True TUC-27FG User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
TUC-27FG
TUC-27FG
Model
Glass
Doors
Capacity
(Cu. Ft.)
(liters)
# of
Shelves
Cabinet Dimensions
(inches)
(mm)
LD†H*
HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TUC-27FG 1 6.5
185
227
5/8
702
301/8
766
293/4
756
1/2
1/3
115/60/1
230-240/50/1
8.6
5.0
5-15P
▲
7
2.13
230
105
† Depth does not include 1 " (26 mm) for rear bumpers or 1/8 " (4 mm) for door handle. ▲Plug type varies by country.
* Height does not include 61/4 " (159 mm) for castors or 6 " (153 mm) for optional legs.
3/05
True’s undercounter units are
designed with enduring quality
that protects your long term
investment.
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility
costs, exceptional food safety
and the best value in today’s
food service marketplace.
Oversized, environmentally
friendly (R404A) forced-air
refrigeration system holds
-10°F (-23.3°C). Ideally suited
for both frozen foods and ice
cream.
All stainless steel, top and
cabinet ends. Matching
aluminum finished back.
Front breathing.
Energy efficient, triple pane
thermal glass door.
Foamed-in-place, high density
polyurethane insulation (CFC
free).
Heavy duty PVC coated wire
shelves.
Undercounter:
Glass Door Freezer

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
293/4"
(756 mm)
125/8"
(321 mm) 75/16"
(186 mm)
3515/16"
(913 mm)
63/16"
(158 mm)
TUC-27FG TFQY04E TFQY04S TFQY01P TFQY043
TUC-27FG
DESIGN
• True’s commitment to using the
highest quality materials and
oversized refrigeration systems
provides the user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
R404A refrigerant.
• Oversized, factory balanced
refrigeration system with guided
airflow to provide uniform product
temperatures.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains -10°F
(-23.3˚C) cabinet temperatures. Ideally
suited for both frozen foods and ice
cream.
• Sealed, cast iron, self-lubricating
evaporator fan motor and larger fan
blades give True undercounter units
a more efficient low velocity, high
volume airflow design. This unique
design insures faster temperature
recovery and shorter run times in the
busiest of food service environments.
• Condensing unit access in back
of cabinet, slides out for easy
maintenance.
• Automatic defrost system time
initiated, time terminated.
CABINET CONSTRUCTION
• Exterior - stainless steel front, top and
cabinet ends. Matching aluminum
finished back.
• Interior - attractive, NSF approved,
white aluminum liner. 300 series
stainless floor with coved corners.
• Insulation - entire cabinet structure is
foamed-in-place using high density,
CFC free, polyurethane insulation.
• 5" (127 mm) diameter stem castors -
locks provided on front set. 36"
(915 mm) work surface height.
DOOR
• Triple pane thermal glass with
extruded aluminum frame.
• Positive seal self-closing door with 90°
stay open feature. Door swings within
cabinet dimensions.
• Door fitted with 15" (381 mm) long
extruded aluminum handle.
• Magnetic door gasket of one piece
construction, removable without tools
for ease of cleaning.
SHELVING
• Two (2) adjustable, heavy duty PVC
coated wire shelves 231/4"L x 16"D
(591 mm x 407 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves
are adjustable on 1/2" (13 mm)
increments.
LIGHTING
• Fluorescent interior lighting.
MODEL FEATURES
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
•
NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for final connection to a
115/60/1 phase - 15 amp dedicated
outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply
❒ 230 - 240V / 50 Hz.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/flanged legs.
❒ 21/2" (64 mm) diameter castors.
❒ Basic overshelf.
❒ Single utility shelf.
❒ Double utility shelf.
❒ 30" (762 mm) deep, 1/2" (13 mm)
thick, white polyethylene cutting
board. Requires “L” brackets.
❒ 30" (762 mm) deep, 1/2" (13 mm)
thick, composite cutting board.
Requires “L” brackets.
❒ Heavy duty, 16 gauge tops.
❒ ADA compliant models with 34"
(864 mm) work surface height.
❒ Remote cabinets (condensing unit
supplied by others), consult factory
technical service department for BTU
information.
115/60/1
NEMA-5-15R
ELEVATION RIGHT VIEW
279/16"
(701 mm)
Undercounter:
Glass Door Freezer
5511/16"
(1415 mm)
301/16"
(764 mm)
245/8"
(626 mm)
1"
(26 mm)
25/16"
(59 mm)
3/32"
(3 mm)
