Triumph Street Triple S User guide

Owner's Handbook
Street Triple S, Street Triple S 660cc, Street Triple R,
Street Triple R - LRH (Low Ride Height),
Street Triple RS
This handbook contains information on the Triumph Street Triple S, Street Triple S 660cc,
Street Triple R, Street Triple R - LRH (Low Ride Height), Street Triple RS motorcycles.
Always store this Owner's Handbook with the motorcycle and refer to it for
information whenever necessary.
The information contained in this publication is based on the latest information
available at the time of printing. Triumph reserves the right to make changes at any
time without prior notice, or obligation.
Not to be reproduced wholly or in part without the written permission of
Triumph Motorcycles Limited.
© Copyright 01.2017 Triumph Motorcycles Limited, Hinckley, Leicestershire, England.
Publication part number 3855572-EN issue 1
1

2
TABLE OF CONTENTS
This handbook contains a number of different sections. The table of contents below
will help you find the beginning of each section where, in the case of the major
sections, a further table of contents will help you find the specific subject required.
Foreword 3
Safety First 6
Warning Labels 12
Parts Identification 14
Serial Numbers 18
Instruments 19
General Information 77
How to Ride the Motorcycle 108
Accessories, Passengers and Loading 120
Maintenance 123
Cleaning and Storage 179
Specifications 188
Specifications 192
Specifications 196
Index 200

Foreword
3
FOREWORD
Warnings, Cautions and
Notes
Throughout this Owner's Handbook
particularly important information is
presented in the following form:
Warning
This warning symbol identifies special
instructions or procedures, which if not
correctly followed could result in
personal injury, or loss of life.
Caution
This caution symbol identifies special
instructions or procedures, which, if
not strictly observed, could result in
damage to, or destruction of,
equipment.
Note:
• This note symbol indicates points of
particular interest for more
efficient and convenient operation.
Warning Labels
At certain areas of the motorcycle, the
symbol (left) can be seen. The symbol
means 'CAUTION: REFER TO THE
HANDBOOK' and will be followed by a
pictorial representation of the subject
concerned.
Never attempt to ride the motorcycle or
make any adjustments without
reference to the relevant instructions
contained in this handbook.
See page 12 for the location of all labels
bearing this symbol. Where necessary,
this symbol will also appear on the
pages containing the relevant
information.
Street Triple R - LRH (Low
Ride Height) Models
Unless stated otherwise, the
information, instructions, and
specifications for the Street Triple R -
LRH (Low Ride Height) model is identical
to those detailed in this Owner’s
Handbook for the Street Triple R
standard ride height model.

Foreword
4
Maintenance
To ensure a long, safe and trouble free
life for your motorcycle, maintenance
should only be carried out by an
authorised Triumph dealer.
Only an authorised Triumph dealer will
have the necessary knowledge,
equipment and skills to maintain your
Triumph motorcycle correctly.
To locate your nearest authorised
Triumph dealer, visit the Triumph web
site at www.triumph.co.uk or telephone
the authorised distributor in your
country. Their address is given in the
service record book that accompanies
this handbook.
Noise Control System
Tampering with the noise control
system is prohibited.
Owners are warned that the law may
prohibit:
1. The removal or rendering
inoperative by any person other
than for purposes of maintenance,
repair or replacement, of any device
or element of design incorporated
into any new vehicle for the
purpose of noise control prior to its
sale or delivery to the ultimate
purchaser or while it is in use and,
2. the use of the vehicle after such
device or element of design has
been removed or rendered
inoperative by any person.
Tyres
With reference to the Pneumatic Tyres
and Tubes for Automotive Vehicles
(Quality Control) Order, 2009, Cl. No. 3 (c),
it is declared by M/s. Triumph
Motorcycles Ltd. that the tyres fitted on
this motorcycle meet the requirements
of IS 15627: 2005 and comply with the
requirements under Central Motor
Vehicle Rules (CMVR), 1989.

