Tripp Lite ISOBAR6ULTRA User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: ISOBAR6ULTRA
6-Outlet Isobar Surge Protector with 6-ft Cord and All-Metal Housing
Highlights
6 outlets/6-ft cord
3330 joule rating—more joules mean more protection!
All-metal housing with diagnostic LEDs
Isolated filter banks remove damaging line noise
$50,000 Insurance for connected equipment (USA , Puerto Rico & Canada
only)
Lifetime warranty
Description
For more than 20 years, America's leading companies have trusted Tripp Lite's Isobar Premium surge and noise protectors to protect sensitive
computer, networking and telecom equipment. With more than 18 million satisfied customers, the Isobar remains the world's number one selling
premium surge protector. Loaded with a generous combination of high quality components, near indestructible all-metal case and unique noise
filtration system, the Isobar offers the highest level of protection attainable in a multi-outlet strip. Robust surge suppression circuits with sine-wave
tracking offer extreme levels of protection against the heaviest surge conditions exceeding IEEE 587 category A & B specifications and reducing
6,000V test surges to harmless levels under 35 volts. Isobar's unique protection system combines large toroidal chokes, ferrite rod-core inductors,
HF/VHF capacitors and multiple layers of metal oxide varistors into exclusive isolated filter banks that remove EMI/RFI interference, even noise
generated by other pieces of connected equipment. ISOBAR6ULTRA offers 6 outlets arranged in three filter banks to prevent system crashes,
reboots and performance problems common as noisy system peripherals are powered off and on. Surge suppression rated at 3330 joules/97,000
amps offers network-grade protection. Widely spaced NEMA 5-15 outlets accommodate up to 4 large transformer plugs without blocking outlets.
Diagnostic LEDs confirm power availability, line fault and protection status. Includes 6 foot AC line cord with space-saving angled input plug, keyhole
mounting tabs and a set of 4 child safety covers.
PLUG/OUTLETS: Input: NEMA 5-15P/Output: 6 NEMA5-15R/6-ft. AC line cord
ELECTRICAL: 120V AC, 50/60Hz (Requires NEMA 5-15R wall receptacle)
SUPPRESSION: AC: 140V RMS Clamping/3330 joules/97,000 amps
FORMAT: Corded all-metal strip with transformer spaced outlets
Applications
Ideal for premium protection of personal computers with peripherals, network and CAD/CAM/CAE workstations, internetworking
accessories, telecommunications systems, point of sale equipment, audio/video and home theater systems in any home, office or industrial
application.
Package Includes
ISOBAR6ULTRA premium surge protector
Set of 4 outlet safety covers
Instruction manual with warranty information
Features
Tripp Lite's ISOBAR is the world's number one selling premium protector series with more than 18 million satisfied customers and a
safety-tested history of 20+ years
Robust surge suppression with sine-wave tracking protects against the heaviest of surge conditions, exceeding IEEE category A&B
specifications and reducing 6,000V test surges to harmless levels less than 35 volts.
Multi-component suppression circuits combine toroidal chokes, ferrite rod-core inductors, HF/VHF capacitors and multiple layers of metal
oxide varistors into exclusive isolated filter banks that remove EMI/RFI interference, even noise from other pieces of connected equipment.
6 outlets arranged in three filter banks prevent system crashes, reboots and performance problems common as noisy peripherals are
powered off and on.

Network grade surge suppression rated at 3330 joules/97,000 amps
Widely spaced outlets accommodate up to 4 large transformer plugs without blocking outlets
3 LED indicators confirm suppressor operation and site wiring status, plus warning of suppressor or electrical fault conditions
Lighted power switch with integrated 12 amp circuit breaker offers power control and overload protection
6 foot AC line cord with space-saving angled input plug6 foot AC line cord with space-saving angled input plug
Keyhole mounting tabs allow permanent installation
Set of 4 outlet covers safely seal off unused outlets
120VAC, 50/60Hz electrical compatibility
$50,000 Ultimate Lifetime Insurance (USA and Canada Only)
Specifications
OVERVIEW
Intended Application Home/Office, Computer Networks
OUTPUT
Frequency
compatibility
50 / 60 Hz
Output watts 1440
Circuit Breaker (amps) 12
Outlet quantity / type 6 NEMA 5-15R
Transformer
accommodation
Supports up to 4 large transformer plug accessories without covering remaining outlets
INPUT
Recommended
Electrical Service
120V (110-125V)
Input connection type NEMA 5-15P input plug
Input plug features Space-saving right angle input plug
Input cord length (ft.) 6
Input cord length (m) 1.83
Voltage compatibility
(VAC)
120
Maximum Surge Amps 135000
LEDS ALARMS & SWITCHES
Switches Combination AC circuit breaker and two position red illuminated on/off power switch
Diagnostic LEDs PROTECTION PRESENT (green), LINE FAULT (red) and LINE OK (green)
SURGE / NOISE SUPPRESSION
AC suppression joule
rating
3330
AC suppression
response time
NM = 0 ns. CM =
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
Clamping voltage
(RMS)
140
AC suppression surge
current rating
97,000 amps (36,000 NM / 61,000 CM)

AC suppression
components used
Metal oxide varistors, toroidal balanced chokes, ferrite rod-core inductors and VHF capacitors.
Safe thermal fusing Prevents unsafe conditions during extreme extended over-voltages and catastrophic occurrences
UL1449 let through
rating
330V
IEEE587 Cat. A
ringwave let through
Less than 35 volts
EMI / RFI filtering 40-80 dB
Isolated filter banks Unique isolated filter bank design offers additional filtering between each duplex pair of outlets on the strip to
prevent electrical noise interference between connected loads. Includes 3 filter banks.
Immunity Conforms to IEE 587 / ANSI C62.41
DATALINE SURGE SUPPRESSION
Cable (Coax) Protection No
Network (Ethernet)
Protection
No
PHYSICAL
Shipping weight (lbs) 2.68
Shipping weight (kg) 1.22
Unit Dimensions
(HWD/in)
2.5 x 9 x 3.50
Unit Dimensions
(HWD/cm)
6.35 x 22.86 x 8.89
Shipping Dimensions
(HWD/in)
11.5 x 7 x 3
Shipping Dimensions
(HWD/cm)
29.21 x 17.78 x 7.62
Unit weight (lbs) 2.18
Unit weight (kg) 0.99
Material of construction Metal
Integrated keyhole
mounting tabs
Metal end caps are fitted with keyhole mounting tabs for wallmount installation
Receptacle Color Black
AC line cord color Gray
Style Strip
Outlets center to
center measurement
Distance between horizontal outlets = 39.45mm; Distance between vertical outlets = 39.30mm
Keyhole slot center to
center measurement
Distance between horizontal tabs = 171.35mm; Distance between vertical tabs = 58.17mm
SPECIAL FEATURES
Appearance Rugged all-metal corded strip format with high quality duplex receptacles
Right-Angle Plug Yes
CERTIFICATIONS

UL1449 3rd Edition (AC
Suppression)
Tested to UL1449 3rd Edition requirements by ETL
cUL / CSA (Canada) Approved for Canada by ETL
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty
Period (Worldwide)
Lifetime limited warranty
Connected Equipment
Insurance (U.S.,
Canada & Puerto Rico)
$50,000 Ultimate Lifetime Insurance
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=104.
