True Manufacturing Company TR1RRI-1S User manual

............ www.truemfg.com ............
TABLE OF CONTENTS
Safety Information
Safety Precautions__________________________ 1
Proper Disposal ____________________________ 2
Connecting Electricity________________________ 3
Adapter Plugs _____________________________ 3
Installation / Operation Instructions
Ownership________________________________ 4
Required Tools ____________________________ 4
Uncrating ________________________________ 4
Equipment Installation ______________________5-6
Wire Size Chart ____________________________ 7
Locating & Installation of Leg/Castors ____________ 8
Leveling & Sealing Cabinet To Floor _____________ 9
Ramp Installation (Roll-In Cabinets) ____________ 10
Electrical Instructions_______________________ 11
Start-up ________________________________ 11
Digital Temperature Display __________________ 11
Temperature Control Adjustment ______________ 12
Shelving/Pilaster Installation - Operation _______ 13-17
Defrost Time Clock Operation (Grasslin) _________ 18
Maintenance, Care & Cleaning
Cleaning Condenser Coil __________________ 19-20
Stainless Steel Equipment Care & Cleaning _______ 21-22
Light Bulb Replacement _____________________ 22
Warranty (U.S.A. & Canada Only!) ______________ 23
CONGRATULATIONS!
You have just purchased the finest commercial
freezer, refrigerator, and heated cabinet available.
You can expect many years of trouble-free operation.
INSTALLATION MANUAL FOR TR, TA, & TG MODELS
TRUE FOOD SERVICE EQUIPMENT, INC.
2001 East Terra Lane • O’Fallon, Missouri 63366-4434
(636)-240-2400 • FAX [phone] • INT’L FAX [phone] • [phone]
Parts Department (800)424-TRUE • Parts Department FAX# [phone]
TR1RRI-1S
TR2R-2G
TR2RRT-2S-2S
*Spanish & Dutch version included.
#897014
TR, TA, & TG Models
(Spec Series®)
®
Spec Series® is a trademark of True Manufacturing Company.

............ www.truemfg.com ............
True Food Service Equipment, Inc.

11
• Thisrefrigeratormustbeproperlyinstalledandlocat-
edinaccordancewiththeInstallationInstructions
beforeitisused.
• Donotallowchildrentoclimb,standorhangonthe
shelvesintherefrigerator.Theycoulddamagethe
refrigeratorandseriouslyinjurethemselves.
• Donottouchthecoldsurfacesinthefreezercom-
partmentwhenhandsaredamporwet.Skinmay
sticktotheseextremelycoldsurfaces.
• Donotstoreorusegasolineorotherflammable
vaporsandliquidsinthevicinityofthisoranyother
appliance.
• Keepfingersoutofthe“pinchpoint”areas;clear-
ancesbetweenthedoorsandbetweenthedoorsand
cabinetarenecessarilysmall;becarefulclosingdoors
whenchildrenareinthearea.
NOTE
We strongly recommend that any servicing
be performed by a qualified individual.
• Unplugtherefrigeratorbeforecleaning
andmakingrepairs.
• Settingtemperaturecontrolstothe0positiondoes
notremovepowertothelightcircuit,perimeterheat-
ers,orevaporatorfans.
WARNING!
Use this appliance for its intended purpose as described in this Owner Manual.
This cabinet contains fluorinated greenhouse gas covered by the Kyoto Protocol
(please refer to cabinet’s inner label for type and volume,
GWP of 134a= 1,300. R404a= 3,800).
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
How to Maintain Your Unit
to Receive the Most Efficient and
Successful Operation
You have selected one of the finest commercial refrigeration units made. It is manufactured
under strict quality controls with only the best quality materials available. Your TRUE unit
when properly maintained will give you many years of trouble-free service.
............ www.truemfg.com ............
SAFETY INFORMATION
True Food Service Equipment, Inc.

............ www.truemfg.com ............
True Food Service Equipment, Inc.
SAFETY INFORMATION
PROPER DISPOSAL OF THE REFRIGERATOR
DANGER!
RISK OF CHILD ENTRAPMENT
USE OF EXTENSION CORDS
NEVER USE AN EXTENSION CORD! TRUE will not warranty any equipment that has been connected to an extension cord.
Childentrapmentandsuffocationarenotproblemsof
thepast.Junkedorabandonedrefrigeratorsarestilldanger-
ous…eveniftheywillsitfor“justafewdays.”Ifyouare
gettingridofyouroldrefrigerator,pleasefollowthe
instructionsbelowtohelppreventaccidents.
Before You Throw Away Your Old Refrigerator or Freezer:
• Takeoffthedoors.
• Leavetheshelvesinplacesothatchildrenmaynot
easilyclimbinside.
Refrigerant Disposal
Youroldrefrigeratormayhaveacoolingsystem
thatuses“OzoneDepleting”chemicals.Ifyouare
throwingawayyouroldrefrigerator,makesurethe
refrigerantisremovedforproperdisposalbya
qualifiedservicetechnician.Ifyouintentionally
releaseanyrefrigerantsyoucanbesubjectto
finesandimprisonmentunderprovisionsofthe
environmentalregulations.
22

