TUMAC EL7 Series Guide

1
MAINTENANCE
EL7electricalboxforcontrolling
automaticdistributionunits
consistingofelectromagneticvibrators
ThedifferentversionsoftheEL7control box forcontrolling automaticdistributionunits
conformtoEECDirectives93/68 and89/336(EMCElectromagnetic Compatibility)and
EECDirective73/23(electricalsafety–lowvoltage)
TUMACS.r.l.
ViadellaLiberazione, 33/35 –20098 –S.Giuliano Milanese(MI)Italy
Tel.[phone] –fax[phone]

2
EL7
Electrical control boxforautomaticdistributionunitsthatconsistof
electromagneticvibrators
1.ON–OFF switch
2.Knob foradjustingvibratorspeed
3.Vibratorconnector
4.Powerplug
5.Version
229
EL7
6
10
OFF
0
1
ON 5
3
2
4
9
7
8
60
Ø4.5

3
VERSIONSOF THEBOX
Version Description Cards(circuits)
present
EL7.ST Stabilised EL7 box EL7_ST
EL7.SE Stabilised EL7 boxwithtimemanagement card EL7_ST+SE
EL7.AC Stabilised EL7 boxwithvibration sensor EL7_AC
EL7.AC.SE Stabilised EL7 boxwithvibration sensorand
timemanagement card EL7_AC+SE
EL7.PLC Stabilised EL7 boxwithregulation byPLC EL7_PLC
EL7.PLC.SE Stabilised EL7 boxwithregulation byPLCand
withtimemanagementcard EL7_PLC+SE
EL7.AC.PLC EL7boxwithvibration sensorand with
regulationbyPLC EL7_AC_PLC
EL7.AC.PLC.SE Stabilised EL7 boxwithvibration sensor,with
regulationbyPLCandtimemanagement card EL7_AC_PLC+SE
RATINGPLATE
6.EL7boxtypecode
7.Powersupply
8.Frequencyofsupplynetwork
9.Intake
10.Serial number
11.Protection grade
ViaDellaLiberazione 33/35 -Tel.[phone]
20098S.GIULIANOMILANESEMILANOITALIA
230 V~
6Amax
Type N°
50/60 Hz
IP55
67910 8 11

4
BOXTECHNICAL FEATURES
•Powersupply:230V(othervoltagesonrequest)+/-20%-50/60Hz
•Max. consumption:1.5W
•Assemblyposition:horizontal orvertical
•Protection grade: IP55
•Storagetemperature: -10°Cto+80 °C
•Operatingtemperature: 0°Cto+45 °C
•Relativehumidityrange: 80%to31°C
•Altitude:upto2000 m
•Material:die-castaluminium
WARNING
Beforeusing thecontrol box,read theinstructionscontainedinthisinstruction manual
carefullybecausetheycontainimportantinstructionsregardingsafeinstallation,useand
maintenance.Keep thisinstructionmanual carefullyforfutureconsultation.
!

5
CONTENTS
1Introduction page6
2General Instructions page6
3Connectingpartsonlid page7
4Description of useofcard:EL7_ST
EL7_PLC
EL7_AC
EL7_AC_PLC
page8
5Fittingvibration sensor(accelerometer)
andspecificuseofcardEL7_AC(EL7_AC_PLC) page15
6Description of useof“SE” time-management card
forversionsthathaveit page18