Foreword
5
Owner's Handbook
Warning
This Owner's Handbook, and all other
instructions that are supplied with
your motorcycle, should be considered
a permanent part of your motorcycle
and should remain with it even if your
motorcycle is subsequently sold.
All riders must read this Owner's
Handbook and all other instructions
which are supplied with your
motorcycle, before riding, in order to
become thoroughly familiar with the
correct operation of your motorcycle's
controls, its features, capabilities and
limitations. Do not lend your
motorcycle to others as riding when
not familiar with your motorcycle's
controls, features, capabilities and
limitations can lead to an accident.
Thank you for choosing a Triumph
motorcycle. This motorcycle is the
product of Triumph's use of proven
engineering, exhaustive testing, and
continuous striving for superior
reliability, safety and performance.
Please read this Owner's Handbook
before riding in order to become
thoroughly familiar with the correct
operation of your motorcycle's controls,
its features, capabilities and limitations.
This handbook includes safe riding tips,
but does not contain all the techniques
and skills necessary to ride a motorcycle
safely.
Triumph strongly recommends that all
riders undertake the necessary training
to ensure safe operation of this
motorcycle.
This handbook is available from your
local dealer in:
• English
• US English
• French
• German
• Italian
• Dutch
• Spanish
• Portuguese
• Swedish
• Japanese
• Thai.
Talk to Triumph
Our relationship with you does not end
with the purchase of your Triumph. Your
feedback on the buying and ownership
experience is very important in helping
us develop our products and services
for you.
Please help us by ensuring your
authorised Triumph dealership has your
email address and registers this with us.
You will then receive an online customer
satisfaction survey invitation to your
email address where you can give us
this feedback.
Your Triumph Team.

Safety First
6
SAFETY FIRST
The Motorcycle
Warning
This motorcycle is designed for on-road
use only. It is not suitable for off-road
use.
Off-road operation could lead to loss of
control of the motorcycle resulting in
an accident causing injury or loss of
life.
Warning
Street Triple - LRH Models
The Street Triple R - LRH (Low Ride
Height) motorcycles is equipped with
lowered suspension and has reduced
ground clearance.
As a result, the cornering banking
angles that can be achieved by the
Street Triple R - LRH (Low Ride Height)
are reduced, when compared with the
standard ride height Street Triple R
model.
When riding, bear in mind that your
motorcycle’s ground clearance is
limited. Operate your motorcycle in an
area free from traffic to gain familiarity
with the motorcycle’s ground clearance
and bank angle limitations.
Banking to an unsafe angle or
unexpected contact with the ground
may cause instability, loss of
motorcycle control and an accident.
Warning
This motorcycle is not designed to tow
a trailer or be fitted with a sidecar.
Fitting a sidecar and/or a trailer may
result in loss of control and an
accident.
Warning
This motorcycle is designed for use as
a two-wheeled vehicle capable of
carrying a rider on his/her own, or a
rider and one passenger (subject to a
passenger seat and footrests being
fitted).
The total weight of the rider, and any
passenger, accessories and luggage
must not exceed the maximum load
limit of:
Street Triple S - 195 kg (430 lb)
Street Triple S 660cc - 195 kg (430 lb)
Street Triple R - 195 kg (430 lb)
Street Triple R - LRH (Low Ride Height) -
170 kg (374.8 lb)
Street Triple RS - 195 kg (430 lb)

Safety First
7
Warning
This motorcycle is fitted with a
catalytic converter below the engine,
which along with the exhaust system
reaches a very high temperature
during engine operation. Flammable
materials such as grass, hay/straw,
leaves, clothing and luggage etc. could
ignite if allowed to come into contact
with any part of the exhaust system
and catalytic converter; always ensure
flammable materials are not allowed to
contact the exhaust system or
catalytic converter.
Fuel and Exhaust Fumes
Warning
PETROL IS HIGHLY FLAMMABLE:
Always turn off the engine when
refuelling.
Do not refuel or open the fuel filler cap
while smoking or in the vicinity of any
open (naked) flame.
Take care not to spill any petrol on the
engine, exhaust pipes or silencers
when refuelling.
If petrol is swallowed, inhaled or
allowed to get into the eyes, seek
immediate medical attention.
Spillage on the skin should be
immediately washed off with soap and
water and clothing contaminated with
petrol should immediately be removed.
Burns and other serious skin
conditions may result from contact
with petrol.
Warning
Never start your engine or let it run for
any length of time in a closed area. The
exhaust fumes are poisonous and may
cause loss of consciousness and death
within a short time. Always operate
your motorcycle in the open-air or in
an area with adequate ventilation.

