TRASSIR Cloud TR-W2D5 Instruction manual

TRASSIR Cloud TR-W2D5
Wi-Fi camera
Quick User Guide
Machine Translated by Google

2
800-18.11.2021
Lens
Antenna
Microphone
General view of the device:
1pc.
1pc.
Equipment:
1. IP camera
2. Mounting kit (screws, adhesive mount) 3. Power supply 12V
DC 4. Antenna 5. Quick start guide 1pc.
1pc.
1pc.
Machine Translated by Google

Then follow the prompts in the app.
Trassir
Indicator status • Indicator
off - no power • Indicator blinking quickly -
camera is ready for setup • Indicator blinking slowly - no
connection to 2.4GHz Wi-Fi network
You can also create an account using trassircloud.com
• The indicator is constantly on - the camera is
successfully connected to Wi-Fi
blink;
Download the TRASSIR Client mobile application (the
camera can only be added using it); Launch the
application, log in with your account, or create a new one*;
Go to Settings: Add Camera
Quick start:
Connect the power adapter from the kit, within a minute the
camera will boot up and the indicator will quickly
3
Machine Translated by Google

4
* Viewing conditions - the camera must be connected to the
TRASSIR Cloud service in accordance with a certain tariff plan ( https://
trassircloud.com/#o5 )
Memory card
MicroSD
Remove the camera dome and insert a microSD card
Micro SD connection
The microSD card is ready for recording. By default, after
installing a MicroSD card, the camera activates the function of
recording the archive by motion detection. The recorded archive
from the MicroSD card can be viewed using the TRASSIR Client*
mobile application
Installing a microSD card
(up to 128 GB) into the slot until it clicks into place.
Machine Translated by Google

Specifications:
Real WDR (105dB)
Day/Night mode
0.005Lk (F1.8) / 0Lk (with IR)
WDR
MicroSD up to 128GB *
WI-FI
Working temperature -40°C ... +60°C
Permission
FullHD@25fps
Audio
Border crossing
Dimensions
*
Compression standards
TR-W2D5
Microphone
Matrix
FullHD (1920x1080)
Maximum
460/600 g
8Mbps
IR illumination
2.8 mm
Nutrition
NET/GROSS weight
2.4 GHz
up to 25 meters
Sensitivity
N.265 / N.264
Ø116.10 x 96.51 mm
5.8 W
Built-in video archive
Mechanical IR filter
Broadcast speed
Motion Sensor
People detector
Area monitoring
Model
Analytics
Program
1/2.9" CMOS 2ÿÿ
Bitrate
consumption
- microSD card sold separately
12ÿ DC (1A)
Lens
5
