TSI Instruments CH-22 User manual

buyTSI.com - 800.223.4540
Contact us for any assistance
800.223.4540
Read this manual before operating
Tire Service International, LLC
3451 S. 40TH ST.
Phoenix, AZ 85040
Ofce: 602.437.5020
Email: [email protected]
Fax: [phone]
CH-22
Small Tire Changer
Revised: July 2022

buyTSI.com - 800.223.4540
1. Remove contents from box and assemble as shown below.
2. Read and follow instructions for optimum use.
3. The CH-22 Small Tire Changer accommodates tires ranging from 4” to 16.5” in diameter. This
is made possible by using different center posts and varying the position of the jaw clamps.
4. With the assortment of other available options, the Small Tire Changer is given a broader
range of tire size capabilities along with increasing a users operational exibility.
5. Use a suitable tire and tube lubricant for mounting and removal.
Notes and Safety Requirements
Primary Features and Replacement Parts
Handle and
Threaded Rod
Assembly
PN 6321
Small Center Post
1/2” and 3/4” Diameter
PN 10950
Mongoose Tire
Tool
PN 6239
Rim Size Decal
PN 4938
Jaw Clamp
PN 6318
Jaw Protector
PN 10793
Large Center Post
5/8” and 1” Diameter
PN 10951
Fig. 1Fig. 1
Pin
PN 144
WARNING - WEAR SAFETY GLASSES
USE CAUTION! Machine can pinch ngers if not careful.

buyTSI.com - 800.223.4540
Set-Up Notes
1. The CH-22 Multi-Tire Changer must be mounted to a solid, level surface, in a clean working
environment and with necessary clear access around the unit.
2. TSI has developed an optional Stand and Floor Plate which assemble into a convienient
package to raise the CH-22 for better handling, provide a tire Bead Breaker and include a
stable platform (see page 7).
A. The CH-23 Stand raises the CH-22 to a good working height, provides a very handy
Bead Breaker and tool storage.
B. The Floor Plate (PN 6192) provides a non-slip surface for the technician.
C. Assemble the three items and then bolt them to the oor
3. Loosen the tire bead before using the CH-22 Multi-Tire Changer
Operating Instructions
Determine the tire size being serviced and set
the jaw clamps (see Fig. 2) accordingly.
Put the pins in matching holes on the two arms
with the free-moving jaw clamps. Slide the jaw
clamps against the pins.
Fig. 2Fig. 2
For best results, have the longer area of the rim
facing down for the jaw clamps. (See Fig. 3)
Most the time the valve stem will be up and
accessible. If not, mount the tire and later ip it
over to connect an air hose to the valve stem for
adding air.
Fig. 3Fig. 3

buyTSI.com - 800.223.4540
Adjust the moveable jaw clamp using the
threaded rod assembly (see Fig. 4) so the tire
ange clears each of the jaws. Ideally the rim
should be centered over the center hole on the
Tire Changer.
Operating Instructions
Fig. 4Fig. 4
Fig. 5Fig. 5
Before tightening the rim, determine the largest
center post to t in the wheel hole (see Fig. 5).
Each post has two sizes.
Make sure to secure the edge of the rim and
tighten the adjusting clamp to secure the
wheel.
Fig. 6Fig. 6
Lubricate the tire and entire rim ange area
around the tire before mounting or dismounting
the tire (see yellow arrow in Fig. 5). Be sure to
use lubricant intended for tire and rim.

buyTSI.com - 800.223.4540
Operating Instructions
Make sure the tire bead is in the “drop center”
of the rim for this process. Press and hold with
one hand while prying the Mongoose Tire Tool
around the center post.
Demount deated tire using the “rod end” of
the Mongoose Tire Tool (see Fig. 7). The ball-
end is pushed under the top bead and rested
on the rim as illustrated. While holding the
Mongoose Tool against the center post with
one hand, and lifting up on the tire with the
other, rotate the tool full circle. Demount the
bottom bead the same way.
Vary the angle of the Mongoose Tire Tool
against the center post can achieve better
results for each user based on the different rim
or tire sizes and the shapes of each.
Fig. 7Fig. 7
Mounting the tire uses the "at-end" of
the Mongoose Tire Tool (see Fig. 8). While
applying pressure to the low side of the tire
(always facing the operator) place the ball-
end between rim and bead. With the at side
against the center post rotate the tool full circle
for both bottom and top beads.
Remember to use lubrication on the rim and
tire bead.
Optional Demount Tool (PN 12489)
To protect chrome or aluminum rims from tool
scrapes use this handy plastic accessory with
the regular size Mongoose Tire Tool or the the
Mini Mongoose Tire Tool.
Hold the Demount tab on the Mongoose Tire
Tool. Push down and into the tire ange/bead
area (see Fig. 9).
Fig. 8Fig. 8
Fig. 9Fig. 9

