Triton ASANA MINI User manual

2180917E - March 2020
IMPORTANT SAFETY ADVICE
The shower head and hose supplied with
this product are a safety critical part of your
shower. Failure to use genuine Triton parts may
cause injury and invalidate your guarantee.
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: [phone]
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The mixer shower installation MUST be carried out by a suitably qualied person, in the sequence
of this instruction book.
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
LOVE2SHOP VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
ASANA MINI
Sequential Mixer

mini exposed sequential thermostatic mixer shower
CONTENTS Page
MAIN COMPONENTS................................................................................1
DIMENSIONS ............................................................................................2
INTRODUCTION........................................................................................3
SITE REQUIREMENTS .................................................................................3
SAFETY WARNINGS ...................................................................................3
PLUMBING REQUIREMENTS ......................................................................4
WATER SYSTEM REQUIREMENTS................................................................4
TYPICAL DOMESTIC INSTALLATIONS................................................... 5 - 7
INSTALLATION................................................................................... 8 - 12
FITTING THE SHOWER .....................................................................9
FLOW REGULATION.......................................................................10
ANTI-SCALD PROTECTION ............................................................10
LEAK TESTING ...............................................................................10
COMMISSIONING.........................................................................11
ADJUSTING THE MAXIMUM TEMPERATURE SETTING ....................12
OPERATING THE SHOWER .......................................................................12
APPROVALS & FLOW RATES.....................................................................13
MAINTENANCE .......................................................................................14
CLEANING THE FILTERS ...........................................................................14
SPARE PARTS............................................................................................15
FAULT FINDING............................................................................... 16 - 17
GUARANTEE, SERVICE POLICY, etc............................................... rear cover
To check the product suitability for commercial and multiple installations, please contact Triton’s
specication advisory service before installation.
Telephone:
E mail:
024 7637 2222
[email protected]
Installers please note these InstructIons are to be left wIth the user

mini exposed sequential thermostatic mixer shower
1
1
2
3
4
5
6
7
Fig.1
Main components
MAIN COMPONENTS
Ref Description
1. Control knob 5. Mounting plate
2. Mixer shower valve 6. Inlet nut and olive X2
3. Blanking plug 7. Wall trim X2
4. Outlet adapter

mini exposed sequential thermostatic mixer shower
2
60mm
135mm
36mm
G1/2
102mm
150mm
200mm
DIMENSIONS - All dimensions regarding the product and installation are approximate.

mini exposed sequential thermostatic mixer shower
3
Replacement parts can be ordered from Triton Customer
Experience. See Spare Parts for details.
INTRODUCTION
This book contains all the necessary tting and
operating instructions for your thermostatic
mixer shower. Please read them carefully and
read through the whole of this book before
beginning your installation.
The shower installation must be carried out by a
suitably competent person and in the sequence
of this instruction book.
Care taken during the installation will give a long
and trouble free life from your mixer shower.
SITE REQUIREMENTS
The installation must be in accordance with
water supply (water ttings) regulation 1999
and/or local Bylaws.
Water Pressure Requirements
Running water pressure:
Low pressure* - 0.1 bar min.
1.0 bar max.
High pressure - 0.5 bar min.
5.0 bar max.
Maximum static water pressure:
Low & High pressure - 10 bar
*This mixer shower is designed for high pressure
systems found in the UK, but can be installed
with low pressure gravity water systems with
reduced ow rates.
For effective operation of the internal seals, the
maximum static pressure must not be exceeded.
Pressure Reducing Valve
On sites where the running pressure is above 5
bar, the use of a suitably sized pressure reducing
valve tted in the cold mains supply pipework
can provide nominally equal pressures at the
mixer shower.
Water Minimum Flow Rate
For best performance within the specied running
pressure range a minimum ow of 8 litres per
minute should be available to both inlets.
Water Temperature Requirements
Recommended maximum: = 65°C
Minimum hot water temperature: = 55°C
Maximum cold water temperature: = 25°C
NOTE: Valves operating outside these conditions
cannot be guaranteed by the Scheme to operate
as Type 2 valves.
A stored water temperature of 60°C is
considered sufcient to meet all normal
requirements and will minimise the effects of
scale in hard water areas.
Water Temperature Adjustment and
Thermal Safety
The mixed water temperature can be adjusted
from cold through to a top limit which must
be preset during installation with full anti-scald
protection throughout the range (35°C to 40°C)
providing the hot water temperature at the inlet
remains 10°C above the outlet temperature.
Should there be a loss of ow to either incoming
supply then water from the shower will stop or
be reduced until both supplies are restored.
SAFETY WARNINGS
a. DO NOT choose a position where the shower
could become frozen.
b. DO NOT connect this mixer shower to any
form of tap or tting not recommended by
the manufacturer.
c. DO NOT allow the inlet pressure or ow
rates to operate outside the guidelines laid
out in Site Requirements.
d. DO NOT connect the mixer shower to a
gravity hot supply and a mains cold supply or
vice versa.
