CERAMIC HOB
TBC 650 F
PLEASE READ THIS INSTRUCTION BOOKLET BEFORE USING THE APPLIANCE

2
Dear Customer,
Please read these user instructions carefully and keep them to refer to later.
Please pass the user instructions on to any future owner of the appliance.
The following symbols are used in the text:
1Safety instructions
Warning! Notes that concern your personal safety.
Important! Notes that show how to avoid damage to the appliance.
3Useful tips and hints
2Environmental information

3
Contents
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cooking surface layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assignment of Control Knobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Control Knobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operating the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Selecting the heat setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Tips on cooking and frying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Examples of cooking applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Electrical Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Rating Plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4
Operating Instructions
1Safety instructions
3Please comply with these instructions. If you do not, any damage resulting
is not covered by the warranty.
5This appliance conforms with the following EU Directives:
–73/23/EEC dated 19.02.1973 Low Voltage Directive
–89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Di-
rective 92/31/EEC
–93/68/EEC dated 22.07.1993 CE Marking Directive
Correct use
•This appliance should be used only for normal domestic cooking and fry-
ing of food.
•The appliance must not be used as a work surface or as a storage sur-
face.
•Additions or modifications to the appliance are not permitted.
•Do not place or store flammable liquids, highly inflammable materials or
fusible objects (e.g. plastic film, plastic, aluminium) on or near the appli-
ance.
Child safety
•Small children must be kept away from the appliance.
•Only let bigger children work on the appliance under supervision.
General safety
•The appliance may only be installed and connected by trained, registered
service engineers, or competent persons.
•Built-in appliances may only be used after they have been built in to suita-
ble built-in units and work surfaces that meet standards.
•In the event of faults with the appliance or damage to the glass ceramic
(cracks, scratches or splits), the appliance must be switched off and dis-
connected from the electrical supply to prevent the possibility of an elec-
tric shock.
•Repairs to the appliance must only be carried out by trained registered
service engineers.

5
Safety during use
•Remove stickers and film from the glass ceramic.
•There is the risk of burns from the appliance if used carelessly.
•Cables from electrical appliances must not touch the hot surface of the
appliance or hot cookware.
•Overheated fat and oil can ignite quickly. When cooking with fat or oil (e.g.
frying chips) do not leave the appliance unattended.
•Switch the cooking zones off after each use.
Safety when cleaning
•For cleaning, the appliance must be switched off and cooled down.
•For safety reasons, the cleaning of the appliance with steam jet or high-
pressure cleaning equipment is not permitted.
How to avoid damage to the appliance
•The ceramic glass can be damaged by objects falling onto it.
•The edge of the ceramic glass can be damaged by being knocked by the
cookware.
•Cookware made of cast iron, cast aluminium or with damaged bottoms
can scratch the ceramic glass if pushed across the surface.
•Objects that melt and things that boil over can burn onto the ceramic
glass and should be removed straightaway.
•To avoid damaging cookware and glass ceramics, do not allow saucepans
or frying pans to boil dry.
•Do not use the cooking zones with empty cookware or without cookware.

6
Description of the Appliance
Cooking surface layout
Assignment of Control Knobs
Single cooking zone
1700W
Control Knobs
Single cooking zone
1700W
Single cooking zone
1200W
Residual heat indicator Single cooking zone
1200W

7
Control Knobs
The cooking power can be set anywhere between level 1 and 9.
Residual heat indicator
The residual heat indicator lights up, as soon as the corresponding cooking
zone is hot.
1Danger! Risk of burns from residual heat. After being switched off, the
cooking zones need some time to cool down. Look at the residual heat indi-
cator.
2Residual heat can be used for melting and keeping food warm.
Operating the appliance
3When a cooking zone is switched on, it may hum briefly. This is a character-
istic of all ceramic glass cooking zones and does not impair either the func-
tion or the life of the appliance.
Selecting the heat setting
1. When boiling water/searing food, select a high heat setting.
2. As soon as steam forms or the fat or oil is hot, set a lower heat setting.
3. To end the cooking process, turn to the Off position.
1
lowest power
9
highest power
0
Off position
Heat setting Ring Control Knob Knob setting
To increase
turn clockwise
1 - 9
To redu c e
turn anti-clock-
wise
9 - 1
switch off 0

