True T-24-GC User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
AVAILABLE AT:
T-24-GC
T-24-GC
†Depth does not include 1" (26 mm) for rear bumpers. ▲Plug type varies by country.
12/05
True’s glass and plate chiller/frosters
are designed with enduring quality
and value. Our commitment to
using the highest quality materials
and oversized refrigeration assures
colder product temperatures and
years of trouble free service.
Large storage capacity to meet the
supply and demand requirements
during peak hours.
Oversized, factory balanced,
refrigeration system holds 0°F
(-17.7°C) and below.
Forced-air cooling, positively guided
airflow provide efficient balanced
temperatures throughout the
cabinet. This unique design insures
fast frosting of dry glasses and
plates.
Exterior - heavy duty, wear resistant
laminated black vinyl front and
sides, matching black aluminum
back. All stainless steel countertop
and lid.
Interior - long lasting, heavy duty
galvanized steel.
Evaporator - epoxy coated at the
time of manufacture to eliminate
the potential of corrosion.
Entire cabinet structure and lids are
foamed-in-place using high density,
CFC free, polyurethane insulation.
Heavy duty, 10 mil thick pure grade
PVC coated adjustable shelves.
Glass and Plate Chiller/Froster:
Solid Lid
R
Model Lids
Capacity
Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†HHP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
8"
(204 mm)
Mugs
10 oz.
Steins
T-24-GC 1 90 85 2 243/4
629
265/8
677
333/8
848
1/4
1/3
115/60/1
230-240/50/1
5.8
2.7
5-15P
▲
9
2.74
180
82

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
T-24-GC TFLY03E TFLY01S TFLY03P TFLY033
T-24-GC
DESIGN
• True’s glass and plate chiller/frosters
are designed with enduring quality and
value. Our commitment to using the
highest quality materials and oversized
refrigeration assures colder product
temperatures and years of trouble free
service.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free) 404A
refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains cabinet
temperatures of 0°F (-17.7°C) and below.
• Sealed, cast iron, self-lubricating
evaporator fan motor and larger fan
blades give True chiller/frosters a more
efficient low velocity, high volume airflow
design. This unique design insures fast
frosting of dry glasses and plates.
• Automatic defrost system time-initiated,
time-terminated.
• Condensing unit accessed from behind
front grill, slides out for easy maintenance.
• Forced-air cooling, positively guided
airflow provide efficient balanced
temperatures throughout the cabinet.
CABINET CONSTRUCTION
• Exterior - heavy duty, wear resistant
laminated black vinyl front and sides,
matching black aluminum back. All
stainless steel countertop and lids.
• Interior - long lasting, heavy duty
galvanized steel.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC
free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
SHELVING
• Two (2) adjustable, heavy duty PVC coated
wire shelves 101/4"L x 195/16"D (261 mm
x 491 mm). Split shelf design allows for
effective rotation of chilled smallware,
working with already chilled plates and
glasses on one side while chilling dry
product on other side.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• Listed under NSF-7 for the storage and/or
display of packaged or bottled product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord
and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230-240V / 50 Hz.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/flanged legs.
❒ 21/2" (64 mm) diameter castors.
❒ 3" (77 mm) diameter castors.
❒ Ratchet lock.
❒ Floor racks.
❒ Additional shelves.
❒ Remote cabinets (condensing unit
supplied by others; system comes standard
with 404A expansion valve and requires
R404A refrigerant), consult factory
technical service department for BTU
information.
115/60/1
NEMA-5-15R
Glass & Plate Chiller/Froster:
Solid Lid
ELEVATION PLAN VIEW
