TREBLAB HD55 User manual

HD55
User’s Manual
WIRELESS BLUETOOTH
SPEAKER
Please read this
manual before
using the product.

Power ON / OFF
Play / Pause &
Calls Hands free
Mode Change Button
OUTDOOR / INDOOR
Thank you for choosing TREBLAB HD55 – Wireless speaker
powered by latest BLUETOOTH ® 4.1 technology!
Expect superior sound quality and rugged construction
combined with hands-free wireless operation.
USB Charging Cable
Audio Cable, 3.5 mm
Treblab HD55
MicNFC Position

Slide Next
/Previous
Rotary Volume
+/-
USB Charging Line In
OPERATION
Long press the power button
Long press the power button
Short press the power button one time
Short press the power button one time
Short press the power button twice “quickly”
Short press the power button one time
Turn clockwise to turn up the Volume and
counterclockwise to turn the Volume down
In the Bluetooth mode, swipe to the right to play
the next track and to the left to play the previous
Short press Mode Change button one time
Power On
Power Off
Answering Call
End Call
Reject call / Disconnect Bluetooth
Pause / Play
Volume+ / Volume-
Previous song / Next song
Mode change (indoor/outdoor)
FUNCTION

Setting Up Your HD55
To turn on your HD55, long press and release the power button.
The LED bulb will light up and an audio cue will indicate the
system is on. To turn the HD55 off, long press and release the
power button. Audio cue will indicate the system is off.
BLUETOOTH ®
POWER
ON/OFF
RECONNECTING
After the connection is lost, the
HD55 will try to reconnect
automatically to any previously
paired devices. If reconnection
does not happen automatically,
please go through the “pairing”
instructions above. TREBLAB
HD55 only can remember the
last 8 paired devices.
1. Pairing: For Bluetooth® pairing, press and
hold the power button for 6 secs. The
Bluetooth® LED will blink RED/BLUE
rapidly indicating device is in pairing mode.
Using your Bluetooth® enabled device,
scan/search for available Bluetooth®
devices
2.
Select TREBLAB HD55 from the device list.
3.
Once HD55 is successfully paired and
connected, the LED will blink BLUE
every 3 secs.
4.
Disconnect by holding the power button
for 6 secs.
5.
AUX INPUT
To play audio using the
supplied audio cable, plug the
cable from the audio device to
the “LINE IN” jack on the side of
the HD55.

To adjust volume of the HD55, turn the
Volume ring clockwise to turn the volume
up and counterclockwise to turn the
volume down.
VOLUME
PHONE CALLS
HD55 can be used to make and receive
phone calls when connected through
Bluetooth® (audio playback will be paused
during calls). Answer/End Call: short press
the “Power” button. To Reject Call: short
press the “Power” button two times.
CHARGING AND BATTERY
To obtain optimum power
capacity, the HD55 should be
charged using the provided USB
cable in your packaging box. To
charge the HD55, plug the USB
side of the cable into a power
source and the Micro USB side
into the port on the back of the
HD55.
To change tracks on the HD55, swipe with
your figer to the right to play the next track
and to the left to play the previous track on
the top surface of the HD55.
CHANGE TRACKS
To pause and resume playback
when connected through
Bluetooth®, short press the
“Power” button.
AUDIO PLAY AND PAUSE

