Trox EK-JZ User manual

Smoke control damper
Type EK-JZ
Installation and operating manual
Read the instructions prior to performing any task!
according to EN12101-8
Declaration of performance DoP / EK-JZ / 001
GB/en

A00000062392, 2, GB/en
Translation of the original
© 2017
TROX GmbH
Heinrich-Trox-Platz
47504 Neukirchen-Vluyn
Germany
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: http://www.troxtechnik.com
04/2017
Smoke control damper Type EK-JZ 2

General information
About this manual
This operating and installation manual enables oper-
ating or service personnel to correctly install the TROX
product described below and to use it safely and effi-
ciently.
This operating and installation manual is intended for
use by fitting and installation companies, in-house tech-
nicians, technical staff, properly trained persons, and
qualified electricians or air conditioning technicians.
It is essential that these individuals read and fully under-
stand this manual before starting any work. The basic
prerequisite for safe working is to comply with the safety
notes and all instructions in this manual.
The local regulations for health and safety at work and
general safety regulations also apply.
This manual must be given to the system owner when
handing over the system. The system owner must
include the manual with the system documentation. The
manual must be kept in a place that is accessible at all
times.
Illustrations in this manual are mainly for information
and may differ from the actual design.
Copyright
This document, including all illustrations, is protected by
copyright and pertains only to the corresponding
product.
Any use without our consent may be an infringement of
copyright, and the violator will be held liable for any
damage.
This applies in particular to:
Publishing content
Copying content
Translating content
Microcopying content
Saving content to electronic systems and editing it
TROX Technical Service
To ensure that your request is processed as quickly as
possible, please keep the following information ready:
Product name
TROX order number
Delivery date
Brief description of the fault
Online www.troxtechnik.com
Phone [phone]
Limitation of liability
The information in this manual has been compiled with
reference to the applicable standards and guidelines,
the state of the art, and our expertise and experience of
many years.
The manufacturer does not accept any liability for dam-
ages resulting from:
Non-compliance with this manual
Incorrect use
Operation or handling by untrained individuals
Unauthorised modifications
Technical changes
Use of non-approved replacement parts
The actual scope of delivery may differ from the infor-
mation in this manual for bespoke constructions, addi-
tional order options or as a result of recent technical
changes.
The obligations agreed in the order, the general terms
and conditions, the manufacturer's terms of delivery,
and the legal regulations in effect at the time the con-
tract is signed shall apply.
We reserve the right to make technical changes.
Defects liability
For details regarding defects liability please refer to
Section VI, Warranty Claims, of the Delivery and Pay-
ment Terms of TROX GmbH.
The Delivery and Payment Terms of TROX GmbH are
available at www.troxtechnik.com.
General information
Smoke control damper Type EK-JZ 3

Safety notes
Symbols are used in this manual to alert readers to
areas of potential hazard. Signal words express the
degree of the hazard.
DANGER!
Imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING!
Potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION!
Potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE!
Potentially hazardous situation which, if not avoided,
may result in property damage.
ENVIRONMENT!
Environmental pollution hazard.
Tips and recommendations
Useful tips and recommendations as well as informa-
tion for efficient and fault-free operation.
Safety notes as part of instructions
Safety notes may refer to individual instructions. In this
case, safety notes will be included in the instructions
and hence facilitate following the instructions. The
above listed signal words will be used.
Example:
1. Untighten the screw.
2.
CAUTION!
Danger of finger entrapment when closing
the lid.
Be careful when closing the lid.
3. Tighten the screw.
Specific safety notes
The following symbols are used in safety notes to alert
you to specific hazards:
Warning signs Type of danger
Warning – danger zone.
General information
Smoke control damper Type EK-JZ4

