LaserLiner ThermoSpot User manual

ThermoSpot
02
06
10
14
18
22
26
30
34
38
42
46
DE
GB
NL
DK
FR
ES
IT
PL
FI
PT
SE
NO
TR
RU
UA
CZ
EE
LV
LT
RO
BG
GR
SI
HU
ThermoSpot
Laser
650 nm
12 m
Laser-Focus
ø 1 m
12:1

06
1.
2. 1.
2.
1 2 3
GB
Read the operating instructions and the enclosed brochure
„Guarantee and additional notices“ completely. Follow the
instructions they contain. This document must be kept in a
safe place and if the laser device is passed on, this document
must be passed on with it.
!
Be sure to pay
attention to polarity.
– Attention: Do not look into the direct or reected beam.
– The laser may not get into the hands of children!
– Do not point the laser beam towards persons.
– If a person‘s eyes are exposed to class 2 laser radiation, they
should shut their eyes and immediately move away from the beam.
– Do not expose the device to mechanical stress, extreme temperatures,
moisture or signicant vibration.
– The device must only be used in accordance with its intended purpose
and within the scope of the specications. Modications or changes to
the device are not permitted, this will otherwise invalidate the approval
and safety specications.
General safety instructions
Laser radiation!
Do not stare into the beam!
Class 2 laser
< 1 mW · 650 nm
EN 60825-1:2007-10

ThermoSpot
07
F
b
d
e
c
af
g
°C / °F
4
5
ThermoSpot
GB
Laser beam switched on
Battery charge
Hold function
Measured value display
Max. value during the measurement
Display lighting
Unit of measurement °C / °F
a
b
c
d
e
f
g
Continuous measurement / Hold
To set the required temperature unit,
press and hold the „°C/°F“ button until
the corresponding symbol appears on
the display.
For continuous measurement
activate the laser (see gure)
and keep the button pressed.
Release the button as soon as
the laser circle pinpoints the
measurement location. The
measured value is held.

08
Measurement procedure notice
This infrared temperature instrument detects the temperature of various
surfaces and materials. A built-in sensor head detects the material-specic
infrared rays emitted by every object. The amount of these emissions is
determined by the material‘s emission coefcient (0 ... 1). This instrument
is permanently set to an emission coefcient of 0.95, which is applicable
to most organic materials as well as plastics, ceramics, wood, rubber and
stone. Please ensure that the space between the instrument and surface
to be measured is free of disturbances (steam, gas, contamination, glass).
Laser circle
The laser circle is a targeting aid to
sight the location for the infrared
measurement. Temperature mea-
surement is only performed on
the surface within the laser circle.
Laser output
Laser warning message
GB

ThermoSpot
09
GB
Technical data Technical revisions reserved. 06.15
Measurement range -38°C … 365°C (-36.4°F … 689°F)
Accuracy
± 2.5°C + 0.05°C / degree
(-38°C … 0°C)
± 2.5°C (0°C … 365°C) or
± 2.5 % whichever value is greater
Optic 12:1 (distance : measured spot)
Resolution 0.2 °C
Emission coefficient 0.95
Laser wavelength 650 nm
Laser type Laser class 2, < 1 mW
Operating temperature 0°C … 50°C
Storage temperature -10°C … 60°C
Relative humidity 20% rH … 80% rH, no condensation
Power supply 2 x 1.5V alkaline batteries (type AAA)
Dimensions (W x H x D) 40 x 155.5 x 113 mm
Weight (incl. batteries) 173 g
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on waste electrical and
electronic equipment.
Further safety and supplementary notices at:
www.laserliner.com/info
