Tufferman Stoealex MT130 User manual

IMPORTANT INFORMATION
• Please read the instructions carefully before you start assembling to ensure
you have all the components listed on the instructions.
• It’s easier to assemble with two people
• You should only require a flat headed screwdriver and a rubber mallet
BE CAREFUL WHEN ASSEMBLING
• Take care not to stretch or lift awkwardly
• Make sure the floor is level
• Use of protective gloves and footwear is recommended
• Please consider the environment when disposing of all packaging
WARNING
• Do not stand or climb on the shelves
• Not suitable for use outdoors or in wet conditions
• Never lean any objects such as ladders or steps against the shelves
• It is recommended that the units are fixed to the wall for safety
• Never exceed the maximum UDL loadings
MULTI - FUNCTIONAL
BOLTLESS SHELVING
www.storalex.com
SHELVING UNIT
NO
NUTS NO BOLTS
JUST
TAP
TOGETHER
COMPONENT CHECK LIST
MT130 SINGLE SUPPORT BEAM
Gloves
recommended
Ensure floor is even Distribute levels evenly
Do not use in a
wet environment
Distribute
weight evenly
Do not use defective
componentry
SUPPLIED BY
0800 917 7533
[email protected].uk
www.tufferman.co.uk
8 x UPRIGHTS 5 x SHELVES8 x FEET 4 x UPRIGHT CONNECTORS
5 x SUPPORT BEAMS
C
M
Y
CM
MY
CY
CMY
K
INSTRUCTIONS_265KG_KV09_R7.pdf 1 24/10/2019 17:00

1 2 3 4
5
6 7 8 9
SUPPLIED BY
0800 917 7533
sal[email protected]o.uk
www.tufferman.co.uk
Please recycle your packaging responsibly.
One final check that there aren’t any tabs
sticking out (see step 5) and the unit
is ready to use.
Add the remainder of the shelves to the unit.Insert the connectors into the uprights making
sure the tabs go correctly into the slots.
With the tabs correctly positioned tap them
gently with a mallet until they are firmly in place.
Once you’ve built up to two levels, pictured, it’s time to add the next
upright sections. Important to note that you can’t add a shelf right at
the top of the upright as that’s where the upright connectors join
When inserting the tabs into the slots you may
need a screwdriver to guide them into place.
Now insert the shelves into the uprights
by inserting the tabs into the slots.
Fit the plastic feet to each of the 4 uprights. you
will have four spare feet if it is used as a single bay
as this product can also make 2 workbenches.
This is the side profile once the
support beam has started to be
inserted into the metal shelf.
Now you have inserted all of the
support beams into the shelves you
are ready to start attaching the
uprights.
Now take a support beam and slide into the underside
of each metal shelf. Centre the support beam and
repeat for the remaining 4 shelves.
The arrows on the uprights must
be facing upwards
UP DOWN
Please read all illustrations in this stage before starting.
