TRASSIR TR-H2B5 User manual
TR-H2B5
2MP outdoor multistandard video camera with
fixed lens
Technical support
www: helpdesk.trassir.com
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
Note: read user manual before using
Website: www.trassir.com
Camera Package
IP camera
User manual
Mounting kit
1 pc
1 pc
1 pc
Specification
TR-H2B5
1/3" CMOS 2MP
FullHD (1920x1080)
Mechanical ICR
Color: 0.01Lux (F1.2)
BW: 0Lux (IR on)
3.6
D-WDR
up to 25 m
AHD / TVI / CVI: 2MP@30fps
CVBS: 960H
2DNR
12V DC
700 mA
157 x 73 x 76
650
IP67
-30°C … +60°C
Model
Image sensor
Resolution
Day/Night Mode
Sensitivity
Lens (mm)
WDR
IR range
Mode
Noise Reduction
Power supply
Power consumption
Dimensions (mm)
Net weight (g)
Ingress protection
Working temperature
Connecting
This camera has three working modes: TVI, AHD and CVI. It also supports
CVBS analogue video standard with PAL 960H resolution. The camera use
TVI standard by default. In order to switch the modes, hold OSD joystick
for 5 sec in corresponding direction.
Dimensions
741-24.3.20
Notes
Power supply should meet the requirements: output voltage, current,
polarities and working temperature. Pay attention that you have
lightning conductor while using IP camera during a storm or plug off
power connector.
Pay attention to temperature requirements of IP camera. Do not use the
camera in extremely hot or cold temperatures (see the specifications for
operating conditions).
Do not expose the camera to heaters.
Do not aim the camera at the sun or at the strong light. It causes
damages to the camera.
Problems and solutions
There is no Image after power supply.
• Wrong power supply voltage, check power supply and the correctness of
connection.
• Check whether the cable is connected properly.
The image has noise and ripples.
• Can be caused by alternate current power supply. Install the stabilizer.
• Check your monitor and use peripheral equipment.
Constant background color alteration on the image.
• Can be cased by electromagnetic field of a fluorescent lamp.
It is a specific property of the analogue video surveillance cameras.
• In order to improve the image, reduce the amount of fluorescent lamps
and increase the distance between camera and fluorescent.
UP
DOWN
RIGHT
LEFT
AHD
TVI
CVBS
CVI
Monitor Video
Video
Power
Connecting Diagramm
Power 12V
Power 12V
Introduction
Congratulations with purchasing of multistandard camera TR-H2B5.
Please read User Manual before using a camera.
Key features
• Resolution 2MP
• Wide Dynamic Range (D-WDR)
• Mechanical IR cut filter
• Four mode: TVI / AHD / CVI / CVBS
• IR range up to 25 m
• Power supply 12V DC