8
Tips on cooking and frying
3Information about acrylamides
According to the latest scientific research, intensive browning of food, espe-
cially in products containing starch, may present a health risk due to acryla-
mide. Therefore we recommend cooking at low temperatures and not
browning foods too much.
Cookware
•You can recognise good cookware from the bottoms of the pans. The bot-
tom should be as thick and flat as possible.
•Cookware made of enamelled steel or with aluminium or copper bottoms
can leave discolourations on the ceramic glass surface which are difficult
or impossible to remove.
Energy saving
2Always place cookware on the cooking
zone before it is switched on.
2If possible, always place lids on the pans.
2Switch cooking zones off before the end
of the cooking time, to take advantage of
residual heat.
2Bottom of pans and cooking zones
should be the same size.

9
Examples of cooking applications
The information given in the following table is for guidance only.
Heat
set-
ting
Cooking
process suitable for Cook time Tips/Hints
0Residual heat setting, Off
position
1
Keeping
food
warm
Keeping cooked foods
warm as required Cover
1-2
Melting
Hollandaise sauce,
melting butter, chocolate,
gelatine
5-25 mins. Stir occasionally
Solidify-
ing
Fluffy omelettes, baked
eggs 10-40 mins. Cook with lid on
2-3
Simmer-
ing
Simmering rice and milk-
based dishes
Heating up ready-cooked
meals
25-50 mins.
Add at least twice as
much liquid as rice, stir
milk dishes part way
through cooking
3-4
Steaming
Braising
Steaming vegetables, fish
Braising meat 20-45 mins.
With vegetables add
only a little liquid (a few
tablespoons)
4-5
Boiling
Steaming potatoes 20-60 mins.
Use only a little liquid, e.
g.: max. ¼ l water for
750 g of potatoes
Cooking larger quantities of
food, stews and soups 60-150 mins. Up to 3 l liquid plus in- gredients
6-7
Gentle
frying
Frying escalope, veal cor-
don bleu, cutlets, rissoles,
sausages, liver, roux, eggs,
pancakes, doughnuts
as required Turn halfway through
cooking
7-8
Heavy
frying
Hash browns, loin steaks,
steaks, Flädle (pancakes for
garnishing soup)
5-15 mins.
per pan
Turn halfway through
cooking
9
Boiling
Searing
Deep fry-
ing
Boiling large quantities of water, cooking pasta, searing meat (gou-
lash, pot roast), deep frying chips

10
Cleaning and care
1Take care! Risk of burns from residual heat.
1Important Sharp objects and abrasive cleaning materials will damage the
appliance. Clean with water and washing up liquid.
1Important Residues from cleaning agents will damage the appliance. Re-
move residues with water and washing up liquid.
Cleaning the appliance after each use
1. Wipe the appliance with a damp cloth and a little washing up liquid.
2. Rub the appliance dry using a clean cloth.
Removing deposits
1. Place the scraper on the glass ceramic surface at an angle.
2. Remove residues by sliding the blade over the surface.
3. Wipe the appliance with a damp cloth and a little washing up liquid.
4. Rub the appliance dry using a clean cloth.
*Scrapers and cleaners for glass ceramic and stainless steel can be purchased in specialist shops, su-
permarkets, the parts department of your local Service Force Centre or from www.shop.elec-
trolux.co.uk
3Remove stubborn residues with a cleaner for glass ceramic or stainless
steel.
3Scratches or dark stains on the glass ceramic that cannot be removed do
not however affect the functioning of the appliance.
Remove
Type of dirt imme-
diately
when the appliance has
cooled down using
sugar, food containing sugar yes --- a scraper*
plastics, tin foil yes ---
limescale and water rings --- yes cleaner for glass ce-
ramic or stainless
steel*
fat splashes --- yes
shiny metallic discolouration --- yes