1 Safety.................................................................. 6
1.1 General safety notes................................... 6
1.2 Correct use.................................................. 6
1.3 Qualified staff............................................... 6
2 Technical data.................................................... 7
2.1 General data................................................ 7
2.2 Dimensions and weight............................... 8
2.3 Open/Close actuators................................ 10
3 Transport and storage..................................... 11
4 Parts and function........................................... 13
5Installation........................................................ 14
5.1 Installation situations................................. 14
5.2 Safety notes on installation....................... 14
5.3 General installation information................. 14
5.3.1 After installation...................................... 15
5.4 Solid walls................................................. 16
5.4.1 Installation in shaft walls......................... 16
5.4.2 Installation in solid walls ........................ 18
5.4.3 Installation on shaft walls....................... 20
5.5 Fire-resistant smoke extract ducts............ 22
5.5.1 Installation on vertical smoke extract
ducts....................................................... 22
5.5.2 Installation on horizontal smoke extract
ducts....................................................... 24
5.5.3 Installation in horizontal smoke extract
ducts....................................................... 26
5.5.4 Installation at the end of horizontal
smoke extract ducts............................... 28
5.6 Suspending the smoke control damper..... 30
5.6.1 General................................................... 30
5.6.2 Fixing to the ceiling slab......................... 30
5.6.3 Suspending the smoke control damper.. 30
6 Connecting the smoke extract duct............... 31
6.1 Smoke extract ducts.................................. 31
6.2 Cover grille................................................ 32
6.3 Inspection access...................................... 32
7 Electrical connection...................................... 33
8 Commissioning/functional test...................... 37
8.1 Commissioning.......................................... 37
8.2 Functional test........................................... 37
9 Maintenance..................................................... 38
10 Decommissioning, removal and disposal..... 40
11 Index................................................................. 41
Table of contents
Smoke control damper Type EK-JZ 5

1 Safety
1.1 General safety notes
Sharp edges, sharp corners and thin sheet metal
parts
CAUTION!
Danger of injury from sharp edges, sharp cor-
ners and thin sheet metal parts!
Sharp edges, sharp corners and thin sheet metal
parts may cause cuts or grazes.
– Be careful when carrying out any work.
– Wear protective gloves, safety shoes and a hard
hat.
Electrical voltage
DANGER!
Danger of electric shock! Do not touch any live com-
ponents! Electrical equipment carries a dangerous
electrical voltage.
– Only skilled qualified electricians are allowed to
work on the electrical system.
– Switch off the power supply before working on
any electrical equipment.
1.2 Correct use
Type EK-JZ smoke control dampers are used in
smoke and heat exhaust systems to remove smoke
and heat. They may be used with the following sys-
tems:
– pressurisation systems
–natural smoke and heat exhaust systems
– heat exhaust systems
Operation of smoke control dampers is allowed only
in compliance with installation regulations and the
technical data in this installation and operating
manual.
Modifying the smoke control damper or using
replacement parts that have not been approved by
TROX is not permitted.
Incorrect use
WARNING!
Danger due to incorrect use!
Incorrect use of the smoke control damper can lead
to dangerous situations.
Never use the smoke control damper:
– in areas with potentially explosive atmospheres
– outdoors without sufficient protection against the
effects of weather
– in atmospheres where chemical reactions,
whether planned or unplanned, may cause
damage to the smoke control damper or lead to
corrosion
1.3 Qualified staff
WARNING!
Danger of injury due to insufficiently qualified
individuals!
Incorrect use may cause considerable injury or
damage to property.
– Only skilled qualified personnel must carry out
work.
The following degrees of qualification are required for
the work described in the operating manual:
Skilled qualified electrician
Skilled qualified electricians are individuals who have
sufficient professional or technical training, knowledge
and actual experience to enable them to work on elec-
trical systems, understand any potential hazards related
to the work under consideration, and recognise and
avoid any risks involved.
Specialist personnel
Specialist personnel are individuals who have sufficient
professional or technical training, knowledge and actual
experience to enable them to carry out their assigned
duties, understand any potential hazards related to the
work under consideration, and recognise and avoid any
risks involved.
Safety
Qualified staff
Smoke control damper Type EK-JZ6

