Troy-Bilt 21C-64M1 Guide

IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING.
Read and understand all instruction, warning, and danger labels.
Lea el manual de operación anexo sobre ensamblaje e inicio.
Need Help? Call 1-888-TO-HELP-U (1-888-864-3578)
1
2
Forward
Clutch Cable
Lower Handle
Forward
Clutch Bail
Upper Handle
3
4
21C-64M1 ©2008 778-11729
Loosely attach
lower handle to
frame using the
5/16-18 x .75
hex head cap
screws and
5/16-18 ange
lock nuts. Do
not tighten
hardware.
Attach upper
handle and handle
support brackets
to lower handle
using the 5/16-18
x 1.50 screws and
5/16-18 ange lock
nuts. Tighten all
hardware in Step 1
and Step 2.
Insert the
Z-tting into
the hole in the
Forward Clutch
Bail.
Handle Support
Brackets
Snap cable connector into
bottom hole in cable bracket.

IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING.
Read and understand all instruction, warning, and danger labels.
Lea el manual de operación anexo sobre ensamblaje e inicio.
Gas
Oil
Throttle
Choke
Move choke control to
full choke position.
Move throttle control
to rabbit (fast)
position.
Fill engine with entire contents of oil bottle supplied.
Do not overll.
Pull starter rope
with quick, full arm
stroke. It may take
more than one pull
to start cold engine.
Once started,
slowly move choke
control to off (run)
position.
Call 1-888-TO-HELP-U
Need Help?
(1-888-864-3578)
Starter Rope
5
6
7
8
Fill tank with gas until fuel reaches the fuel level
indicator. Do not overll.
