TTS Easi-Speak Sound-Station User manual

™
User Guide
Version 3
Please Read All Instructions Carefully Before Using

Sound-Station User Guide
2
Please retain these instructions for future reference
Sound-Station contains a rechargeable NiMH
battery pack
Do not attempt to remove the battery.
The external charger must be regularly examined for
potential hazard, such as damage to the cable or
cord, plug, enclosure or other parts and that in the
event of such damage, the Sound-Station must not
be used until that damage had been properly
rectified
Rechargeable batteries are only to be charged under
adult supervision
Do not short-circuit the supply terminals.
Do not allow your Sound-Station to come into
contact with water or other liquids
In the event of an electro-static discharge, your
Sound-Station may malfunction. In this case, you
may need to turn it off to reset it
Warranty is void if the case is opened for any reason
The warranty does not cover any data loss from the
Easi-Speak unit nor any consequential loss of
information

Sound-Station User Guide
3
FCC compliance
NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR
ANY RADIO OR TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID
THE USER AUTHORITY TO OPERATE THE
EQUIPMENT
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help

Sound-Station User Guide
4
Know Your Sound-Station
Jack Plug –connects to headphone
socket on your Easi-Speak
Stereo speakers
Power LED
Line-in
socket
6 x Headphone
Sockets
d.c. socket for
external charger
On/Off
Volume

Sound-Station User Guide
5
Using Your Sound-Station
The Easi-Speak connects to the Sound-Station via the
headphone output socket. With the USB cap in place,
turn the Easi-Speak until the headphone socket faces the
male jack plug on the Sound-Station and push it into
place. Turn the Sound-Station on and press the Easi-
Speak play button, then adjust the Sound-Station volume
control to the desired level. It may be necessary to
increase the Easi-Speak volume, before docking, to
achieve the best results (the volume controls are not
accessible once the Easi-Speak is docked).
Power LED
The power LED is illuminated whenever the Sound-
Station is turned on. When not in use turn your Sound-
Station off by rotating the volume switch until you hear
a “click” and the Red power light turns off.
Charging the Battery
Sound-Station is supplied with a partially charged battery
and can be used immediately without charging first. The
battery can be charged by connecting the external power
supply to the d.c. power input.
Even when the battery is fully discharged, Sound-
Station will operate normally when the external power
supply is connected whilst charging the battery at the
same time.

Sound-Station User Guide
6
A complete charge of a fully discharged battery will
take about 24 hours. The Sound-Station is intended to
be permanently left on charge so that it is always ready
for use.
Technical specification
Built-in 1300mAH NiMH battery
Output power 2W RMS (Typ)
Total Harmonic Distortion+Noise 0.3% (Typ)
Six stereo 3.5mm headphone sockets(Green)
One stereo 3.5mm line-in socket (Pink), 100mV RMS
Max
Battery life approx 3 hours (depends on volume
setting and type of audio)
External PSU: 100 –240 VAC, 6V DC 1500 mA,
Centre positive
Weight 816g
Dimensions 310 x 193 x 90mm

Sound-Station User Guide
7
Troubleshooting
Sound-Station is designed to work reliably and
predictably in all normal conditions. However, it is
possible that problems may occur. Please check the
following before contacting technical support:
Problem
Power LED appears dim
Solution
Battery is low. Charge the battery.
Sound-Station can be used whilst
charging
Problem
Power LED doesn’t come on
Solution
Battery completely flat. Recharge
Problem
Sound is too quiet
Solution
The Easi-Speak recording is very quiet.
Increase the Easi-Speak volume setting
before docking
Problem
Sound is distorted
Solution
Reduce the Sound-Station volume until
the sound is free from distortion.

Sound-Station User Guide
8
Support & Warranty
This product is provided with a one-year warranty for
problems found during normal usage. Mistreating the
Sound-Station™ or opening the unit will invalidate this
warranty. Any data stored on the Easi-Speak and any
consequential loss is not covered by this warranty. The
battery is not user replaceable.
All out of warranty repairs will be subject to a
replacement fee.
Please visit www.tts-group.co.uk for latest product
information.
Email feedback@tts-group.co.uk for technical
support.
TTS Group Ltd Freephone: 0800 318686
Park Lane Business Park Freefax: 0800 137525
Kirkby-in-Ashfield
Nottinghamshire, UK
NG17 9GU

Sound-Station User Guide
9
RMEducational Software, Inc TTS Group Ltd
310 Barnstable Road Park Lane Business Park,
Suite 101, Unit A & B Kirkby-in-Ashfield,
Hyannis, MA 02601 Nottinghamshire,
USA NG17 9LE
+1 508 862 0700 United Kingdom
+44(0)800 318 686
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any
interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user's authority to operate the
equipment.
