TSL Tallyman TM1 User manual

TallyMan V1.81 on
|
Introduction
1
Tallyman Controller Installation Manual

TallyMan V1.81 on
|
Introduction
2
Contents
Introduction ............................................................................................................................................ 4
Installation .............................................................................................................................................. 5
TM1 ..................................................................................................................................................... 5
Connections .................................................................................................................................... 5
Pin out details ................................................................................................................................. 6
Default IP ....................................................................................................................................... 10
Initial setu ................................................................................................................................... 10
TM2 ................................................................................................................................................... 13
Connections .................................................................................................................................. 13
Pin out details ............................................................................................................................... 14
Default IP ....................................................................................................................................... 18
Initial setu ................................................................................................................................... 18
TM2+ ................................................................................................................................................. 21
Connections .................................................................................................................................. 21
Pin out details ............................................................................................................................... 22
Default IP ....................................................................................................................................... 28
Initial setu ................................................................................................................................... 28
TMC-1 ................................................................................................................................................ 31
Connections .................................................................................................................................. 31
Pin out details ............................................................................................................................... 32
Default IP ....................................................................................................................................... 34
Initial setu ................................................................................................................................... 34
S ecification .......................................................................................................................................... 35
TM1 ................................................................................................................................................... 35
Internal Power Supply Specification .......................................................................................... 35
TM2 ................................................................................................................................................... 36
Internal Power Supply Specification .......................................................................................... 36
TM2+ ................................................................................................................................................. 38
Internal Power Supply Specification .......................................................................................... 38
TMC-1 ................................................................................................................................................ 39
Internal Power Supply Specification .......................................................................................... 39
Motherboard ................................................................................................................................. 40
CPU ................................................................................................................................................ 40

TallyMan V1.81 on
|
Introduction
3
Memory ......................................................................................................................................... 40
Disk Drive (Solid state) .................................................................................................................. 40
Safety .................................................................................................................................................... 41
Installation ........................................................................................................................................ 41
Earthing/Grounding ...................................................................................................................... 41
Mounting ....................................................................................................................................... 41
Power ............................................................................................................................................ 41
Ventilation ..................................................................................................................................... 41
EC Declaration of conformity ........................................................................................................ 42
Warranty, Maintenance and Re air ..................................................................................................... 43
Failure during warranty .................................................................................................................... 43
Technical su ort information ......................................................................................................... 43
TSL Returns Procedure ...................................................................................................................... 43
Fault re ort details required ......................................................................................................... 43
Packing .......................................................................................................................................... 43

TallyMan V1.81 on
|
Introduction
4
Introduction
The following document covers installation of the TSL Tallyman controllers TM1, TM2, TM2+ and
TMC-1.
The TSL tally system consists of a number of dis lays, either discrete modules or Multiviewers / IMD
(In-Picture-Dis lay); controlled by a 19” 1RU remotely located TallyMan Controller.
The TallyMan Controller distributes ower and rovides the control for the dis lays. It also carries
user-defined interfaces for routing matrices, vision mixers and out ut drivers for cue lights and
additional tally control for cameras etc.
All o erational set-u s such as the router assignments, mnemonics and tally routing are
rogrammed with a set-u com uter running another version of TallyMan normally connected to
the Ethernet Port on the TallyMan Controller exce t in the case of the TMC-1 that is configured
locally.
Back to To ^

TallyMan V1.81 on
|
Instal
lation
5
Installation
TM1
The TallyMan controller should be installed in a standard 19” rack with good ventilation, no other
s ecial recautions need be taken, further information regarding earthing, mounting, ower etc may
be found in the Safety section.
Connections
Tally 1 This is for the arallel tallies. 1 – 32
Tally 2 This is for the arallel tallies 33 – 64
Control 1 RS422 – User Assignable. Used for Mixer/Router/Multiviewer connection
Control 2 RS422 – User Assignable. Used for Mixer/Router/Multiviewer connection
Control 3 RS232 – User Assignable. Used for Serial configuration of Controller Network
settings and available for Mixer/Router/Multiviewer connection
Control 4 RJ45 UMD Dis lay Ports - Power and RS422 serial data is available from these
orts.
Ethernet This is for configuration via the configuration PC and network comms with IP
ca able devices.
Power The unit is owered via an IEC 60320 C14 cou ler. The inlet is auto ranging 100-
240V. No cable is su lied with this device.
Back to To ^

