1
HDMI over Cat6
Splitter Kits, 4K/60 Hz
Splitter Models: B127A-002-BH,
B127A-004-BH, B127A-008-BH
Splitter and Receiver Kit Models:
B127A-002-BHPH2, B127A-004-BHPH3
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Owner's Manual
WARRANTY REGISTRATION
Register your product today and be automatically entered to win
an ISOBAR®surge protector in our monthly drawing!
tripplite.com/warranty
Este manual está disponible en español en la página de Tripp Lite:
tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite :
tripplite.com
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website
verfügbar: tripplite.com
21-08-019-933DB9-EN.indd 121-08-019-933DB9-EN.indd 1 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM

2
External
Power Supply
Mounting
Hardware
(Y/N)
HDMI
Accessory
Cable
B127A-002-BH Y Y N
B127A-002-BHPH2 Y Y N
B127A-004-BH Y Y Y
B127A-004-BHPH3 Y Y Y
B127A-008-BH Y Y N
All
• Extend 4K audio and video signals up to 230 ft. away to an
HDMI display
• Support video resolutions up to 4K x 2K (3840 x 2160) @
60 Hz, as specified in HDMI 2.0, with 4:4:4 Chroma
Subsampling
• Carry High Dynamic Range (HDR) signals for expanded color
accuracy
• Comply with HDCP 2.2 standards
• Power over Cable (PoC) technology provides power from splitter
to connected receiver units over Cat6 cabling
• Plug and play – no software or drivers required
Package Contents
Product Features
21-08-019-933DB9-EN.indd 221-08-019-933DB9-EN.indd 2 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM

3
Product Features
B127A-002-BH
• Extends and splits a 4K audio/video signal with power to two
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Compatible with Tripp Lite B127A-Series Receiver units such
as B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Included mounting hardware allows splitter unit to be wall-
mounted, rack-mounted or pole-mounted
B127A-002-BHPH2
• Extends and splits a 4K audio/video signal with power to two
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Kit includes two pigtail receivers that each support 4K/60 Hz
video resolutions
• Compatible with Tripp Lite B127A-Series Receiver units such
as B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
21-08-019-933DB9-EN.indd 321-08-019-933DB9-EN.indd 3 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM

4
Product Features
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Included mounting hardware allows splitter unit to be wall-
mounted, rack-mounted or pole-mounted
B127A-004-BH
• Extends and splits a 4K audio/video signal with power to four
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Compatible with Tripp Lite B127A-Series Receiver units such
as B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Local HDMI port supports 4K/60 Hz video resolution to display
the image being transmitted to connected displays
• Cascade an additional B127A-002-BH, B127A-004-BH
or B127A-008-BH splitter unit from the local HDMI port to
expand your installation
21-08-019-933DB9-EN.indd 421-08-019-933DB9-EN.indd 4 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM

5
Product Features
• Included mounting hardware allows splitter unit to be wall-
mounted, rack-mounted or pole-mounted
B127A-004-BHPH3
• Extends and splits a 4K audio/video signal with power to four
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Kit includes three pigtail receivers that each support 4K/60 Hz
video resolutions
• Compatible with Tripp Lite B127A-Series Receiver units such as
B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Local HDMI port supports 4K/60 Hz video resolution to display
the image being transmitted to connected displays
• Cascade an additional B127A-002-BH, B127A-004-BH
or B127A-008-BH splitter unit from the local HDMI port to
expand your installation
• Included mounting hardware allows splitter unit to be wall-
mounted, rack-mounted or pole-mounted
21-08-019-933DB9-EN.indd 521-08-019-933DB9-EN.indd 5 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM

6
Product Features
B127A-008-BH
• Extends and splits a 4K audio/video signal with power to eight
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Compatible with Tripp Lite B127A-Series Receiver units such
as B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Local HDMI port supports 4K/60 Hz video resolution to display
the image being transmitted to connected displays
• Cascade an additional B127A-002-BH, B127A-004-BH
or B127A-008-BH splitter unit from the local HDMI port to
expand your installation
• Included mounting hardware allows splitter unit to be
wall-mounted, rack-mounted or pole-mounted
21-08-019-933DB9-EN.indd 621-08-019-933DB9-EN.indd 6 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM

7
Disclaimer
Product Features
Before installation, please check the following settings of your
source(s) and TV/monitor(s):
1. Set display to 60 Hz. Double-check factory settings, as
default can be set to a lower frequency (Hz) than advertised.
2. Ensure the input setting of your monitor is set at HDMI 2.0.
Some displays may have default setting at HDMI 1.4.
3. Verify your monitor has the HDR feature enabled. Some
displays may have this feature disabled as a factory setting.
4. Check if the Ultra HD (UHD) Deep Color setting is enabled on
your TV/monitor. Confirm with your TV/monitor manufacturer
which HDMI ports support UHD Deep Color.
Note for B127A-004-BH, B127A-004-BHPH3 and B127A-008-BH:
To connect a local monitor to your installation, the UHD Deep Color
setting may need to be disabled on your local TV/monitor (depending
on make) to achieve 4K @ 60 Hz resolution.
Optional Accessories:
• N202-Series Cat6 24 AWG Solid Wire Patch Cables
• P569-XXX-CERT or P568-XXX-2A Series High-Speed
HDMI 2.0 Cables
• B127A-010-H Signal Booster
• B127A-1A0-BH Box-Style Receiver
• B127A-1P0-PH Pigtail Receiver
• B127A-1A0-FH Faceplate Receiver
21-08-019-933DB9-EN.indd 721-08-019-933DB9-EN.indd 7 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM

8
Mounting Instructions
The B127A-002-BH, B127A-004-BH, B127A-008-BH,
B127A-002-BHPH2 and B127A-004-BHPH3 include mounting
hardware that allows for a variety of mounting methods.
The following images illustrate how the included mounting
brackets can be attached for different installations.
Note: The model shown in the below images is for illustrative purposes
only. Your product may vary by model number, size or port orientation.
The mounting options for all over IP units are the same.
Wall-Mount
19” Rack-Mount Pole-Mount
21-08-019-933DB9-EN.indd 821-08-019-933DB9-EN.indd 8 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM

9
Installation
Standard Splitter Kit Installation
(2-Port Models)
Notes:
1) Test to ensure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat6 cable. Using stranded wire Cat6 cable or cable with a gauge
(AWG) size higher than 24 AWG will result in shorter extension distance.
Higher gauge cabling, such as 26 AWG, has a more limited transmission
capability than lower gauge cabling. All Tripp Lite N202-Series Cat6
cables are made with 24 AWG solid wire cabling.
3) The first installation diagram shows a B127A-002-BHPH2 kit, which
includes a B127A-002-BH splitter unit and two B127A-1P0-PH receiver
units. The second diagram shows the B127A-002-BH splitter used with
an included B127A-1P0-PH receiver and B127A-1A0-BH receiver (sold
separately at tripplite.com).
4) External power is not required for remote receiver units because of
Power over Cable (PoC) technology incorporated in the transmitter units.
21-08-019-933DB9-EN.indd 921-08-019-933DB9-EN.indd 9 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM

10
Installation
B127A-002-BH
1Up to 230 ft. (70 m) Cat6 cable at 4K/60 Hz
2Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60 Hz
MONITOR
HDR PLAYER
B127A-1A0-BH
B127A-002-BH
B127A-1P0-PH
21-08-019-933DB9-EN.indd 1021-08-019-933DB9-EN.indd 10 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM

11
Installation
B127A-002-BHPH2
1Up to 230 ft. (70 m) Cat6 cable at 4K/60 Hz
2Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60 Hz
HDR PLAYER
B127A-002-BH
B127A-1P0-PH
B127A-1P0-PH
1. Make sure all equipment in the installation—such as TVs,
Blu-ray™ players and the transmitter—is powered OFF.
2. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the HDMI source to
the INPUT port on the local transmitter unit.
3. Optional: For extended range, connect up to two
B127A-010-H signal repeater units to the splitter and each
receiver via Cat6 cabling.
4. Using Cat6 cable (such as Tripp Lite N202-Series 24 AWG
Cat6 Cabling), connect the RJ45 port on the local splitter unit
to the RJ45 port on the remote receiver unit.
21-08-019-933DB9-EN.indd 1121-08-019-933DB9-EN.indd 11 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM

