Owner’s Manual
VGA Over Cat5 Extenders
and Extender/Splitters
Extender Kit Models: B130-101, B130-101A,
B130-101-WP-1, B130-101A-WP-1,
B130-101S, B130-111, B130-111A and B130-101-U
Local Unit Models: B132-002-1,
B132-002A, B132-004-1 and B132-004A
Remote Unit Models: B132-100-1, B132-100A,
B132-100-WP-1, B132-100A-WP-1,
B132-110 and B132-110A
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2014 Tripp Lite. All rights reserved. SmartRack is a trademark of Tripp Lite.
WARRANTY
REGISTRATION:
register online today for a
chance to win a FREE Tripp Lite
product—www.tripplite.com/warranty
14-01-055 933064.indd 1 1/9/2014 2:36:08 PM

2
Table of Contents
Package Contents 3
Product Features 4
All 4
B130-101 4
B130-101A 4
B130-101-WP-1 4
B130-101A-WP-1 5
B130-101S 5
B130-111 5
B130-111A 6
B130-101-U 6
B132-002-1 6
B132-002A 6
B132-004-1 7
B132-004A 7
B132-100-1 8
B132-100A 8
B132-100-WP-1 8
B132-100A-WP-1 8
B132-110 9
B132-110A 9
Optional Accessories 10
Mounting Hardware Instructions 11
Installation 12
Extender Kit Installation 12
Non-Kit Standard Installation 14
Non-Kit Daisychain Installation 16
Extender/Repeater Kit Installation 18
Non-Kit Remote/Repeater Installation 20
Non-Kit Daisychain Remote/Repeater Installation 24
Warranty 27
14-01-055 933064.indd 2 1/9/2014 2:36:08 PM

3
Package Contents
B130-101 B130-101A B130-101-WP-1 B130-101A-WP-1 B130-101S B130-111 B130-111A B130-101-U B132-002-1 B132-002A B132-004-1 B132-004A B132-100-1 B132-100A B132-100-WP-1 B132-100A-WP-1 B132-110 B132-110A
Local Unit (L), Remote
Unit (R) or Both (B) B B B B B B B B L L L L R R R R R R
1 or 2 External Power
Supplies (Input: 100-
240V, 50/60Hz, 0.5A
Output: 5V, 2A)
22222220 1111111111
Mounting Hardware X X X X X X X X X X X X X
Wallplate Screws X X X X
Screwdriver X X X X X X X X X X X X X X
3.5mm Male to DB9 Male
Adapter Cable X
3.5mm Male to DB9
Female Adapter Cable X
1 ft. VGA Splitter Cable X
1 ft. VGA + Audio Splitter
Cable X
1 ft. VGA Daisychain Cable X
1 ft. VGA + Audio
Daisychain Cable X
14-01-055 933064.indd 3 1/9/2014 2:36:09 PM

4
Product Features
All
•Support a maximum resolution of 1920 x 1440 @ 60Hz.
•All operating systems supported.
•Plugandplay;nosoftwareordriversrequired.
•HDCPcompliant.
B130-101
•ExtendsaVGAVideosignal(1024x768@60Hz)upto1,000ft.from
the source.
•FeaturesanadditionalVGAport,allowingfortheconnectionofalocal
monitor.
•Includesmountinghardwarethatallowsunitstobewall-mounted,
rackmounted or pole mounted.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
B130-101A
•ExtendsbothaVGAVideo(1024x768@60Hz)andanaudiosignal
up to 1,000 ft. from the source.
•FeaturesadditionalVGAand3.5mmports,allowingfortheconnection
of a local monitor and speakers.
•Includesmountinghardwarethatallowsunitstobewall-mounted,
rackmounted or pole mounted.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
B130-101-WP-1
•ExtendsaVGAVideosignal(1024x768@60Hz)upto1,000ft.from
the source.
•IncludesaVGAsplittercable,whichallowsfortheconnectionofalocal
monitor.
•IncludesRJ45jacks,allowingforeasyconnectionviastandardpatch
cables;no110punchdownconnectionsrequired.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
14-01-055 933064.indd 4 1/9/2014 2:36:09 PM

