TUF 1.2 XL User manual

Operating Manual
TUF 1.2 XL

2
TABLE OF CONTENTS
Safety Instructions………………………………………………………........……Page 2-3
Description………………………………..………………………….....………….Page 4-6
Operation………………………………..……………………………….....………Page 6-9
Application………………………………..………………….....….….……………Page 10-11
Maintenance……………………………..……….…….………………….......…..Page 12
Troubleshooting…………………………………..…………………….…….....…Page 13
SAFETY INSTRUCTIONS
WARNING: BE SURE to read and understand all instructions in this manual before
using this level. Failure to follow all instructions may result in hazardous radiation
exposure, electric shock, fire and/or serious personal injury.
CAUTION: Do not attempt to modify the performance of the laser device in any way.
This may result in a dangerous exposure to laser radiation.
WARNING: LASER RADIATION. Do not stare into beam. Class 2 laser product.
Turn the laser beam on only when using this tool.
WARNING: Use of controls, adjustments, or the performance of procedures other
than those specified in this manual may result in hazardous radiation exposure.
WARNING: The use of optical instruments such as, but not limited to, telescopes or
transits to view the laser beam will increase eye hazard.
• Do not remove or deface any product labels.
• Avoid direct eye exposure. The laser beam can cause flash blindness.
• The laser level is not a toy. Always keep it out of the reach of children.
• The laser light emitted from this tool should never be directed toward any person for
any reason.
• Do not operate the tool around children or allow children to operate the tool.

3
• Do not place the tool in a position that may cause anyone to stare at the laser beam,
whether intentionally or unintentionally.
• Do not use on surfaces such as sheet steel that have shiny, reflective surfaces. The
reflective surface could reflect the beam back at the operator.
• Always turn the tool off when not in use. Leaving the tool on increases the risk of
someone inadvertently staring into the laser beam.
• Do not attempt to modify the performance of this laser device in any way. This may
result in a dangerous exposure to laser radiation.
• Do not attempt to repair or disassemble the laser level. If unqualified persons
attempt to repair this product, serious injury may occur. Any repair required on this
laser product should be performed only by authorized service personnel.
• Do not operate the tool in combustible areas, such as in the presence of flammable
liquids, gases, or dust.
• Use of other accessories that have been designed for use with other laser tools
could result in serious injury.
• Keep batteries out of reach of children.
NOTES
• Avoid heavy impact or falling of the tool. After heavy exterior impact on the tool, an
accuracy check should always becarried out before work.
• Avoid exposing the tool to crash, shock, continuous vibration, do not position the
tool in the tailstock box of the car or motorcycle.
• Avoid exposing the tool to extreme hot or cold temperature. Protect the tool against
direct sun irradiation.
• Switch the tool off during transportation or when carrying it by the carrying bag.
When switching off, the levelling pendulum will be locked to protect the accuracy.
• Clean the tool with a soft, wet cloths. Do not clean it directly on the water faucet, it
will damage the tool.

4
DESCRIPTION
This Auto Leveling Laser Level has a compact design. The small size makes it easy to
bring with you. The integrated rubber ensures a comfortable grip and can protect the
level from damage when suffering an accidental impact.
The projected laser lines are leveled automatically. The Auto Leveling Laser Level
is equipped with a safety feature that locks the laser unit when it is switched off and
protects it from damage.
1. KNOW YOUR TOOL
Fig.1
2
1
9
6
7
8
4
5
3

5
1) ON/OFF switch: turn on/off the tool, lock/unlock the pendulum.
2) Function panel: switch the working modes and indicate the working status.
3) Laser light aperture: the side vertical laser is projected from this aperture.
4) Laser light aperture: the front vertical laser is projected from this aperture.
5) Laser light aperture: the front horizontal laser is projected from this aperture.
6) Battery compartment: holds three “AA” batteries.
7) Laser aperture for lower laser dot
8) 1/4” (6.35 mm) threaded tripod hole: for mounting
the Auto Leveling Laser Level to a general tripod (sold
separately).
9) Conversion adapter: by this adapter, the tool can
be mounted on a 5/8” (15.9mm) threaded tripod (only
available in tripod version).
Function panel (Fig. 2)
1) Mode button: cycles the Auto Leveling Laser Level
through six laser projection modes when depressed
repeatedly.
2) Indoor/outdoor measurement switch button: cycles
the measurement mode between indoors and outdoors. The fault mode is indoor
measurement.
3) LED indicator of indoor measurement: indicates the working status of indoor
measurement. Green means the tool works in self leveling; red means the tool works
in the locking mode, or over its maximum working range 4°. The LED blinking in red
means low battery.
4) LED indicator of outdoor measurement: indicates the working status of outdoor
measurement. Green means the tool works in self leveling; red means the tool works
in the locking mode, or over its maximum working range 4°. The LED blinking in red
means low battery.
1
MODE
SHIFT
indoor outdoor
4
3
2
Fig.2