33
Thepowercordofthisapplianceisequipped
withagroundingplugwhichmates
withastandardgroundingwalloutlet
tominimizethepossibilityofelectricshock
hazardfromthisappliance.
Havethewalloutletandcircuitcheckedby
aqualifiedelectriciantomakesuretheoutlet
isproperlygrounded.
Iftheoutletisastandard2-prongoutlet,itisyourpersonal
responsibilityandobligationtohaveitreplacedwiththe
properlygroundedwalloutlet.
Therefrigeratorshouldalwaysbepluggedinto
itsownindividualelectricalcircuit,whichhas
avoltageratingthatmatchestheratingplate.
Thisprovidesthebestperformanceandalsoprevents
overloadingbuildingwiringcircuitswhichcouldcausea
firehazardfromoverheatedwires.
Neverunplugyourrefrigeratorbypullingonthepower
cord.Alwaysgripplugfirmlyandpullstraightoutfrom
theoutlet.
Repairorreplaceimmediatelyallpowercordsthathave
becomefrayedorotherwisedamaged.Donotuseacord
thatshowscracksorabrasiondamagealongitslengthor
ateitherend.
Whenremovingtherefrigeratorawayfromthewall,be
carefulnottorolloverordamagethepowercord.
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the ground prong from the power cord. For personal safety, this appliance
must be properly grounded.
WARNING!
USE OF ADAPTER PLUGS
NEVER USE AN ADAPTER PLUG! TRUE will not warranty any equipment that has been connected to an adapter plug.
............ www.truemfg.com ............
SAFETY INFORMATION
True Food Service Equipment, Inc.
NorthAmericaUseOnly!
NEMAplugs
TRUEusesthesetypesofplugs.If
youdonothavetherightoutlethave
acertifiedelectricianinstallthecorrect
powersource.

............ www.truemfg.com ............
True Food Service Equipment, Inc.
INSTALLATION / OPERATION INSTRUCTIONS
Toensurethatyourunitworksproperlyfromthefirst
day,itmustbeinstalledproperly.Wehighlyrecommend
atrainedrefrigerationmechanicandelectricianinstall
yourTRUEequipment.Thecostofaprofessional
installationismoneywellspent.
BeforeyoustarttoinstallyourTRUEunit,carefully
inspectitforfreightdamage.Ifdamageisdiscovered,
immediatelyfileaclaimwiththedeliveryfreightcarrier.
TRUE is not responsible for damage incurred during
shipment.
OWNERSHIP
• AdjustableWrench
• PhillipsHeadScrewdriver
• Level
REQUIRED TOOLS
Thefollowingprocedureisrecommendedforuncrating
theunit:
A. Removetheouterpackaging,(cardboardandbubblesor
styrofoamcornersandclearplastic).Inspectforcon-
cealeddamage.Again,immediatelyfileaclaimwith
thefreightcarrierifthereisdamage.
B. Moveyourunitasclosetothefinallocationaspossi-
blebeforeremovingthewoodenskid.
C. Removedoorbracketonglassdoormodels.Donot
throwthisbracketaway.Forfuturecabinetmove-
mentthisbracketwillneedtobeinstalledsoglass
doordoesnotreceiveanydamage.(Seeimagefor
bracketremoval.)
NOTE
Keys for coolers with door locks are located
in warranty packets.
UNCRATING
INSTALLATION / OPERATION INSTRUCTIONS
REMOTE UNITS (This section applies to remotes only!)
• Remotecabinetsmustbeorderedasremote. 
 Wedonotrecommendconvertingforastandard
 selfcontainedtoremotesystem.
• Allremotecabinetsmustbehardwired.
• Nocastorsavailable.
• Allremotecabinetscomestandardusing
 404Arefrigerant.
• Allremoteunitscomestandardwithexpansion 
 valve,liquidlinesolenoid,heatedcondensatepan,
 anddefrosttimerwhenapplicable.
• ContactTRUETechnicalServicefor
 BTUrequirements.
• Nowiringnecessarybetweencabinetand 
 condensingunit.
• Allremotecondensingunitspurchasedfrom 
 TRUEare208/230voltssinglephase.
If you have any questions regarding this section, please
call TRUE at 1-(800)-325-6152.
44

............ www.truemfg.com ............
True Food Service Equipment, Inc.
55
INSTALLATION / OPERATION INSTRUCTIONS
TOOLS REQUIRED:
A. Gloves
B. Utility Knife
C. Phillips Screw Driver or Cordless
Drill with Phillips Bit
D. ¾” Socket
E. (2) Four Wheel Dolly
NOTE: Remove all the packing
material from the cabinet. Be sure
to save all the packing material to
use when tipping the cabinet on its
side.
STEP 1
Locate the wire harness coming out
of the back of the digital display/
energy saving switch and remove the
male molex plug from the control box
located on the right hand side of the
condensing unit. (See image 1).
STEP 2
Open the doors, locate and remove the
Phillips screws on the underside of the
rain shield. (See images 2-3)
STEP 3
Locate and remove the screws on top
of the rain shield. You can now remove
the rain shield. Be sure to lay it down
on a flat surface to prevent the rain
shield from falling over and being
damaged. (See image 4)
STEP 4
Remove both doors. To do this, open
the door 90º and lift up on the door.
Be sure to place the door upright on
a secure surface to prevent the doors
from falling over and being damaged.
(See image 5).
STEP 5
Place a piece of packing material on
the left side of the cabinet. If you’re
using a four wheel dolly place this on
the left side of the cabinet. Be sure
that the dolly is padded. If not, place
several pieces of cardboard on it to
protect the dolly from scratching the
left side of the cabinet. (See image 6)
NOTE: Depending on the size of
your dolly you might need to use
more than one.
Image 1
Image 3
Image 2
Image 4
Image 5
Image 6
INSTALLATION THROUGH 34 INCH DOOR OPENINGS

