JAI RM-1405GE User manual

RM/TM-1405GE
RMC/TMC-1405GE
Digital Monochrome/Color
Progressive Scan, Interline-Transfer GE Camera
Document Version: F
Document P/N: 10167

Disclaimer iii
R
M
/T
M
-14
05G
E
Se
ri
es
Disclaimer
The material contained in this manual consists of information that is proprietary to JAI Inc., and may only be
used by the purchasers of the product. JAI, Inc. makes no warranty for the use of its product and assumes no
responsibility for any errors which may appear or for damages resulting from the use of the information
contained herein. JAI, Inc. reserves the right to make changes without notice.
Microsoft, Windows 95, 98, NT, 2000, XP, and Windows Explorer are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries.
Warranty
Please contact your factory representative for details about the warranty.
Certifications
CE Compliance
The RM/TM-1405GE series of cameras has been certified to conform to the requirements of Council Directive
89/336/EC for electromagnetic compatibility and to comply with the following European Standards:
EMCEN55022: 1998 + A1: 2000 CLASS A
EN55024: 1998 + A1: 2001
All JAI Inc. products bearing the CE mark have been declared to be in conformance with the applicable EEC
Council Directives. However, certain factory-installed options or customer-requested modifications may
compromise electromagnetic compatibility and affect CE compliance. Please note that the use of interconnect
cables that are not properly grounded and shielded may affect CE compliance.
Contact the JAI Inc. Applications Engineering Department for further information regarding CE compliance.
FCC
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area may cause harmful interference, in which case the user will be required to correct the interference at his
own expense.

RM/TM-1405GE Series
iv Disclaimer
WARNING
Changes or modifications to this unit not expressly approved by the party responsible for FCC compliance could
void the user’s authority to operate the equipment.
RM/TM-1405GE Series Operation Manual
JAI Inc.
625 River Oaks Parkway
San Jose, CA 95134
Tel:[phone]
Tel:[phone]
Fax:[phone]
www.jai.com
September 18, 2009

Table of Contents v
R
M
/T
M
-14
05G
E
Se
ri
es
Table of Contents
Disclaimer Notice................................................................................................... iii
Table of Contents ................................................................................................... v
List of Figures ....................................................................................................... vii
List of Tables.........................................................................................................ix
1Hardware Introduction ................................................................................ 9
1.1Product Description ................................................................................... 9
1.2Features ................................................................................................. 9
2Installation ............................................................................................. 11
2.1Getting Started........................................................................................ 11
2.1.1Unpacking Instructions ............................................................................... 11
2.1.2Components............................................................................................ 11
2.1.3Accessories and Options ............................................................................. 11
2.2Camera Setup.......................................................................................... 11
2.2.1Heat Dissipation....................................................................................... 11
2.2.2Connector Pin Configurations ....................................................................... 12
2.2.3Power Supplies and Power Cable Setup ........................................................... 12
2.2.4Attaching the Camera Lens.......................................................................... 14
2.2.5Adjustable Back-Focus ............................................................................... 14
3Operation .............................................................................................. 16
3.1Progressive Scanning ................................................................................. 16
3.2Bayer Color Filter (Color Versions)................................................................. 16
3.2.1Color Filter Array ..................................................................................... 16
3.2.2Bayer Color Filter Array (CFA) ...................................................................... 16
3.2.3Starting Pixel Configuration......................................................................... 17
3.2.4Sync and Data ......................................................................................... 17
3.2.5Camera Functions..................................................................................... 18
3.2.6Interpolation Software ............................................................................... 18
3.2.7Color Interpolation ................................................................................... 19
3.3Electronic Shutter .................................................................................... 19
3.4External Sync .......................................................................................... 19
3.5Asynchronous Reset................................................................................... 19
3.5.1Async No Shutter...................................................................................... 19
3.5.2Async Programmable Shutter Speed Control ..................................................... 20
3.5.3External VINIT With Pulse Width (No-Delay Shutter)............................................ 21
3.6Programmable Look-Up Table (LUT) and Knee Control ......................................... 21
3.7Camera Timing Charts................................................................................ 22
3.8Video Output .......................................................................................... 23
3.9External HD Locking and External VD Reset ...................................................... 24
3.10Asynchronous Reset................................................................................... 25
4Functions & Operations .............................................................................. 26
4.1GigE Vision Standard Interface ..................................................................... 26
4.2GigE Vision-Aware Software......................................................................... 26
4.3Recommended Network Configurations ........................................................... 26
4.3.1Verified Network Interface Cards (NICs) .......................................................... 26
4.3.2Video data rate (network bandwidth) ............................................................. 27
4.3.3Disable Firewalls ...................................................................................... 27
4.3.4Enabling Jumbo Frame ............................................................................... 28
4.3.5Setting Receive Descriptors ......................................................................... 30