6
SPECIFICATION
Model No. 1.2 XL
Working range to approx. 20m *
Accuracy ±0.3mm/m
Working range ±4°
Laser type 635(laser line) /650nm (laser dot), P<2mW
Laser class Class 2
Working temperature -5°C – 50°C
Storage temperature -20°C – 70°C
Tripod nut 1/4”
Batteries 3 “AA” 1.5V batteries
Estimated battery life About 6 hours (with alkaline batteries)*
IP Class (excluding battery compartment) IP54 (dust and splash water protected)
* The maximum working range will be reduced in bright condition.
** The battery life is tested in standard condition with all lasers being turned on. To
extend the battery life, shut off the laser line not used, e.g. shut off the plumb line when
performing a level measurement.
OPERATION
To Install/Replace Batteries (Fig. 3)
This Auto Leveling Laser level uses three “AA” alkaline batteries.
1. Push the hook as the arrow to take away the battery cover.
2. Insert three new “AA” alkaline batteries, following the polarity (+/-) as indicated on the
inside of the battery compartment.
3. Replace the battery cover and lock it in place.
CAUTION: Always turn the level off before installing or replacing the batteries.
NOTE:
• Replace the batteries when the LED indicator blinks in red. The laser will be shut off

7
in one hour approximately from the
LED indicator starts to blink. Shutting
off the laser line not used can extent
the battery life.
• Remove the batteries when the tool
is not used for a period of time.
• Do not mix old and new batteries.
• The 3 AA batteries should match
each other in brand and type.
• Remove depleted batteries
immediately, and dispose of them
according to your local ordinance.
Never dispose of batteries in fire.
Turn ON/OFF the Auto Leveling Laser
Level (Fig. 4)
1. Push the ON/OFF switch to the “ON”
position” to turn on the laser. The Auto
Leveling Laser Level defaults to turn
on all the lasers. The LED indicator of
indoor measurement will be lit at the
same time.
2. Push the ON/OFF switch to the “OFF”
position to shut off the laser. The
pendulum will be locked to protect the
accuracy.
Laser Line Projection Modes
The Auto-Leveling Laser Level has
six laser projection modes. To select
a specific laser projection mode, press the Mode button until you reach the desired
projection mode. This laser level defaults to turn on all the lasers when it is switched on.
Fig.3
Fig.4

8
To choose a projection mode, press the Mode button:
1. Once to select the front horizontal and vertical laser lines.
2. Two times to select the front horizontal laser line.
3. Three times to select the front vertical laser line.
4. Four times to select the front vertical line, side vertical line and lower laser dot. The
two vertical lines are crossed on the ceiling.
5. Five times to select lock mode, all the laser will be turned on.
6. Six times to return to the default mode.
NOTE:
• In the lock mode, the lasers are projected continuously even if the slope angle
exceeds 4°; The LED indicator lights in red. This mode can not be used to perform
horizontal or vertical leveling, because the laser lines/dot are no longer self-
balancing.
• In the other modes, LED lights in green when the tool is self leveled. When the tool
is out of working range, the laser lines will blink and the LED indicator will light in
red. Adjust the tool to level approximately to recover self leveling.
• Choose the proper projection mode in your actual working. Shutting off the laser line
not used can extend the battery life.
Indoor and Outdoor measurements
The indoor measurement mode is used for short distance measurement under normal
room brightness, e.g. indoors. But when it works outdoors, the strong sunlight will make
the laser lines hard to identify. Now switch to the outdoor measurement mode, the
laser lines will project in pulse, by the laser receiver (sold separately), the laser can be
detected up to 40m away.
When the laser level is turned on, it defaults to indoor measurement mode. Press the
Indoor/outdoor measurement button to switch to outdoor measurement mode, the LED
indicator of outdoor measurement will be lit on.
NOTE:
When switch to outdoor measurement mode, the laser will project in pulse instead