2 Technical data
2.1 General data
Nominal sizes B x H 200 × 430 – 1200 × 2030 mm
Casing length 250 mm
Volume flow rate range up to 24361 l/s
up to 87700 m³/h
Differential pressure range Pressure level 2, -1000...500 Pa
Operating temperature at least -30 °C to 50 °C
Upstream velocity ≤ 10 m/s with the maximum size
>10...15 m/s with smaller sizes, up to 87700 m³/h
Closed blade air leakage EN 1751, Class 4
Casing air leakage EN 1751, Class C
EC conformity EU Construction Products Regulation no. 305/2011
EN 12101-8 – Smoke and heat control systems –
Smoke control dampers
EN 1366-10 – Fire resistance tests for service installa-
tions – Smoke control dampers
EN 1366-2 – Fire resistance tests for service installa-
tions – Part 2: Fire dampers
EN 13501-4 – Fire classification of construction products
and building elements – Fire resistance tests on compo-
nents of smoke control
EN 1751 – Ventilation for buildings – Air terminal
devices
Declaration of performance DoP / EK-JZ / 001
Rating plate
Fig. 1: Smoke control damper rating plate (example)
①CE mark
②Manufacturer's address
③No. of the declaration of performance
④Type
⑤The last two digits of the year in which the CE
marking was affixed
⑥Year of manufacture
⑦Website from which the DoP can be downloaded
⑧Regulated characteristics; the fire resistance class
depends on the application and may vary
⑨Number of the European standard and year of its
publication
⑩Notified body
Technical data
General data
Smoke control damper Type EK-JZ 7

2.2 Dimensions and weight
Fig. 2: EK-JZ
B x H = nominal size = area exposed to the airflow
①Subframe for connection to the duct (steel,
operating side only, optional)
②Keep clear to provide access to the actuator
encasing
ⒶInstallation side
ⒷOperating side
Technical data
Dimensions and weight
Smoke control damper Type EK-JZ8

Dimensions [mm] Number
B H C Blades Handles
200..1200
(50 mm)
430 – 2 1
630 3 1
830 4 1
1030 5 1
1230 6 1
1430 550 7 2
1630 650 8 2
1830 9 2
2030 10 2
Weight [kg]
B
[mm]
H [mm]
430 630 830 1030 1230 1430 1630 1830 2030
200 29 37 46 54 62 71 79 87 95
250 31 39 48 56 65 73 82 91 99
300 32 41 50 59 67 76 85 94 103
350 33 43 53 61 70 79 88 98 107
400 35 44 54 63 73 82 92 101 111
450 36 46 56 66 75 85 95 105 114
500 38 48 58 68 78 88 98 108 118
550 39 50 61 70 81 91 101 112 122
600 41 51 62 73 83 94 105 115 126
650 42 53 64 75 86 97 108 119 130
700 44 55 66 77 89 100 111 122 134
750 45 57 69 80 91 103 114 126 137
800 47 58 70 82 94 106 118 129 141
850 48 60 72 84 97 109 121 133 145
900 49 62 75 87 99 112 124 136 149
950 51 64 77 89 102 115 127 140 153
1000 52 65 78 91 104 117 130 143 156
1050 54 67 80 94 107 120 134 147 160
1100 55 69 83 96 110 123 137 150 164
1150 57 71 85 98 112 126 140 154 168
1200 58 72 87 101 115 129 143 158 172
Technical data
Dimensions and weight
Smoke control damper Type EK-JZ 9

2.3 Open/Close actuators
Open/Close actuator BLE...
Construction 230-12 TR 24-12-ST TR
Supply voltage 230 V AC 50/60 Hz 24 V AC 50/60 Hz /
24 V DC
Power rating Opening and closing 5 W 7.5 W
Hold position < 1 W < 0.5 W
Rating 12 VA, Imax. 2.7 A at 5 ms 9 VA, Imax. 2.7 A at 5 ms
Running time < 30 s (90°)
Limit switch Type of contact 2 changeover contacts
Switching voltage 5 V DC...250 V AC
Switching current 1 mA...3 A
IEC protection class II III
Protection level IP 54
Open/Close actuator BE...
Construction 230-12 TR 24-12-ST TR
Supply voltage 230 V AC 50/60 Hz 24 V AC 50/60 Hz /
24 V DC
Power rating Opening and closing 8 W 12 W
Hold position 0.5 W
Rating 15 VA, Imax. 7.9 A at 5 ms 18 VA, Imax. 8.2 A at 5 ms
Running time < 60 s (90°)
Limit switch Type of contact 2 changeover contacts
Switching voltage 5 V DC…250 V AC
Switching current 1 mA…6 A
IEC protection class II III
Protection level IP 54
Technical data
Open/Close actuators
Smoke control damper Type EK-JZ10