Safety First
8
Helmet and Clothing
Warning
When riding the motorcycle, both rider
and passenger must always wear a
motorcycle helmet, eye protection,
gloves, boots, trousers (close fitting
around the knee and ankle) and a
brightly coloured jacket. Brightly
coloured clothing will considerably
increase a rider's (or passenger's)
visibility to other operators of road
vehicles. Although full protection is not
possible, wearing correct protective
clothing can reduce the risk of injury
when riding.
Warning
A helmet is one of the most important
pieces of riding gear as it offers
protection against head injuries. You
and your passenger's helmet should be
carefully chosen and should fit you or
your passenger's head comfortably
and securely. A brightly coloured
helmet will increase a rider's (or
passenger's) visibility to other
operators of road vehicles.
An open face helmet offers some
protection in an accident though a full
face helmet will offer more.
Always wear a visor or approved
goggles to help vision and to protect
your eyes.
cbma
Parking
Warning
Always switch off the engine and
remove the ignition key before leaving
the motorcycle unattended. By
removing the key, the risk of use of the
motorcycle by unauthorised or
untrained persons is reduced.
When parking the motorcycle, always
remember the following:
Engage first gear to help prevent the
motorcycle from rolling off the stand.
The engine and exhaust system will be
hot after riding. DO NOT park where
pedestrians, animals and/or children
are likely to touch the motorcycle.
Do not park on soft ground or on a
steeply inclined surface. Parking under
these conditions may cause the
motorcycle to fall over.
For further details, please refer to the
'How to Ride the Motorcycle' section of
this Owner's Handbook.

Safety First
9
Parts and Accessories
Warning
Owners should be aware that the only
approved parts, accessories and
conversions for any Triumph
motorcycle are those which carry
official Triumph approval and are fitted
to the motorcycle by an authorised
dealer.
In particular, it is extremely hazardous
to fit or replace parts or accessories
whose fitting requires the dismantling
of, or addition to, either the electrical
or fuel systems and any such
modification could cause a safety
hazard.
The fitting of any non-approved parts,
accessories or conversions may
adversely affect the handling, stability
or other aspect of the motorcycle
operation that may result in an
accident causing injury or death.
Triumph does not accept any liability
whatsoever for defects caused by the
fitting of non-approved parts,
accessories or conversions or the fitting
of any approved parts, accessories or
conversions by non-approved personnel.
Maintenance/Equipment
Warning
Consult your authorised Triumph
dealer whenever there is doubt as to
the correct or safe operation of this
Triumph motorcycle.
Remember that continued operation of
an incorrectly performing motorcycle
may aggravate a fault and may also
compromise safety.
Warning
Ensure all equipment that is required
by law is installed and functioning
correctly. The removal or alteration of
the motorcycle’s lights, silencers,
emission or noise control systems can
violate the law. Incorrect or improper
modification may adversely affect the
handling, stability or other aspect of
the motorcycle operation, which may
result in an accident causing injury or
death.
Warning
If the motorcycle is involved in an
accident, collision or fall, it must be
taken to an authorised Triumph dealer
for inspection and repair. Any accident
can cause damage to the motorcycle
that, if not correctly repaired, may
cause a second accident that may
result in injury or death.