............ www.truemfg.com ............
True Food Service Equipment, Inc.
66
INSTALLATION / OPERATION INSTRUCTIONS
STEP 6
Using at least two people, tilt the
top left side of the cabinet while it’s
still on the skid. Start by having one
person on each side of the cabinet and
lower the left side down so that the
person on the left side can support the
weight momentarily by himself until
the person from the other side can join
in lowering the cabinet as shown in
images 8-9.
STEP 7
Remove the skid from the bottom of
the cabinet. (See image 10).
STEP 8
You can now move the cabinet into the
location where the cabinet is to go.
STEP 9
Once the cabinet is in place, stand the
cabinet upright and level the cabinet.
STEP 10
Place the ramps on the front of the
cabinet. At this point it may be
necessary to seal the cabinet to the
floor per local codes. (See images
11-12)
STEP 11
Once the cabinet is in its final location
and level, the roll-in ramp can be
installed. The ramp has three slotted
holes in back. These slotted holes
slide over three thumb screws located
in the front of the cabinet near the
floor (See Image 11).
STEP 12
Reinstall the doors and be sure
they are closing smoothly and not
binding up on the ramp. To adjust
door sweeper gasket, loosen slotted
thumbscrews. The gasket can then be
moved up or down and side to side. The
gasket should make some contact with
the ramp when the door is closing.
This can be checked by opening up
the door 3-4” and allowing the door
to close. This process may have to be
done several times before securing the
sweeper gasket bracket. Once gasket
is properly adjusted, tighten slotted
thumbscrews. (See image 13).
STEP 13
Reinstall the rain shield. Be sure to
reconnect the wire harness from the
display/energy saving switch back in
the female molex connector.
BEFORE PLUGGING THE CABINET
IN BE SURE THAT THE CABINET
HAS BEEN UPRIGHT FOR AT
LEAST DOUBLE THE AMOUNT OF
TIME THAT IT WAS ON ITS SIDE.
EXAMPLE: IF THE CABINET WAS
ON ITS SIDE FOR 1 HOUR DO NOT
PLUG THE CABINET IN FOR 2
HOURS. SHOULD THE CABINET
BE ON ITS SIDE FOR MORE THAN
4 HOURS, PLEASE ALLOW THE
CABINET TO REMAIN UPRIGHT
FOR AT LEAST 24 HOURS. THIS
IS TO ENSURE THAT ANY OIL
THAT MIGHT HAVE MIGRATED
OUT OF THE COMPRESSOR HAS A
CHANCE TO MIGRATE BACK TO THE
COMPRESSOR.
CAUTION: FAILURE TO DO THIS
COULD RESULT IN PREMATURE
COMPRESSOR FAILURE
Image 8
Image 9
Image 11
Image 10
Image 12
Image 13
INSTALLATION THROUGH 34 INCH DOOR OPENINGS
... CONTINUED ...

77
............ www.truemfg.com ............
True Food Service Equipment, Inc.
INSTALLATION / OPERATION INSTRUCTIONS
CONDUCTORS AND CIRCUITS
Wire Gauge for 2% Voltage Drop in Supply Circuits.
115 Volt Distance In Feet To Center of Load
Amps 20 30 40 50 60 70 80 90 100 120 140 160
2 14 14 14 14 14 14 14 14 14 14 14 14
3 14 14 14 14 14 14 14 14 14 14 14 12
4 14 14 14 14 14 14 14 14 14 12 12 12
5 14 14 14 14 14 14 14 12 12 12 10 10
6 14 14 14 14 14 14 12 12 12 10 10 10
7 14 14 14 14 14 12 12 12 10 10 10 8
8 14 14 14 14 12 12 12 10 10 10 8 8
9 14 14 14 12 12 12 10 10 10 8 8 8
10 14 14 14 12 12 10 10 10 10 8 8 8
12 14 14 12 12 10 10 10 8 8 8 8 6
14 14 14 12 10 10 10 8 8 8 6 6 6
16 14 12 12 10 10 8 8 8 8 6 6 6
18 14 12 10 10 8 8 8 8 8 8 8 5
20 14 12 10 10 8 8 8 6 6 6 5 5
25 12 10 10 8 8 6 6 6 6 5 4 4
30 12 10 8 8 6 6 6 6 5 4 4 3
35 10 10 8 6 6 6 5 5 4 4 3 2
40 10 8 8 6 6 5 5 4 4 3 2 2
45 10 8 6 6 6 5 4 4 3 3 2 1
50 10 8 6 6 5 4 4 3 3 2 1 1
Wire Gauge for 2% Voltage Drop in Supply Circuits.
230 Volt Distance In Feet To Center of Load
Amps 20 30 40 50 60 70 80 90 100 120 140 160
5 14 14 14 14 14 14 14 14 14 14 14 14
6 14 14 14 14 14 14 14 14 14 14 14 12
7 14 14 14 14 14 14 14 14 14 14 12 12
8 14 14 14 14 14 14 14 14 14 12 12 12
9 14 14 14 14 14 14 14 14 12 12 12 10
10 14 14 14 14 14 14 14 12 12 12 10 10
12 14 14 14 14 14 14 12 12 12 10 10 10
14 14 14 14 14 14 12 12 12 10 10 10 8
16 14 14 14 14 12 12 12 10 10 10 8 8
18 14 14 14 12 12 12 10 10 10 8 8 8
20 14 14 14 12 10 10 10 10 10 8 8 8
25 14 14 12 12 10 10 10 10 8 8 6 6
30 14 12 12 10 10 10 8 8 8 6 6 6
35 14 12 10 10 10 8 8 8 8 6 6 5
40 14 12 10 10 8 8 8 6 6 6 5 5
50 12 10 10 8 6 6 6 6 6 5 4 4
60 12 10 8 6 6 6 6 6 5 4 4 3
70 10 10 8 6 6 6 5 5 4 4 2 2
80 10 8 8 6 6 5 5 4 4 3 2 2
90 10 8 6 6 5 5 4 4 3 3 1 1
100 10 8 6 6 5 4 4 3 3 2 1 1

