TRENDnet TU2-IDSA User manual

The USB 2.0 to SATA/IDE combo adapter allows users to use IDE or
SATA hard drives over a USB 2.0 connection. It works with most IDE
(up to ATA 133) and SATA 1.0a devices. This device provides a
simple, yet powerful data transfer and backup solution.
TU2-IDSA(V1.0R)
USB 2.0 to SATA / IDE Converter Adapter
TU2-IDSA
rev:10.13.2006
• Compliant with USB 2.0 and SATA (Serial ATA) 1.0a Specifications
• Compliant with USB Mass Storage Class Bulk-Only Transport Specification
• Supports combo connectors IDE (40pin & 44pin) for 2.5” / 3.5” /5.5” IDE & SATA devices
• Turns an internal IDE/SATA hard drive or CD/DVD-ROM into an external USB device
• Operates IDE and SATA devices simultaneously
• Compliant with Windows 98SE/ME/2000/XP/2003 Server Mac OS X
• Plug & Play for easy Installation
• 2-Year Warranty
FEATURES

Supported OS
Temperature
Connectors
Data Rate
Power Source
Humidity
Certification
• USB 2.0, 1.1
• Windows 98SE/ME/2000/XP/2003 Server and Mac OS X
• Operating: 0°C ~ 40°C (32°F ~ 104°F)
• SATA: 7-pin Signal Male
• 1.5/12/480Mbps (USB)
• Adapter: 70g(2.5oz.)
• 85% (Non-Condensing)
• Power Supply: 240g (8.5oz.)
• 48 x 28 x 16mm (1.9 x 1.1 x 0.6 in.)
• FCC, CE
• Input: AC 100~240V
• Output: 12V DC, 2A
Dimensions
Weight
Interface
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
USB 2.0 to SATA / IDE Converter Adapter
TU2-IDSA(V1.0R)
PACKAGE CONTENTS
• TU2-IDSA
• Multi-Language Quick Installation Guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
3135 Kashiwa Street,Torrance, CA 90505 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
NETWORKING SOLUTIONS
SPECIFICATIONS
IDE Hard Drive
SATA Hard Drive
CD/DVD ROM
USB 2.0 to SATA/IDE Combo Adapter
(TU2-IDSA)
Notebook
• Serial ATA Cable
• AC/DC Power Supply
• Hard Drive Power Cable
• 2.5” to 3.5” IDE Converter
• Serial ATA 1.0a (Serial ATA)
• Ultra ATA 133 (Parallel ATA)
• DC: Mini 4-pin Power Connector
• IDE: IDE 44-pin Female
• IDE 2.5” to 3.5” Converter: IDE 44-pin Male to 40-pin Female
• IDE 44-pin Male to 40-pin Female
• USB: USB 2.0 Type A Male
• DC In: 2.1mm Power Plug