6
1. INTRODUCTION
The electricalcontrolboxtowhichthismanual referscan beused toregulateandmanage
automaticdistribution unitsconsisting ofelectromagneticindustrialvibratorsthathavea
maximumintakethat isnot greaterthanthatindicated on theratingplateonthebox.It hasin
factbeen conceivedforcontrol systemsusingmodulesthatarealsodifferentfromone
anotheranddialogue.
Inalltheavailableversionstheboxinquestion is stabilised inasmuchasthecircuit(EL7_ST,
EL7_PLC, EL7_AC, EL7_AC_PLC)isnotonlystableintermsof temperatureandreliablebut
isalsoequipped withfeaturesthatenableittocompensateanylinevariations(±20)thus
keepingconstanttheintensityofvibrationsregardless ofthefluctuationstowhichthenetwork
issubjected overthespaceoftwenty-fourhours.Thisfeatureisunalteredbyanytypeof
powersupply.
The EL7.AC and EL7.AC.PLC aretheversionswithvibration sensors.Thecircuitsthatthey
contain(EL7_AC or EL7_AC_PLC)notonlyenablelinevoltagevariationstobestabilised but
alsostabilisethe weightvariations withwhichthevibratorisloaded.
The versions EL7.SE, EL7.AC.SE, EL7.PLC.SE and EL7.AC.PLC.SE consistoftwocircuits,
oneforactual regulation ofthevibrator(EL7_ST, EL7_AC, EL7_PLC and EL7_AC_PLC)and
theotherformanagingtime(SE).
2. GENERAL INSTRUCTIONS
Beforeconnectingthecontrol boxtothepowersupply,makesurethatthepowersupplyis
compatiblewiththeratingplatevalues.
The control boxmustbeused onlyforthepurposesforwhichithasbeendesigned,i.e.for
controllinganelectromagneticvibrator.Anyotheruseisimproperandthereforehazardous.
The manufacturercannotbeheldresponsibleforanyimproper,incorrectorunreasonableuse.
Intheeventof faultsand/ormalfunctionsof theappliance,switchitoff and donottamperwith
it. Foranyrepairs,contactonlyTUMAC,whichwill useoriginal spareparts.Failuretocomply
withtheseinstructionsmayjeopardisethesafetyoftheappliance.
Anyadjustment, measurementorcheckthatisrequired must becarriedout byauthorised and
qualified personnel.Themanufactureracceptsnoliabilityforharmtopersons,animalsor
thingscaused byinterventionstothecontrolbox byunauthorised andunqualified personnel.
WARNING
Donotusetheappliancenearzonessubjecttovibrationsorindampand/oracid
environments.Ifthevibratorhasafault,checkthewiring,checksettings,disconnectthe
powersupplyand checkthat thefuseshavenotburntout. If thefuseshaveburntout, replace
themwithidenticalones(iffusesburnoutrepeatedly,checkvibratorpowerintake).
!

7
3CONNECTINGPARTSONLID
Beforeswitchingon thecontrol box,check thatthesystemisproperlyearthed andthen
connectthepartsofthelidtotheclampsoftheconnectorsofthecard(EL7_ST,EL7_AC,
EL7_PLCorEL7_AC_PLC)asshowninthefig.below(Fig.1).
Fig.1
CONNECTOR
VIBRATOR 3
POTENTIOMETER
100K
SWITCH
Connector1
1
2Clamp5
Clamp6
Connector2
Clamp8
Clamp6
Clamp7
Doublefaston
forsupplyingany
secondexternalcard
N
L
Connector1
Connector1
forsupplyingany
second external card
Clamp2
Clamp1
Clamp2
Clamp1

8
WARNING
Beforecarryingoutanyoperation on thecardscontainedinthebox,disconnectthepower
supplyand loosen thescrewsonthelidtoopen thebox.
4DESCRIPTIONOF USEOFCARD:EL7_ST (Fig. 2)
EL7_PLC(Fig. 2)
EL7_AC_ (Fig. 3)
EL7_AC_PLC(Fig.3)
The routineinstructionson theuseofthecardsEL7_ST,EL7_PLC,EL7_ACand
EL7_AC_PLCfollow.Forthedimensionsoftheabovecards, see Fig.4.
•Wiring
Connect connector1asfollows:
−thepowersupplytoclamps1-2;
−vibratortoclamps5-6;
−earthtoclamps3-4.
IncompliancewiththeEMCstandard,thecardisequipped withafilterwithleakage
current towardsearthof less than 1mA.
•Variation invibrationfrequency
Vibrationfrequencycan bechanged:
−3000v/m-50Hz(3600v/m-60Hz)
−6000v/m-100Hz(7200v/m-120Hz)
viajumperY1asinthefig. (disconnectpowersupplybeforemakingselection);
!