............ www.truemfg.com ............
True Food Service Equipment, Inc.
INSTALLATION / OPERATION INSTRUCTIONS
LOCATING
Thread castor into the underside of cabi-
net frame rail.
Thread leg into cabinet bottom frame rail. The end of the leg is adjustable to easy
leveling.
Use the tool provided to tighten the
castor into place.
For leveling, insert the shim between the
castor and frame rail.
INSTALLATION OF LEGS AND CASTORS
Important Safeguard for installation of leg/castor (Images 1-5 demonstrate procedure)
Securing Castors and Legs
Toobtainmaximumstrengthandstabilityoftheunit,it
isimportantthatyoumakesureeachcastorissecure.
Legsarehand-tightenedsecurelyagainstthelowerrail
assembly.Thebearingraceonthecastorofthetopedge
ofthelegmustmakefirmcontactwiththerail.
Unit Leveling
Fourlevelingshimshavebeenprovidedforlevelingcastored
unitspositionedonunevenfloors.Shimsmustbepositioned
betweenrailendandbearingrace.
A. Turnthebearingracecounter-clockwiseuntilthe
cabinetislevel.Levelfronttobackandsidetoside
(diagonally).
B. Installthedesirednumberofshims,makingsurethe
slotoftheshimisincontactwiththethreadedstem
ofthecastor.
C. Ifmorethanoneshimisused,turntheslot
ata90°anglesotheyarenotinline.
D. Turnthebearingraceclockwisetotightenandsecure
thecastorbytighteningtheanchoringboltwitha3/4
inchopen-endwrench,socket,orthetoolprovided.
CAUTION
To avoid damage to lower rail assembly,
slowly raise unit to upright position.
A. Removelouverfromthefrontofcabinetandbackguard
(ifapplicable)fromrearofcabinet.
B. Skidboltsarelocatedineachof4cornersinsidecabinet
bottom(seeimage1).
C. Removeskidbolts(seeimage2).
D. Cutstrapsifapplicable(seeimage3).
E. Carefullyliftcabinetoffofskid.
Removing skid from
bottom of cabinet.
1 2
4 5
3
21
3
88

99
............ www.truemfg.com ............
True Food Service Equipment, Inc.
A. Setunitinitsfinallocation.Besurethereisadequate
ventilationinyourroom.Underextremeheat
conditions,(100°F+,38°C+),youmaywanttoinstall
anexhaustfan.
WARNING
Warranty is void if ventilation is insufficient.
B. ProperlevelingofyourTRUEcooleriscriticalto
operatingsuccess(fornon-mobilemodels).Effective
condensateremovalanddooroperationwillbe
effectedbyleveling.
C. Thecoolershouldbeleveledfronttobackandsideto
sidewithalevel.
D. Ensurethatthedrainhoseorhosesarepositionedin
thepan.
E. Freeplugandcordfromthetopofthecabinet(do
notplugin).
F. Theunitshouldbeplacedcloseenoughtothe
electricalsupplysothatextensioncordsarenever
used.
WARNING
Cabinet warranties are void if OEM power cord is tampered
with. True will not warranty any units that are connected to
an extension cord.
Optional
A. Itmaybenecessarytosealthecabinettothefloorfor
localsanitarycodesorifthecustomersodesires.TRUE
recommendseitherofthefollowingmethods:
B. Usingavinylcovebasetrimasproducedby
Armstrong,Johnson,orKentile(availableatfloor
coveringsuppliers)orusingmasticsavailableathard-
warestores.
C. Whenapplyingthecovebasetrim,thoroughlyclean
boththecabinetandfloorofdirtandgrease.Applya
recommendedcontactcementtothecovebasetrim.
Aftercovebasetrimhasdried,fillincracksand
jointswithacaulkingmaterial.
D. Whenapplyingamastic,drawanoutlineofthecabi-
netonthefloor.Raiseandblockthefrontsideofthe
cabinet.Applyabeadofmastictothefloor1/2”
insidetheoutlinedrawn.Lowerthecabinet.Raiseand
blocktherearsideofthecabinet.Applythebeadof
mastic,lowerthecabinet.
LEVELING
SEALING CABINET TO FLOOR
INSTALLATION / OPERATION INSTRUCTIONS
Fulldoubledoorpassthruunitshavetwoshipping
bracketsontheinsideoftheunit.Thesetwobrackets
needtoberemovedoncetheunithasbeenplacedinto
itsfinallocation.
Shipping Bracket Removal
A. Afterunithasbeenplacedintoafinallocationopen
thefrontandreardoorsforeasyaccesstothetwo
brackets(seeimage1).
B. Useaflatheadscrewdrivertoloosenthethumb
screwsfromthebrackets.Eachbrackethastwo
thumbscrewsoneachendandfourinthemiddle
(seeimage2).
WARNING
Be careful not to scratch or damage the cabinet when
removing the bracket.
PASS THRU UNIT INSTALLATION
Bracket location.
Bracket removal. Thumb screw locations.
WARNING
Any relocation of this unit requires
shipping bracket to be reinstalled
before proceeding.
1
2

