Certifier™Anesthesia
Sensor Kit
Model 4093
User Manual
P/N 6017331, Revision A
September 2023

2 Certifier™ Anesthesia Sensor Kit Model 4093
Contents
CONTENTS .................................................................................................. 2
LIST OF COMPONENTS............................................................................. 3
Anesthesia Sensor Kit (Model 4093) .............................................. 3
Optional Accessory......................................................................... 3
MULTI-GAS ANESTHETIC ANALYZER.................................................... 4
Principle of Operation ..................................................................... 4
AVAILABLE MEASUREMENTS ................................................................ 4
CONNECTING THE ANESTHESIA SENSOR ........................................... 5
TOUCHSCREEN OPERATION................................................................... 6
Module Card.................................................................................... 6
Selecting Measurements ................................................................ 7
ZEROING THE ANESTHESIA SENSOR ................................................... 9
Zeroing Procedure.......................................................................... 9
STATUS LED ............................................................................................. 11
MESSAGES AND ERRORS ..................................................................... 12
TROUBLESHOOTING............................................................................... 13
MAINTENANCE ......................................................................................... 14
CLEANING .................................................................................................14
SPECIFICATIONS...................................................................................... 15
Measurements .............................................................................. 15
Gas Concentration Conversion..................................................... 16
Electrical and Environmental ........................................................ 16
Physical Characteristics................................................................ 16
General ......................................................................................... 17
Airway Adapters............................................................................ 18
Effects from Water Vapor Partial Pressure on Gas Readings...... 18
Interfering Gas Vapor Effect ......................................................... 19

User Manual 3
List of Components
Anesthesia Sensor Kit (Model 4093)
Material Description
Part Number
Anesthesia Sensor
Cell (with DB9
connector cable)
130386
Convertor, DB9 Serial
to USB-A
130402
Anesthesia Airway
Adapter, Adult/Pediatric
130403
Optional Accessory
Description
Part Number
Anesthesia Airway
Adapter, Infant
130404

4 Certifier™ Anesthesia Sensor Kit Model 4093
Multi-Gas Anesthetic Analyzer
The anesthesia sensor is a mainstream gas analyzer that works in
conjunction with the TSI®Certifier™Plus or Certifier™Pro test
systems to measure real-time gas concentrations of CO2, N2O, and
anesthetic agents Halothane, Enflurane, Isoflurane, Sevoflurane,
and Desflurane.
Principle of Operation
The measurement of CO2, N2O, and anesthetic agents in gas mixtures
is based on the fact that different gas components absorb infrared light
at specific wavelengths. A beam of infrared light is directed through the
gas flow in the anesthesia sensor adapter. As the beam passes
through the adapter, some of the light is absorbed by the gas mixture.
The amount of absorbed light is measured by a miniaturized
spectrometer which incorporates multiple light filters and an infrared
detector that converts the light beam to an electrical signal and then a
digital value. The ratio of light measured through the filters is used to
calculate the gas concentration.
Available Measurements
Symbol
Description
AA1
Anesthetic agent as a percentage of concentration (if
detected, that specific agent will be displayed).
CO2
Concentration of carbon dioxide as a percentage.
N2O
Concentration of nitrous oxide as a percentage.
PATM
Atmospheric pressure displayed in units cmH2O, kPa, Pa,
hPa, mbar, mmHg, inH2O, or psi.

User Manual 5
Connecting the Anesthesia Sensor
The anesthesia sensor is connected to the USB-A port of the
Certifier™flow analyzer which provides power and user control from
its instrument display.
An airway adapter is inserted into the sensor module which can then
connect to the test circuit. There are two types of airway adapters that
can be used with the anesthesia sensor: adult/pediatric and infant.
Follow the steps below to setup the anesthesia sensor:
1. Attach an airway adapter to the anesthesia sensor. The adapter will
click when properly seated.
2. Connect the anesthesia sensor cable to either USB-A port on
the Certifier™flow analyzer using the supplied DB-9 serial to
USB converter.
3. Power on the Certifier™instrument and configure the anesthesia
sensor measurements.
4. Wait a minimum of 30 seconds then perform the zeroing procedure.
5. The green status LED on the anesthesia sensor illuminates when
the sensor is ready for use.
6. Connect the attached airway adapter to the anesthesia test circuit.
7. Position the anesthesia sensor with the status LED pointing upwards.