buyTSI.com - 800.223.4540
Operating Instructions
Insert the Demount tab into the rim ange
area (see Fig. 10). With your other hand guide
the tire beads into the “drop center” of the
rim opposite the side where you've placed the
Mongoose Tire Tool and demount tab.
Optional Mount Tool (PN 12488)
Fig. 12 shows optional PN 12488 Mount tab
with the Mongoose Tire Tool. Place the tire over
the rim and plunge the two tools over the edge
of the rim (see Fig. 13). Use the Mongoose Tire
Tool to pry against the center post in a circular
motion to mount the tire.
Fig. 10Fig. 10
Fig. 11Fig. 11
Fig. 12Fig. 12
Fig. 13Fig. 13
Repeat for both sides of the tire. Upon
mounting the tire wipe off the lubricant and
clean the tools and tire.
Loosen the Handle and Threaded Rod
Assembly to remove the tire.
USE LUBRICANT AND BE CAREFUL TO
AVOID PINCHING FINGERS
Pry up on the Mongoose Tire Tool and demount
tab in an arced motion so they rest on the rim
as shown in Fig. 11. With the tool against the
center post rotate them in a circular motion
around the post until the tire is free from the
rim.
Do this for both tire beads until the tire is
completely demounted.

buyTSI.com - 800.223.4540
CH-22 Tire Changer and Options
Small Tire Changer
CH-22
Optional Stand
with bead breaker
PN CH-23
Optional Floor
Plate
PN 6192
CH-22 shown
mounted to
OPTIONAL Stand
and OPTIONAL
Floor Plate
(sold separately)
Mini Mongoose
Tire Tool
PN CH-4M
Mongoose Tire Tool
PN 12489 and 12488
Optional Items

buyTSI.com - 800.223.4540
Register your product
online!
www.buytsi.com/registration
Visit www.buyTSI.com for any additional information. Also be sure to follow us on all the Socials,
and subscribe to our YouTube channel for all our product videos.
Copyright © 2022 Tire Service International, LLC
No part of this manual may be reproduced
without specic approval from Tire Service
International, LLC.
Warranty & Workmanship you can depend on.
With over 30 years of manufacturing experience we maintain the ability to provide competitive
prices while employing and manufacturing the majority of our products in the USA. Pride in
our workmanship and standing behind each and every product is not just our claim but our
uncompromising responsibility.
Tire Service International equipment is warranted to be free from defects in materials and
workmanship for a period of one year from the date of original purchase to the original owner.
Repair labor is warranted for 90 days from the date of original purchase. Bushings, blades, bearings
and normal wear and tear are not covered under warranty. Careless handling, negligence, misuse,
abuse, mutilation, improper operation, making unauthorized repairs, additions, and or alterations
automatically cancel this warranty and relieves TSI of any obligation. Cheetah tanks claimed to be
defective while under warranty will be evaluated at our manufacturing plant and either repaired
if possible or exchanged and returned or credit issued to the customer account at our discretion.
Damage resulting from dropping the tanks will not receive warranty consideration. Warranty parts
need to be returned prepaid to the plant for credit. Any replacement parts shipped from the plant
will be shipped at the customer's expense. Machines requiring warranty work must be brought to
the manufacturing plant in 201 Chelsea Rd, Monticello, MN or to a repair facility authorized by TSI.
!!WARNING!! Goods returned without an RGA will be refused. A Returned Goods Authorization
form must be obtained before returning any material or goods. All non-warranty returns will be
subject to a 15% restocking fee plus any additional charges for reconditioning/repacking.
Warranty and Return Policy
