TRENDnet TV-IP751WC User manual

SecurView Pro /10.01.2012
SecurView Pro Quick Installation Guide (1)
SecurView Pro Software

SecurView Pro Management Software Requirements
SecurView Pro Management Software Requirements ..................................................................... 1
SecurView Pro Installation ............................................................................................................... 2
Add Cameras ................................................................................................................................... 3
Schedule Continuous and Motion Detection Recordings ................................................................. 4
Archive Video Playback .................................................................................................................... 6
Table of Contents
1
Supported Operating Systems 1-8 Cameras
CPU CPU
9-32 Cameras
Memory Memory
Windows 7 (32/64-bit) /
Windows Server 2008 /
Windows Vista (32/64-bit) /
Windows Server 2003 /
Windows XP (32/64-bit)
2GHz 2GHz
2GB RAM
or above
4GB RAM
or above

2
SecurView Pro Installation
1. Insert the Utility CD-ROM into your CD-ROM drive.
2. Click Install SecurView Pro.
3. Select your language and then click OK.
4. Click next for all steps and then click Finish.
5. The server setup wizard will automatically run. Click next for all steps and then click F inish.
6. Double click the SecurView Pro icon on your desktop to open up the program.

3
6. Video will now appear. The camera will be
listed in the structure pane.
4. ATTENTION! At this screen, hit enter to
move cursor to third line. Input the user name
followed by a comma and then input the
password on the same line for your IP
camera and then click Next. (On one line
enter: Username, password)
5. Follow the wizard instructions and then click
Finish.
1. Right click on the server in the structure pane
as shown in the screen below.
2. Select Tasks and then click Automatically
discover network video devices.
3. Follow the wizard instructions and then click
Next.
Add Cameras

4
Schedule Continuous and Motion Detection Recordings
1. Right click on the IP camera in the structure pane and click Camera Setup Wizard.
2. Click Next and follow the Camera Setup Wizard.
3. Select the camera and then click Next.
4. Click Next.

5
6. Select Use schedule recording and then
click Configure schedule.
5. Check the Use Motion Detector box and
click Next.
7. The Manage schedule window appears.
Choose one of the profiles and drag your
mouse over the desired time and day of the
week. (The schedule displayed below is set
up for continuous recording during the day
and motion detection recording at all other
times) Click OK to save your settings.
8. Click Next.
9. Follow the wizard instructions and then click
Finish.

6
Archive Video Playback
1. Right click Archive in the structure pane and click Open Archive.
2. The archive window appears. Select your camera in the structure pane.
3. Playback options include play, pause, previous or next frame, refresh, save current frame and
rewind/fast forward.
For detailed information regarding advanced features of SecurView Pro, please refer to the User's
Guide. The User's Guide can be found on the IP camera's CD-ROM.