6 Certifier™ Anesthesia Sensor Kit Model 4093
C A U T I O N
•DO NOT run anesthetic agents through Certifier™flow
modules/channels.
▪Use of the anesthesia sensor with Certifier™Flow Analyzers
is for testing purposes only and should not be used for
human measurements.
Touchscreen Operation
Once the anesthesia sensor is connected to the Certifier™flow
analyzer, a module card will be generated at the top of the dashboard
for the connected sensor.
Module Card
The module card will display the model number of the connected
sensor (IRMA AX+) and the anesthetic agent detected by the
anesthesia sensor. If no anesthetic agent is detected, the module card
will display “No Agent.”
Press the IRMA AX+ module card to view and edit settings for the
anesthesia sensor.

User Manual 7
The manufacturer (Masimo®) and serial number (ex. 914990) of the
anesthesia sensor are displayed in the heading of the module card
dialog screen.
Three different levels of oxygen concentration can be selected based
on the oxygen percentage present in the gas flowing through the
anesthesia sensor.
If an anesthetic agent is detected, it will be displayed in this dialog
screen. “No Agent” will be displayed if the sensor does not detect an
anesthetic agent.
NOTICE
Anesthetic agents cannot be selected by the user but instead are
automatically detected by the anesthesia sensor.
Selecting Measurements
From the Parameter screen, access the measurement selection screen
by pressing on any of the currently displayed measurement symbols,
readings, or units of measurement, or by pressing the pencil icon in the
right navigation bar.

8 Certifier™ Anesthesia Sensor Kit Model 4093
Press the (+) ADD tile to select an additional measurement, or press
the measurement symbol of a currently selected measurement to
change that measurement parameter.
Once pressed, a list of available measurements will be displayed in
alphabetical order. If more than one module is connected, a letter (ex.
M, A, B) will indicate which module the measurement is coming from.
The letter “M” is used to indicate measurements coming from the
Masimo®anesthesia sensor module. Swipe up and down to scroll
through the list options then tap to select.
Press the orange Xbutton in the right navigation bar at any time
to disregard all changes and return to the Parameter screen.
Press the green checkmark button in the right navigation bar
to save changes and returns you to the Parameter screen.

User Manual 9
Zeroing the Anesthesia Sensor
Zeroing should be performed every time the airway adapter is replaced,
or whenever an offset in gas values or an unspecified gas accuracy
message is displayed.
Before proceeding with the zeroing procedure, allow 30 seconds
for warm up after powering on the anesthesia sensor or after
changing the adapter. The green LED on the sensor will be
blinking for approximately 5 seconds while zeroing is in process.
Zeroing Procedure
Zeroing is performed by snapping a new airway adapter on the
anesthesia sensor without connecting to the test circuit and then using
the Certifier™ flow analyzer to transmit a zero reference command to
the anesthesia sensor.
NOTICE
The presence of ambient air (0% CO2) in the airway adapter is
of crucial importance for a successful zeroing. No span zeroing
is required.
Press the flow module card for the anesthesia sensor.
On the anesthesia sensor module card, select the ZERO button.

10 Certifier™ Anesthesia Sensor Kit Model 4093
Expose the anesthesia sensor to ambient air and press CONFIRM.
A dialog screen will appear while the anesthesia sensor goes through
the zeroing process. It takes approximately 5–10 seconds to zero the
anesthesia sensor.
A message will be displayed once the zeroing process has completed.
Press DONE to return to the previous screen.