............ www.truemfg.com ............
True Food Service Equipment, Inc.
10 10
INSTALLATION / OPERATION INSTRUCTIONS
Oncethecabinetisinitsfinallocationandleveltheroll-
inrampcanbeinstalled.Theramphasthreeslotted
holesinback.Theseslottedholesslideoverthreethumb
screwslocatedinthefrontofthecabinetnearthefloor
(seeimage1).
RAMP INSTALLATION FOR ROLL-IN CABINETS
1
3
2
4
DOOR SWEEP GASKET ADJUSTMENT
Toadjustdoorsweepergasket,loosenslottedthumb-
screws.Thegasketcanthenbemovedupordownand
sidetoside.Thegasketshouldmakesomecontactwiththe
rampwhenthedoorisclosing.Thiscanbecheckedby
openingupthedoor3-4”andallowingthedoortoclose.
Thisprocessmayhavetobedoneseveraltimesbefore
securingthesweepergasketbracket.Oncegasketisprop-
erlyadjusted,tightenslottedthumbscrews(seeimage5).
5

11 11
............ www.truemfg.com ............
True Food Service Equipment, Inc.
INSTALLATION / OPERATION INSTRUCTIONS
A. Beforeyournewunitisconnectedtoapowersupply,
checktheincomingvoltagewithavoltmeter.If
anythinglessthan100%oftheratedvoltagefor
operationisnoted,correctimmediately.
B. Allunitsareequippedwithaservicecord,andmust
bepoweredatproperoperatingvoltageatalltimes.
Refertocabinetdataplateforthisvoltage.
TRUE requiresthatasoleusecircuitbededicatedforthe
unit.Failuretodosovoidswarranty.
WARNING
Compressor warranties are void if compressor burns out due
to low voltage.
WARNING
Power supply cord ground should not be removed!
NOTE
To reference wiring diagram - locate the diagram inside large
junction box on top of unit.
ELECTRICAL INSTRUCTIONS
DIGITAL TEMPERATURE DISPLAY
A. Thecompressorisreadytooperate.
Pluginthecooler.
B. TemperaturecontrolsetatNo.4positiongives
refrigeratorsanapproximatetemperatureof35°Fand
freezersanapproximatetemperatureof-10°F.Allow
unittofunctionseveralhours,completelycooling
cabinetbeforechangingthecontrolsetting.
C. Excessivetamperingwiththecontrolcouldlead
toservicedifficulties.Shoulditeverbecome
necessarytoreplacetemperaturecontrol,besure
itisorderedfromyourTRUEdealerora
recommendedserviceagent.
D. GoodairflowinyourTRUEunitiscritical.Be
carefultoloadproductsothatitneitherpresses
againstthebackwall,norcomeswithinfourinches
oftheevaporatorhousing(InteriorTop).Refrigerated
airoffthecoilmustcirculatedownthebackwall.
NOTE
If the unit is disconnected or shut off, wait five minutes before
starting again.
RECOMMENDATION
Before loading product we recommend you run your TRUE unit
empty for two to three days. This allows you to be sure electrical
wiring and installation are correct and no shipping damage has
occurred. Remember, our factory warranty does not cover product
loss!
REPLACEMENT PARTS
TRUE maintains a record of the cabinet serial number for your
cooler. If at any time during the life of your cooler, a part is
needed, you may obtain this part by furnishing the model number
and serial number to the company from whom you purchased
the cooler. Call Toll-Free: (800)-424-TRUE (Direct to Parts
Department). (800)-325-6152 (U.S.A. & Canada only) or call:
(636)-240-2400.
STARTUP
Thedigitaltemperaturedisplaycanview°Cor°F.Toachieve
this,thereisasmallplugthatwillneedtoberemovedto
achieve°Creading.Seeimage1fortemperaturedisplaylocation.
Iftheplugiskeptinthebackofthedigitaldisplay°Fwillbe
viewable.Seeimagesforreference.Whentemperaturedisplay
isin°Cmodeplacethepluginasafeplacesoitcanbeeasily
reinstalledfor°Freading.
Image 1 (Rear of Rainshield)
Image 2 Image 3
°F °C

............ www.truemfg.com ............
True Food Service Equipment, Inc.
12 12
TERMS:
Cut-out-Temperaturesensed
bythecontrollerthatshutsthecom-
pressoroff.
Cut-in-Temperaturesensed
bythecontrollerthatturnsthecom-
pressoron.
REQUIRED TOOLS
•PhillipsHeadScrewdriver
•5/64”or2mmAllenWrench
•T-7TorxWrench
STEP 1
Unplugthecooler.
STEP 2
Removethescrewsthatsecurethe
temperaturecontroltotheinsetbox
lowerleftsideofthecabinet(when
facingthefront
ofthecabinet).
S T E P 3
Pulloutgentlyfromcabinet.
S T E P 4
Forhighelevationinstallations,
itmaybenecessaryto“warm-up”
thesetpoints.Tomaketheadjust-
ment,inserttheappropriatetoolin
eachadjustmentscrewandturn1/4
ofarevolutionclockwise(tothe
right).Thisprocedurewilladjust
boththecut-inandcut-outabout
2°Fwarmer.
S T E P 5
Makesuretoreconnectthepink
wiretotheproperspade
terminalwhenreinstalling.
NOTE:
Mechanical temperature
controllers are affected when
functioning at high altitude.
The cut-in and cut-out
temperatures will be colder
than when the controller
functions closer to sea level.
Danfoss Temperature Control (High Altitude Adjustment Only!)
Cut-out Adjustment Screw Allen (5/64”
or 2 mm) (clockwise for warmer)
Cut-in Adjustment Screw Torx (T-7)
(clockwise for warmer)
Compressor Connection (pink)
Compressor Connection (pink)
TEMPERATURE CONTROL ADJUSTMENT FOR
HIGH ALTITUDE ONLY!
INSTALLATION / OPERATION INSTRUCTIONS