RM/TM-1405GE Series
vi Table of Contents
4.3.6Interrupt Moderation rate ........................................................................... 30
4.3.7Calculating and setting Inter-Packet Delay....................................................... 30
4.3.8Confirm the Filter Driver is used ................................................................... 31
5Configuring the Camera.............................................................................. 33
5.1Acquisition and Trigger Controls ................................................................... 33
5.2AnalogControls ........................................................................................ 34
5.3Image Size Controls................................................................................... 35
5.4LUT (Look Up Table) ................................................................................. 37
5.5UserSets ................................................................................................ 38
5.6DeviceInformation .................................................................................... 39
5.7GigEVisionTransportLayer ........................................................................... 39
5.7.1Persistent IP ........................................................................................... 39
5.7.2Stream Channel Packet Size ........................................................................ 40
5.8IPEngine ................................................................................................ 40
5.8.1SignalRoutingBlock ................................................................................... 42
5.8.2ControlBits ............................................................................................. 44
5.8.3PLC LookupTable...................................................................................... 45
5.8.4PLCSpecialConfigurations............................................................................ 46
5.8.5Counters................................................................................................ 48
5.8.6Pulse Generators controls ........................................................................... 49
5.8.7PLC Grabber Features................................................................................ 50
5.8.8IPEngine Examples: ................................................................................... 50
5.9Register Map........................................................................................... 51
6Troubleshooting ....................................................................................... 56
6.1Problems and Solutions .............................................................................. 56
6.1.1Symptom: No Video................................................................................... 56
6.1.2Symptom: Dark Video ................................................................................ 56
6.1.3Symptom: Non-Synchronized Video ................................................................ 56
6.2Information and Support Resources................................................................ 56
7Appendix ............................................................................................... 58
7.1Specifications.......................................................................................... 58
7.1.1TM-1405GE Physical Dimensions.................................................................... 59
7.1.2Spectral Response .................................................................................... 60

List of Figures vii
R
M
/T
M
-14
05G
E
Se
ri
es
List of Figures
Figure 1.12-Pin Connector Pinouts............................................................................ 12
Figure 2.GigE Ethernet Connector ............................................................................ 12
Figure 3.12P-02S Interface Cable (optional) ................................................................ 13
Figure 4.Back-Focus Set-Screw Locations.................................................................... 15
Figure 5.Example of Color CCD CFA Pattern ................................................................ 17
Figure 6.Example of TMC-1405GE in Default Mode......................................................... 18
Figure 7.Async No Shutter...................................................................................... 20
Figure 8.Async ProgrammableShutter Speed Control ...................................................... 20
Figure 9.No-Delay Shutter...................................................................................... 21
Figure 10.Acquisition And Trigger Controls Category ....................................................... 33
Figure 11.AnalogControls Category............................................................................. 35
Figure 12.Image Output Example............................................................................... 36
Figure 13.LookUp Table .......................................................................................... 37
Figure 14.UserSets Category .................................................................................... 38
Figure 15.DeviceInformation Category ........................................................................ 39
Figure 16.GigEVisionTransportLayer Persistent IP ........................................................... 40
Figure 17.PLC LUT Diagram...................................................................................... 41
Figure 18.PLC ...................................................................................................... 42
Figure 19.SignalRoutingBlock.................................................................................... 42
Figure 20.ControlBits ............................................................................................. 45
Figure 21.PLC Q Output .......................................................................................... 45
Figure 22.PLC Special Configurations .......................................................................... 47
Figure 23.CountersAndTimersControls......................................................................... 47
Figure 24.Physical Dimensions .................................................................................. 59
Figure 25.Monochrome Spectral Response .................................................................... 60
Figure 26.Color Spectral Response ............................................................................. 60