11
What to do if …
If you are unable to remedy the problem by following the above sug-
gestions, please contact your local Service Force Centre.
1Warning! Repairs to the appliance are only to be carried out by qualified
service engineers. Considerable danger to the user may result from improp-
er repairs.
3If the appliance has been operated incorrectly, the visit from the service
technician or dealer may not take place free of charge, even during the war-
ranty period.
Problem Possible cause Remedy
The cooking zones are not
functioning.
The desired heat setting is
not set.
Set the heat setting.
The fuse in the house’s elec-
trical wiring (fuse box) has
been tripped.
Check the fuse.
If the fuses trip a number of
times, please call an author-
ised electrician.
The residual heat indicator is
not displaying anything
The cooking zone was only
on for a short time and is
therefore not hot
If the cooking zone is sup-
posed to be hot, call your lo-
cal Service Force Centre.

12
Disposal
2Packaging material
The packaging materials are environmentally friendly and can be recycled.
The plastic components are identified by markings, e.g. >PE<, >PS<, etc.
Please dispose of the packaging materials in the appropriate container at
your local waste disposal facilities.
2Old appliance
The symbol Won the product or on its packaging indicates that this prod-
uct may not be treated as household waste. Instead it shall be handed over
to the applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service
or the shop where you purchased the product.

13
Installation Instructions
Safety instructions
The laws, ordinances, directives and standards in force in the country of use
are to be followed (safety regulations, proper recycling in accordance with
the regulations, etc.)
Installation may only be carried out by a qualified electrician.
The minimum distances to other appliances and units are to be observed.
Anti-shock protection must be provided by the installation, for example
drawers may only be installed with a protective floor directly underneath the
appliance.
The cut surfaces of the worktop are to be protected against moisture using
a suitable sealant.
The sealant seals the appliance to the work top with no gap.
Avoid installing the appliance next to doors and under windows. Otherwise
hot cookware may be knocked off the rings when doors and windows are
opened.
1WARNING!
Risk of injury from electrical current.
•The electrical mains terminal is live.
•Observe connection schematic.
•Observe electrical safety rules.
•Ensure anti-shock protection through correct installation by a qualified
electrician.
•The appliance must be connected to the electrical supply by a qualified
electrician.
1IMPORTANT!
Risk of injury from electrical current.
Loose and inappropriate plug and socket connections can make the termi-
nal overheat.
•Have the clamping joints correctly installed by a qualified electrician.
•Use strain relief clamp on cable.
•In the event of single-phase or two-phase connection, the appropriate
mains cable of type H05BB-F Tmax 90°C (or higher) must be used.
•If this appliance’s mains cable is damaged, it must be replaced by a spe-
cial cable (type H05BB-F Tmax 90°C; or higher). Please contact your local
Service Force Center for further advice.

14
A device must be provided in the electrical installation which allows the ap-
pliance to be disconnected from the mains at all poles with a contact open-
ing width of at least 3 mm
Suitable isolation devices include line protecting cut-outs, fuses (screw type
fuses are to be removed from the holder), earth leakage trips and contac-
tors.
Electrical Connection Diagram
For UK only: 230V...240V~
Sticking on the seal
•Clean the worktop in the area of the cut-out section.
•Stick the one-sided self-adhesive sealing tape supplied all the way round
the lower edge of the cooking surface along the outer edge of the glass
ceramic panel. Do not stretch it. The cut ends should lie in the middle of
one side. When you have cut it to length (add a few mm), press the two
ends flush up against one another.

15
Assembly

16

17

18
Rating Plate
PEE2001
TBC650 F
5,8 kW
949 592 004
230 V 50 Hz
TRICITY BENDIX

19

www.electrolux.com
www.tricity-bendix.co.uk
822 930 779-A-200906-01 Subject to change without notice
