True TSD-69G User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
S
A
V
I
N
G
S
E
N
E
R
G
Y
S
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
TSD-69G
TSD-69G
Model Doors
Capacity
(Cu. Ft.)
(liters)
# of
Shelves
Cabinet Dimensions
(inches)
(mm)
LD†H*
HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TSD-69G 3 69
1954
978
1/8
1985
295/8
753
791/8
2010
1/2
N/A
115/60/1
230-240/50/1
12.0
N/A
5-15
▲
9
2.74
640
291
† Depth does not include 3/8 " (10 mm) for door handles. ▲Plug type varies by country.
* Height does not include 61/8 " (156 mm) for legs or 5 " (127 mm) for optional castors.
3/05
R
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility
costs, exceptional food safety
and the best value in today’s
food service marketplace.
Oversized, factory balanced,
refrigeration system holds 33°F
to 38°F (.5°C to 3.3°C) for the
best in food preservation.
Energy efficent, “Low-E”,
double pane thermal glass
doors.
Adjustable, heavy duty PVC
coated shelves.
NSF-7 compliant for open food
product .
Unique space saving design for
space tight kitchens.
Bottom mounted units feature:
”No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest,
most grease free area of
kitchen.
Easily accessible condenser coil
for cleaning.
TSD Series:
Reach-In Glass Slide Door Refrigerator
Shown with optional shelving.
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TSD-69G TFGY15E TFGY12S TFGY12P TFGY153
TSD-69G
DESIGN
• True’s sliding door reach-in’s are
designed with enduring quality that
protects your long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures,
lower utility costs, exceptional food
safety and the best value in today’s
food service marketplace.
REFRIGERATION SYSTEM
• Factory engineered self-contained,
capillary tube system using
environmentally friendly (CFC free)
134A refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains 33°F to
38°F (.5°C to 3.3°C) for the best in food
preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motors and larger fan
blades give True reach-in’s a more
efficient low velocity, high volume
airflow design. This unique design
insures faster temperature recovery
and shorter run times in the busiest of
food service environments.
• Bottom mounted condensing unit
positioned for easy maintenance.
Compressor runs in coolest and most
grease free area of the kitchen. Allows
for storage area on top of unit.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel front
grill and shroud. Anodized quality
aluminum exterior ends and back.
• Interior - attractive, NSF approved,
white aluminum liner. 300 series
stainless floor with coved corners.
• Insulation - entire cabinet structure is
foamed-in-place using high density,
CFC free, polyurethane insulation.
• Cabinet mounted on a welded, heavy
duty galvanized frame rail. Rail dipped
in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 6" (153 mm) legs.
DOORS
• “Low-E”, double pane thermal glass
inserts with mitered plastic channel
frames.
• Self-closing doors, efficient counter
balanced weight system for smooth,
even, positive closure. Sliding doors
ride on stainless steel V-Channel with
stainless steel bearings. Doors fit
within plastic channel frame.
• Each door is fitted with a 12" (305 mm)
long molded plastic handle.
SHELVING
• Nine (9) adjustable, heavy duty PVC
coated wire shelves 237/8"L x 209/16"D
(607mm x 621mm). Four (4) chrome
plated shelf clips per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Safety shielded flourescent interior
lighting.
MODEL FEATURES
• Exterior mounted temperature
monitor.
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
• NSF-7 compliant for open food
product.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for final connection to a
115/60/1 phase - 15 amp dedicated
outlet. Cord and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead time may apply.
❒230 - 240V / 50 Hz.
❒4" (102 mm) diameter castors.
❒Seismic/flanged legs.
❒Door locks.
❒Stainless steel interior.
❒Additional shelves.
❒Remote cabinets (condensing unit
supplied by others), consult factory
technical service department for BTU
information.
115/60/1
NEMA-5-15R
7615/16"
(1955 mm)
851/8"
(2163 mm)
61/16"
(154 mm)
ELEVATION PLAN VIEW
TSD Series:
Reach-In Glass Slide Door Refrigerator
21/8"
(54 mm)
299/16"
(751 mm)
297/8"
(759 mm)
781/8"
(1985 mm)