9
•Setting minimumandmaximumvibratorspeed
The vibrator’sminimumand maximumspeedscan beseteitheronlybyapotentiometer
command(versions:EL7_STandEL7_AC)orbyapotentiometerand PLCcommand
(versions:EL7_PLCandEL7_AC_PLC);inthelattercasetheselection mustbemadeby
jumperY4asshownin thefig. (disconnectpowersupplybeforemaking the
selection).
−Setting speed bypotentiometercommand
Settingminimumspeed:
Turntominimumthespeed-adjustmentknob(100Kpotentiometer) locatedon the
lidofthebox,thenadjust theminimumTRIMMERuntiltherequired minimumspeed
isreached.
Settingmaximumspeed:
Turntomaximumthespeed-adjustmentknob (100Kpotentiometer)) located on the
lidofthebox,thenadjustthemaximumTRIMMERuntil therequired maximum
speed isreached.
−Setting speed throughPLCcommand
Speedcanbeset byconnectingan externalsignal comingfromthePLCthatvaries
from0-10Vtoinputs2and3of theconnector2orbyconnectingan external signal
varyingfrom0-20mAtoinputs1and3oftheconnector2.
Payattentionto+and -polarities
Settingminimumspeed:
Transmittheexternal minimumsignal andadjusttheminimumTRIMMERuntil the
requiredminimumspeedisreached.
Settingmaximumspeed:
Transmittheexternal maximumsignal andadjustthemaximum(automatic)
TRIMMERuntil therequired maximumspeedisreached.
•Variation ofinitial ramptime
Initial ramptimecan bechanged:
−slow1second
−fast0.1seconds
bymeansofjumperY2asinthefig. (disconnectpowersupplybeforemaking the
selection).
•Switchingcontrol boxON-OFF
The vibratorcan beswitched off usingtheconnector2inthefollowing manner:
connecttheinputs3-5oftheconnector2withacleancontactthatcarriesnovoltage
(e.g. relaycontact)orconnectorofinput3-4ofconnector2with24-VDCinputsignal (e.g.
fromPLC).Inthelattercase, payattention to+and –polarity.
Disconnectpowersupplybeforemaking theconnections.
•Inversion ofON-OFF logic
Toinvertthelogicoftheinputsignal (0-24VDC),positionthe2jumpersY3on ONoron
OFF asshowninfigs (disconnectpowersupplybeforemakingtheselection).

10
Card EL7_ST
Card EL7_PLC
Fig.2
Y2
Vibrator
connector
L
6,5A(8A)
F5x20
Connector1
321 54 6
Adjusting
Trimmerfor
controlby
potentiometer
Vibrationfrequency change
3000/6000
6,5A(8A)
F5x20
LEDON
Y1
6000
MIN
3000
MIN
MAX Adjustingtrimmer
forconrolbyPLC
0-20mA
0-10V
Relaycontact
+
8
MAX
Connector2
Slow= 1sec
Ramp
Fast= 0,1sec
Y3 Y4
57 6 4 3
+
2 1
-
Potentiometer
100K
OFFON
+
-
-
Inputsforcontrolby
PLC
ON-OFF from24VDC
PLC
FromON-OFFswitch N
24V= ON
0V= OFF
24V= OFF
0V= ON
ON-OFF signalswitch
byPLC
Adjustment by
potentiometer
Adjustment
byPLC

11
Technical features
EL7_ST
EL7_PLC
•Powersupply:230V(othervoltagesonrequest)+/-20%-50/60Hz
•Max. consumption:1.5W
•Max. currenttovibrator:6.3ARMS(8Abyrequest)
•Minimumload: 50mARMS
•Fuses:6.3AF250V5x20H1500A
•Adjusting potentiometer:100Kohmlinear
•Vibrationfrequency:3000/6000 vibrationperminute
•Ramptime:0.1sec.or1sec. (selectable)
•Min. setting: 80V+/-30%
•Max. setting: 200V-30%
•ON/OFF input: cleancontact0-30VDC
•Automaticinput consumption:1mAmaxwith0-10V
•Inputimpedance0-10V:50Komh/ 0-20mA: 50ohm
•Protection grade: IP00
•Assemblyposition:horizontal orvertical.
•Storagetemperature: -10°Cto+80 °C
•Operatingtemperature: 0°Cto+45 °C
•Relativehumidityrange: 80%to31°C
•Installationcategory: II
•Europeanstandards: EMC-CE

