TreeTop Products PW1415 User manual

REV# 1
INGROUND MOUNT SURFACE MOUNT
INSTRUCTIONS
PW1415-PW1420

1
Surface Mount Base
G
2
1/4" x 1.5" Lag Screw
E
F
2
#10 x 2.5" Screw
D
B
C
E
1
Receptacle
D
A
1
Inground Post
1
Surface Mount
Post
2
1/4" Flat Washer
2
1/4" x 1.5" Lag Screw
2
1/4" x 1.5" Lag Screw
SURFACE MOUNT HARDWARE
2
2" Mounting Bracket
1
Bag Dispenser
OR
INSTRUCTIONS
PW1415-PW1420
2/6
HARDWARE &
TOOLS REQUIRED
FOR ASSEMBLY

1
Surface Mount Base
L
2
1/4" x 1.5" Lag Screw
J
K
2
#10 x 2.5" Screw
F
2
1/4" x 1.5" Lag Screw
G
2
1/4" Flat Washer
H
2
Mounting Spacer
I
REQUIRED TOOLS
(NOT INCLUDED)
1 - 7/16" WRENCH
1 - #2 SQUARE BIT
2
1/4" Flat Washer
2
1/4" x 1.5" Lag Screw
2
1/4" x 1.5" Lag Screw
SURFACE MOUNT HARDWARE
INSTRUCTIONS
PW1415-PW1420
3/6
HARDWARE &
TOOLS REQUIRED
FOR ASSEMBLY

18.00
12.00
19
M
B
J
K
L
C
Inground Mount
Dig a hole 12 inches in diameter to a depth of •
18 inches
Insert the inground mount (B) post into the hole •
Level the post with the ground •
Pour concrete into the hole and allow to set •
Surface Mount
Insert the post (C) into the surface mount base(L) •
Secure the post to the base with 2 1/4" x 1.5" lag •
screws (J)and washers (K) provided
Place the post upright in desired location •
Square the post assembly to the ground •
Attach the surface mount base to the ground •
using approiate hardware (not included)
GROUND
INSTRUCTIONS
PW1415-PW1420
4/6
MOUNT
POST

Q
DETAIL Q
SCALE 1 : 5
A
F
T
DETAIL T
SCALE 2 : 9
A
F
NOTE: LID REMOVED TO SHOW DETAIL
MOUNT THE DISPENSER
Slide the pet bags dispenser (A) onto the post •
Install the #10 x 2.5" screw (F) to secure the dispenser to the post •
(Only 1 is needed but 2 are supplied in case of stripping)
INSTRUCTIONS
PW1415-PW1420
5/6
DISPENSER

FIGURE 1
G
H
E
I
SHORT SLAT
TO THE FRONT
DETAIL
SCALE 1 : 4
UPPER RING
Mount the Receptacle
Place the receptacle on the ground in front of the post with the •
short slat in the front
Mark the post 1.5" below the top ring •
INGROUND MOUNT- Mark the post 1.5" above the bottom ring •
SURFACE MOUNT- Mark the post 6" above the bottom ring •
Drill 1/8" pilot holes at your marks 1" to 2" deep •
Install both mounting brackets in the pilot holes per Figure 1 •
Use a 7/16 wrench to tighten •
INSTRUCTIONS
PW1415-PW1420
6/6
RECEPTACLE

69.00 INGROUND MOUNT
19.25
3.50
51.00 SURFACE MOUNT
10.50
18.21
19.36
3.50
5.13
8.63
4.50
8.98
16.27
NOTE: ALL MATERIAL IS RECYCLED PLASTIC LUMBER UNLESS NOTED
ALL DIMENSIONS SHOWN IN INCHES
PW1415-PW1420
