TTI TSC-3000R User manual
MULTIBAND SCANNING RECEIVER
INSTRUCTION MANUAL
www.ttikorea.co.kr
Manufactured by
TSC-3000R
CAUTIONS................................................. 5
1. SUPPLIED ACCESSORIES ...................... 6
2. FITTING AND REMOVING THE BATTERY
PACK ......................................................... 6
3. INSTALLING THE ANTENNA .................... 7
4. INSTALLING THE LANYARD .................... 7
5. CHARGING THE BATTERY ...................... 8
6. CONTROLS .............................................. 10
Power On/Off Lock Button .................. 11
Control Knob ....................................... 11
Up/Down Keys.................................... 11
Squelch Up/Down Keys ...................... 11
Function Keys..................................... 11
Menu Keys.......................................... 11
Enter/VFO Keys ................................. 11
Keypad................................................ 11
Accessory Jack .................................. 11
LCD Display........................................ 11
Jack Cover Securiting Point ................ 11
Antenna............................................... 11
Lanyard Slot ...................................... 11
7. KEYPAD .................................................... 12
8. EXTENDED FUNCTION KEYS ................ 13
AW ....................................................... 14
MW .......................................................14
MR .......................................................14
CANC ...................................................14
MODE ..................................................14
SKIP.....................................................14
DW .......................................................14
PRI ......................................................14
TONE ...................................................14
DLY ......................................................14
LMT ......................................................14
ATT ......................................................14
CONTENTS
ENGLISH
9. LCD DISPLAY ............................................ 15
10. GENERAL OPERATION ........................... 16
Turning the unit On or OFF..................16
KEY Lock ............................................ 16
Volume................................................ 16
Squelch............................................... 16
Func Keys .......................................... 16
Menu Keys.......................................... 17
E/VFO Key [Enter/VFO] ...................... 17
Control Knob ....................................... 17
11. SELECTING FREQUENCIES ................... 18
Direct Frequency Input ........................ 18
Using the Control Knob ....................... 19
Mode Selection ................................... 20
Frequency Step Selection ................... 21
12. FREQUENCY BANDS............................... 22
13. FREQUENCY SEARCH ............................ 23
Band Search....................................... 23
Full Search ..........................................24
Limited Search .................................... 25
Priority Search.................................... 28
Dual Watch ......................................... 30
14. MEMORY BANKS ..................................... 31
Manual Memories............................... 31
Automatic Memories ........................... 31
Limited Search Memories................... 32
Dual Watch Memories........................ 32
15. STORING FREQUENCIES INTO THE
MEMORIES ............................................... 33
Manual Memories............................... 33
Automatic Memories........................... 35
Limited Search Memories ................... 37
Dual Watch Memories........................ 40
16. CHANNEL SCAN ....................................... 42
Band Scan.......................................... 42
Full Scan............................................. 43
Priority Scan ....................................... 44
CONTENTS
ENGLISH
17. MENU SETTINGS ...................................... 46
VFO Mode ........................................... 47
Memory Read Mode ............................ 48
18.COPYING FREQUENCIES BETWEEN
MEMORY BANKS ...................................... 49
Bank Copy ...........................................49
Channel Copy ..................................... 50
Channel Move .................................... 51
All Clear .............................................. 52
Bank Clear .......................................... 53
Channel Clear ..................................... 54
19. CLONING STORED MEMORIES WITH
ANOTHER UNIT ....................................... 55
20. SPECIFICATION ....................................... 56
General ............................................... 56
Bank Copy ...........................................57
21. NOTES .......................................................58
CONTENTS
ENGLISH
• Please read these instructions carefully before operating your
receiver. Your scanner is a complex and powerful unit with many
functions. Please retain this manual for future reference. Any
illegal use offending the national law is not allowed.
Never connect the receiver to the power source other than the
specified battery. Otherwise the damage to your receiver may
occur.
• Ne v er use the receiver in or near the mining area, near
explosives or where signs indicate ‘Blasting Area’. Never use or
charge the receiver in a potentially explosive atmosphere.
• Do Not place the receiver in front of the vehicle airbag.
Do Not operate the receiver on board the aircraft.
Always charge the receiver at normal room temperature.
• Always replace the accessory jack cover when the jack is not in
use.
• Use only munufacturer-supplied rechargeable battery in your
receiver.
• Do Not expose the receiver to water. It is not waterproof.
Avoid storing or charging the receiver in direct sunlight.
• Avoid storing the receiver in temperatures below -20°C or
above +60°C .
CAUTIONS
5
TSC-3000R
ENGLISH
Removing
1) Ensure the receiver is switched
off.
2) Holding the receiver in one hand,
press down on the battery
release catch.
3) List the top of the battery pack
away from the receiver.
• Scanner Receiver
• Antenna
• Lanyard Strap
• Rechargeable Battery Pack
• Earphone
• Charger Cradle
• Power Adaptor
SUPPLIED ACCESSORIES
FITTING AND REMOVING THE BATTERY PACK
Fitting
1) Ensure the receiver is switched
off.
2) Align the bottom of the battery
pack with the securing slots in
the base of the receiver.
3) Press the top of the battery pack
into the back of the receiver until
it ‘clicks’.
ENGLISH
6
TSC-3000R
1) Place the antenna onto the
antenna socket on top of the radio.
2) Rotate the antenna clockwise to
screw into place.
3) Do not over tighten.
INSTALLING THE ANTENNA
1) Slide the small end loop of the
lanyard through the slot in the rear
of the receiver’s top panel.
2) Feed the large end of the lanyard
through the loop and tighten.
INSTALLING THE LANYARD
7
TSC-3000R
ENGLISH
Your scanner receiver is supplied with a rechargeable battery
pack, desktop charging cradle and AC adaptor.
The charging time for a discharged battery is typically 12– 15
hours. When the battery is fully charged, the LED will turn GREEN.
To charge the battery:
1) Fit the battery to the receiver (see instructions above). Ensure
the receiver is switched off.
2) Connect the AC Adaptor to the charging cradle.
3) Plug the AC adaptor into a mains power outlet.
4) Insert the receiver into the charging cradle until it ‘clicks’ home.
The charging LED will glow RED and charging will begin.
• If the charging LED blinks RED and GREEN or does not light
at all, remove the receiver into the cradle and reinsert it.
CHARGING THE BATTERY
ENGLISH
8
TSC-3000R
21
3
4
Adaptor DC Plug
1AC Adaptor
2
Charging LED
3Chaging Cradle
4
NOTE : If you find yourself in a position where you need to charge
the battery but the charging Cradle is not available, you
can plug the AC Adaptor directly into the receivers
charging socket located under the Accessory Jack cover.
9
TSC-3000R
ENGLISH
CONTROLS
1
9
11
12
7
8
10
13
4
6
5
3
2
Keypad
8
Accessory Jack
9
LCD Display
10
Jack Cover Securing Point
11
Antenna
12
Lanyard Slot
13
Power On/Off Lock Button
1
Control Knob
2
Up/Down Keys
3
Squelch Up/Down Keys
4
Function Key
5
Menu Key
6
Enter/VFO Key
7
10
TSC-3000R