RM/TM-1405GE Series
viii List of Tables
List of Tables
Table 1Table 1 12-Pin Connector............................................................................ 12
Table 2Video Output (Horizontal Timing).................................................................. 23
Table 3Video Output (Vertical Timing)..................................................................... 24
Table 4External HD Locking and External VD Reset (Horizontal Timing) ............................. 24
Table 5External HD Locking and External VD Reset (Vertical Timing) ................................ 24
Table 6Asynchronous Reset .................................................................................. 25
Table 7Asynchronous Direct Shutter and Pulse-Width Control ......................................... 25
Table 8TM-1405GE Camera Specifications Table ......................................................... 58

Hardware Introduction 9
R
M
/T
M
-14
05G
E
Se
ri
es
TM-1405GE Hardware
Operation Manual
1Hardware Introduction
1.1 Product Description
The JAI TM-1405GE is a high-speed progressive scan CCD camera. The interline-type CCD permits full
vertical and horizontal resolution of very high speed shutter images and applications. The electronic
shutter, which has speeds to 1/21,000 second, can be reset asynchronously by external pulse control.
The frame rate for a full image is 30 fps, with partial scan modes of up to 1 line. A 2:1 ratio imager
format with uniform square pixels provides superior image definition in any orientation.
The TM-1405GE has a full dynamic range control function, which can be set at externally selectable
look-up table (LUT) knee slopes to convert 10-bit input to 8-bit output, thereby optimizing the CCD’s
full dynamic range in the normal output signal range. 10-bit linear output is also selectable.
Applications for the TM-1405GE include machine vision, medical imaging, intelligent transportation
systems, high-definition graphics, on-line inspection, gauging, character reading, archiving, and high
security surveillance.
The TM-1405GE series consists of the RM/TM-1405GE (monochrome) and the RMC/TMC-1405GE
(color). Unless otherwise noted, all information contained in this manual is relevant to both models.
1.2 Features
The TM-1405GE has the following features:
•Miniature size and light weight
The printed circuit boards in the TM-1405GE have been arranged to create modular electronics,
giving the camera flexibility. In addition, the use of miniature solid-state components results in
a compact, lightweight camera that is 50.8mm x 50.8mm x 83.5mm in dimensions, and weighs
only 140 grams.
•Imager
The TM-1405GE uses a progressive scan interline transfer CCD that has the following features:
−Resolution of 1392 x 1040 active pixels for excellent image quality.
−4.65 x 4.65 µm square pixels for precise dimensional measurement.
−High-speed electronic shutter capability for high dynamic resolution of moving objects
that eliminates the need for a mechanical shutter.
−Progressive scan CCD eliminates interlace deterioration of image and increases ease of
computer interface.
−High sensitivity and low noise at fast scanning. The CCD has an excellent S/N ratio at the
default setting greater than 51dB.
•Electronic shutter
The TM-1405GE has a substrate drain-type shutter mechanism which provides superb pictures at
various speeds without smearing.

RM/TM-1405GE Series
10 Hardware Introduction
•Asynchronous reset
The TM-1405GE captures asynchronous reset images and provides single-shot video output with
single FDV. This makes it simpler for an ordinary frame grabber to capture the asynchronous
reset images. The TM-1405GE’s asynchronous reset is flexible and accepts external horizontal
drive (HD) for phase locking. When the VINIT (5V) pulse is applied to pin 6 on the Hirose, or the
PLC 12-pin connector, it resets the camera's scanning and purging of the CCD.
The TM-1405GE has three modes to control the asynchronous reset and shutter speed:
−Async, no shutter. The video signal and FDV are reset by external VINIT.
−Async Programmable shutter. The shutter speed depends on the number of horizontal
lines controlled by the user.
−External VINIT with pulse width. The duration between pulse edges controls the shutter
speed externally.
•Output
The TM-1405GE has a 10-bit/8-bit Gigabit Ethernet output. The analog output is 714 mV p-p
composite video (75 ohms) on all models.
•Warranty
Contact your factory representative for details about the warranty.