User Manual 11
Status LED
The status LED provides visual indication of the anesthesia sensor
status and illuminates in different colors depending on the state of
the device.
NOTICE
Without an airway adapter connected, the status LED will not
illuminate.
The status LED is located above the airway adapter inlet on the front of
the anesthesia sensor device.
LED
Status
Steady green light
Anesthesia sensor OK
Blinking green light
Zeroing in progress
Steady blue light
Anesthesia agent present
Steady red light
Anesthesia sensor error
Blinking red light
Check airway adapter

12 Certifier™ Anesthesia Sensor Kit Model 4093
Messages and Errors
Descriptions of active messages or errors from the anesthesia sensor
can be viewed in the Active Warnings and Errors screen on the
Certifier™display. The following table lists the common anesthesia
sensor related messages, their possible cause, and the next steps.
Message
Possible Cause
Next Steps
No adapter
(check adapter)
An airway adapter is
not installed.
Connect an airway
adapter to the sensor.
Replace adapter
(check adapter)
The airway adapter
should be replaced.
Replace the airway
adapter.
Ambient pressure
out of range
(unspecified
accuracy)
Ambient pressure
measurement is
outside of operating
range.
Verify operating
conditions according to
the specifications. If
normal, replace the
sensor.
Temperature out
of range
(unspecified
accuracy)
The internal
temperature is
outside of the
operating range.
Verify operating
conditions according
to the specifications.
If normal, replace
the sensor.
Software error
(gas sensor error)
Sensor software
error.
If persistent, replace
the sensor.
Hardware error
(gas sensor error)
Sensor hardware
error.
If persistent, replace
the sensor.
Factory calibration
lost/missing (gas
sensor error)
The sensor’s factory
calibration is lost or
missing.
If persistent, replace
the sensor.

User Manual 13
Troubleshooting
The table below lists the symptoms, possible causes, and
recommended corrective actions for problems that may be encountered
while operating the anesthesia sensor.
If the symptom is not listed or if none of the recommended corrective
actions solve the problem, contact technical support at
[email protected] or customer support at 800-680-1220 or
651-490-2860 for assistance.
Symptom
Possible Cause
Corrective Action
Measurement
values are not
displaying.
Anesthesia sensor
requires a power cycle.
Disconnect and
reconnect the sensor
to the Certifier™
flow analyzer.
Status LED is dark
(indicator is off).
Sensor is not plugged
into Certifier™ flow
analyzer or there is an
internal error.
Verify the sensor
is connected to
the Certifier™
flow analyzer.
Status LED is
steady red.
Sensor requires a
power cycle or has an
internal error.
Disconnect and
reconnect the sensor
to the Certifier™
flow analyzer.
Gas readings from
the sensor are
questionable.
Sensor is not
connected correctly to
the test circuit or the
test circuit is leaking.
Disconnect and
reconnect sensor
to test circuit and
check the test
circuit for leaks.
Gas readings from
the sensor are
questionable.
Sensor may need to
be zeroed.
Zero the anesthesia
sensor.

14 Certifier™ Anesthesia Sensor Kit Model 4093
Maintenance
Once a year it is recommended to perform a gas span check on the
anesthesia sensor with a reference instrument or with calibration gas.
To do an operational check on the anesthesia sensor:
1. Connect an airway adapter to the anesthesia sensor.
2. Connect the anesthesia sensor to the Certifier™ flow analyzer and
power on the instrument.
3. Verify that the anesthesia sensor status LED displays a steady
great light.
4. Breathe briefly into the anesthesia sensor airway adapter and verify
that a CO2values are displayed on the Certifier™ flow analyzer.
Cleaning
To clean the anesthesia sensor:
1. Remove the airway adapter.
2. Wipe each of the sensor’s outer surfaces, paying attention to
crevices and hard to reach areas, until the surfaces are free of any
visible residue using one of the following solutions:
a. A cloth moistened with 70% isopropyl alcohol
b. A quaternary ammonium chloride solution wipe
c. A soft bristled brush as needed.
3. Repeat the above cleaning step using a fresh cloth or wipe.
4. Allow the sensor to thoroughly dry before using again.
The surfaces of the anesthesia sensor have been tested to be
chemically resistant to the following disinfections/solutions:
▪70% Isopropyl alcohol
▪70% Ethyl alcohol
▪Quaternary ammonium chloride solution wipes
▪Cidex®Plus (3.4% glutaraldehyde)
▪0.5% sodium hypochlorite (1:10 bleach to water solution)
▪Accelerated hydrogen peroxide
NOTICE
The airway adapters are not intended to be cleaned.

