Troy-Bilt 12AG836E711 Guide

IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .
Read and understand all instruction, warning and danger labels.
Lea el manual de operación anexo sobre ensamblaje e inicio.
Need Help? Call 1-888-TO-HELP-U (1-888-864-3578)
Secure cable to lower handle with
cable tie provided with unit.
Lift handle to extended position.
Tighten star knobs.
Hold blade control handle against upper handle.
Slowly slip starter rope into rope guide.
Tighten rope guide wing knob.
778-11133© 2006 12AG836E711
1
2
1
3
4
2
Recoil Starter
Blade Control
Star Knobs
3
4
Insert carriage bolts and tighten with star knobs.
1
2

IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .
Read and understand all instruction, warning and danger labels.
Lea el manual de operación anexo sobre ensamblaje e inicio.
Push primer five times.
Fill tank with gas to within 1/2 inch of top of tank. Depress blade control handle and hold.
Fill engine with entire contents of oil
bottle supplied with your mower.
Pull starter rope with quick, full arm stroke.
If engine does not start after five pulls,
repeat steps seven thru nine.
Call 1-888-TO-HELP-U
Need Help?
(1-888-864-3578)
Gas Cap
Oil Fill
Primer
5
6
7
8
9
Electric start battery must be charged for 8-12 hours
before initial use. See Operator Manual maintenance
section.
NOTE: If wanting to use the grass catcher, first remove the
mulching baffle. See Setup Section in Operator’s Manual.