3 Transport and storage
Delivery check
Check delivered items immediately after arrival for
transport damage and completeness. In case of any
damage or an incomplete shipment, contact the ship-
ping company and your supplier immediately.
A complete shipment includes:
Smoke control damper(s)
– Attachments/accessories, if any
Installation and operating manual (one per ship-
ment)
Transport on site
If possible, take the smoke control damper in its trans-
port packaging up to the installation location.
Smaller dampers can be lifted and placed in the installa-
tion opening by two people. Ask someone to give you a
hand.
Dampers which are supplied with U channel sections as
a transport aid have to be moved with suitable lifting
equipment, e.g. a forklift truck.
1. Unpack the damper and place it upright on the
floor. Do not remove the straps yet.
2. Place the U channel sections between the upper-
most blade and the frame.
3. Move the fork carefully underneath the uppermost
blade, then lift it. Put a piece of wood or anything
similar between the blade and the fork so as not to
damage the blade.
Transport and storage
Smoke control damper Type EK-JZ 11

Carefully lift the smoke control damper with the
forklift truck and place it in the installation opening.
4. Once you have installed the smoke control
damper, remove the straps; in case of mortar-
based installation, remove the straps only after the
mortar has cured. Remove the corner protectors.
Dispose of the straps and corner protectors.
Storage
If the unit has to be stored temporarily:
Remove any plastic wrapping.
Protect the unit from dust and contamination.
Store the unit in a dry place and away from direct
sunlight.
Do not expose the unit to the effects of weather (not
even in its packaging).
Do not store the unit below -30 °C or above 50 °C.
Packaging
Properly dispose of packaging material.
Transport and storage
Smoke control damper Type EK-JZ12

4 Parts and function
Smoke control dampers are used in mechanical smoke
extract systems. They are used for extracting smoke
gases and for providing additional supply air to one or
more fire compartments.
Smoke control dampers are made from calcium silicate
boards, and the electric actuator and the optional con-
trol module are encased such that the functional relia-
bility is ensured even in the event of a fire.
Regular maintenance of the smoke control damper is
required to ensure its functional reliability
Ä 9 ‘Mainte-
nance’ on page 38.
Fig. 3: EK-JZ smoke control damper
①Casing
②Blades
③Blade tip seal (special profile seal)
④Side seal
⑤Travel stop, bottom
⑥Rating plate
⑦Actuator
⑧Cover fixing
⑨Linkage
⑩Actuator encasing
⑪Cover of the actuator encasing (sectional view)
⑫Handle (to remove the cover)
⑬Travel stop, top
Smoke extract
Fig. 4: Smoke extract system
①EK-JZ in a solid shaft wall
②EK-JZ in a solid wall
③EK-JZ on a solid shaft wall
④Installation on a vertical smoke extract duct (shaft)
⑤Installation on horizontal smoke extract ducts
⑥Installation in horizontal smoke extract ducts
⑦Installation at the end of horizontal smoke extract
ducts
⑧EK-JZ as additional supply air inlet
⑨Cover grille
During normal operation Type EK-JZ smoke control
dampers remain closed. For smoke extract, the smoke
control dampers in the affected fire compartment fully
open such that smoke can be extracted. All other smoke
control dampers remain closed.
In the event of a fire, smoke control dampers that are
used as additional supply air inlets in the affected fire
compartment also open such that smoke can be
extracted. To ensure the creation of a layer that is nearly
free from smoke, smoke control dampers used as addi-
tional supply air inlets should be installed near the
ground.
The control input signal for the actuator may come from
a duct smoke detector or from the central fire alarm
system. Using cables with specific circuit integrity for the
supply voltage ensures that the actuator is supplied with
voltage even in the event of a fire and hence that its
function and the communication are maintained.
Ventilation
During ventilation operation the smoke control dampers
of the smoke extract system remain fully open. Smoke
control dampers which are used as additional supply air
inlets remain closed during ventilation operation.
Depending on where the dampers are installed, country-
specific regulations may apply to ventilation applica-
tions.
Parts and function
Smoke control damper Type EK-JZ 13

