TRUlink 26478 User manual

1
USER GUIDE
USB TO 2-PORT SERIAL ADAPTER
GUÍA DEL USUARIO
GUIDE D’UTILISATION
Model: 26478
®
i

1
TABLE OF CONTENTS
T
ABLE OF
C
ONTENTS
Introduction..................................................................1
Features.......................................................................2
System Requirements.................................................3
Package Contents .......................................................4
Device Overview..........................................................5
Device Installation .......................................................6
Technical Specifications..............................................8
Cables To Go One Year Warranty ..............................9
Important Safety Information.....................................10
I
NDICE
Introducción ................................................................ 2
Características............................................................ 3
Requisitos del sistema................................................ 4
Contenido del paquete................................................ 5
Descripción general del dispositivo ............................ 6
Instalación del dispositivo........................................... 7
Especificaciones técnicas........................................... 8
Un año de garantía Cables to Go............................... 9
Información de seguridad importante....................... 10
T
ABLE DES MATIERES
Introduction..................................................................2
Fonctions.....................................................................3
Configuration du système............................................4
Contenu du pack .........................................................5
Vue générale du périphérique.....................................6
Installation du périphérique.........................................7
Caractéristiques techniques........................................8
Garantie d'un an Cables To Go...................................9
Informations de sécurité importantes........................10

2
INTRODUCTION
Thank you for purchasing the TruLink®USB to 2-Port Serial Adapter. This USB to Serial Adapter provides an external plug-and-play solution to add up to two RS-232
serial devices to a USB-enabled computer. Many newer computers, particularly laptop computers and handheld devices, no longer include the legacy serial ports, and
desktop computers have reduced the number of serial ports. Users with serial devices may find themselves unable to communicate with installed equipment. The USB to
Serial Adapter is a great solution for connecting those legacy devices to a new computer. The two DB9 serial ports ensure you’ll have the connections you need, when
you need them. We recommend that you read this manual thoroughly and retain for future reference.
INTRODUCCIÓN
INTRODUCTION
INTRODUCTION

3
FEATURES
F
EATURES
Free your computer’s RS-232 port for other uses
Aluminum housing provides a robust solution
Supports automatic handshake mode
Supports remote wakeup and power management
Data Transfer Speed: 12/1.5 Mbps
USB 1.1 compliant
Serial Interface: RS-232
F
ONCTIONS
C
ARACTERÍSTICAS

4
SYSTEM REQUIREMENTS
S
YSTEM
R
EQUIREMENTS
Windows®98SE, ME, 2000,XP, Vista, or
Windows®7
Mac®OS 8.6 or Higher
Linux
One available USB Port
R
EQUISITOS DEL SISTEMA
C
ONFIGURATION DU SYSTEME

5
PACKAGE CONTENTS
P
ACKAGE
C
ONTENTS
USB to 2-Port Serial Adapter
Driver CD
User Manual
C
ONTENIDO DEL PAQUETE
C
ONTENU DU PACK

6
DEVICE OVERVIEW /PANORAMICA DEL DISPOSITIVO /VUE GENERALE DU PERIPHERIQUE

7
DEVICE INSTALLATION
D
EVICE
I
NSTALLATION
Step 1: Connect your Serial peripheral device to a DB9
input on the adapter,
Step 2: Insert the driver CD into your computer’s CD
Drive, then connect the USB cable from the adapter to an
available USB port on the computer.
Step 3: The New Hardware Wizard should appear. Click
on the radio button for Install the software automatically,
and then click on Next. The computer will then pull the
driver files from the CD, this may take several minutes.
Step4: Once the files have been copied from the CD to
the computer, you will see a screen that has a Finish
button at the bottom. Click on the Finish button to
complete the installation.
VERIFYING DEVICE INSTALLATION
To verify device installation the adapter must be
connected to the computer and you must check for the
device in Device Manager. The easiest way to access
Device Manager is to click on Start, right click on My
Computer/Computer, and then select Properties. This will
open the System Properties window. Within the System
Properties window in XP you will need to click on the
Hardware Tab, and then click on the Device Manager
Button. In Vista and 7 there will be a link in the top left
corner, simply click that link to open the Device Manager.
The adapter should appear in Device Manager under Port
(COM & LPT) as 2 separate USB Serial Ports.
If you would like to uninstall the adapter from the
computer, then you will need to go to the Device Manager
as explained above. Right-click on each USB Serial Port
listing created by the adapter, and then select Uninstall.
I
NSTALACIÓN DEL DISPOSITIVO
I
NSTALLATION DU PERIPHERIQUE

8
Product No.
26478
Chips
FTDI
Connectors
USB A Male x 1
DB9 Male x 2
Housing
Plastic
Product Dimension
2.86 x 2.75 x 1.0 in.
Product Weight
0.2 lbs
USB Cable Length
2 ft.
TECHNICAL SPECIFICATIONS /ESPECIFICACIONES TÉCNICAS /CARACTERISTIQUES TECHNIQUES

