis. If one of
the power supply modules loses power, the chassis mother board automatically
switches to the other power supply.
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
I
0
-+
I
0
AC Power Supply DC Power Supply

19
CPSMC13xx-100 PointSystem ™ Chassis
power supply
Warning: Do NOT connect the power supply module to the external power source before installing it
into the chassis. Failure to observe this caution could result in equipment damage and/or personal
injury or death.
3.5 Power Supply Module Maintenance
3.5.1 Installing the Power Supply Module
The AC and DC modules are installed in the same manner:
1. Remove the power supply module protective plate from the installation slot by
removing and retaining the screw that secures the protective plate to the front
of the chassis.
2. Carefully slide the power supply module into the installation slot, aligning the
power supply module with the installation guides.
3. Ensure that the power supply module is firmly seated inside the chassis. If the
power supply module does not fit flush against the frame, remove the module
and ensure that it is aligned with the installation guides before installing.
4. Rotate the attached panel fastener screw clockwise to secure the power supply
module to the chassis.
5. Connect the power supply module to the external power source.
(AC: see page 13 / 48-VDC: see page 15 / 24-VDC: see page 17.)
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
I
0
I
0
I
0

20
CPSMC13xx-100 PointSystem ™ Chassis
power supply
Warning: Do NOT connect the power supply module to the external power source before installing it
into the chassis. Failure to observe this caution could result in equipment damage and/or personal
injury or death.
3.5.2 Replacing the Power Supply Module
NOTE: Any of the power supply modules may be “hot swapped” provided the
module to be swapped has been disconnected from the external power source and
the On/Off switch has been set to “0”.
The AC and DC modules are replaced in the same manner:
1. Set the On/Off switch on the power supply module to be replaced to “0”.
2. Disconnect the power supply module to be replaced from the external power
source.
2. Loosen the panel fastener screw that secures the power supply module to the
chassis.
3. Slide the power supply module from the chassis.
4. Carefully slide the replacement power supply module into the installation slot,
aligning the power supply module with the installation guides.
5. Ensure that the the power supply module is firmly seated against the back of the
chassis. If the power supply module does not fit flush against the frame, remove
the module and ensure that it is aligned with the installation guides before
installing.
6. Rotate the attached panel fastener screw clockwise to secure the power supply
module to the chassis.
7. Connect the power supply module to the external power source.
(AC: see page 13 / 48-VDC: see page 15 / 24-VDC: see page 17.)
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
I
0
I
0