............ www.truemfg.com ............
True Food Service Equipment, Inc.
13 13
TRUETR,TA,andTGcabinetsareavailablewithfour
differentshelving/trayslideoptions.
TypeKit#1. AngleTypeTraySlide
TypeKit#2. RodStyleTraySlide
TypeKit#3. UniversalTraySlide
TypeKit#4. ChromeShelves&ShelfSupports
Required Tools:
• StandardScrewdriver(Flathead)
• Rubber/PlasticMallet
• TapeMeasure
Installation Procedures (Wire Shelves):
Chrome,Stainless,orPVCcoatedwireshelvescomewith
knobstyleshelfsupports(image1)andplasticplugs
(image3).Notethatheatedcabinetsuseshelfstandards
(seepage13).
Screwintheknobstyleshelfsupportsinthedesired
height(rememberallsupportswillneedtobeinstalledatthe
sameheighttokeeptheshelflevel.
Oncetheshelvesareinstalledplugtheremainingthread-
edholeswiththeplasticplugsprovided(seeimage3).
PILASTER INSTALLATION & OPERATION
Type Kit #4 Chrome Shelves or PVC Coated Shelves Pilaster Installation
(Side Wall of
Cabinet)
Pilaster Installation
(Back Wall of
Cabinet / Two &
Three Door Models)
Pilaster Installation
Two and Three Door
Models
(Middle of Wall in
Rear of Cabinet)
White plastic
plugs go into
the threaded
holes when
they are not
used by the
different shelving
systems.
(Not available
in heated
cabinets.)
NOTE: The package containing the pilasters will have the same serial number as cooler.
Please check to make sure these serial numbers are the same. Please see pages 14-15
on shelving diagrams for your specific model.
14
5
6
2
3
INSTALLATION / OPERATION INSTRUCTIONS

............ www.truemfg.com ............
True Food Service Equipment, Inc.
14 14
Installation Procedures (Pilasters):
Installslottedthumbscrewsintothreadedholesalong
theinsidewallofthecabinet.
Slidepilastersintopositionbehindtheslottedscrews.
Leaveallofthethumbscrewslooseforadjustmentswhen
installingtrayslides.
Itiscriticaltomeasurefromthecenterofthesquarehole
onthefrontpilastertothecenterholeoftherearpilaster.
Thismeasurementshouldbe245/8”(seeimage13).Do
thesameontheoppositesideofcabinetforsingledoor.
Makesurethemeasurement(245/8”)isthesameinthe
centerpilastersin2and3doorunits.Tapthetrayslides
intothePilasterswitharubberMallet.
Angle&RodTypeshelvingusesa181/8”distance
betweenPilasters.UniversalTrayslideshavea211/4”
distancebetweenPilasters(seeimage14).
AfterthepilastersareinstalledtheUniversalTray,Angle
TypeTray,andRodStyleTraySlideswillslideintothe
pilasters(seeimages7-12).Whendisassemblingorchanging
trayslidesarubbermalletmaybeusedtotakeoutthe
differenttrayslides.Gentlytapontheundersideofthetray
slidetoloosenitfromthepilaster.
PILASTER INSTALL/OPERATION CONTINUED...
Type Kit #1 (Angle Type Tray Slide) Type Kit #2 (Rod Style Tray Slide) Type Kit #3 (Universal Tray Slide)
24 5/8
(Critical Measurement Front to Rear Pilasters)
18 1/8”
Angle Type
&
Rod Type
21 1/4”
Universal
Tray Slide
Top view (Critical Measurement side to side)
7
13
8 10 12
11
9
14
INSTALLATION / OPERATION INSTRUCTIONS

............ www.truemfg.com ............
True Food Service Equipment, Inc.
15 15
Shelf
Standards
Thumb
Screw
Thumb
Screw
Ceiling of Cabinet
Shelf
Shelf
Standards
Shelf
Clip
Shelf
HEATED CABINET SHELVING INSTALLATION/
OPERATION
SHELF INSTALLATION:
A. Hookshelfclipsontoshelfstandards.
B. Positionallfourshelfclipsequalindistancefromthe
floorforflatshelves.
C. Shelvesareorientedsothatcrosssupportbarsarefac-
ingdown.
D. Placeshelvesonshelfclipsmakingsureall
cornersareseatedproperly.
INSTALLING SHELF STANDARDS IN HEATED CABINETS:
(See Image 2)
A. Wheninstallingshelfstandardsmakesurethenum-
bersonthestandardsarefacingup.Thesenumbers
helpwithinstallingshelfclipsatalevelheight.
B. Allstandardsareinstalledintheuppermostthread-
edholeneartheceilingofthecabinet.Thiswillleave
athreadedholevacantbeloweachshelfstandard.A
plasticplugisprovided
tocovertheopenthreadedslot.
Image 1
Image 2
INSTALLATION / OPERATION INSTRUCTIONS