User Manual 15
C A U T I O N
▪DO NOT immerse the anesthesia sensor in any liquid and never
saturate the sensor completely with any disinfection solution.
▪DO NOT apply excessive pressure on the IR-windows.
Specifications
Measurements
Standard Conditions
The following measurement specifications are valid with no drift for dry
single gases at 22 ±5°C and 1013 ±40 hPa.
Gas
Range*
Accuracy
CO2
0 to 15 vol%
15 to 25 vol%
±(0.2 vol% +2% of reading)
Unspecified
N2O
0 to 100 vol%
±(2 vol% +2% of reading)
HAL, ISO, ENF
0 to 8 vol%
8 to 25 vol%
±(0.15 vol% +5% of reading)
Unspecified
SEV
0 to 10 vol%
10 to 25 vol%
±(0.15 vol% +5% of reading)
Unspecified
DES
0 to 22 vol%
22 to 25 vol%
±(0.15 vol% +5% of reading)
Unspecified
*All gas concentrations are reporting in units of volume percent and may be translated
into mmHg or kPa by using the reported atmospheric pressure.
All Conditions
The following measurement specifications are valid with no drift for all
specified environmental conditions except for interference specified in
the sections Interfering Gas Vapor Effect and Effects from Water Vapor
Partial Pressure on Gas Readings.
Gas
Accuracy
CO2
±(0.3 kPa +4% of reading)
N2O
±(2 kPa +5% of reading)
Agents**
±(0.2 kPa +10% of reading)
**The accuracy specification for the anesthesia sensor is not valid if
more than two agents are present in the gas mixture. If more than
two agents are present, an alarm will be set.

16 Certifier™ Anesthesia Sensor Kit Model 4093
Gas Concentration Conversion
Gas concentration is reported in units of volume percent. The
concentration is defined as: %gas = (partial pressure of gas
component)/(total pressure of gas component)*100.
Note that the total pressure of the gas mixture is estimated by
measuring the actual atmospheric pressure (range 525 to 1200 hPa)
in the sensor probe.
Electrical and Environmental
Item
Specification
Power Supply
4.5 to 5.5 VDC
≤1.4 W (normal operation @ 5V)
<2.0 W (power surge @ 5V can last up to
300 ms when entering measurement mode
from sleep mode or during start-up)
Operating Temperature
10°C to 40°C (50°F to 104°F)
Storage/Transport
Temperature
-40°C to 70°C (-40°F to 158°F)
Operating Humidity
<50 hPa H2O (non-condensing)
(68% RH at 40°C)
Storage/Transport
Humidity
10% to 95% RH (non-condensing)
(95% RH at 40oC)
Operating Atmospheric
Pressure
525 to 1200 hPa (525 hPa corresponding to
an altitude of 5211m/17,100 feet)
Storage/Transport
Atmospheric Pressure
500 to 1200 hPa (500 hPa corresponding to
an altitude of 5572m/18,280 feet)
Compliance
EN ISO 80601-2-55:2018,
EN 60601-1-2:2015, EN ISO 5356-1:2015,
MDD 92/42/EEC
Physical Characteristics
Item
Specification
Dimensions*
38 x 37 x 34 mm (1.49 x 1.45 x 1.34 in.)
Weight*
< 25 g (< 0.05 lbs.)
Cable Length
2.5 m ±0.1 m (98 in. ±4 in.)
Expected Service Life
5 years
*Excluding cable.

