Trust TELEVIEWER V2 User manual

1 14135-va-qm
TELEVIEWER V2 QUICK INSTALLATION GUIDE
OVERVIEW
Overview
Before START:
1. Set resolution: 1024 x 768 @ 85 Hz (maximum)
(Start – Settings – Control Panel – Display – tab “Settings”)
2. Check manual of Computer (VGA, sound), Monitor, TV or VCR or Video Projector
3. Shut down the computer.
1
Disconnect Monitor cable
Connect Monitor cable
Connect
VGA
2
Connect VGA cable
Connect to “VGA In”
Connect
VGA
3
power
Use:
a. USB power cable or
b. PS/2 Ke
y
board Power Cable
PC
VGA OUT
PC
VGA IN
1
2
3
4A
4B
4C

2 14135-va-qm
TELEVIEWER V2 QUICK INSTALLATION GUIDE
Use powered USB-port
4
Connect Televiewer V2 to TV/VCR/Projector
Use S-Video, Video or SCART cable. Check manual TV/VCR/Projector
S-Video -> 4A
Video Out -> 4B
SCART -> 4C
4A
S-Video out (recommended)
S-VIDEO
4B
Video out
VIDEO
4C
SCART
SCART
S-Video out
S-Video in
Video out
Video In
A
udio input Æ5
Video out
SCART in
A
udio input Æ5
PS/2 Keyboard Power
b
To keyboard
To DC-IN, Televiewer V2
a

3 14135-va-qm
TELEVIEWER V2 QUICK INSTALLATION GUIDE
5
AUDIO
6
Turn on PC, Monitor and television
ON
REMINDERS
Set TV correct input channel
Use powered USB-port
Use S-Video for best image quality
Do not connect both Video/Scart and S-Video cable !!
Use the Televiewer V2 to show pictures/photos, DVD or presentation on TV, VCR or Projector
Set TV/VCR/Projector on correct input channel. Refer manual.
SUPPORTED RESOLUTIONS
Resolution Refresh Rate
640 x 480 60,72, 75, 85 Hz
800 x 600 56, 60, 72, 75, 85 Hz
1024 x 768 60, 70, 72, 75, 85 Hz
BUTTONS
←, →, ↓, ↑ Moving / Control arrows
MENU Activate menu
ZOOM Switch between ZOOM (300%) and Normal view (100%)
SIZE Overscan/Underscan
MENU
: decrease the level
: increase the level
: select the function
A
udio out
White: Audio Left
Red: Audio Right
Connect ÆTelevision / VCR
(
Ste
p
4B or 4C
)
Audio