5 Installation
5.1 Installation situations
Installation situations
Supporting construc-
tion
Installation location Minimum
thickness
[mm]
Performance
level
Installa-
tion type
Installa-
tion infor-
mation
Solid walls
Gross density
≥ 500 kg/m³
In solid shaft walls (Fig. 4/1) 100 EI 120 S T (N)
Ä 16
In solid walls (Fig. 4/2) 100 EI 90 S T (N)
Ä 18
On solid shaft walls (Fig. 4/3) 100 EI 120 S T
Ä 20
Fire-resistant smoke
extract ducts
tested to EN 1366-8,
gross density
≥ 520 kg/m³
On vertical smoke extract ducts
(Fig. 4/4)
35 EI 120 S LE
Ä 22
On horizontal smoke extract ducts
(Fig. 4/5)
Ä 24
In horizontal smoke extract ducts
(Fig. 4/6)
Ä 26
At the end of horizontal smoke
extract ducts (Fig. 4/7)
Ä 28
E = Dry mortarless installation
N = Mortar-based installation
LE = As specified for the duct
5.2 Safety notes on installation
Sharp edges, sharp corners and thin sheet metal
parts
CAUTION!
Danger of injury from sharp edges, sharp cor-
ners and thin sheet metal parts!
Sharp edges, sharp corners and thin sheet metal
parts may cause cuts or grazes.
– Be careful when carrying out any work.
– Wear protective gloves, safety shoes and a hard
hat.
5.3 General installation information
NOTICE!
Be careful to not damage the smoke control
damper
– Protect the smoke control damper from contami-
nation and damage.
– Cover the flange openings and the actuator (e.g.
with plastic foil) to protect them from mortar and
dripping water.
Please note:
Smoke control damper and electric actuator must
remain accessible for maintenance.
Make sure that no loads are imposed on the casing
as this may impair the function of the smoke control
damper.
Install the smoke control damper without torsion.
Mortar-based installation: The installation gap must
be large enough such that mortar can be filled in
even in case of thicker walls.
Before installation: Perform a functional test and
close the smoke control damper.
Ä 37
Installation position
The smoke control damper has to be installed such that
the damper blade shaft is horizontal. The actuator
encasing has to remain accessible even after installa-
tion. The actuator encasing has to be on the right side
of the damper.
Installation
General installation information
Smoke control damper Type EK-JZ14

Fig. 5: Horizontal installation
a If you install several smoke control dampers, there
should be a gap of at least 200 mm between them.
Mineral wool as filling material
Unless otherwise stated in the relevant installation
details, mineral wool with a gross density of ≥ 80 kg/m³
and a melting point of 1000 °C must be used.
Fig. 6: Installation gap
①Wall
②Mineral wool
③Ablative coating
④EK-JZ
For a smooth look you can apply ablative coating of one
of the following types to the mineral wool in the installa-
tion gap:
Hilti:
– Ablative coating CFS-CT
Hensel:
– Ablative coating HENSOMASTIK 5 KS Farbe
Promat:
–Ablative coating Promastopp-CC
Mortars for mortar-based installation
In case of mortar-based installation, the open spaces
between the fire damper casing and the wall or ceiling
slab must be closed off with mortar. Entrapped air is to
be avoided. The mortar bed depth should be equal to
the thickness of the wall but must be at least 100 mm.
The following mortars are acceptable:
DIN 1053: Groups II, IIa, III, IIIa; fire protection
mortar of groups II, III
EN 998-2: Classes M 2.5 to M 10 or fire protection
mortar of classes M 2.5 to M 10
Equivalent mortars that meet the requirements of
the above standards, gypsum mortar or concrete
Ceramic fibre paper
≥100
①
Fig. 7: Ceramic fibre paper, applying
Glue one strip or two parallel strips of ceramic fibre
paper (Fig. 7/1) to the underside of the damper frame
such that the edges of the paper are flush with the
edges of the damper frame. Do not glue the ceramic
fibre paper onto the trim panels.
Ceramic fibre paper is available as an accessory
(optional); alternatively, it can be provided by others.
The paper has to meet the following requirements:
Kerafix 2000 premium or equivalent
Self-adhesive
Thickness: 3 to 10 mm
Width: ≥ 40 mm
5.3.1 After installation
Remove the straps (in case of mortar-based installa-
tion, do this only after the mortar has cured)
Check that the diagonal length of the damper is cor-
rect.
Clean the smoke control damper.
Test the function of the smoke control damper.
Connect the smoke extract duct.
Make electrical connections.
Installation
General installation information > After installation
Smoke control damper Type EK-JZ 15