5
B130-101A-WP-1
•ExtendsbothaVGAVideo(1024x768@60Hz)andanaudiosignalupto
1,000 ft. from the source.
•IncludesaVGA+Audiosplittercable,whichallowsfortheconnectionofa
local monitor and speakers.
•AllwallplateunitscomewithRJ45jacks,allowingforeasyconnectionvia
standardpatchcables;no110punchdownconnectionsrequired.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
B130-101S
•ExtendsbothaVGAVideo(1024x768@60Hz)andRS232Serialsignal
up to 1,000 ft. from the source.
•Includesmountinghardwarethatallowsunitstobewall-mounted,
rackmounted or pole mounted.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
B130-111
•Kitcomeswithbothlocaltransmitterandremote/repeaterunits.
•Locatemultiplemonitorsatdifferentpointsinachainofupto2,000ft.by
connecting an additional remote receiver unit (B132-100-1 or
B132-100-WP-1), or a remote/repeater unit (B132-110).
•Upto4remoteunits(3remote/repeatersand1receiver)canbeconnected
together, providing video to up to 4 remote displays in a full chain.
•Extenda1024x768(60Hz)signalupto1,000ft.betweenthelocal
transmitter and the first remote/repeater unit in the installation.
•Extenda1024x768(60Hz)signaluptoanadditional1,000ft.from
the first remote/repeater unit to the last display in the installation, for a
maximum extension distance of 2,000 ft..
•LocalunitincludesanadditionalVGAport,allowingfortheconnectionofa
local monitor.
•Featuresbuilt-inEqualizationandGaincontrolstoadjustthevideoimage.
•Includesmountinghardwarethatallowsunitstobewall-mounted,
rackmounted or pole mounted.
Product Features continued
14-01-055 933064.indd 5 1/9/2014 2:36:09 PM

6
Product Features continued
B130-111A
•Kitcomeswithbothlocaltransmitterandremote/repeaterunits.
•Locatemultiplemonitors/speakersatdifferentpointsinachainofupto
2,000 ft. by connecting an additional remote receiver unit (B132-100A or
B132-100A-WP-1), or a remote/repeater unit (B132-110A).
•Upto4remoteunits(3remote/repeatersand1receiver)canbeconnected
together, providing audio/video to up to 4 remote displays/speakers in a full
chain.
•Extenda1024x768(60Hz)videoandaudiosignalupto1,000ft.
between the local transmitter and the first remote/repeater unit in the
installation.
•Extenda1024x768(60Hz)videoandaudiosignaluptoanadditional
1,000 ft. from the first remote/repeater unit to the last set of display and
speakers in the installation, for a maximum extension distance of 2,000 ft..
•LocalunitincludesadditionalVGAvideoand3.5mmaudioports,allowing
for the connection of a local monitor and speakers.
•Featuresbuilt-inEqualizationandGaincontrolstoadjustthevideoimage.
•Includesmountinghardwarethatallowsunitstobewall-mounted,
rackmounted or pole mounted.
B130-101-U
•ExtendsaVGAVideosignal(1024x768@60Hz)upto500ft.fromthe
source.
•PowerissuppliedbytheUSBconnectiononthelocaltransmitterunit;
noexternalpowersuppliesarerequired.
•Dongle-stylelocalandremoteunitscomewithbuilt-inVGAconnectors;
noexternalVGAcablesarerequired.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
14-01-055 933064.indd 6 1/9/2014 2:36:09 PM

