GDM-12F
GDM-12F
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
GDM-12F 1 12
340
324
7/8
632
233/8
594
623/8
1585
1/2115/60/1 9.0 5-15P 9
2.74
300
137
†Depth does not include 13/8"(35 mm) for door handle and 1"(26 mm) for rear bumpers. ▲ Plug type varies by country.
*Height does not include 1"(26 mm) for upper door hinge.
Glass Door Merchandiser:
Swing Door Freezer
The world’s #1 manufacturer of
glass door merchandisers.
Designed using the highest quality
materials and components to
provide the user with an attractive,
point of purchase merchandiser
that brilliantly displays frozen food
and ice cream, resulting in high
impulse sales.
Oversized, factory balanced,
refrigeration system holds -10°F
(-23.3°C). Ideal for ice cream and
frozen food products.
Exterior - non-peel or chip white
laminated vinyl; durable and
permanent.
Interior - attractive, NSF approved,
white aluminum interior liner with
300 series stainless steel floor.
Self closing door. Positive seal,
torsion type closure system.
Triple pane thermal glass door
assembly with mitered plastic
channel frame.
Entire cabinet structure is foamed-
in-place using high density, CFC
free, polyurethane insulation.
Bottom mounted units feature
”No stoop” lower shelf to maximize
product visibility.
Easily accessible condenser coil for
cleaning.
Shown with optional novelty basket.
5/07
R
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
GDM-12F
GDM-12F
DESIGN
• True’s glass door freezers are designed
with enduring quality that protects your
long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures,
and lower utility costs in an attractive
merchandiser that brilliantly displays
frozen food and ice cream.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free) R404A
refrigerant.
• Extra large evaporator coil balanced with
higher horsepower compressor and large
condenser; maintains -10°F (-23.3°C).
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger fan
blades give True merchandisers a more
efficient low velocity, high volume airflow
design. This unique design ensures colder
standard temperatures and faster recovery
in high use situations.
• Bottom mounted condensing unit positioned
for easy maintenance. “No stoop” lower
shelf maximizes visibility by raising
merchandised product to higher level.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible
defrost cycle.
CABINET CONSTRUCTION
• Exterior - non-peel or chip white
laminated vinyl; durable and permanent.
• Interior - attractive, NSF approved, white
aluminum liner with 300 series stainless
steel floor.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC
free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with leg levelers.
• Back-lit door sign decal. Variety of decal
options available.
DOOR
• Triple pane thermal glass door assembly
with mitered plastic channel frame.
• Door fitted with 12" (305 mm) long
extruded handle.
• Self closing doors. Positive seal, torsion
type closure system.
• Magnetic door gasket of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Three (3) adjustable, heavy duty PVC
coated wire shelves 2013/16"L x 163/4"D
(529 mm x 426 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Safety shielded fluorescent interior
lighting.
• Cabinet lighting utilizes electronic ballast
and T-8 bulbs for brighter illumination,
longer bulb life and increased energy
efficiency.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• See our website www.truemfg.com for
latest color and decal offerings.
• Backguard and floor rack ensures
optimum airflow.
• Listed under NSF-7 for the storage and/or
display of packaged or bottled product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase, 15 amp dedicated outlet. Cord and
plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒Black exterior.
❒Rosewood exterior.
❒Stainless steel exterior.
❒Black aluminum interior liner with
black shelving.
❒21/2" (64 mm) diameter castors.
❒4" (102 mm) diameter castors.
❒11/4" (32 mm) pricing strips.
❒Novelty baskets.
❒Remote cabinets (condensing unit supplied
by others; system comes standard with
404A expansion valve and requires R404A
refrigerant), consult factory technical
service department for BTU information.
115/60/1
NEMA-5-15R
Glass Door Merchandiser:
Swing Door Freezer
ELEVATION PLAN VIEW
2413/16"
(631 mm)
237/32"
(590 mm)
4717/32 "
(1207 mm)
235/16"
(593 mm)
13/8"
(35 mm)
2411/16"
(628 mm)
601/8"
(1528 mm)
625/16"
(1583 mm)
631/4"
(1607 mm)
17/8"
(48 mm)
5/16"
(8 mm)
15/16"
(24 mm)
1"
(26 mm)