Safety First
10
Riding
Warning
Never ride the motorcycle when
fatigued or under the influence of
alcohol or other drugs.
Riding when under the influence of
alcohol or other drugs is illegal.
Riding when fatigued or under the
influence of alcohol or other drugs
reduces the rider's ability to maintain
control of the motorcycle and may lead
to loss of control and an accident.
Warning
All riders must be licenced to operate
the motorcycle. Operation of the
motorcycle without a licence is illegal
and could lead to prosecution.
Operation of the motorcycle without
formal training in the correct riding
techniques that are necessary to
become licenced is dangerous and may
lead to loss of motorcycle control and
an accident.
Warning
Always ride defensively and wear the
protective equipment mentioned
elsewhere in this foreword. Remember,
in an accident, a motorcycle does not
give the same impact protection as a
car.
Warning
This Triumph motorcycle should be
operated within the legal speed limits
for the particular road travelled.
Operating a motorcycle at high speeds
can be potentially dangerous since the
time available to react to given traffic
situations is greatly reduced as road
speed increases. Always reduce speed
in potentially hazardous driving
conditions such as bad weather or
heavy traffic.
Warning
Continually observe and react to
changes in road surface, traffic and
wind conditions. All two-wheeled
vehicles are subject to external forces
which may cause an accident. These
forces include but are not limited to:
Wind draft from passing vehicles
Potholes, uneven or damaged road
surfaces
Bad weather
Rider error.
Always operate the motorcycle at
moderate speed and away from heavy
traffic until you have become
thoroughly familiar with its handling
and operating characteristics. Never
exceed the legal speed limit.

Safety First
11
Handlebars and Footrests
Warning
The rider must maintain control of the
vehicle by keeping hands on the
handlebars at all times.
The handling and stability of a
motorcycle will be adversely affected if
the rider removes their hands from the
handlebars, resulting in loss of
motorcycle control and an accident.
Warning
The rider must always use the
footrests provided, during operation of
the vehicle.
By using the footrests, the rider will
reduce the risk of inadvertent contact
with any motorcycle components and
will also reduce the risk of injury from
entrapment of clothing.
Warning
Use of a motorcycle with bank angle
indicators worn beyond the maximum
limit will allow the motorcycle to be
banked to an unsafe angle. Therefore,
always replace the bank angle
indicator pegs before they are worn to
their maximum limit. Banking to an
unsafe angle may cause instability, loss
of motorcycle control and an accident.
Details of the bank angle wear limits
can be found in the Maintenance and
Adjustment section on page 163.
Warning
The bank angle indicators must not be
used as a guide to how far the
motorcycle may be safely banked. This
depends on many various conditions
including, but not limited to, road
surface, tyre condition and weather.
Banking to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.
Warning
When banking and the bank angle
indicator, attached to the rider's
footrest, makes contact with the
ground, the motorcycle is nearing its
bank angle limit. A further increase of
the banking angle is unsafe. Banking to
an unsafe angle may cause instability,
loss of motorcycle control and an
accident.
cjxz
2
1
1. Footrest
2. Bank angle indicator

Warning Labels
12
WARNING LABELS
Warning Label Locations
The labels detailed on this and the following pages draw your attention to important
safety information in this handbook. Before riding, ensure that all riders have
understood and complied with all the information to which these labels relate.
6
5
4
3
2
N
1
1
5
4
67
R.P.M.
32
1. Headlights (page 174)
2. Mirrors (page 148)
3. Running-in (page 105)
4. Gears (page 111)
5. Coolant (page 133)
6. Tyres (page 164)
7. Drive Chain (page 138)

Warning Labels
13
Warning Label Locations (continued)
Caution
All warning labels and decals, with the exception of the Running-in label, are fitted
to the motorcycle using a strong adhesive. In some cases, labels are installed prior
to an application of paint lacquer. Therefore, any attempt to remove the warning
labels will cause damage to the paintwork or bodywork.
4
P
b
1
2 3
5
DAILY SAFETY CHECKS
TÄGLICHE SICHERHEITSKONTROLLEN
CONTROLES DE SECURITE QUOTIDIENS
CHEQUEOS DE SEGURIDAD DIARIOS
VERIFICAÇÕES DIÁRIAS DE SEGURANÇA
VERIFICHE GIORNALIERE DI SICUREZZA
DAGELIJSKE VEILIGHEIDSINSPECTIES
DAGLIG SÄKERHETSKONTROLL
運行前点検
1. Daily Safety checks (page 106)
2. Unleaded Fuel (page 92)
3. Helmet (page 8)
4. Engine Oil (page 130)
5. Tyre Pressure Monitoring System
(if fitted) (page 165)