12
Installation
5. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the remote receiver
unit’s HDMI port to a monitor.
6. Turn on the power to your connected TVs/monitors. The LOCAL
(orange) LED will illuminate to indicate the local port has been
connected to a display.
7. Connect the external power supply to the splitter unit. Plug
it into an available wall outlet or a Tripp Lite surge protector,
power distribution unit (PDU) or uninterruptible power supply
(UPS). The POWER (green) LED on the local splitter unit will
illuminate to indicate the unit is receiving power from the
external power supply. The POWER (green) LED on the remote
receiver unit’s RJ45 port will illuminate to indicate the unit is
receiving power from the local transmitter unit through PoC
technology.
8. Turn on the power to the HDMI source. The RJ45 (orange)
LED will illuminate on both the local transmitter and remote
receiver units to indicate a signal is being received from the
source to display. The screen should now display on the
connected monitor(s).
21-08-019-933DB9-EN.indd 1221-08-019-933DB9-EN.indd 12 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM

13
Installation
Standard Splitter Kit Installation
(4-Port Models)
Notes:
1) Test to ensure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat6 cable. Using stranded wire Cat6 cable or cable with a gauge
(AWG) size higher than 24 AWG will result in shorter extension distance.
Higher gauge cabling, such as 26 AWG, has a more limited transmission
capability than lower gauge cabling. All Tripp Lite N202-Series Cat6
cables are made with 24 AWG solid wire cabling.
3) The first installation diagram shows a B127A-004-BHPH3 kit, which
includes a B127A-004-BH splitter unit and three B127A-1P0-PH receiver
units. The second diagram shows a B127A-004-BH splitter unit with an
included B127A-1P0-PH receiver and additional B127A-1A0-BH,
B127A-1A0-FH and B127A-2A0-FH receiver units (sold separately at
tripplite.com).
4) External power is not required for remote receiver units because of
Power over Cable (PoC) technology incorporated in the transmitter units.
21-08-019-933DB9-EN.indd 1321-08-019-933DB9-EN.indd 13 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM

14
Installation
OUTPUT1
DATA
REMOTE
OUTPUT INPUT
OUTPUT 4 OUTPUT 3 OUTPUT 2 OUTPUT 1 INPUT LOCAL
DC 24V, 1A


 


OUTPUT1
DATA
OUTPUT2
REMOTE


B127A-004-BH
1Up to 230 ft. (70 m) Cat6 cable at 4K/60 Hz
2Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60 Hz
OPTIONAL LOCAL
MONITOR HDR PLAYER
B127A-1P0-PH
B127A-1A0-BH
B127A-1A0-FH
B127A-2A0-FH
B127A-004-BH
21-08-019-933DB9-EN.indd 1421-08-019-933DB9-EN.indd 14 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM

15
B127A-004-BHPH3
1Up to 230 ft. (70 m) Cat6 cable at 4K/60 Hz
2Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60 Hz
HDR PLAYER
B127A-004-BH
B127A-1P0-PH
B127A-1P0-PH
B127A-1P0-PH
1. Make sure all equipment in the installation—such as TVs,
Blu-ray players and the transmitter—is powered OFF.
2. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the HDMI source to
the INPUT port on the local splitter unit.
Installation
OPTIONAL LOCAL
MONITOR
21-08-019-933DB9-EN.indd 1521-08-019-933DB9-EN.indd 15 8/24/2021 3:07:49 PM8/24/2021 3:07:49 PM

16
Installation
3. Optional: For extended range, connect up to four
B127A-010-H signal repeater units between splitter and
each receiver via Cat6 cabling.
4a. Optional for B127A-004-BHPH3: Using an HDMI 2.0 cable
(such as Tripp Lite P569-XXX-CERT or P568-XXX-2A Series
cables), connect a local monitor to the LOCAL OUT port
on the B127A-004-BHPH3 local splitter unit. The LOCAL
(orange) LED will illuminate to indicate a display has been
connected to the local port.
Note: The HDMI local display port only supports 4K/60Hz resolutions
and will not work properly with lesser resolutions.
or
4b. Optional for B127A-004-BHPH3: Cascade an additional
B127A-002-BH, B127A-004-BH or B127A-008-BH splitter
unit via the local HDMI port (sold separately). Repeat steps
4 and 5 below as necessary.
5. Using Cat6 cable (such as Tripp Lite N202-Series 24 AWG
Cat6 Cabling), connect the RJ45 port on the local splitter
unit to the RJ45 port on the remote receiver unit.
6. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the remote receiver
unit’s HDMI port to a monitor.
7. Turn on the power to your connected TVs/monitors. The
LOCAL (orange) LED will illuminate to indicate the local port
has been connected to a display.
21-08-019-933DB9-EN.indd 1621-08-019-933DB9-EN.indd 16 8/24/2021 3:07:49 PM8/24/2021 3:07:49 PM

