Tsurumi Pump PL Series Instructions for use

☎
US 1-866-877-6637 |
☎
CAN 1-866-766-3426 |www.aquascapeinc.com
1
www.aquascapeinc.com
801172001429 / B-10091-4
Waterfall and vault
water pump
For Model:
• 3-PL (Item #29975)
• 5-PL (Item #29976)
• 9-PL (Item #29977)
INSTRUCTIONS & MAINTENANCE
PL Series
Solids Handling
Pond Pump
Made in Japan, by Tsurumi Mfg. Co. Ltd.

☎
US 1-866-877-6637 |
☎
CAN 1-866-766-3426 |www.aquascapeinc.com
2
PL Series
Solids Handling Pond Pump
AQUASCAPE
Aquascape
Solids Handling Pond Pump
Model
Serial Number DOM Y/M
Performance Range
1,400 gph. - 3,000 gph.
Bore: 2” Input Watts: 320 Volts: 115
AMP: 3.2 PH: 1 Hz:60 Pole:2 Ins: E
01653
3-PL
ROTATION
PL Series
Solids Handling Pond Pump
Introduction

☎
US 1-866-877-6637 |
☎
CAN 1-866-766-3426 |www.aquascapeinc.com
3
Keep this manual or a copy of it with the machine. If you lose this manual or need an additional
copy, please visit our website at www.aquascapeinc.com. This machine is built with user safety
in mind, however, it can present hazards if improperly operated and serviced. Follow operating
instructions carefully! If you have questions about operating or servicing this equipment, please
contact Aquascape at US 1.866.877.6637 | CAN 1.866.766.3426
WARNING
• Reduce the risk of electric shock - Refer to instruction manual for proper
installation before connecting to power supply.
• Risk of electric shock - To reduce the risk of electric shock, pumps supplied with a
grounding-type attachment plug shall be connected to a properly grounded,
grounding-type receptacle. Install only on a circuit protected by a ground-fault circuit
interrupter (GFCI).
• Risk of electric shock - This pump has not been investigated for use in
swimming pool, deep well, fountains or marine areas.
• Only qualified persons shall conduct service and/or install an acceptable motor-
control switch and attachment plug, or approved enclosure with applicable fittings, for
power supply connection according to federal, state and local codes.
• If connected to a circuit protected by a fuse, use a type D (time-delay) fuse.
• The pump must not be used when people are in the water.
• Leakage of pump lubricants may cause pollution of water.
• Proper plug must be provided according to local codes and standards. Refer to wiring
diagram.
• Never operate pump while it is suspended in air. The recoil may result in injury or
other major accident.
• Do not use in the vicinity of explosive or flammable materials.

☎
US 1-866-877-6637 |
☎
CAN 1-866-766-3426 |www.aquascapeinc.com
4
PL Series
Solids Handling Pond Pump
5
6
6
7
7
8
9
10
11
13
16
18

☎
