TRENDnet TEW-646UBH User manual

FEATURES
• 1 x USB 2.0 connector
• 1 x 2dBi detachable antenna (Reverse SMA)
• 500mW wireless transmission power
• USB bus powered adapter
• Wi-Fi compliant with IEEE 802.11n standard
• One-touch wireless connection with external Wi-Fi Protected Setup (WPS) button
• Backwards compatible with IEEE 802.11g and IEEE 802.11b devices
• Supports Ad-Hoc (Client-Client) and Infrastructure (AP-Client) Mode
• Maximum reliability, throughput, and connectivity with automatic data rate switching
• Supports 64/128-bit WEP, WPA/WPA2-RADIUS and WPA /WPA2-PSK
• Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization
• Universal Plug and Play (UPnP) supported
• Easy user setup and intuitive diagnostic utility
• Coverage of up to 100 meters indoor (330 feet) and 200 meters outdoor (660 feet) *
• 3-year limited warranty
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifi cations. Actual data throughput and coverage
will vary depending on interference, network traffi c, building materials and other conditions.
TEW-646UBH
rev: 05.06.2011
High Power 150Mbps Wireless N USB Adapter
TEW-646UBH (V1.0R)
The High Power 150Mbps Wireless N USB Adapter (model TEW-646UBH)
connects a laptop or desktop computer to a high speed wireless n network.
An adjustable external antenna and a 200% increase** in power output
maximizes wireless throughput and coverage.
Setup is a breeze with one-touch Wi-Fi Protected Setup (WPS) technology.
Advanced wireless encryption protects your valuable data. Wi-Fi Multimedia
(WMM) Quality of Service (QoS) prioritizes important video, audio, and
gaming traffi c. Stream video, download fi les, play games, and talk online
with this high power adapter.

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,
without notice. For the most recent product information please visit http://www.trendnet.com Copyright ©TRENDnet.All Rights Reserved.
High Power 150Mbps Wireless N USB Adapter
TEW-646UBH (V1.0R)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TEW-646UBH
CD-ROM (Utility & User’s Guide)
Multi-Language Quick Installation Guide
RELATED PRODUCTS
TEW-657BRM 150Mbps Wireless N ADSL 2/2+ Modem Router
TEW-651BR 150Mbps Wireless N Home Router
TEW-648UB 150Mbps Mini Wireless N USB Adapter
SPECIFICATIONS
HARDWARE
Interface • USB 2.0
Standards • IEEE 802.11b, IEEE 802.11g, based on IEEE 802.11n technology
LED Indicators • Power, Link
WPS Button • Enables WPS connection
Power Consumption • 2.5 W
Antenna Connectors • SMA
Supported OS • Windows: 7 (32/64-bit), Vista (32/64-bit), XP(32/64-bit) • Mac: OS 10.4-10.6
Dimensions (LxWxH) • 60 x 16 x 8 mm (2.3 x 0.6 x 0.3 in.)
Weight • 5.7 g (0.2 oz)
Temperature • Operating: 0° ~ 55° C (32° ~ 131° F) • Storage: -20° ~ 70° C (-4 ~ 158° F)
Humidity • Max. 90% (non-condensing)
Certifi cations • CE, FCC
WIRELESS
Modulation • OFDM, DSSS
Antenna • 1 x 2dBi omni-directional detachable antenna (Reverse SMA)
Frequency • 2.4 ~ 2.497 GHz
Quality of Service • 802.11e, WMM
Data Rate (auto fallback) • 802.11b: 11Mbps • 802.11g: 54Mbps • 802.11n: 150Mbps
Output Power • 802.11b: 27dBm • 802.11g: 24dBm • 802.11n: 22dBm
Receiving Sensitivity • 802.11b: -86dBm at 11mpbs • 802.11g: -72dBm at 54Mbps • 802.11n: -65dBm at 150Mbps
Encryption • 64/128-bit WEP, WPA/WPA2-RADIUS, WPA /WPA2-PSK
Channels • 1~11 (FCC), 1~13 (ETSI)