TallyMan V1.81 on
|
Installation
6
Pin out details
Ethernet
The cable required to connect the TM1 controller with the configuring com uter is as follows:
Signal Name
RJ
-
45 Ethernet Pin
Numbers
Crosso er Cable
Pinouts
TX +
1
3
TX
-
2
6
RX +
3
1
EPWR
+ Power
4
4
EPWR + Power
5
5
RX
-
6
2
EPWR
-
Power
7
7
EPWR
-
Power
8
8
For a hub connection, use a straight-through cable. For TallyMan Controller to Com uter, use a
crossover cable
Back to To ^

TallyMan V1.81 on
|
Installation
7
Control Ports
Control orts 1 and 2 – Serial RS422
Pin Numbers
Signal
Pin Numbers
Signal
1
0v/Chassis
6
0v
2
TX
-
7
TX+
3
RX+
8
RX
-
4
0v
9
0v
5
-
Control Port 3 – Serial RS232 (Maintenance ort)
Pin Numbers
Signal
Pin Numbers
Signal
1
-
6
-
2
RX
7
RTS
3
TX
8
CTS
4
DTR
9
-
5
0v
Control Port 4 - Serial RS422 Dis lay Ports
RJ45 DISPLAY CONNECTORS
1
0v
2
0v
3
RX
-
4
TX+
5
TX
-
6
RX+
7
+24v
8
+24v
The Dis lay orts are wired in to in, all 8 dis lay orts are aralleled and are addressed as ort 4.
UMD dis lays should be distributed evenly between the eight dis lay drive out uts on the TM1
controller. Cables to the UMDs should be screened CAT5 cable, in order to conform to Euro ean CE
requirements it is recommended that CAT5E FTP cable is used.
Back to To ^

TallyMan V1.81 on
|
Installation
8
Parallel Tally connectors
TALLY 1 & 2 INPUT/OUTPUT CONNECTORS
D37 SOCKET
1
TALLY 1
20
TALLY 20
2
TALLY 2
21
TALLY 21
3
TALLY 3
22
TALLY 22
4
TALLY 4
23
TALLY 23
5
TALLY 5
24
TALLY 24
6
TALLY 6
25
TALLY 25
7
TALLY 7
26
TALLY 26
8
TALLY 8
27
TALLY 27
9
TALLY 9
28
TALLY 28
10
TALLY 10
29
TALLY 29
11
TALLY 11
30
TALLY 30
12
TALLY 12
31
TALLY 31
13
TALLY 13
32
TALLY 32
14
TALLY 14
33
0v
15
TALLY 15
34
+12 / +24V see note
16
TALLY 16
35
Ext Voltage Ref Pin
17
TALLY 17
36
0v
18
TALLY 18
37
-
19
TALLY 19
Parallel (GPI) tallies are connected directly to the Tally 1 and Tally 2 D37 connectors on the TM1
controller.
These are freely assignable as in uts or out uts in grou s of eight. Tally in uts will occu y the lowest
numbered ins starting with the Tally 1 connector. The out ut arallel tallies (if any are assigned)
will start from the next available in on the D37 connector.
The following tally in/ out arrangements are ossible between the Tally 1 and Tally 2 connectors:
Inputs
Outputs
0
64
8
56
16
48
24
40
32
32
40
24
48
16
56
8
64
0

TallyMan V1.81 on
|
Installation
9
Tally inputs
A ground or 0V to the in is required to activate a tally in ut. The common or ground connection is
connected to in 36.
Tally outputs
Tally out uts consist of o en collector driver circuits. Common (ground) a ears on in 36. The
circuit is ca able of sinking a roximately 150mAto ground to activate relays etc.
Notes:
1) Pin 34 carries a +12 V, or from Serial Number: 66200 +24V su ly rated at 0.5A. Do not use
this internal +12V for relay coil su ly.
2) Pin 35
LK1 on the internal EAB2 cards is set for the ull-u resistors to be referenced to normally + 5V or, by
changing the link to ositions Centre/Ext, an external voltage reference a lied to Pin 35 on the D37
connector.
If using an external voltage above 5V, the link on the card should be set for external ull-u ( osition
2-3, labelled EXT, away from the D37), and the external voltage should be a lied to Pin 35. Putting
the link to EXT and a lying the voltage to Pin 35 also enables the onboard s ike su ression diodes.
Back to To ^

TallyMan V1.81 on
|
Installation
10
Default IP
The default IP arameters of TSL Tallyman controllers are:
IP Address: 192.168.205.121
Subnet Mask: 255.255.255.0
Connection for configuration ur oses is via a PC running TallyMan, available for download from the
TSL website www.TSL.co.uk
Initial setup
Connect a PC running a terminal rogram (Hy er terminal/Putty/Tera Term Pro for exam le) to the
Maintenance Port, Port 3 on the TallyMan controller.
Hy erTerminal Settings