9
of continuous signals, so the brightness of the
laser lines seems a little darker than in the indoor
measurement mode in visual. It has no affection
to the measurement, in outdoor measurement
the tool should be used with laser receiver (not
included).
Mounting to a Tripod (only available in tripod
version)
This Auto Leveling Laser Level can be mounted
on a general 1/4” tripod directly (sold separately).
By the tripod the tool can easily be adjusted to a
proper height and orientation.
By the attached conversion adapter, the tool can
also be mounted on a 5/8” tripod and allow the
laser dot go through the tripod pole and projected
on the floor.
1. Align the 5/8” thread hole in the adapter with the
5/8” tripod and mount the adapter to the tripod
(Fig. 5).
2. Move the tool back and forth on the adapter,
make sure the laser aperture located on the
bottom of the tool is aligned with the 5/8” thread
hole of the adapter, and connect the tool with
the adapter with the 1/4” knob of the adapter
(Fig. 6).
3. Turn on the laser; slowly adjust the tool on the
adapter to let the laser dot just go through the
tripod pole and project on the floor. Lock the tool
with the adapter by tightening the 1/4” knob in
position (Fig. 7).
Fig.5
Fig.6
Fig.7

10
APPLICATION
This Auto Leveling Laser Level is easy to use for a variety of applications, it is ideal for
the following applications:
• Laying tile and flooring
• Installing closets
• Installing a drop ceiling
• Framing doors and windows
• Installing electrical wiring and pipes
• Installing banister
• Wallpapering and stencil work
• Painting
• Wall hanging of pictures, photos, artwork
• Room partitioning
Laying tiles Installing stairs and banisters

11
MAINTENANCE
Installing cabinet
Room partitioning

12
MAINTENANCE
This Auto Leveling Laser Level has been designed as a low-maintenance tool. However,
in order to maintain its performance, ALWAYS be sure to follow these simple directions:.
• ALWAYS handle the tool with care. Treat it as a precision optical device, such as a
camera or binoculars.
• AVOID exposing the tool to shock, continuous vibration, or extreme hot or cold
temperatures.
• STORE the tool indoors and in a safe place.
• After you have finished usingthe tool, ALWAYS make sure the switchis in the “OFF”
position.
• ALWAYS keep the tool free of dust and liquids. If necessary, use ONLY a soft cloth
or cotton swab and glass cleaner to clean the laser-light aperture.
WARNING: ALWAYS remove the batteries when cleaning the laser-light aperture.
• ALWAYS clean and thoroughly dry the tool after each use.
• Check the batteries regularly to avoid corrosion. REMOVE the batteries from the tool
if it is not going to be used for an extended period.
•DO NOT disassemble the tool. This will not only void the warranty, but could expose
the user to hazardous radiation.
• DO NOT attempt to change any part of the laser lens.

13
TROUBLESHOOTING
Problem Cause Solution
The laser cannot be turned
on.
Batteries are installed
incorrectly
Reinstall the batteries according to
the polarity indicators in the battery
compartment
Batteries are low voltage Replace with new batteries
The ON/OFF button is not
pushed to the position Slide the button once again
The tool is out of operating
temperature range
Make sure the operating temperature
within the range of -5°C~50°C.
LED indicator blinks in red
continuously. Low battery Replace with new batteries
LED indicator lights in red
and the laser line blinks.
The tool is over its
maximum working range
Place the tool on a more level
surface, closer to horizontal (within
4°)
The laser line is not level
or plumb.
The projection mode is in
lock mode
Switch to other AutoLeveling modes,
make sure LED lights in green.
Big change of the operating
temperature
Wait until the temperature of the tool
is close to the room temperature.
The tool suffers a strong
impact or drop
Send the tool to the authorized
service personnel for repair
The laser line gets thicker
or blurry
Dirt on the glass of the
laser aperture Clean it with soft cloths
The laser line is hard to
identify
The surrounding is too
bright
Reduce the room brightness.
Switch to the outdoor measurement
mode and find the laser line with
laser receiver (sold separately)
Low battery Replace with new batteries