7
Product Features continued
B132-002-1
•WorkswiththeB132-100-1andB132-100-WP-1remoteunitstoextenda
VGA Video signal (1024 x 768 @ 60Hz) up to 1,000 ft. from the source.
•AbletotransmitasingleVGAVideosignalto2monitors.
•Includesmountinghardwarethatallowsunittobewall-mounted,
rackmounted or pole mounted.
B132-002A
•WorkswiththeB132-100AandB132-100A-WP-1remoteunitstoextend
both a VGA Video (1024 x 768 @ 60Hz) and an audio signal up to
1,000 ft. from the source.
•TransmitsasingleVGAVideoandaudiosignalto2setsofmonitorsand
speakers.
•Includesmountinghardwarethatallowsunittobewall-mounted,
rackmounted or pole mounted.
B132-004-1
•FeaturesanadditionalVGAport,allowingfortheconnectionofalocal
monitor.
•WorkswiththeB132-100-1andB132-100-WP-1remoteunitstoextenda
VGA Video signal (1024 x 768 @ 60Hz) up to 1,000 ft. from the source.
•Abletotransmitupto5(4remote,1local)VGAVideosignals.
•Expandthenumberofconnectedmonitorstoupto25(24remote,1local)
by daisychaining up to 6 local units together.
Note: B132-002-1 local units cannot be daisychained.
•Includesmountinghardwarethatallowsunittobewall-mounted,
rackmounted or pole mounted.
•UptothreelocalunitscanbeconnectedtoaTrippLiteB132-004-RB
rackmountbracketandmountedinjust1Uofrackspace.
14-01-055 933064.indd 7 1/9/2014 2:36:09 PM

8
Product Features continued
B132-004A
•WorkswiththeB132-100AandB132-100A-WP-1remoteunitstoextend
both a VGA Video (1024 x 768 @ 60Hz) and an audio signal up to 1,000
ft. from the source.
•FeaturesadditionalVGAand3.5mmports,allowingfortheconnectionofa
local monitor and speakers.
•TransmitsasingleVGAVideoandaudiosignaltoupto5sets
(4 remote, 1 local) of monitors and speakers.
•Expandthenumberofconnectedmonitors/speakerstoupto25
(24 remote, 1 local) by daisychaining up to 6 local units together.
Note: B132-002A local units cannot be daisychained.
•Includesmountinghardwarethatallowsunittobewall-mounted,
rackmounted or pole mounted.
•UptothreelocalunitscanbeconnectedtoaTrippLiteB132-004-RB
rackmountbracketandmountedinjust1Uofrackspace.
B132-100-1
•Includesmountinghardwarethatallowsunittobewall-mounted,
rackmounted or pole mounted.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
B132-100A
•Includesmountinghardwarethatallowsunittobewall-mounted,
rackmounted or pole mounted.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
B132-100-WP-1
•IncludesRJ45jacks,allowingforeasyconnectionviastandardpatchcables;
no110punchdownconnectionsrequired.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
B132-100A-WP-1
•IncludesRJ45jacks,allowingforeasyconnectionviastandardpatchcables;
no110punchdownconnectionsrequired.
•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.
14-01-055 933064.indd 8 1/9/2014 2:36:09 PM

9
Product Features continued
B132-110
•BothextendsandexpandsyourTrippLiteVGAoverCat5installation,
allowing you to locate multiple monitors at different points in a chain of up
to 2,000 ft..
•Upto4remoteunits(3remote/repeatersand1receiver)canbeconnected
together, providing video to up to 4 remote displays in a full chain.
•Extenda1024x768(60Hz)signalupto1,000ft.betweenthelocal
transmitter and the first remote/repeater unit in the installation.
•Extenda1024x768(60Hz)signaluptoanadditional1,000ft.from
the first remote/repeater unit to the last display in the installation, for a
maximum extension distance of 2,000 ft..
•Featuresbuilt-inEqualizationandGaincontrolstoadjustthevideoimage.
•Includesmountinghardwarethatallowsunittobewall-mounted,
rackmounted or pole mounted.
B132-110A
•BothextendsandexpandsyourTrippLiteVGA+AudiooverCat5
installation, allowing you to locate multiple monitors/speakers at different
points in a chain of up to 2,000 ft..
•Upto4remoteunits(3remote/repeatersand1receiver)canbeconnected
together, providing audio/video to up to 4 remote displays/speakers in a full
chain.
•Extenda1024x768(60Hz)videoandaudiosignalupto1,000ft.
between the local transmitter and the first remote/repeater unit in the
installation.
•Extenda1024x768(60Hz)videoandaudiosignaluptoanadditional
1,000 ft. from the first remote/repeater unit to the last set of display and
speakers in the installation, for a maximum extension distance of 2,000 ft..
•Featuresbuilt-inEqualizationandGaincontrolstoadjustthevideoimage.
•Includesmountinghardwarethatallowsunittobewall-mounted,
rackmounted or pole mounted.
14-01-055 933064.indd 9 1/9/2014 2:36:09 PM