9
At Cables To Go, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device.
If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this
device. To request a Return Merchandise Authorization (RMA) number, contact customer service at 800-506-9607 or
www.cablestogo.com
En Cables To Go queremos que confíe completamente en su compra. Esa es la razón por la que ofrecemos un año de
garantía en este dispositivo. Si experimenta problemas debidos a mano de obra o defectos de material durante el periodo de
validez de esta garantía, repararemos o sustituiremos este dispositivo. Para solicitar un número de autorización de devolución
de mercancía, contacte con el servicio de atención al cliente en el número de teléfono 800-506-9607 o visite
www.cablestogo.com
Chez Cables To Go, nous voulons que vous soyez complètement satisfait de votre achat. C'est pourquoi vous bénéficiez d'un
an de garantie sur cet appareil. Si vous rencontrez des problèmes liés à des défauts matériels ou de fabrication pendant la
durée de cette garantie, nous réparerons ou remplacerons cet appareil. Pour demander un numéro d'autorisation de retour de
marchandise (ARM), contactez le service client au 800-506-9607 ou www.cablestogo.com
CABLES TO GO®ONE YEAR WARRANTY /UN AÑO DE GARANTÍA CABLES TO GO®/GARANTIE D'UN AN DE CABLES
TO GO®

10
I
MPORTANT
S
AFETY
I
NFORMATION
Do not plug the unit in any outlet that does not have enough
current to allow the device to function. Refer to the
specifications in this manual for power level of the unit.
Liquid: If this unit or its corresponding power adapter has had
liquid spilled on or in it, do not attempt to use the unit. Do not
attempt to use this product in an outdoor environment as
elements such as rain, snow, hail, etc. can damage the product.
In case of a storm, it is recommended that you unplug this
device from the outlet.
Avoid placing this product next to objects that produce heat
such as portable heaters, space heaters, or heating ducts.
THERE ARE NO USER SERVICEABLE PARTS. Do not
attempt to open this product and expose the internal circuitry. If
you feel that the product is defective, unplug the unit and refer
to the warranty information section of this manual.
I
NFORMATIONS DE SECURITE IMPORTANTES
Pour permettre à l'appareil de fonctionner, ne branchez pas l'unité
sur une prise ne délivrant pas assez de courant. Reportez-vous
aux spécifications de ce manuel pour connaître le niveau
d'alimentation de l'unité.
Liquide : Si du liquide s'est répandu sur ou à l'intérieur de cette
unité ou son adaptateur d'alimentation correspondant, n'essayez
pas d'utiliser cette unité. N'essayez pas d'utiliser ce produit dans
un environnement extérieur car des éléments tels que la pluie, la
neige, la grêle, etc. peuvent endommager ce produit.
En cas de tempête, il est recommandé de débrancher cet appareil
de la source de courant.
Évitez de placer ce produit près d'objets produisant de la chaleur
comme les appareils de chauffage portables ou non et les
conduits de chauffage
AUCUNE PIÈCE NE NÉCESSITE D'ÊTRE ENTRETENUE PAR
L'UTILISATEUR. N'essayez pas d'ouvrir ce produit et d'exposer
sa circuiterie interne. Si vous pensez que ce produit présente des
défauts, débranchez l'unité et reportez-vous à la section de ce
guide comportant des informations de garantie.
I
NFORMACIÓN DE SEGURIDAD IMPORTANTE
No conecte la unidad en una salida que no disponga de
suficiente corriente como para permitir que el dispositivo
funcione. Consulte en este manual las especificaciones sobre
nivel de potencia de la unidad.
Líquidos: Si se han derramado líquidos sobre la unidad, en la
unidad o en su correspondiente adaptador de potencia, no
intente utilizar la unidad. No intente utilizar este producto en el
exterior, ya que elementos como la lluvia, la nieve, el granizo,
etc. pueden dañar el producto.
En caso de tormenta, se recomienda que desconecte este
dispositivo del enchufe.
Evite situar este producto cerca de objetos que produzcan calor,
como calefacciones portátiles, calefactores o conductos de
calefacción.
NO HAY PIEZAS QUE PUEDA REPARAR EL PROPIO
USUARIO. No intente abrir este producto y exponer la circuitería
interna. Si cree que el producto presenta algún defecto,
desconecte la unidad y consulte la sección de garantía de este
manual.
IMPORTANT SAFETY INFORMATION

11
For more information on this product or to check for updated drivers,
manuals or frequently asked questions please visit our website.
Para obtener más información sobre este producto o para comprobar controladores actualizados,
manuales o preguntas frecuentes, visite nuestro sitio web.
Pour plus d'informations concernant ce produit ou pour rechercher des pilotes actualisés,
des manuels ou des questions souvent posées, veuillez visiter notre site web.
www.cablestogo.com
VER.1.0.08.03.10