12
Card EL7_AC
Card EL7_AC_PLC
Fig.3
Brown
Yellow
Blue
Vibration sensor
Sensivityadjustment
Slow= 1sec
Ramp
Fast= 0,1sec
Adjusting
Trimmerfor
controlby
potentiometer
Y2
6,5A(8A)
F5x20
Connector1
123456
Vibrationfrequencychange
3000/6000
6,5A(8A)
F5x20
LEDON
30006000
MIN
Adjusting Trimmer
forcontrolbyPLC
MIN
MAX
Relaycontact
0-10V
0-20mA
ON-OFFsignalswitch
byPLC
24V= OFF
0V= ON
24V= ON
0V= OFF
+
MAX
8Connector2
Y3 Y4
267 5 43
+
1
-
Potentiometer
100K
ON OFF
-Inputsforcontrolby
PLC
Adjustment byPLC
Adjustment by
potentiometer
123
ON-OFF from24 VDC
PLC
+
-
Y1
Vibrator
connector
FromON-OFF switch N
L

13
Technical features
EL7_AC
EL7_AC_PLC
•Powersupply:230V(othervoltagesonrequest)+/-20%-50/60Hz
•Max. consumption:1.5W
•Max. currenttovibrator:6.3ARMS(8Abyrequest)
•Minimumload: 50mARMS
•Fuses:6.3AF250V5x20H1500A
•Adjusting potentiometer.: 100Kohmlinear
•Vibrationfrequency:3000/6000 vibrationperminute
•Ramptime:0.1sec.or1sec. (selectable)
•Min. setting: 80V+/-30%
•Max. setting: 200V-30%
•ON/OFF input: cleancontact0÷30VDC
•Automaticinput consumption:1mAmaxwith0-10V
•Inputimpedance0-10V:50Komh/ 0-20mA: 50ohm
•Protection grade: IP00
•Assemblyposition:horizontal orvertical.
•Storagetemperature: -10°Cto+80 °C
•Operatingtemperature: 0°Cto+45 °C
•Relativehumidityrange: 80%to31°C
•Installationcategory: II
•Europeanstandards: EMC-CE

14
Dimensions
Card EL7_ST(EL7_PLC)
Card EL7_AC(EL7_AC_PLC)
Fig.4
Fixing hole card
SE
Y2
Connector1
3
21 5 46
Y1
6000 3000
8Connector2
Slow=1sec
Ramp
Fast=0,1sec
Y3 Y4
57 6 4321

15
5FITTINGVIBRATIONSENSOR(ACCELEROMETER)AND SPECIFIC
USE OF CARD EL7_AC(EL7_AC_PLC)
The vibration sensor(Fig.5)mustbelocated insuchawaythatthesensitivepartisarranged
accordingtothevibrationdirection andinsuchapositionthatitpicksupall vibrations(see fig.
6).
Fig.5
~
Blue
Yellow
Brown
Resin-coatedcontainerwith
fixingracketforgeneral
industrialuse