10
Optional Accessories
• B132-004-RB1URackmountBracket
• N001-SeriesCat5eSnaglessPatchCables
• N002-SeriesCat5ePatchCables
• N020-01K-GYGrayCat5eBulkStrandedCable–1,000ft.
• N022-01K-GYGrayCat5eBulk24AwgSolidCable–1,000ft.
• N030-01010pkofRJ45PlugsforSolidWireCat5eCable
• N031-05050pkofRJ45PlugsforStrandedWireCat5eCable
• N201-SeriesCat6SnaglessPatchCables
• N202-SeriesCat6Snagless24AwgSolidPatchCables
• N222-01K-GYGrayCat6Bulk24AwgSolidCable–1,000ft.
• P312-SeriesAudioCables
• P502-SeriesVGAMonitorCableswithRGBCoax
• P504-SeriesVGAMonitor+AudioCableswithRGBCoax
• P520-006RS232SerialExtensionCable–6ft.
• P524-01KZero-SkewUTPBulkCable–1,000ft.
14-01-055 933064.indd 10 1/9/2014 2:36:10 PM

11
Mounting Hardware Instructions
All of the non-wallplate VGA extender products come with mounting
hardware that allows them to be mounted in a variety of ways. The
following images show the different ways the included mounting brackets
can be attached for different mounting methods.
Note: The B132-004-1 and B132-004A can also be mounted to a Tripp Lite
B132-004-RB 1U rackmount bracket. Up to 3 B132-004-1 or B132-004A local
units can be connected to a B132-004-RB.
Wallmount
19” Rackmount Pole Mount
14-01-055 933064.indd 11 1/9/2014 2:36:12 PM

12
Installation
Extender Kit Installation (B130-101, B130-101A,
B130-101-WP-1, B130-101A-WP-1, B130-101S, B130-101-U)
Note:
1. The diagram above shows a B130-101A VGA + Audio Extender Kit installation.
Installation will be the same for other extender kit models, with the exception of
units featuring VGA + Audio, VGA + RS232 serial or VGA only. The B130-101-U
gets power from the USB cable built-in to the local unit, and doesn’t require
external supplies.
2. Test to make sure the entire installation works properly before pulling cables
through ceilings/walls.
3. To achieve maximum distance and performance, 24Awg solid wire Cat5e/6 cable
must be used. The use of stranded wire Cat5e/6 cable, or cable with a gauge
(Awg) size higher than 24Awg, will result in shorter extension distance. All Tripp
Lite
N202-Series cables are made with 24Awg solid wire cabling. Tripp Lite N022-
01K-GY (Cat5e) and N222-01K-GY (Cat6) are 24Awg solid wire bulk cables. For
optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as
Tripp Lite P524-01K. For the B130-101-U, use Zero-Skew cable for distances
between 250 and 500 ft.
4. To achieve maximum resolution, it is recommended that you use Tripp Lite
P502-Series VGA Video or P504-Series VGA Video and Audio cables with RGB
coax.
*If this is a feature of your extender kit.
Local Unit
Remote Unit
14-01-055 933064.indd 12 1/9/2014 2:36:13 PM