Parts Identification
14
PARTS IDENTIFICATION
Parts Identification
2 3 4 5 6
12 11 9 8 714 13
1
1015
1. Headlight
2. Fuel filler cap
3. Fuel tank
4. Rear suspension unit
5. Seat lock
6. Rear light
7. Drive chain adjuster
8. Drive chain
9. Gear change pedal
10. Side stand
11. Coolant expansion tank
12. Oil filter
13. Front direction indicator
14. Front brake caliper
15. Front brake disc

Parts Identification
15
Parts Identification - Continued
576
111314 8910
3
12
241
1. Licence plate light
2. Rear direction indicator
3. Tool kit (under seat)
4. Battery (under seat)
5. Rear brake fluid reservoir
6. Radiator/Coolant pressure cap
7. Front fork
8. Clutch cable
9. Engine oil level dipstick
10. Oil filler cap
11. Rear brake pedal
12. Silencer
13. Rear brake disc
14. Rear brake caliper

Parts Identification
16
Street Triple S, Street Triple S 660cc
17 15 14 13
12 3 4 5 6 7 8 9
16
10 12
11
1. Clutch lever
2. High beam button
3. Instrument TRIP button
4. SCROLL button
5. SET button
6. Instrument assembly (LCD)
7. Trip computer display
8. Speedometer
9. Tachometer
10. Front brake fluid reservoir
11. Engine stop/start switch
12. Front brake lever
13. Hazard warning light switch
14. Ignition switch
15. Mode button
16. Horn button
17. Direction indicator switch

Parts Identification
17
Street Triple R, Street Triple R Low Ride Height (LRH),
Street Triple RS
cjwr
16 15 14
12 3 7 8 9 10
17
11 13
124 56
1. Clutch lever
2. High beam/pass button
3. Daytime Running lights (DRL) switch if
fitted
4. MODE button
5. Direction indicator switch
6. Instrument assembly (TFT)
7. Information tray/Mode display
8. Speedometer
9. Tachometer
10. Front brake fluid reservoir
11. Engine start/stop switch
12. Hazard warning light switch
13. Front brake lever
14. HOME button
15. Ignition switch
16. Joystick selection button
17. Horn button

Serial Numbers
18
SERIAL NUMBERS
Vehicle Identification Number (VIN)
cjxv
1
1. VIN number
The Vehicle Identification Number (VIN)
is stamped into the steering head area
of the frame. It is also displayed on a
label attached to the left hand side of
the frame, adjacent to the radiator cowl.
Record the vehicle identification number
in the space provided below.
Engine Serial Number
cjxp
1
1. Engine serial number
The engine serial number is stamped on
the engine crankcase, directly above the
clutch cover.
Record the engine serial number in the
space provided below.

Instruments
19
INSTRUMENTS
Instruments Description
Street Triple R, Street Triple R - LRH
(Low Ride Height) and Street Triple RS
models are fitted with a full colour TFT
(Thin Film Transistor) digital display.
Street Triple S and Street Triple S 660cc
models are fitted with a LCD (Liquid
Crystal Display) instrument assembly.
For TFT digital display operating
instructions, see page 20.
Thin Film Transistor display (TFT)
For LCD instrument operating
instructions, see page 56.
TC
TC
Liquid Crystal Display (LCD)

Instruments
20
TFT Digital Display
Table of Contents
Instrument Panel Layout 21
Warning Lights 22
Warning and Information Messages 26
Speedometer and Odometer 27
Tachometer 28
Fuel Gauge 28
Ambient Air Temperature 28
Service Interval Announcement (SIA) 29
Gear Position Display 30
TFT Display Navigation 30
TFT Themes and Styles 31
Riding Modes 32
Riding Mode Selection 33
Information Tray 35
Main Menu 41
Instrument Panel Position Adjustment 55
