TRIUMPH BOARD Presenter User manual

© TRIUMPH BOARD
User Manual
Presenter
2020

© TRIUMPH BOARD Page 2of 9
Contents
1. Device Requirements.................................................................................................................................. 3
1.1 Receiver.......................................................................................................................................... 3
1.2 Sender............................................................................................................................................ 3
2. Product Appearance.................................................................................................................................... 3
3. Pairing..........................................................................................................................................................4
2.1 Indicator Status in Pairing.............................................................................................................. 4
2.2 Pair with Android Receiver............................................................................................................4
2.3 Pair with Windows Receiver.......................................................................................................... 6
4. Share Screen...............................................................................................................................................8
3.1 Indicator Status in Sharing ............................................................................................................ 8
3.2 Start/Stop Sharing..........................................................................................................................8
3.3 Extend Screen................................................................................................................................8

© TRIUMPH BOARD Page 3of 9
1. Device Requirements
1.1 Receiver
1) ESharePro app is installed and activated.
2) Network: 5G Wi-Fi hotspot or LAN or WLAN.
1.2 Sender
1) Windows PC: Win 7 / Win 8 / Win 10
2) MacBook: macOS 9.0 or later
3) Chrome Book
4) Linux
5) Other devices with HDMI output available
2. Product Appearance
Picture 1 HDMI Screen Sharing Button Appearance

© TRIUMPH BOARD Page 4of 9
3. Pairing
2.1 Indicator Status in Pairing
1) Blinking in blue: HDMI Screen Sharing Button (hereinafter referred to as
the “Button”) is starting up or pairing.
2) Continuously on and in blue: The Button is paired successfully.
3) Blinking in red: The Button fails to pair with the receiver.
2.2 Pair with Android Receiver
2.2.1 Auto Pair
1) Prerequisite: 5G Wi-Fi hotspot is enabled on the Android receiver.
2) Steps: plug the Button into the USB port of Android receiver, and the Button
will pair with the receiver automatically. Please don’t unplug the Button while
pairing, as shown in Picture 2:
Picture 2 Auto Pair with Android Receiver

© TRIUMPH BOARD Page 5of 9
3) It shows the Button is paired if the message “Saved!” pops up, as shown in
Picture 3:
Picture 3 Paired with Android Receiver
2.2.2 Pair Manually
1) Prerequisite: LAN or WLAN is available for Android receiver.
2) Steps:
Step 1: plug the Button into the USB port of Android receiver, and enter the Wi-Fi
SSID and password associated with the receiver in the pairing dialog, as shown in
Picture 4:
Picture 4 Manually Pair with Android Receiver

© TRIUMPH BOARD Page 6of 9
Step 2: Check if the network information is entered correctly, and then tap the “Save”
button. It shows the Button is paired if the message “Saved!” pops up, as shown in
Picture 5:
Picture 5 Paired with Android Receiver
2.3 Pair with Windows Receiver
1) Prerequisite: 5G Wi-Fi hotspot is enabled, or LAN/WLAN is available for
Windows receiver.
2) Steps:
Step 1: plug the Button into the USB port of Windows receiver, and the pairing dialog
will pop up automatically, as shown in Picture 6:
Picture 6 Manually Pair with Windows Receiver

© TRIUMPH BOARD Page 7of 9
Step 2: Select the SSID in the drop-down list of “Network”, or you can also enter the
SSID, as shown in Picture 7:
Picture 7 Select SSID for Pairing
Step 3: Enter the password and the IP address of the windows receiver (shown on the
Eshare Server screen) and tap the “Save” button. It shows the Button is paired if the
message “Saved!” pops up, as shown in Picture 8 and Picture 9:
Picture 8 Manually Pair with Windows Receiver
Picture 9 Paired with Windows Receiver

© TRIUMPH BOARD Page 8of 9
Note: The automatic paring is unavailable on Windows receiver.
4. Share Screen
4.1 Indicator Status in Sharing
1) Blinking in blue: The Button is connecting.
2) Continuously on and in blue: The Button is connected.
3) Blinking in red: The Button fails to connect with the receiver.
Plug both USB and HDMI cables of the Button into the sender, and the Button indicator
will blink in blue.
It shows that the Button is connected with the receiver and ready for screen sharing if
the indicator turns blue and continuously on.
4.2 Start/Stop Sharing
Plug the paired Button into the sender and wait until the indicator turns blue and is
continuously on. Tap the button to start screen sharing, tap again to stop sharing.
4.3 Extend Screen
You can also set the display mode as extend display in the display settings of the OS
on the sender.

© TRIUMPH BOARD Page 9of 9
5. Technical support
Please fill in your RMA or Product question on our website:
https://www.triumphboard.com/support/technical-support/
If you have any questions, please email us at [e-mail].
TRIUMPH BOARD a.s.
Neklanova 122/15
128 00 Prague 2
Czech Republic
European Union
Phone: [phone]
E-mail: [e-mail] www.triumphboard.com