13
Installation continued
1Make sure that the VGA, Audio* and RS232 Serial* source is
powered off.
2(B130-101, B130-101A and B130-101S only) – Connect the VGA
and Audio* source to the INPUT port(s) on the local unit using a VGA
and Audio* cable.
3(B130-101S only) – Connect the included 3.5mm Male to DB9
Female adapter cable to the 3.5mm INPUT port on the local unit, and
then connect the computer to the adapter using a DB9 cable.
4 (B130-101-U only) – Connect the built-in VGA and USB connectors
on the local unit to the source computer.
5(B130-101-WP-1 and B130-101A-WP-1 only) – If you wish to
connect a local monitor and speakers*, connect the male end of the
included splitter cable to the source port(s), and then connect one
of the female ends of the splitter cable to the INPUT port(s) on the
local unit using a VGA and Audio* cable. If you are not connecting a
local monitor and speakers*, connect the source directly to the INPUT
port(s) on the local unit.
6(Optional) – Connect a local monitor and speakers* to the LOCAL
port(s) on the local unit, or the remaining female connector(s) on
your splitter cable*, using a VGA and Audio* cable.
Note: The B130-101S comes with a local video port only, and does not
contain a local RS-232 Serial port.
7Connect the external power supply to the local unit, and then plug
it into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU)
or Uninterruptible Power Supply (UPS). The B130-101-U gets power
fromtheUSBcablebuilt-intothelocalunit,anddoesn’trequire
external power supplies.
8UsingCat5e/6cable,connecttheRJ45OUTPUT port on the local unit
totheRJ45INPUT port on the remote unit.
9(B130-101-U only) – Connect the built-in VGA connector on the
remote unit to the VGA port on a monitor.
*If this is a feature of your extender kit.
14-01-055 933064.indd 13 1/9/2014 2:36:13 PM

14
Installation continued
10 Connect a monitor and speakers* to the OUTPUT ports on the remote
unit using a VGA and Audio* cable.
11 (B130-101S only) – Connect the included 3.5mm Male to DB9 Male
adapter cable to the 3.5mm OUTPUT port on the remote unit, and
then connect the serial device to the adapter using a DB9 cable.
12 Connect the external power supply to the remote unit, and then plug
it into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU)
or Uninterruptible Power Supply (UPS). The B130-101-U gets power
fromtheUSBcablebuilt-intothelocalunit,anddoesn’trequire
external power supplies.
13 Turn on the power to the monitor, speakers* and RS232 serial
device.*
14 Turn on the power to the monitor, audio* and RS232 serial* source.
15 Ifnecessary,adjusttheEqualization and Gain controls using the
included screwdriver to improve the video image.
14-01-055 933064.indd 14 1/9/2014 2:36:13 PM

15
Installation continued
Non-Kit Standard Installation
Note:
1. The diagram above shows a B132-004A VGA + Audio Extender/Splitter Kit
installation. Installation will be the same for non-Audio models, except that an Audio
source and speakers will not be connected.
2. Test to make sure the entire installation works properly before pulling cables through
ceilings/walls.
3. To achieve maximum distance and performance, 24Awg solid wire Cat5e/6 cable
must be used. The use of stranded wire Cat5e/6 cable, or cable with a gauge (Awg)
size higher than 24Awg, will result in shorter extension distance. All
Tripp Lite N202-Series cables are made with 24Awg solid wire cabling.
Tripp Lite N022-01K-GY (Cat5e) and N222-01K-GY (Cat6) are 24Awg solid wire bulk
cables. For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable,
such as Tripp Lite P524-01K.
4. To achieve maximum resolution, it is recommended that you use Tripp Lite
P502-Series VGA Video or P504-Series VGA Video and Audio cables with RGB coax.
Source PC
B132-100A-WP-1B132-004A
B132-100A
14-01-055 933064.indd 15 1/9/2014 2:36:13 PM