User Manual 17
General
Item
Specification
Data update frequency
20 Hz
Compensation
Automatic pressure, temperature and full
spectral interference correction.
Calibration
Zeroing recommended when changing
airway adapter, no span calibration
is required.
Warm-up time
<20 seconds (agent identification enabled
and full accuracy)
Rise time* (@ 10 l/min)
CO2≤90 ms
N2O ≤300 ms
HAL, ISO, ENF, SEV, DES ≤300 ms
Primary agent
threshold
0.15 vol%. When an agent is identified,
concentrations will be reported even below
0.15 vol% as long as apnea is not detected.
Agent identification
time
<20 seconds (typically <10 seconds)
Automatic agent
detection
Primary agent
Analyzer system
response time**
<1 second
Recovery time after
defibrillator test
Unaffected
Drift of measurement
accuracy
No drift
Surface temperature at
ambient temperature of
23°C (73.4°F)
Maximum 46°C (115°F)
Compliance
EN ISO 80601-2-55:2018,
EN 60601-1-2:2015, EN ISO 5356-1:2015
*Measured at 10 l/min with gas concentration steps corresponding to 30% of total
measuring range for each gas.
**Measured according to EN ISO 80601-2-55.

18 Certifier™ Anesthesia Sensor Kit Model 4093
Airway Adapters
Item
Specification
Disposable
adult/pediatric
Adds less than 6 ml dead space. Pressure
drop less than 0.3 cm H2O @ 30 L/min.
Disposable infant
Adds less than 1 ml dead space. Pressure
drop less than 1.3 cm H2O @ 10 L/min.
Effects from Water Vapor Partial Pressure on
Gas Readings
The effects of water vapor are illustrated by the examples in the
following table. The two columns on the right show the relative error in
displayed concentrations when adding or removing water vapor from
the gas mixture, and referencing the measurement to dry gas
conditions at actual temperature and pressure (ATPD) or saturated
conditions at body temperature (BTPS).
The table illustrates that the gas concentrations at body temperature
saturated (BTPS), are 6.2% lower than the corresponding
concentrations in the same gas mixture after removal of all water
vapor (ATPD).
Temp
(oC)
RH (%)
P
(hPa)
H2O part.
Press.
(hPa)
Err rel
(%)
Err rel
ATPD
(%)
Err rel
(%)
BPTS
10
20
1013
2
0
-0.2
6.0
20
20
1013
5
0
-0.5
5.7
25
0
1013
0 (ATPD)
0
0
6.2
25
23
1013
7.3
0
-0.7
5.5
25
50
1013
16
0
-1.6
4.6
30
80
1013
42
0
-4.1
2.0
37
100
1013
63 (BTPS)
0
-6.2
0
37
100
700
63
0
-9.0
-2.8

User Manual 19
Interfering Gas Vapor Effect
Gas or Vapor
Gas
Level
CO2
Agents
N2O
N2O 3
60 vol%
- 1 2
- 1
- 1
HAL 3
4 vol%
- 1
- 1
- 1
ENF, ISO, SEV 3
5 vol%
- 1
- 1
- 1
DES 3
15 vol%
- 1
- 1
- 1
O2 4
100 vol%
- 1 2
- 1
- 1
Note 1: Negligible interface, effect included in the measurement specifications.
Note 2: For probes not measuring N2O or O2the concentrations shall be set from the
host. The anesthesia sensor does not measure O2.
Note 3: According to EN ISO 80601-2-55 standard.
Note 4: In addition to the EN ISO 80601-2-55 standard.

________________
TSI and TSI logo are registered trademarks of TSI Incorporated in the United States and may
be protected under other country’s trademark registrations. Masimo is a registered trademark of
Masimo Corporation.
TSI Incorporated –Visit our website www.tsi.com for more information.
USA Tel: [phone]
UK Tel: [phone]
France Tel: [phone]
Germany Tel: [phone]
India Tel: [phone]
China Tel: [phone]
Singapore Tel: [phone]
P/N 6017331 Rev A ©2023 TSI Incorporated Printed in U.S.A.