TallyMan V1.81 on
|
Installation
11
Start Hy erTerminal and then ower u the TM1 and wait for about 10 seconds. Press Y on the
keyboard within 1 sec of the message a earing. Follow the on-screen instruction
•Pressing S or Enter on the PC’s keyboard will set the TallyMan units as the Main Unit
•Pressing C will set it as a Controller so that it may be an Object in the system tree under a
Main Controller, this is not necessary to share objects and tally information between
controllers, more information on object sharing can be found in the sharing objects section
of the TallyMan configuration manual.
•Pressing B will set the unit as a Redundant Backu unit. See the section on Backu for
information on how to use this facility.
•Pressing D will delete the current setu file; ressing any other key will allow access to the IP
settings.
•Pressing Y will revert the unit to factory software and will downgrade the unit to the revious
version of the TallyMan Program rovided that an u grade has taken lace in the field.
•IP Addresses are set as shown. If no entry is made and Enter in the PC’s keyboard is ressed
the original settings will be ke t.
When all settings are correct remove the RS232 cable and re- ower the unit.
Notes.
Use the following cable to connect your PC comm. Port to Port 3 of the TallyMan:

TallyMan V1.81 on
|
Installation
12
PC
TM1
2
3
3
2
5
5
Back to To ^

TallyMan V1.81 on
|
Installation
13
TM2
The TallyMan controller should be installed in a standard 19” rack with good ventilation, no other
s ecial recautions need be taken, further information regarding earthing, mounting, ower etc may
be found in the Safety section.
Connections
Tally 1 This is for the arallel tallies. 1 – 32
Tally 2 This is for the arallel tallies 33-64
Tally 3 This is for the arallel tallies 65-96
Tally 4 This is for the arallel tallies 97-128
Control 1 RS422 – User Assignable. Used for Mixer/Router/Multiviewer connection
Control 2 RS422 – User Assignable. Used for Mixer/Router/Multiviewer connection
Control 3 RS232 – User Assignable. Used for Serial configuration of Controller Network settings
and available for Mixer/Router/Multiviewer connection
Control 4 RJ45 UMD Dis lay Ports - Power and RS422 serial data is available from these orts.
Control 5 RS422 – User Assignable. Used for Mixer/Router/Multiviewer connection
Control 6 RS422 – User Assignable. Used for Mixer/Router/Multiviewer connection
Control 7 RS422 – User Assignable. Used for Mixer/Router/Multiviewer connection
Ethernet This is for configuration via the configuration PC and network comms with IP ca able
devices.
Power The unit is owered via an IEC 60320 C14 cou ler. The inlet is auto ranging 100-
240V. No cable is su lied with this device.
Back to To ^

TallyMan V1.81 on
|
Installation
14
Pin out details
Ethernet
The cable required to connect the TM2 controller with the configuring com uter is as follows:
Signal Name
RJ
-
45 Ethernet Pin
Numbers
Crosso er Cable
Pinouts
TX +
1
3
TX
-
2
6
RX +
3
1
EPWR + Power
4
4
EPWR + Power
5
5
RX
-
6
2
EPWR
-
Power
7
7
EPWR
-
Power
8
8
For a hub connection, use a straight-through cable. For TallyMan Controller to Com uter, use a
crossover cable
Back to To ^

TallyMan V1.81 on
|
Installation
15
Control Ports
Control orts 1,2,5,6 & 7 – Serial RS422
Pin Numbers
Signal
Pin Numbers
Signal
1
0v/Chassis
6
0v
2
TX
-
7
TX+
3
RX+
8
RX
-
4
0v
9
0v
5
-
Control Port 3 – Serial RS232 (Maintenance ort)
Pin
Numbers
Signal
Pin Numbers
Signal
1
-
6
-
2
RX
7
RTS
3
TX
8
CTS
4
DTR
9
-
5
0v
Control Port 4 - Serial RS422 Dis lay Ports
RJ45 DISPLAY CONNECTORS
1
0v
2
0v
3
RX
-
4
TX+
5
TX
-
6
RX+
7
+24v
8
+24v
The Dis lay orts are wired in to in, all 8 dis lay orts are aralleled and are addressed as ort 4.
UMD dis lays should be distributed evenly between the eight dis lay drive out uts on the TM2
controller. Cables to the UMDs should be screened CAT5 cable, in order to conform with Euro ean
CE requirements it is recommended that CAT5E FTP cable is used
Back to To ^

