TRASSIR Cloud TR-W2C1 User manual

TRASSIR Cloud TR-W2C1
Wi-Fi camera
User Manual

2
Camera package:
1. IP-camera 1pc.
2. Fixing kit (mounting hole template) 1pc.
3. Power supply unit 5V DC 1pc.
4. Power cable, 2 m 1pc.
5. User manual 1pc.
Rare panel
Microphone
Reset
Status
indicator
MicroSD
Lens
Speaker
Back panel
Product overview:
R
E
S
E
T
702-22.4.2021

Quick start:
3
Connect the power supply to the camera and
wait one minute before the setup and LED indicator
flashes fast
Download TRASSIR Client application
(You can add the camera only with it)
Run the TRASSIR Client application, enter your username
and password or create new account*
Go to Settings
Add camera
Trassir
Follow the instruction on the page
*
Go to trassircloud.com to create a new account.
Status LED indicator:
• Does not flash if the power supply is absent
• Flashes fast if the camera is available for setup
• Flashes slow if there is no connection to 2.4 GHz Wi-Fi
network
• Shows steady if the camera is already connected to Wi-Fi
network

4
MicroSD connection
MicroSD card installation
Insert the MicroSD card (up to 128 Gb) into the slot till it
goes click.
MicroSD is available for record. The camera starts the
default recording to the MicroSD card when it detects
motion. Use the TRASSIR Client mobile application for
viewing the archive from the SD card.
*Camera needs to be connected to the TRASSIR Cloud service according to the
existing tariff plans ( https://trassircloud.com/#o5 )

5
Specification
Model TR-W2C1
Image sensor 1/2.9" CMOS 2MP
Resolution FullHD (1920x1080)
Frame rate FullHD@25fps
Day/Night Mode Mechanical ICR
Sensitivity 0.005Lux (F1.8) / 0Lux (IR on)
IR range up to 10 m
Lens 2.8 mm
WDR Real WDR (105dB)
Video compression Н.265 / Н.264
Bitrate 8Mbps
Local storage MicroSD up to 128Gb*
Audio Microphone/Speaker
Motion detector Digital
Wi-Fi 2.4 GHz
Power supply 5V DC (1A)
Power
consumption 4.5 W
Dimensions 110 x 66 x 66 mm
Net weight 250 g
Working temperature -10°C ... +50°C
* - MicroSD card is not included into camera package
