Installing the Flex Tube
1. Place a hose clamp
over the end of the Flex
Tube (A).
2. Slide the end of the
Flex Tube with the clamp
on it over the elbow tube
(B).
3. Align the bump on the
Flex Tube with the bump
on the elbow tube.
4. Tighten the screw on
the hose clamp to secure
the Flex Tube to the
elbow tube.
Installing the Upper
Blower Tube
1. Place a hose clamp over
the other end of the Flex
Tube (C).
2. Slide the en
d
o
f th
e
h
ose
d of the hose
with the clamp on it over the
top end of the upper blower
tube (D).
3. Align the bump on the
Flex Tube with the bump on
the upper blower tube.
4. Tighten the screw on
the hose clamp to
secure the Flex
Tube to the
upper blower
tube.
Installing the Blower Tubes
and Nozzle
1. Align the bump slot on the
top end of each tube with the
bump on the bottom end of
the blower tube above it (A).
2. Insert each bump into each
bump slot (B).
3. Twist the tubes as shown until
the bumps lock into
place (C).
IMPORTANT: READ THE OPERATOR’S MANUAL THOROUGHLY AND FOLLOW
THE SAFE OPERATION PRACTICES WHILE OPERATING THE UNIT Lea la traducción en Español en el manual.
Read and understand all instruction, warning and danger labels on the unit.
FLIP OVER FOR
Fast Start Guide
Tilt the unit backwards 30°. Remove
the oil plug from the back of the
engine and pour the entire bottle
of 4-cycle oil into the fill hole.
NOTE: Do not mix gas and oil.
3
1
2
Remove the fuel cap. Place the gas
container’s spout into the fill hole in
the fuel tank. Do not overfill.
4
B
C
C
A
D
C
B
B
A
A
30°
778-12449 P00
ASSEMBLY TOOLS REQUIRED:
• T-20 Torx® Screwdriver
• Flat-head Screwdriver

Read and understand all instruction, warning and danger labels on this unit.
778-12449 P00
Starting
Position
3
1
Primer
Bulb
On/Off
Switch
Crouch in the starting position.
Pull the rope 5times.
4Move the choke lever to Position 2.
Pull the rope 3-5 times to start.
Squeeze the trigger for 30-60
seconds to warm up.
6TO STOP ENGINE:
Release the
throttle and press
and hold the
On/Off Control to Off.
Need Help?
Call 1-800-828-5500
Press the
primer bulb
until it fills
with fuel
(10 times).
2123
123
5Move the choke lever to Position 3.
Continue warming for an additional
60 seconds. The unit may be used
during this time.
123
Move the choke lever to Position 1.
Do not squeeze the trigger until step 4.