17
Installation
8. Connect the external power supply to the splitter unit. Plug
it into an available wall outlet or a Tripp Lite surge protector,
power distribution unit (PDU) or uninterruptible power supply
(UPS). The POWER (green) LED on the local splitter unit will
illuminate to indicate the unit is receiving power from the
external power supply. The POWER (green) LED on the remote
receiver unit’s RJ45 port will illuminate to indicate the unit is
receiving power from the local transmitter unit through PoC
technology.
9. Turn on the power to the HDMI source. The RJ45 (orange)
LED will illuminate on both the local transmitter and remote
receiver units to indicate a signal is being received from the
source to display. The screen should now display on the
connected monitor(s).
21-08-019-933DB9-EN.indd 1721-08-019-933DB9-EN.indd 17 8/24/2021 3:07:49 PM8/24/2021 3:07:49 PM

18
Installation
Standard Splitter Kit Installation
(8-Port Model)
Notes:
1) Test to ensure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat6 cable. Using stranded wire Cat6 cable or cable with a gauge
(AWG) size higher than 24 AWG will result in shorter extension distance.
Higher gauge cabling, such as 26 AWG, has a more limited transmission
capability than lower gauge cabling. All Tripp Lite N202-Series Cat6
cables are made with 24 AWG solid wire cabling.
3) The installation diagram shows a B127A-008-BH splitter unit with
an assortment of B127A-Series receivers, including B127A-1A0-BH,
B127A-1P0-PH and B127A-1A0-FH (sold separately at tripplite.com).
4) External power is not required for remote receiver units because of
Power over Cable (PoC) technology incorporated in the transmitter unit.
21-08-019-933DB9-EN.indd 1821-08-019-933DB9-EN.indd 18 8/24/2021 3:07:49 PM8/24/2021 3:07:49 PM

19
Installation
OUTPUT INPUT
B127A-1A0-BH

OUTPUT1
DATA
REMOTE
B127A-008-BH
LOCAL-OUTINPUT
RJ45RJ45
RJ45 HDMI
RJ45RJ45RJ45RJ45RJ45 HDMI
2
3
4
56
7
81
B127A-008-BH



HDR PLAYER
OPTIONAL LOCAL MONITOR
OUTPUT1
DATA
REMOTE
B127A-1A0-FH
B127A-1A0-FH
Up to 230 ft. (70 m) Cat6 cable at 4K/60Hz
Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60Hz
   

B127A-1P0-PH
OUTPUT INPUT
B127A-1A0-BH


21-08-019-933DB9-EN.indd 1921-08-019-933DB9-EN.indd 19 8/24/2021 3:07:49 PM8/24/2021 3:07:49 PM

20
Installation
1. Make sure all equipment in the installation—such as TVs,
Blu-ray players and the transmitter—is powered OFF.
2. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the HDMI source to
the INPUT port on the local splitter unit.
3. Optional: For extended range, connect up to eight B127A-
010-H signal repeater units between splitter and each
receiver via Cat6 cabling.
4a. Optional for B127A-008-BH: Using an HDMI 2.0 cable
(such as Tripp Lite P569-XXX-CERT or P568-XXX-2A Series
cables), connect a local monitor to the LOCALOUT port on
the B127A-008-BH local splitter unit. The LOCAL (orange)
LED will illuminate to indicate a display has been connected
to the local port.
or
4b. Optional for B127A-008-BH: Cascade an additional
B127A-002-BH, B127A-004-BH or B127A-008-BH splitter
unit via the local HDMI port (sold separately). Repeat steps 4
and 5 below as necessary.
Note: The HDMI local display port only supports 4K/60Hz resolutions
and will not work properly with lesser resolutions.
4. Using Cat6 cable (such as Tripp Lite N202-Series 24AWG
Cat6 Cabling), connect the RJ45 port on the local splitter unit
to the RJ45 port on the remote receiver unit.
5. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A Series cables), connect the remote receiver
unit’s HDMI port to a monitor.
21-08-019-933DB9-EN.indd 2021-08-019-933DB9-EN.indd 20 8/24/2021 3:07:50 PM8/24/2021 3:07:50 PM