5.4 Solid walls
5.4.1 Installation in shaft walls


  
b
h
W
250
W
W
③
B + 280
b
H + 80
s2
s1
s1
① ② ④
h
③
⑤
⑤
⑦
③
Ⓐ
Ⓑ
Ⓐ
Ⓑ
②
A
A-A
A
A-A
⑥
⑥
⑥
s2: 20 – 100
s1: 20 – 40
90°
②
⑥
Fig. 8: Installation in a solid shaft wall
①EK-JZ
②Mineral wool
③Solid shaft wall
④Cover grille (only if the damper is not connected to
a duct)
⑤Ceramic fibre paper
⑥Screw connection (suitable for the type of wall;
screws to be provided by others)
⑦Mortar
ⒶInstallation side
ⒷOperating side
h × b Installation opening
s1Mineral wool: 20 – 40 mm
s2Mineral wool: 20 – 40 mm; mortar: 20 – 100 mm
W Wall thickness ≥ 100 mm
Personnel:
Installation
Solid walls > Installation in shaft walls
Smoke control damper Type EK-JZ16

Specialist personnel
Materials:
Mineral wool
Ä ‘Mineral wool as filling material’ on page 15
Ceramic fibre paper
Ä ‘Ceramic fibre paper’ on page 15
Mortar
Ä ‘Mortars for mortar-based installation’ on page 15
Fire-resistant screws (with suitability certificate)
Requirements:
Solid walls made of, for example, concrete, aerated concrete or masonry, gross density ≥ 500 kg/m³ and
W ≥ 100 mm
≥ 40 mm distance to load-bearing structural elements
≥ 200 mm distance between two smoke control dampers
Installation
1. Create an installation opening according to Fig. 8. The installation opening has to be rectangular, with smooth
surfaces (± 5 mm).
If the surfaces are not smooth, use mortar to make them smooth.
Place mineral wool along the left side (vertical), approx. 20 to 40 mm thick.
2. Glue one strip or two parallel strips of ceramic fibre paper (Fig. 8/5) to the underside of the damper frame such
that the edges of paper are flush with the edges of the damper frame,
Ä 15.
3. Place the smoke control damper with the ceramic fibre paper in the installation opening and press it towards
the mineral wool on the left. Make sure that the damper is vertical; use wedges to hold the damper in the cor-
rect position; the damper has to be installed without torsion (check the diagonal length; allowed tolerance:
2 mm).
Install the damper such that the operating side is flush with the wall (A-A section).
4. Fill the installation gap on the right with mineral wool. If the gap is wider than 40 mm, it has to be filled with
mortar. Fill the gap with mortar, ideally until it is as thick as the wall, but at least 100 mm.
Fill the installation gap at the top with mineral wool. Note: Do not use mortar for the gap at the top.
Do not leave any gaps or spaces between the damper and the wall. If you have used any objects to facilitate
damper installation, e.g. wedges, remove them now. Fill any remaining hollow spaces with mineral wool or
mortar.
5.
CAUTION!
Malfunction of the smoke control damper
Use only the fixing points marked on the damper frame (drilled hole, indentations) to screw fix the smoke
control damper. Do not use any screws anywhere else on the damper frame as they may prevent the
blades from closing properly. Fixing points on the H section only from H ≥ 1230 mm.
Drill screw holes at the fixing points marked on the damper frame (Fig. 8/6), then screw fix the damper to the
wall. Be careful when you tighten the screws; do not exercise any tension as this may damage the damper.
Installation
Solid walls > Installation in shaft walls
Smoke control damper Type EK-JZ 17

5.4.2 Installation in solid walls


   - 
W
250
W
W
b
h
③
B + 280
b
H + 80
s2
s1
s1
②
②① ④
h
③
⑤
⑥
⑤
⑦
③
Ⓐ
Ⓑ
Ⓐ
Ⓑ
②
②A
A-A
A
A-A
⑥
⑥⑧
④⑥
s2: 20 – 100
s2: 20 – 40
90°
Fig. 9: Installation in a solid shaft wall
①EK-JZ
②Mineral wool
③Solid wall
④Cover grille (only if the damper is not connected to
a duct)
⑤Ceramic fibre paper
⑥Screw connection (suitable for the type of wall;
screws to be provided by others)
⑦Mortar
⑧Calcium silicate smoke extract duct
ⒶInstallation side
ⒷOperating side
h × b Installation opening
s1Mineral wool: 20 – 40 mm
s2Mineral wool: 20 – 40 mm; mortar: 20 – 100 mm
W Wall thickness ≥ 100 mm
Personnel:
Specialist personnel
Installation
Solid walls > Installation in solid walls
Smoke control damper Type EK-JZ18

