True T-49DT-G User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
AVAILABLE AT:
T-49DT-G
T-49DT-G
Model Doors
Capacity
(Cu. Ft.)
(liters)
Ref. Frz. Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†H*
HP
Ref. Frz. Voltage
Total
Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
T-49DT-G 2 23
652
23
652
654
1/8
1375
293/4
756
783/8
1991
1/33/4115/208-230/60/1 14.2 14-20P 9
2.74
630
286
* Height does not include 5 " (127 mm) for castors or 6 " (153 mm) for optional legs.
† Depth does not include 13/8" (35 mm) for door handles.
11/05
Designed using the highest
quality materials and components
to provide the user with colder
product temperatures, lower utility
costs, exceptional food safety and
the best value in today’s food
service marketplace.
Refrigerator located in left section;
freezer in the right.
Equipped with two, self-contained,
independent refrigeration systems.
Oversized and factory balanced;
refrigerator section holds 33°F
to 38°F (.5°C to 3.3°C); freezer holds
-10°F (-23.3°C).
Energy efficient, “Low-E”, double
pane thermal tempered glass door
in refrigerator section.
Energy efficient, triple pane themal
insulated glass door in freezer
section.
Adjustable, heavy duty PVC coated
shelves.
Positive seal self-closing doors.
Lifetime guaranteed door hinges
and torsion type closure system.
Bottom mounted units feature:
”No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest,
most grease free area of kitchen.
Easily accessible condenser coil for
cleaning.
DT Series:
Reach-In Glass Door Dual Temperature Refrigerator/Freezer
R
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
T-49DT-G TFEY67E TFEY07S TFEY07P TFEY673
T-49DT-G
DESIGN
• True’s glass door reach-in’s are designed with
enduring quality that protects your long term
investment.
• True’s commitment to using the highest
quality materials and oversized refrigeration
systems provides the user with colder product
temperatures, lower utility costs, exceptional
food safety and the best value in today’s food
service marketplace.
REFRIGERATION SYSTEM
• Equipped with two, independent, factory
engineered, self-contained, capillary tube
refrigeration systems using environmentally
friendly (CFC free) refrigerant. Refrigerator
uses 134A and freezer uses R404A.
• Refrigerator located in left section; freezer in
the right.
• Extra large evaporator coils balanced
with higher horsepower compressors
and large condensers; maintain colder
standard temperatures for the best in food
preservation. Refrigerator holds 33°F to 38°F
(.5°C to 3.3°C); freezers holds -10°F (-23.3°C).
• Sealed, cast iron, self-lubricating evaporator
fan motors and larger fan blades give True
reach-in’s a more efficient low velocity, high
volume airflow design. This unique design
insures faster temperature recovery and
shorter run times in the busiest of foodservice
environments.
• Bottom mounted condensing unit positioned
for easy cleaning. Compressor runs in coolest
and most grease free area of the kitchen.
Allows for storage area on top of unit.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible
defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel front grill
and shroud. Anodized quality aluminum
exterior ends, back and top.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor with
coved corners.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC free,
polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 4" (102 mm) diameter
stem castors - locks provided on front set.
DOORS
• “Low-E”, double pane thermal glass assembly
in refrigerator door. Triple pane thermal glass
assembly in freezer door.
• Extruded aluminum frames. Door locks
standard.
• Each door fitted with 15" (381 mm) long
extruded aluminum handle.
• Positive seal self-closing doors. Lifetime
guaranteed door hinges and torsion type
closure system.
• Magnetic door gaskets of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Six (6) adjustable, heavy duty PVC coated wire
shelves 227/8"L X 231/4"D (582 mm x 591 mm).
Four (4) chrome plated shelf clips included per
shelf.
• Shelf support pilasters made of same material
as cabinet interior; shelves are adjustable on
1/2" (13 mm) increments.
LIGHTING
• Fluorescent interior lighting. Each door
utilizes full-length, patented, integrated door
light (IDL) system. Safety shielded.
MODEL FEATURES
• Two (2) exterior mounted temperature
monitors, one for refrigerator section and one
for freezer section.
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
• Rear airflow guards prevent product from
blocking optimal airflow.
• NSF-7 compliant for open food products.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a
115/208-230/60 Hz, single phase, 3 pole, 4 wire
- 20 amp dedicated outlet. Cord and plug set
included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒Additional shelves.
❒Novelty baskets.
❒Half door bun tray racks. Each holds up to
eleven 18"L x 26"D (458 mm x 661 mm) sheet
pans (sold separately) (airflow guard needs to
be removed from freezer).
❒ Full door bun tray racks. Each holds up to
twenty-two 18"L x 26"D (458 mm x 661 mm
sheet pans (sold separately) (airflow guard
needs to be removed from freezer).
❒Remote cabinets (condensing unit supplied
by others; system comes standard with
404A expansion valve and requires R404A
refigerant). Consult factory technical service
deptartment for BTU information.
115/208-230/1
NEMA-14-20R
DT Series:
Reach-In Dual Temperature Glass Door
Refrigerator/Freezer
ELEVATION PLAN VIEW
541/8"
(1375 mm)
835/16"
(2117 mm)
785/16"
(1990 mm)
5"
(127 mm)
257/16"
(647 mm)
5415/16 "
(1396 mm)
2923/32"
(755 mm)
13/8"
(35 mm)
7615/16"
(1955 mm)
13/8 "
(35 mm)
313/32"
(790 mm)