Do not charge your speaker longer than for 5
hours at a time, as this will lead to a reduction
of battery capacity and void your manufac-
turer's warranty.
Unplug the HD55 from the charging cable
and the cable itself from the power source
when not in use.
If left unused, a fully charged battery will lose
its charge over time. We recommend fully
charging the HD55 twice a month to ensure
sufficient battery life.
Do not leave the speaker exposed to extreme
heat or cold because this will reduce the
capacity and lifespan of the battery.
Do not place the speaker close to fire as the
batteries may explode. Batteries may also
explode if damaged.
To charge the HD55 use only the cable
provided in the packaging box.
Make sure the speaker is completely dry
before charging.
Never disassemble or modify your
speaker for any reason. Doing so may
cause the speaker to malfunction or
become combustible. Damaging the
speaker will void your manufacturer’s
warranty. Do not use excessive force
when operating the speaker. Do not
let the speaker drop onto a hard
surface.
Avoid exposing the speaker to
extreme temperatures (below
32F/2Co or above 104F/40Co).
Extreme temperatures may cause the
deformation of the protective cover
and reduce lifespan of the HD55.
Avoid putting LED lights close to the
eyes of humans and animals.
Do not use the speaker outdoors
during a thunderstorm. Thunder-
storms may cause malfunction and
increase the risk of electric shock.
IMPORTANT CHARGING AND BATTERY
INFORMATION
IMPORTANT SAFETY
INFORMATION

Never disassemble or modify your
speaker for any reason. Doing so may
cause the speaker to malfunction or
become combustible. Damaging the
speaker will void your manufacturer’s
warranty. Do not use excessive force
when operating the speaker. Do not
let the speaker drop onto a hard
surface.
Avoid exposing the speaker to
extreme temperatures (below
32F/2Co or above 104F/40Co).
Extreme temperatures may cause the
deformation of the protective cover
and reduce lifespan of the HD55.
Avoid putting LED lights close to the
eyes of humans and animals.
Do not use the speaker outdoors
during a thunderstorm. Thunder-
storms may cause malfunction and
increase the risk of electric shock.
The LED does not come on when turning
the speaker on
This can happen when the battery has lost
charge. Charge the HD55 for at least 30
minutes and the problem should be solved.
Can't connect the speaker to your device
1. TURN OFF THE HD55.
2. Go to the Bluetooth menu on your source
device and delete all saved devices from the
list by clicking on “Forget this device”.
3. Turn the Bluetooth on your source device
OFF then back ON; TREBLAB HD55 will be
deleted.
4. Power OFF your source device then and
then turn it back ON.
5. Power ON the HD55.
6. Enter the device into the pairing mode and
follow the instruction for connecting.
My device is asking for a password
If prompted for a password, enter
0000 on your device.
Frequent disconnection and noise
1. Ensure the HD55 is fully charged.
2. Ensure that the distance between
your device and the speaker is less
than 30 feet / 10 meters.
3. Ensure that nothing is blocking
the signal between your device and
the HD55.
4. Check if the music is paused.
5. Check if the volume level is set
both on the source device and on
the speaker.
6. Check if the speaker is running
out of power.
TROUBLESHOOTING INSTRUCTIONS

TECHNICAL SPECIFICATIONS
SUITABLE:
UNSUITABLE:
Swimming
Diving into water
Snorkeling or Scuba
Diving
Showering
Splashing
Snow
Accidential
short rain
Bluetooth version
Bluetooth profiles
Operating distance
4.1 + EDR
A2DP, AVRCP
30 feet / 10 meters
Battery life
Charging time
Battery capacity
Up to 10 hours
Up to 5 hours
4000mAh
Frequency range
Audio input
Charging port type
80Hz- 20KHz
AUX
Micro USB
TREBLAB FX100 MEETS IP4 WATEPROOF STANDART
All kinds of watersports
Incidental exposure to
water of up to 3 feet/1
meter for up to 30
minutes

We truly appreciate that you chose TREBLAB as your trusted brand of
Bluetooth speakers and sincerely hope you enjoy the great sound and
seamless usability TREBLAB HD55 provides. We love making our
customers happy by providing true value with our products.
If for any reason, you are not completely satisfied with your purchase, or have
any questions, please let us know by contacting us at [e-mail]. We
care about our customers more than anything and are always here to serve you.
THANK YOU
Contact us:
[email protected]
1 YEAR PARTS AND LABOR WARRANTY.
Please visit TREBLAB.COM to register
for your warranty and get a 10%OFF
coupon for your next purchase!
Manufactured by:
Productech Corp www.treblab.com
1 YEAR WARRANTY

Made in China