16
1Make sure that the VGA and Audio* source is powered off.
2Connect the VGA and Audio* source to the INPUT port(s) on the local unit
(B132-002-1, B132-002A, B132-004-1 or B132-004A) using a VGA
and Audio* cable.
3(Optional – B132-004-1 and B132-004A only) – Connect a local
monitor and speakers* to the LOCAL port(s) on the B132-004-1 or
B132-004A local unit.
4Connect the external power supply to the local unit, and then plug it
into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU) or
Uninterruptible Power Supply (UPS).
5UsingCat5e/6cable,connectanavailableRJ45OUTPUT port on the local
unittotheRJ45INPUT port on a remote unit (B132-100-1, B132-100A,
B132-100-WP-1 or B132-100A-WP-1).
6Repeat step 5 for each remote unit you are connecting to the installation.
7Connect a monitor and speakers* to the OUTPUT port(s) on the remote
unit using a VGA and Audio* cable.
8Repeat step 7 for each remote unit in the installation.
9Connect the external power supply to the remote unit, and then plug
it into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU) or
Uninterruptible Power Supply (UPS).
10 Repeat step 9 for each remote unit in the installation.
11 Turn on the power to the monitor and speakers.*
12 Turn on the power to the monitor and audio* source.
13 Ifnecessary,adjusttheEqualization and Gain controls using the included
screwdriver to improve the video image.
Installation continued
*If this is a feature of your extender kit.
14-01-055 933064.indd 16 1/9/2014 2:36:13 PM

17
Installation continued
Non-Kit Daisychain Installation
(B132-004-1 and B132-004A only)
Note:
1. The diagram above shows a B132-004A VGA + Audio Extender/Splitter Kit daisychain
installation. Installation will be the same for non-Audio models, except that an Audio
source and speakers will not be connected.
2. Test to make sure the entire installation works properly before pulling cables through
ceilings/walls.
3. To achieve maximum distance and performance, 24Awg solid wire Cat5e/6 cable
must be used. The use of stranded wire Cat5e/6 cable, or cable with a gauge (Awg)
size higher than 24Awg, will result in shorter extension distance. All
Tripp Lite N202-Series cables are made with 24Awg solid wire cabling.
Tripp Lite N022-01K-GY (Cat5e) and N222-01K-GY (Cat6) are 24Awg solid wire bulk
cables. For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable,
such as Tripp Lite P524-01K.
4. To achieve maximum resolution, it is recommended that you use Tripp Lite
P502-Series VGA Video or P504-Series VGA Video and Audio cables with RGB coax.
Source PC
Local PC and
Speakers (Optional)
B132-100A-WP-1
B132-004A
B132-100A
14-01-055 933064.indd 17 1/9/2014 2:36:14 PM

18
1Make sure that the VGA and Audio* source is powered off.
2Connect the VGA and Audio* source to the INPUT port(s) on the local unit
(B132-004-1 or B132-004A) using a VGA and Audio* cable.
3Using the included daisychain cable, connect the LOCAL port(s) on the
B132-004-1 or B132-004A to the INPUT ports on a second level
B132-004-1 or B132-004A.
Note: A standard VGA cable can be used to increase the distance between units
with no more than 6 ft. between.
4Repeat step 3 for each additional local unit you are adding to the
daisychain, with no more than 6 local units in the entire installation.
5(Optional) – Connect a local monitor and speakers* to the LOCAL port(s)
of the last B132-004-1 or B132-004A in the daisychain using a VGA and
audio cable.
6Connect the external power supply to the first local unit in the installation,
and then plug it into a Tripp Lite Surge Suppressor, Power Distribution Unit
(PDU) or Uninterruptible Power Supply (UPS).
7Repeat step 6 for each additional local unit in the installation.
8UsingCat5e/6cable,connectanavailableRJ45OUTPUT port on the local
unittotheRJ45INPUT port on a remote unit (B132-100-1, B132-100A,
B132-100-WP-1 or B132-100A-WP-1).
9Repeat step 8 for each remote unit you are connecting to the installation.
10 Connect a monitor and speakers* to the OUTPUT ports on the remote
unit using a VGA and Audio* cable.
11 Repeat step 10 for each remote unit in the installation.
12 Connect the external power supply to the remote unit, and then plug
it into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU) or
Uninterruptible Power Supply (UPS).
13 Repeat step 12 for each remote unit in the installation.
14 Turn on the power to the monitor and speakers.*
15 Turn on the power to the monitor and audio* source.
16 Ifnecessary,adjusttheEqualization and Gain controls using the included
screwdriver to improve the video image.
Installation continued
*If this is a feature of your extender kit.
14-01-055 933064.indd 18 1/9/2014 2:36:14 PM

