TRENDnet TPL-306E User manual

FEATURES
• 200Mbps building-wide networking over an existing connected electrical system
• Compliant with the HomePlug® AV and IEEE 1901 standard
• 1 x 10/100Mbps Auto-MDIX Ethernet Port
• Compact form factor saves space
• One-touch Sync button to change the default encryption key
• Connect one 200Mbps** Powerline AV Adapter to the Internet and then plug in up to 5* additional Powerline AV adapters for
instant building connectivity
• Share data intensive fi les, play games, download music, and more at faster data transfer rates
• Advanced 128-bit AES encryption to ensure total network security
• Power Save mode reduces electrical consumption by 80%
• Neighbor network support for up to 4 overlapping networks
• Three LED indicators: Power (on/off), Powerline Connection (green (best), amber (better), red (good), off(no connection)),
Ethernet Connection (solid (connection), blinking (transfer activity), off (no connection))
• Network signal transmits up to 300 meters (984 ft.)
• Auto QoS support through traffi c classifi cation and multiple priority queuing
• Compatible with all operating systems
• Optional management utility compatible with Windows 7 (32/64-bit), Vista (32/64-bit), and XP (32/64-bit) operating systems
• 3-year limited warranty
* Maximum of 6 adapters (nodes) for streaming video across your network
** 200Mbps is the maximum theoretical Powerline data rate. Actual throughput will vary depending on environment
*** Networked Powerline devices need to be plugged into power outlets that are on the same electrical system
**** GFCI outlets and AFCI circuit breakers may degrade Powerline network signals
TPL-306E
rev: 11.11.2011
200Mbps Compact Powerline AV Adapter
TPL--306E (V1.0R)
The 200Mbps Compact Powerline AV Adapter, model TPL-306E, uses
any electrical outlet to create a secure high speed building-wide network.
Connect one adapter to your existing network and plug another adapter
in to any outlet on your electrical system for instant high speed network
access throughout your home.
The compact form factor offers more space around electrical outlets for
other devices. Adapters connect automatically with no installation
required. For added security, TRENDnet recommends using the
one-touch connect button to change the default network key.
Use up to 6 adapters to network devices in different rooms without the
need for new cabling. Power Save mode reduces power consumption by
up to 80%. LED displays convey device status for easy power
management and troubleshooting. Quality of Service technology
prioritizes video, audio, and online gaming. Advanced AES encryption
secures your network. This adapter is ideal for use in buildings that
interfere with wireless networking signals.

200Mbps Compact Powerline AV Adapter
TPL--306E (V1.0R)
SPECIFICATIONS
HARDWARE
Standards • IEEE 802.3, IEEE 802.3x, IEEE 802.3u, HomePlug® AV, IEEE 1901
Interface • 1 x 10/100Mbps Auto-MDIX RJ-45 port
• Power prong:
• A: North America Type B (NEMA 5–15)
• EU: Euro Type C (CEE 7/16)
• UK : United Kingdom Type G (BS 1363)
Frequency Band • 2 ~ 28 MHz
Modulation • OFDM Symbol Modulation on link synchronization, 1024/256/64/8 - QAM, QPSK, BPSK, ROBO Carrier
Protocol • TDMA and CSMA/CA
Speed • Powerline: Up to 200Mbps**
• Ethernet: Up to 200Mbps (Full Duplex mode)
Utility OS Compatibility • Windows 7 (32/64-bit), Vista (32/64-bit), XP(32/64-bit)
Nodes • Up to 6 (max.)
Overlapping
Powerline Networks
• Up to 4 (per electrical system)
Coverage • Up to 300 m (984 ft.)
Security • 128-Bit AES (Advanced Encryption Standard)
LED • Power (PWR)
• Powerline (PL) Connection
• Best (Green)
• Better (Amber)
• Good (Red)
• No connection (Off)
• Ethernet (ETH) Connection
• Solid
• Blinking
• Off
Buttons • Sync, Reset
Dimension (L x W X H) • A: 55 x 87 x 51 mm (2.2 x 3.4 x 2 in.)
• EU: 55 x 87 x 65 mm (2.2 x 3.4 x 2.6 in.)
• UK: 55 x 87 x 58 mm (2.2 x 3.4 x 2.3 in.)
Weight • A: 74 g (2.6 oz)
• EU: 79.4 g (2.8 oz)
• UK: 85 g (3 oz)
Power Source • 100~240V AC, 50~60Hz
TPL-306E
rev: 11.11.2011

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,
without notice. For the most recent product information please visit http://www.trendnet.com Copyright ©TRENDnet.All Rights Reserved.
NETWORKING SOLUTIONS
200Mbps Compact Powerline AV Adapter
TPL--306E (V1.0R)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TPL-306E
Multi-Language Quick Installation Guide
CD-ROM (Utility & User’s Guide)
Network cable (1.5 m / 5 ft.)
RELATED PRODUCTS
TPL-307E 200Mbps Powerline AV Adapter with Bonus Outlet
TPL-310AP 200Mbps Powerline AV Wireless N Access Point
TPL-402E 500Mbps Powerline AV Adapter with Bonus Outlet
HARDWARE
Consumption • Active mode: 3.1 Watts (max.)
• Standby mode: 0.5 Watts (max.)
Temperature • Operating: 0° ~ 40°C (32° ~ 104°F)
• Storage: -20° ~ 70°C (-4° ~ 158°F)
Humidity • Max. 90% (non-condensing)
Certifi cations • CE, FCC, HomePlug® AV