TallyMan V1.81 on
|
Installation
16
Parallel Tally connectors
TALLY 1,2,3 & 4 INPUT/OUTPUT CONNECTORS
D37 SOCKET
1
TALLY 1
20
TALLY 20
2
TALLY 2
21
TALLY 21
3
TALLY 3
22
TALLY 22
4
TALLY
4
23
TALLY 23
5
TALLY 5
24
TALLY 24
6
TALLY 6
25
TALLY 25
7
TALLY 7
26
TALLY 26
8
TALLY 8
27
TALLY 27
9
TALLY 9
28
TALLY 28
10
TALLY 10
29
TALLY 29
11
TALLY 11
30
TALLY 30
12
TALLY 12
31
TALLY 31
13
TALLY 13
32
TALLY 32
14
TALLY 14
33
0v
15
TALLY 15
34
+12 / +24V see note
16
TALLY 16
35
Ext Voltage Ref Pin
17
TALLY 17
36
0v
18
TALLY 18
37
-
19
TALLY 19
Parallel (GPI) tallies are connected directly to the Tally 1, 2, 3 & 4 D37 connectors on the TM2
controller.
These are freely assignable as in uts or out uts in grou s of eight. Tally in uts will occu y the lowest
numbered ins starting with the Tally 1 connector. The out ut arallel tallies (if any are assigned)
will start from the next available in on the D37 connector.
The following tally in/out arrangements are ossible between the Tally 1 and Tally 2 connectors:
Inputs
Outputs
0
64
8
56
16
48
24
40
32
32
40
24
48
16
56
8
64
0

TallyMan V1.81 on
|
Installation
17
Tally inputs
To activate a Tally in ut, ull the relevant in to ground or 0V. The common or ground connection is
connected to in 36.
Tally outputs
Tally out uts consist of o en collector driver circuits. Common (ground) a ears on in 36. The
circuit is ca able of sinking a roximately 150mAto ground to activate relays etc.
Notes:
1) Pin 34 carries a +12 V, or from Serial Number: 66200 +24V su ly rated at 0.5A. Do not use
this internal +12V for relay coil su ly.
2) Pin 35
LK1 on the internal EAB2 cards is set for the ull-u resistors to be referenced to normally + 5V or, by
changing the link to ositions Centre/Ext, an external voltage reference a lied to Pin 35 on the D37
connector.
If using an external voltage above 5V, the link on the card should be set for external ull-u ( osition
2-3, labelled EXT, away from the D37), and the external voltage should be a lied to Pin 35. Putting
the link to EXT and a lying the voltage to Pin 35 also enables the onboard s ike su ression diodes.
Back to To ^

TallyMan V1.81 on
|
Installation
18
Default IP
The default IP arameters of TSL Tallyman controllers are:
IP Address: 192.168.205.121
Subnet Mask: 255.255.255.0
Connection for configuration ur oses is via a PC running TallyMan, available for download from the
TSL website www.TSL.co.uk
Initial setup
Connect a PC running a terminal rogram (Hy er terminal/Putty/Tera Term Pro for exam le) to the
Maintenance Port, Port 3 on the TallyMan controller.
Hy erTerminal Settings

TallyMan V1.81 on
|
Installation
19
Start Hy erTerminal and then ower u the TM2 and wait for about 10 secs. Press Y on the
keyboard within 1 sec of the message a earing. Follow the on-screen instruction
•Pressing S or Enter on the PC’s keyboard will set the TallyMan units as the Main Unit
•Pressing C will set it as a Controller so that it may be an Object in the system tree under a
Main Controller, this is not necessary to share objects and tally information between
controllers, more information on object sharing can be found in the sharing objects section
of the TallyMan configuration manual.
•Pressing B will set the unit as a Redundant Backu unit. See the section on Backu for
information on how to use this facility.
•Pressing D will delete the current setu file; ressing any other key will allow access to the IP
settings.
•Pressing Y will revert the unit to factory software and will downgrade the unit to the revious
version of the TallyMan Program rovided that an u grade has taken lace in the field.
•IP Addresses are set as shown. If no entry is made and Enter in the PC’s keyboard is ressed
the original settings will be ke t.
When all settings are correct remove the RS232 cable and re- ower the unit.
Notes.
Use the following cable to connect your PC comm. Port to Port 3 of the TallyMan:

TallyMan V1.81 on
|
Installation
20
Back to To ^
PC
TM2
2
3
3
2
5
5
