TreeTop Products BC2065 User manual

BC2065
BC2066
BC2067
BC2068
BC2069
REV# 2
3/14/2018
BENCH INSTRUCTIONS

A
B
C
F
E
D
NOTE: IT IS IMPORTANT TO KEEP ALL SCREWS LOOSE
DURING ASSEMBLY UNTIL ENTIRE BENCH IS ASSEMBLED
REQUIRED TOOLS
(NOT INCLUDED)
- POWER DRILL
- #2 PHILLIPS BIT
- LEVEL
- SAKCRETE
- GUIDE WIRE / BRACING
1
LEFT SIDE
BENCH END
PRI7213L
2
FRONT/TOP
PLASTIC SEAT BOARDS
ABC-P0232
6
PLASTIC SEAT BOARDS
ABC-P0236
1
CENTER
BENCH END
PRI7213C
1
RIGHT SIDE
BENCH END
PRI7213R
40
#12 X 2" PAN HEAD SCREWS
SMPP012C200A188
BENCH INSTRUCTIONS
2/7
HARDWARE &
TOOLS REQUIRED
FOR ASSEMBLY

FRONT OF BENCH
A
C
F
FRONT OF BENCH
A
B
C
B
D
F
A
F
D
STEP 1
Seat Assembly
Lay Left Bench End (A) and Right Bench End (C) •
on its back with the front legs pointing up
Lay a Plastic Seat Board (F) over the bench •
ends (A & C) closest to the rear leg on the seat
Align the marks in the Plastic Seat Board (F) with •
the predrilled holes in the Bench Ends (A & C)
Secure the Plastic Seat Board (F) with the •
#12 x 2 screws (D)
Repeat for 2 more Plastic Seat Boards (F) starting •
at the rear and working toward the front
STEP 2
Seat Assembly
With the bench still on its back, lay the Center •
Bench End (B) onto Plastic Seat Boards (F)
Align the marks in the Plastic Seat Board (F) with •
the predrilled holes in the Center Bench End (B)
Secure the three Plastic Seat Boards (F) with the •
#12 x 2 screws (D) to the Center Bench End (B)
BENCH INSTRUCTIONS
3/7
ASSEMBLY

A B C
F
FRONT OF BENCH
A
C
E
B
A
D
E
C
F
D
STEP 4
Back Assembly
Turn bench over •
Lay a Plastic Seat Board (F) over the bench •
ends (A,B,C) closest to the seat
Align the marks in the Plastic Seat Board (F) with •
the predrilled holes in the Bench Ends (A,B,C)
Secure the Plastic Seat Board (F) with the •
#12 x 2 screws (D)
Repeat for 2 more Plastic Seat Boards (F) starting •
at the seat and working toward the top
STEP 3
Seat Assembly
With the bench still on its back, lay the Front/Top •
Plastic Seat Board (E) onto the Bench Ends (A,B,C)
Align the marks in the Plastic Seat Board (E) with •
the predrilled holes in the Bench Ends (A,B,C)
Secure the three Plastic Seat Boards (F) with the •
#12 x 2 screws (D) to the Bench Ends (A,B,C)
BENCH INSTRUCTIONS
4/7
ASSEMBLY

C
E
D
NOTE:
THERE IS APPROXIMATELY
A 0.5" GAP BETWEEN
THE TOP THREE BOARDS
STEP 5
Back Assembly
Lay a Front/Top Plastic Seat Board (E) over the bench •
ends (A,B,C) at the top of the bench
Align the marks in the Front/Top Plastic Seat Board (F) with •
the predrilled holes in the Bench Ends (A,B,C)
Secure the Front/Top Plastic Seat Board (F) with the •
#12 x 2 screws (D)
BENCH INSTRUCTIONS
5/7
ASSEMBLY

STEP #6
INGROUND MOUNT
Lay Bench Flat on the ground where A.
it will be installed
Dig three holes, approximately 8" in B.
diameter to a depth of 18"
STEP #7
INGROUND MOUNT
Place Bench Ends (A) into holes A.
Fill with Sakcrete to a level about B.
4" - 6" below ground level
Use guide wire to secure until C.
Sakcrete is dry
Use a level to make sure Bench D.
is square and level
BENCH INSTRUCTIONS
INGROUND
INSTRUCTIONS
6/7

76.00
3.00
33.50 33.50
5.54
3.50
51.63
5.54 3.50
16.10
71.88
33.00
25.61
17.58
SIDE
FRONT
CONSTRUCTION MATERIALS:
Recycled Plastic
HARDWARE:
Stainless Steel
ALL DIMENSIONS ARE SHOWN IN INCHES
TOP
BC2065
BC2066
BC2067
BC2068
BC2069
REV# 2
3/14/2018
BENCH SPECIFICATIONS
