TRENDnet TV-M7 - SecurView Wireless Internet Surveillance... User manual

TV-M7
H/W: A1
Quick Installation Guide

Table of Contents
English .................................................................................................................. 1
1
7
2
9
1. Before You Start
2. Hardware Installation .....................................................................................
3. Configure the Wireless Settings ....................................................................
............................................................................................
4. Add IP Camera ..............................................................................................
5. Remote Control Function ...............................................................................
Table of Contents
Version 11.18.2008
Troubleshooting .......................................................................................................
3
6

1. Before You Start
English
1
Installation Requirements
Package Contents
?
?
?
?AC Power Adapter (12V, 1.5A)
?Remote Control
?
?
TV-M7
User Guide CD-ROM
Quick Installation Guide
USB Cable (Type-A to Mini-B)
2 x Frame Design Plates
?
?An available DHCP Server – wireless routers usually have a built-in
DHCP server
Wireless Router or Access Point
Application
Family Monitoring
(TV-IP212W)
Business Monitoring
(TV-IP410W)
Cable/DSL
Modem
Internet
Home Monitoring
(TV-IP110)
300Mbps Wireless N
Gigabit Router
(TEW-639GR)
Wireless 54Mbps 100Mbps
7” Wireless Internet
Camera and Photo Monitor
(TV-M7)

2. Hardware Installation
English
2
3. Verify that the Pwr LED is
green.
2. Turn the Power Switch to the On
position on top of the TV-M7.
1. Connect the AC Power Adapter to
the Digital Photo Frame and
then to a power outlet.

English
3
3. Configure Wireless Settings
1. The main menu will appear after
you turn on the TV-M7. If the main
menu does not appear, press
Home on the remote control. Then
press Setup.
3. Select SSID (Wireless Network
Name) and then press Enter.
4. Select AUTO SCAN and then
press Enter.
2. Select Networking Setup using
the down arrow on the remote
control. Then press Enter.

English
4
7. Select Authentication Mode to
select the encryption type (e.g.
WEP, WPA-PSK, WPA2-PSK).
5. Select the SSID for your wireless
Network and then press Enter.
6. Press ESC.
8. Select Key (WEP) or Pre-Shared
Key (WPA-PSK/WPA2-PSK) to
enter your encryption key.

English
5
9. Select Apply Settings using the
down arrow on the remote control.
Then press Enter.
10. Press ESC to exit out of Setup.
11. Verify that the LINK LED is
blinking green.

English
6
Note:
1. The TV-M7 supports the following IP Cameras: TV-IP110, TV-IP110W, TV
-IP212, TV-IP212W, TV-IP312, TV-IP312W, TV-IP410, TV-IP410W, TV-IP422
and TV-IP422W. All other IP cameras are not supported.
2. Make sure both the TV-M7 and your IP cameras(s) have IP address in the
same subnet. For example, if TV-M7 has an IP Address of 192.168.10.80,
then your IP camera must use 192.168.10.X.
4. Add IP Camera
4. Use the up and down arrows to
select your IP Cameras and then
press Enter. If you would like to
select multiple camera(s), press
the Zoom/Select button for each
camera and then press Enter.
3. Select your IP Camera and then
press Enter.
5. Live video from your IP Camera
will now appear.
1. The main menu will appear after
you turn on the TV-M7. If the main
menu does not appear, press
Home on the remote control. Then
press Setup.
2. Select IP Cameras and Network.
Then press Enter.

English
7
5. Remote Control Function
Button Function
HOME Enter Main Menu screen
SETUP Enter Setup screen
SNAPSHOT Take snapshot in IP CAM view. Snapshots are saved in internal
memory.
ESC Exit Sub Menu
PHOTO/MUSIC Play Slideshow
UP ARROW Navigate Up
LEFT ARROW Navigate Left
RIGHT ARROW Navigate Right

English
8
Note: For detailed information regarding the TV-M7 configuration and
advanced settings, please refer to the Troubleshooting section, User's Guide
on the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com.
Your installation is now complete.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
Button Function
DOWN ARROW Navigate Down
ENTER Execute Selection
ROTATE /
REFRESH
Rotate Image in Photo mode
Refresh screen
5x Zoom on Image
ZOOM /
SELECT Select camera or cameras in IP Cameras menu
VOLUME UP Turn Volume Up
VOLUME DOWN Turn Volume Down
MUTE Turn Off Audio
IP CAM Display IP camera(s)
CALENDAR Set up time and date
PLAY/PAUSE Play/Pause Slideshow and Video
STOP Stop Video
REWIND Rewind Video
FAST FORWARD Fast Forward Video
