FEATURES/BENEFITS
EV-2/07- All dimensions rounded up to the nearest 1/8" ITrue Website: www.truemfg.com IToll Free Number • 1-800-325-6152 ISpecifications subject to change without notice.
• Oversized and balanced, environmentally
friendly (R404A), refrigeration system, factory
sealed and pre-lubricated for long life.
• Freezer holds -10°F (air off evaporator coil,
-20°F) for the best in food preservation.
• An ideal -10°F for roll-in racks supporting
frozen food and ice cream.
• Accepts roll-in rack (inboard castor) with
maximum dimensions of 27"W x 29"D x 66"H.
(supplied by others).
• Exterior - 300 series stainless steel doors,
front, back & bottom. Stainless steel sides.
• Exterior, digital temperature display.
• Interior - attractive, NSF approved, white
aluminum sides and back. 300 series stain-
less floor and door liner.
• Lifetime guaranteed recessed door handles.
• Door locks standard.
• Three rugged cam-lift hinges per door, life-
time guaranteed. Designed for easy product
access with a full 180 degree open capabil-
ity and stay open feature at 120 degrees.
• Heavy gauge stainless steel ramp standard.
• Incandescent interior lighting.
• Interior bumpers protect cabinet walls from
abuse caused by roll-in carts.
• Foamed-in-place polyurethane high density
cell insulation (CFC Free).
• Automatic defrost system time-initiated,
temperature-terminated.
• Automatic evaporator fan motor delay during
defrost cycle.
• Minimum wattage heater in cabinet frame.
• Energy saver switch.
• Standard backguard improves airflow.
• Field reversible door swing.
• Self-contained system.
• Wiper gaskets for positive seal, reversible.
TA1FRI-1S
Remote cabinets available 14% off list (condensing units
supplied by others; system comes standard with
404A expansion valve and requires R404A refrigerant).
Consult factory technical service dept. for BTU information.
TA SerieS
† Depth does not include 41/4" for ramps.
* Height does not include 1" for system mechanical components.
roll-infreezers
Model
Swing
Doors
Cu.
Ft. HP Amps
Crated
Weight
Cabinet Dimensions
L D† H*
SOLID DOORS
TA1FRI-1S 1 37 3/412.2 485 35 x 34
1
/ 2 x 83
3
/ 4
TA2FRI-2S 2 75 1.2 8.0 N/A 68 x 34
1
/ 2 x 83
3
/ 4
NEW
TA2FRI-2S
