Edwards Signature Series Assembly instructions

P/N 3102362-EN • REV 01 • ISS 06APR16 1 of 2
SIGA-PD Intelligent
Photoelectric Smoke Detector
Installation Sheet
Description
The Signature Series model SIGA-PD Intelligent Photoelectric Smoke
Detector is an intelligent device that uses an optical sensing chamber
to detect smoke. The detector analyzes data from the sensing
chamber to determine whether to initiate an alarm.
LED indicator. The LED indicator (see Figure 1 below) displays the
following states:
• Normal: Green LED indicator flashes, no action.
• Alarm/active: Red LED indicator flashes, evacuate the area.
Figure 1: SIGA-PD features
2
(1) Self-locking tab
(2) LED indicator
Installation
Notes
• This detector does not operate without electrical power. As fires
frequently cause power interruption, discuss further safeguards
with the local fire protection specialist.
• This detector does not sense fires in areas where smoke cannot
reach the detector. Smoke from fires in walls, roofs, or on the
opposite side of closed doors may not reach the detector.
• Photoelectric detectors have a wide range of fire-sensing
capabilities and are best suited for detecting slow, smoldering fires.
• To ensure proper operation, store the detector within the
recommended ranges. Allow the detector to stabilize to room
temperature before applying power.
• The dust cover (supplied) must remain on the detector during
installation and be removed prior to commissioning and service.
The dust cover is not a substitute for removing the detector during
new construction or heavy remodeling.
• Do not use smoke detectors with detector guards unless the
combination has been evaluated and found suitable.
• In Canada, install according to CAN/ULC-S524 Standard for the
Installation of Fire Alarm Systems, CSA C22.1 Canadian Electrical
Code, and the local authority having jurisdiction.
• Upon completion of the original installation and following any
modifications or additions to the system, perform a calibrated
sensitivity test per NFPA code. The Signature Series devices can
perform this test and the panel can generate a system sensitivity
report.
To install the detector:
1. Install and wire the base, as described on the installation sheet
supplied with the base.
2. Remove the serial number label from the detector and attach it to
the project documentation.
3. Attach the detector to the base by rotating the detector clockwise
until it snaps into the locked position.
Testing
Before testing, notify the proper authorities that the fire alarm system is
undergoing maintenance and will be temporarily out of service.
To perform an initial installation test:
1. Remove the detector from its base and verify that the proper
detector address, trouble signals, and messages are reported.
2. For SIGA-PD detectors placed in the air ducts, verify that the
airflow is within specifications. See “Specifications” on page 2.
3. If wired for Class A operation, verify that the detector continues to
operate first with SLC_IN disconnected, and then with SLC_OUT
disconnected. (Refer to the installation sheet for the base.)
4. Place a momentary ground fault on the SLC circuit to verify
operation of ground fault detection circuitry.
5. Run a system detector sensitivity report on all detectors and verify
that the readings fall within acceptable limits.
6. Perform a sensor function test, as described below.
To perform a sensor function test:
1. If desired, use the fire alarm control panel to put the detector or
zone into a service group for testing. (Refer to the panel technical
reference manual for instructions.)

2 / 2 P/N 3102362-EN • REV 01 • ISS 06APR16
2. Activate the smoke sensor using No Climb Products model Smoke
Centurion/M8, FireTech Smoke or Smoke Sabre smoke aerosol
spray, a smoke generator, or the Testifire detector tester per the
manufacturer’s instructions.
Maintenance
To ensure proper operation, plan maintenance (regular or selected) of
the detector in accordance with the AHJ and all applicable governing
laws, codes, or standards. Refer to CAN/ULC-S536 Standard for the
Inspection and Testing of Fire Alarm Systems and NFPA 72 National
Fire Alarm and Signaling Code.
Refer to application bulletin P/N 3102403-EN for additional information
and cleaning instructions.
Specifications
Operating voltage 15.20 to 19.95 VDC
Current
Normal operating
Alarm
32 µA
32 µA
Vibration level 10 to 35 Hz, with an amplitude of
0.01 in.
A
ir velocit
y
[1] 0 to 4,000 ft./min (0 to 20.32 m/s)
Wall mounting: distance from
ceiling
12 in. (305 mm) max.
Compatible bases
Standard
Relay
Isolator
Audible
SIGA-SB, SIGA-SB4
SIGA-RB, SIGA-RB4
SIGA-IB, SIGA-IB4
SIGA-AB4G, SIGA-AB4GT
SIGA-AB4G-LF
Compatible detector testers Testifire 1000, Testifire 2000
Operating environment
Temperature
Relative humidity
32 to 120°F (0 to 49°C)
0 to 93% noncondensing
Storage temperature −4 to 140°F (−20 to 60°C)
Environmental compensation Automatic
[1] For duct installation, use a SIGA-DMP duct detector mounting plate
and install per P/N 387053P-EN.
Regulatory Information
North American
standards
CAN/ULC-S529, UL 268, UL 268A
UL/ULC smoke
sensitivity range
0.53 to 3.94 %/ft. (1.7 to 12.35 %/m) obscuration
FCC compliance This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Industry Canada
compliance
This Class A digital apparatus complies with
Canadian ICES-003.
Contact information
For contact information, see www.edwardsfiresafety.com
© 2016 Walter Kidde Portable Equipment, Inc.
All rights reserved.