19
Installation continued
Extender/Repeater Kit Installation
(B130-101. B130-101A, B130-111 and B130-111A)
Note:
1. An extender/repeater kit installation can start with a B130-101, B130-101A,
B130-111 or B130-111A. The only difference between these kits is the type of
remote unit that comes with them. The B130-101 and B130-101A come with
remote receiver units, and the B130-111 and B130-111A come with remote/
repeater units.
2. The diagram above shows a B130-111A installation, with the maximum number of
remote units connected. Installation will be the same for the B130-111, except there
will be no audio connections. Installation will be the same for the B130-101 and
B130-101A, except that instead of adding remote units to the end of the installation,
remote/repeater units will be inserted in between the local and remote units that
come with the kits.
3. A 1024 x 768 (60Hz) signal can be extended up to 1,000 ft. from the source to
the first remote/repeater unit in the installation. A 1024 x 768 (60Hz) signal can be
extended up to an additional 1,000 ft. between the first remote/repeater unit and the
last display in the installation. Up to 4 remote units (3 remote/repeaters and 1 remote
receiver) can be connected together to transmit a signal to up 4 points in a 2,000 ft.
chain.
14-01-055 933064.indd 19 1/9/2014 2:36:14 PM

20
Installation continued
4. To achieve maximum distance and performance, 24Awg solid wire Cat5e/6 cable
must be used. The use of stranded wire Cat5e/6 cable, or cable with a gauge (AWG)
size higher than 24Awg, will result in shorter extension distance. All Tripp Lite N202-
Series cables are made with 24Awg solid wire cabling. Tripp Lite N022-01K-GY
(Cat5e) and N222-01K-GY (Cat6) are 24Awg solid wire bulk cables. For optimal
image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite
P524-01K.
5. To achieve maximum distance and performance, it is recommended that you use
Tripp Lite P502-Seriess VGA Video or P504-Series VGA + Audio cables with RGB
coax.
6. Test to make sure the entire installation works properly before pulling cables through
ceilings/walls.
1Make sure that the VGA Video and Audio* source is powered off.
2Connect the VGA Video and Audio* source to the INPUT port(s) on the
local unit using a VGA and Audio* cable.
3(Optional) –Connectalocalmonitorandspeakers*totheLOCAL port(s)
on the local unit using a VGA Video and Audio* cable.
4Connect the external power supply to the local unit, and then plug it
into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU) or
Uninterruptible Power Supply (UPS). The Red power LED and the Green
RJ45LEDwillilluminatetoindicatetheunitisreceivingpower.
5UsingCat5e/6cable,connecttheRJ45OUTPUT port on the local unit to
theRJ45INPUT port on the remote/repeater unit.
Note: If starting with a B130-101 or B130-101A, a remote/repeater unit
(B132-110 or B132-110A) must be added in between the local and remote units
that come with the kit.
6Connect a monitor and speakers* to the OUTPUT port(s) on the remote/
repeater unit using a VGA Video and Audio* cable.
7Connect the external power supply to the remote/repeater unit, and then
plug it into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU) or
Uninterruptible Power Supply (UPS). The Red power LED and the Green
RJ45LEDsilluminatetoindicatetheunitisreceivingpower.
*If this is a feature of your extender kit.
14-01-055 933064.indd 20 1/9/2014 2:36:14 PM