............ www.truemfg.com ............
True Food Service Equipment, Inc.
16 16
TA/TG/TR2RPT-2S-2S
#1 TRAY SLIDE UNIVERSAL TRAY SLIDE
#2 TRAY SLIDE WIRE SHELF
PART #890097
PART #890070 PART #890071
PART #890075
TA/TG/TR2RPT-2S-2S
18 3/16"
CRITICAL
2 1/8" 21 1/4"
CRITICAL 5/8"
24 5/8"
18 3/16"
CRITICAL
2 1/8"
890077
PILASTER E
PILASTER B
890080
890079
PILASTER D
PILASTER A
890076
890077
890080
PILASTER B
PILASTER E
UNIVERSAL TRAY SLIDE#1 TRAY SLIDE
TA/TG/TR2R-2S/2F-2S
WIRE SHELF#2 TRAY SLIDE
PART #890082
PART #890071PART #890070
PART #890075
TA/TG/TR2R-2S/2F-2S
2 1/8" 18 3/16"
CRITICAL
22 7/8" (TYP)
5/8"
21 1/4"
CRITICAL
24 5/8"
2 1/8" 18 3/16"
CRITICAL
PILASTER B
890077
PILASTER E
890080
PILASTER A
PILASTER D
890079
890076
890077
PILASTER E
PILASTER B
890080
BACK GUARD
890385
BACK GUARD
890385
BACK GUARD
890385
BACK GUARD
890385
TA/TG/TR1RPT-1S-1S
#1 TRAY SLIDE #2 TRAY SLIDE
UNIVERSAL TRAY SLID
EW
IRE SHELF
PART #890096
PART #890075PART #890070
PART #890071
TA/TG/TR1RPT-1S-1S
TA/TG/TR1RPT-1S-1STA/TG/TR1RPT-1S-1S
3 5/8"
(TYP)
18 3/8"
CRITICA
18 3/8"
CRITICA
24 5/8"
2 1/8"
(TYP)
21 3/8"
CRITICA
3 5/8"
(TYP)
PILASTER C
890078
890077
PILASTER B
890078
PILASTER C
UNIVERSAL TRAY SLIDE
TA/TG/TR1R-1S/1F-1S
#1 TRAY SLIDE #2 TRAY SLIDE
WIRE SHELF
PART #890081
PART #890070 PART #890075
PART #890071
TA/TG/TR1R-1S/1F-1S
TA/TG/TR1R-1S/1F-1S TA/TG/TR1R-1S/1F-1S
18 3/8"
CRITICAL
3 5/8"
(TYP)
18 3/8"
CRITICA
L
2 1/8"
(TYP) 21 3/8" CRITICAL
24 5/8"
3 5/8"
(TYP)
PILASTER B
890077
890078
PILASTER C
890385
BACK GUARD
BACK GUARD
890385
890385
BACK GUARD
890078
890385
BACK GUARD
PILASTER C
TA, TG, TR2RPT-2S-2S
TA, TG, TR1RPT-1S-1S TA, TG, TR1R-1S/1F-1S
TA, TG, TR2R-2S/2F-2S
INSTALLATION / OPERATION INSTRUCTIONS

............ www.truemfg.com ............
True Food Service Equipment, Inc.
17 17
UNIVERSAL TRAY SLIDE#1 TRAY SLIDE #2 TRAY SLIDE
WIRE SHELF
PART #890081PART #890082
WIRE SHELF WIRE SHELF
PART #890082
PART #890070 PART #890075 PART #890071
PART #890070
#1 TRAY SLIDE
PART #890071
TA/TG/TR3R-3S/3F-3S
UNIVERSAL TRAY SLIDE
PART #890075
#2 TRAY SLIDE
TA/TG/TR3R-3S/3F-3S
TA/TG/TR3R-3S/3F-3S
18 3/16"
CRITICA
2 1/8"
24 5/8"
18 1/8"
CRITICAL
21 1/4"
CRITICAL 5/8"
24 5/8"
2 1/8" 18 3/16"
CRITICAL
21 1/4"
CRITICAL
18 3/16"
CRITICAL 2 1/8"
PILASTER B
890077
PILASTER E
890080
890079
PILASTER D
PILASTER A
890076
PILASTER E
890080
BACK GUARD
890385
BACK GUARD
890385 890385
BACK GUARD
890385
BACK GUARD
890385
BACK GUARD
890385
890080
PILASTER E
BACK GUARD
PILASTER B
890077
890385 890385
BACK GUARD
890079
PILASTER D
BACK GUARD
890385
890077
PILASTER B
PILASTER E
890080
BACK GUARD
UNIVERSAL TRAY SLIDE
TA/TG/TR1DT-2HS
#1 TRAY SLIDE #2 TRAY SLIDE
WIRE SHELF
PART #890081
PART #890070 PART #890359
PART #890071
TA/TG/TR1DT-2HS
TA/TG/TR1DT-2HS TA/TG/TR1DT-2HS
3 5/8"
(TYP) 18 3/8" CRITICAL 3 5/8" (TYP) 18 3/8" CRITICAL
18 3/8"
CRITICAL
24 5/8"
2 1/8"
(TYP)
2 1/8"
(TYP) 21 3/8" CRITICAL
PILASTER F
890139
890140
PILASTER G
BACK GUARD
890141
BACK GUARD
890141
BACK GUARD
890141
890141
BACK GUARD
PILASTER G
890140
COOLER SIDE
TA/TG/TR2DT-2S
FREEZER SIDE
UNIVERSAL TRAY SLIDE
#1 TRAY SLIDE
#1 TRAY SLIDE
COOLER SIDE FREEZER SIDE
UNIVERSAL TRAY SLIDE
#2 TRAY SLIDE
COOLER SIDE
WIRE SHELF
FREEZER SIDE
PART #890305
PART #890071PART #890070
PART #890071 PART #890070
PART #890075
PART #890075 (BOTTOM HALF SECTION)
COOLER SIDE
#2 TRAY SLIDE
WIRE SHELF
PART #890305
FREEZER SIDE
PART #890712 (TOP HALF SECTION)
TA/TG/TR2DT-2S
TA/TG/TR2DT-2S TA/TG/TR2DT-2S
18 1/4"
CRITICAL
2 1/8"
(TYP)
21 1/4"
CRITICAL
24 5/8"
5/8"
(TYP)
21 1/4"
CRITICAL
5/8"
(TYP)
18 1/4"
CRITICAL
18 1/4"
CRITICAL
2 1/8"
(TYP)
18 1/4"
CRITICAL
2 1/8"
(TYP)
2 1/8"
(TYP)
PILASTER B
890077 890302
PILASTER H
BACK GUARD
890304
890303
PILASTER I
890076
PILASTER A
890304
BACK GUARD
PILASTER B
890077
BACK GUARD
890385
BACK GUARD
890385 890304
BACK GUARD
BACK GUARD
890385
BACK GUARD
PILASTER I
890303
890385
BACK GUARDBACK GUARD
890304
TA, TG, TR3R-3S/3F-3S
TA, TG, TR2DT-2S
TA, TG, TR1DT-2HS
INSTALLATION / OPERATION INSTRUCTIONS

