Transmitter Solutions MONARCH 418ELPW2K User manual

1A - General information
The Transmitter Solutions Monarch - 418ELPW2K is a key chain style
mini transmitter operating at 418 MHz. It has been designed for use
with programmable telephone entry, security, and access control
systems operating with a 418 MHz frequency receiver.
The code sent by the transmitter includes a 16 bit security code which
allows up to 65,536 number combinations and 8 bits of facility code
which allows up to 256 facility codes .
CONTENTS
1A - General information
1B - Technical specifications
1C - Main components
1 - TRANSMITTER OVERVIEW
2 - NUMBERING
3 - PROGRAMMING
4 - OPERATION
5 - BATTERY ACCESS
1B - Technical specifications
Operating frequency 418 MHz
Number of keys: 2
Battery life: 18 24 months
Number combinations :
Operating temperature: -20°F÷+131°F (-20°C
Overall dimensions: 2.4”x1.4”x0.63” (61x36x16 mm)
).rg02(.zo1:thgieW
6102RCseirettabmuihtilV3x2:yrettaB
÷
65,536
Facility Codes : 256
÷+55°C)
The Transmitter Solutions - 418R receiver which operates with this
transmitter has a Wiegand 26 bit format output, which will operate any
type of access control system equipped to accept a 26 bit Wiegand
input. The CR 2016 lithium batteries have a shelf life of about 6 months.
Part 15 of FCC Regulations and
ehthtiwseilpmocylluftcudorpehT
European Directives 99/5/CE, 89/336/CEE, 73/23/CEE.
1C - Main components
Push-button B
Red
LED
Key
holder
ring
Battery
door
Push-button A
6 - TROUBLESHOOTING
Green & White Case
Transmitter
Solutions
Thank you for choosing a Transmitter Solutions product .
Please read this manual carefully before using the product.
Made in Italy. Copyright Transmitter Solutions© 2006 by
Manual
MONARCH 418ELPW2K

2 - NUMBERING
6 - TROUBLESHOOTING
PROBLEM SOLUTION
The operating range is reduced
Check to verify the
transmitter is programmed
into your system
Replace the transmitter
batteries
To access the battery turn the battery door
. Place the 2 lithium CR2016 batteries
into their holder making sure they make contact
with the internal ring and with the positive (+) side
of the battery facing the back of the transmitter.
clockwise
NOTE: Please dispose of the batteries properly
according to local laws and regulations.
Test proper battery installation by verifying that
the red LED illuminates when either button is
pushed.
5 - BATTERY ACCESS
3 - PROGRAMMING
Each transmitter is manufactured and sold with a different factory set
sequence number and facility code.
The transmitter facility code and sequence number must be
programmed into your system memory. Your own installer or reseller will
provide you the necessary instructions for your system.
Replace the transmitter
batteries
Transmitter Solutions - Type : 418ELPW2K
FCC ID : SU7418ELPW2K
This device complies with FCC Rules
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept interference received, including
interference that may cause undesired operation.
Part. 15 of the
The system does not receiver the
transmitter signal.
The transmitter LED is ON
The system does not receiver the
transmitter signal.
The transmitter LED will not light
4 - OPERATION
a. Firmly depress either button until the small red LED illuminates.
b. After the LED has illuminated, release the button. If the device you are
attempting to activate does not respond, repeat steps a. and b. or
consult section 6 (Troubleshooting) of this manual.
Back of
transmitter
The warranty period of Transmitter Solutions 418 transmitters is 60 months,
beginning from the manufacturing date of the transmitter. During this period, if the
product does not operate correctly, due to a defective component, the product
will be repaired or replaced at the sole discretion of Transmitter Solutions.
The warranty does not extend to the transmitter case which can be damaged by
conditions outside the control of Transmitter Solutions or to battery life.
TRANSMITTER SOLUTIONS
7380 S. Eastern Ave, Ste 124-320
Las Vegas, NV 89123 -
[phone] - [phone] F
[email protected]