Materials:
Mineral wool
Ä ‘Mineral wool as filling material’ on page 15
Ceramic fibre paper
Ä ‘Ceramic fibre paper’ on page 15
Mortar
Ä ‘Mortars for mortar-based installation’ on page 15
Fire-resistant screws (with suitability certificate)
Requirements:
Solid walls made of, for example, concrete, aerated concrete or masonry, gross density ≥ 500 kg/m³ and
W ≥ 100 mm
≥ 40 mm distance to load-bearing structural elements
≥ 200 mm distance between two smoke control dampers
Installation
1. Create an installation opening according to Fig. 9. The installation opening has to be rectangular, with smooth
surfaces (± 5 mm).
If the surfaces are not smooth, use mortar to make them smooth.
Place mineral wool along the left side (vertical), approx. 20 to 40 mm thick.
2. Glue one strip or two parallel strips of ceramic fibre paper (Fig. 8/5) to the underside of the damper frame such
that the edges of paper are flush with the edges of the damper frame,
Ä 15.
3. Place the smoke control damper with the ceramic fibre paper in the installation opening and press it towards
the mineral wool on the left. Make sure that the damper is vertical; use wedges to hold the damper in the cor-
rect position; the damper has to be installed without torsion (check the diagonal length; allowed tolerance:
2 mm).
Install the damper such that the operating side is flush with the wall (A-A section).
4. Fill the installation gap on the right with mineral wool. If the gap is wider than 40 mm, it has to be filled with
mortar. Fill the gap with mortar, ideally until it is as thick as the wall, but at least 100 mm.
Fill the installation gap at the top with mineral wool. Note: Do not use mortar for the gap at the top.
Do not leave any gaps or spaces between the damper and the wall. If you have used any objects to facilitate
damper installation, e.g. wedges, remove them now. Fill any remaining hollow spaces with mineral wool or
mortar.
5.
CAUTION!
Malfunction of the smoke control damper
Use only the fixing points marked on the damper frame (drilled hole, indentations) (Fig. 9/6) to screw fix the
smoke control damper. Do not use any screws anywhere else on the damper frame as they may prevent
the blades from closing properly. Fixing points on the H section only from H ≥ 1230 mm.
Drill screw holes at the fixing points marked on the frame (Fig. 9/6), then screw fix the frame to the wall. Be
careful when you tighten the screws; do not exercise any tension as this may damage the damper.
6. Connect a smoke extract duct made of calcium silicate to the installation side of the damper (Fig. 9/8),
Ä 6 ‘Connecting the smoke extract duct’ on page 31.
Connect a smoke extract duct made of calcium silicate or sheet steel to the operating side of the damper
Ä 6 ‘Connecting the smoke extract duct’ on page 31. If the operating side is not connected to a duct, a cover
grille is required
Ä 6.2 ‘Cover grille’ on page 32.
Installation
Solid walls > Installation in solid walls
Smoke control damper Type EK-JZ 19

5.4.3 Installation on shaft walls
60
35 25240 95
250
W
95
≥ 125
b x h
h
b
A-A
A
B
B
③
①⑥ ② ③
②
⑤
③
⑦ ⑧
⑨
④
②
B-B
Ⓑ
Ⓐ
Fig. 10: Installation on a solid shaft wall
①EK-JZ
②Angle section made from strips of fire-rated PRO-
MATECT®-LS board d = 35 mm or equivalent
③Solid shaft wall
④Dry wall screw 4 × 70 mm (by others)
⑤Screw connection with approved anchors
∅ ≤ 6 mm (by others); ≤ 200 mm distance between
screws
⑥Cover grille (only if the damper is not connected to
a duct)
⑦Installation with a suitable load-bearing support,
e.g. a mounting system or a block of stone of the
same width as the damper
⑧Installation onto the concrete floor, onto a con-
crete plinth or onto the fully bricked up space
underneath the damper
⑨Ceramic fibre paper strip
ⒶInstallation side
ⒷOperating side
h × b Installation opening = B x H
W Wall thickness ≥ 100 mm
Installation
Solid walls > Installation on shaft walls
Smoke control damper Type EK-JZ20