............ www.truemfg.com ............
True Food Service Equipment, Inc.
18 18
FREEZERS DEFROST TIME CLOCK
OPERATION (Grasslin Timer)
RECOMMENDED DEFROST SETTINGS:
TRUEManufacturinghasfactorysetyour
defrosttimeclocktoarecommended
timeanddurationdefrostscenario.All
refrigerationequipmentoperatingbelow30°F
willaccumulatefrostontheevaporatorcoil
andwillrequireroutinedefrost.YourTRUE
equipmenthasbeendesignedforthree
defrostperiods(6:00a.m.,2:00p.m.and
10:00p.m.).Ifyoudecidetodeviatefrom
thesedefrosttimesettingspleasefollowthe
proceduresforadjustmentbelow.
REQUIRED TOOLS:
• Phillips Screwdriver
• 1/4” Nut Driver or Socket
Locating The Defrost Timer:
Takeoffthetimerboxlidbyremovingfour
(4)cornerscrews.
Single Door Models:
Defrosttimerislocatedintopofthecabinet
inthetimerboxconnectedtotheevaporator
housing.
Two Door Models:
Defrosttimerislocatedintopofthecabinet
intimerboxconnectedtotheevaporator
housing.
Three Door Models:
Defrosttimerislocatedontopandright-
handsideofthecabinet.Thetimerisin
thetimerboxconnectedtothesideofthe
condenserhousing.
Setting the timer:
(UNPLUG UNIT FROM
POWER SUPPLY!)
DO NOT SET THE TIME BY
ROTATING THE “OUTER” DIAL.
Turntheminutehandclockwiseuntilthe
timeofdayontheouterdialisalignedwith
thetrianglemarkerontheinnerdial(two
o’clockposition).
Adjusting The Defrost Timer:
(timeinitiated,timeortemperature
terminated)
YourTRUEfreezercontainsadefrostsystem
thatistemperatureterminated,howeverthe
timeclockhasbeendesignedwithatime
terminationback-upsothatthedefrost
periodwillnotexceedthirtyminutes.While
TRUErequiresaminimum3defrostperiods
nottoexceed30minutestheprocedureon
thispageshouldbefollowedtocustomize
yourspecificneeds.
NOTICE:
If timer is not set for a minimum of 3 defrost
per day for 30 minutes each, the coil may
develop excessive frost. This may lead to
system failure and product loss, which is not
covered under warranty.
The following procedure may be followed to
customize your needs.
High usage, high temperature, and high
humidity may require 4 defrost settings per
day.
WARNING:
Always follow the manufacturer’s
recommended settings when programming the
amount and duration of the defrost cycles.
STEP 1
Thewhitetabslocatedontheoutmostarea
ofthetimeclockhavebeenfactorysetfor
(6:00a.m.,2:00p.m.,and10:00p.m.).Each
tabrepresents15minutesofdefrosttime.
Noticethatateachdefrosttimetwowhite
tabsaresetfor15minuteseachforatotalof
30minutesofdefrost.
STEP 2
Inordertoprogramthetimetobeginthe
defrostcycle,flipthewhitetabsouttosetthe
defrosttime.Toeliminateadefrosttimeflip
thewhitetabsbacktowardthecenterofthe
DefrostTimer.
STEP 3
TRUErecommendsa30minutedefrost
cyclethreetimesperday.
Inner most dial.
Time of day.
Outer most dial. White tabs represent 15
minutes of defrost time.
Defrost Timer Box Image 1
Defrost Timer Image 2
INSTALLATION / OPERATION INSTRUCTIONS MAINTENANCE, CARE & CLEANING