16
Fig.6
DIRECTION OFVIBRATIONS

17
Oncethesensorhasbeenfixed,connectittothe EL7.AC (EL7_AC_PLC)circuitandafter
poweringupthecontrolbox,setmin.andmax.vibratorspeed(see paragraph4)inorderto
obtainasufficientlyampleadjustment. Thenset thevibratoratthedesired speed.
The EL7controlboxAC(EL7_AC_PLC),usesthedatasupplied bythevibration sensor
(accelerometer)tovarythesupplytothevibratorin ordertomaintainthesetspeedwhatever
thequantityand weightofthematerial loadedon thevibrator.
The circuitissuppliedwithstandardcalibration butthevibratorvibrationmaybedifferentfrom
thereferencevibration andthereforefromthestandardcalibration.
Toovercomethisdifficulty, itissufficient toadjustthesensitivitysetting trimmerlocatedon the
interfacecircuitoftheaccelerometerinterfaceinsuchawayastoadjusttheoperation of
vibratorswithwidelydifferingvibrationrangeswithouthavingtoshifttheposition ofthe
accelerometer.
The trimmershiftsboththeminimumandmaximumlimitsoastofacilitatealignmentofthe
requiredvariation.
The followingpointsmustbeconsidered inordertoobtain anoptimal working point:
−Ifthecircuit isoptimised withanemptyvibrator,theworkpointmust besufficientlybelow
linevoltagethatwhentheloadisincreasedthecircuitcan keepvibration stableby
supplyingmoreoutputvoltage.
−Ifthevibratorwithfullload isoptimised,thevoltageonthevibratorwillfallasthechannel
orthecontainerempties, sotheworkpoint can benearerlinevoltage.
The circuitEL7_AC(EL7_AC_PLC)issupplied withresponsetimesthataresuchasnotto
causeoscillationproblemsin thevastmajorityofcases.
Ifthevibratorandcircuitnevertheless failtoreachastableoperatingcondition,thismeans
thatthequalityof thevibratorismuchbelowthenormal standards(too muchsensitivityortoo
lightastructure).
Insuchcases,everything mustbestiffened bymechanicallymodifyingthevibratoror
increasingthespringpack.
The EL7_AC(EL7_AC_PLC)circuitswithvibrationsensorenabletheoperation ofthevibrator
orofthesystemtobegreatlyimproved but cannot completelycorrect systemdesignerrors.
Butagood designcan onlybenefitevenfurtherfromsuchcircuitsthathavebeenspecially
designedand engineered tooptimiseandperfectlycontrol alltypesofelectromagnetic
vibratorsinalloperatingconditions.

18
6 INSTRUCTIONSONUSEOFTIME MANAGEMENTCARD “SE”
(Fig.7),FORVERSIONSTHAT HAVE IT
The instructionson theuseof theSEcardfollow.Forthedimensions,see Fig.8.
•Powersupply-230V+/-20%50/60Hz(othervoltageson request)
connector1:clamps1+2
•PNPsensororNPN-10-30VDC
connector2:clamps1+2+3
Toselectthesensortobeused andtherelativedesired function,afterconnection move
thejumpers Y1 and Y2 asfollows:
1.NPNsensorormechanicalsensor
Withcyclestart sensorsignal
2.NPNsensor
Withcycleendsensorsignal
3.PNPsensor
Withcyclestart sensorsignal
4.PNPsensor
Withcycleendsensorsignal
CHECKJUMPERSCAREFULLYBEFOREPOWERINGUP
•Mechanical sensor
connector2:clamp1+2
•VibratorON-OFF
connector4:clamps4+5
•VibratorSTOPdelay(delayfrom0to 5seconds)
Adjust trimmerT1
A
BB
A1
BB
AA 2 43
!

19
•VibratorSTARTdelay(delayfrom0to5seconds)
Adjust trimmerT2
•External enabling input(fromanothercard)
connector3:clamps3+4 (closed contact=enabled input)
Insertbridgewhen remoteenablingisnotused
•External enabling (foranothercard)
connector4:clamps1+2+3 (1+2normallyopenand2+3 normallyclosed)
•Solenoid valve24VDC
connector5:clamps1+2 (operationparallel tovibratorwithanticipationof1secondand
delayedswitch-off of2seconds)
•Workpieceflowinterruption alarm
connector4:clamps6and7
foralarmcontrol withcleancontact (alarmcontactnormallyopen)
For24Vlampcontrol, use
connector3:clamp1
connector4:clamp7
andmakeabridgebetween
connector3:clamp2and
connector4:clamp6.
Alarm RESET isautomaticassoonasworkpieceflowresumes.
•Delaytoworkpieceflowinterruption alarm(alarmfrom0to30seconds)
Adjust trimmerT3
•Vibratorblock RESET
connector4:clamp10+connector2:clamp1
Vibratorblockinserted (bridgebetweenclamps8and9oftheconnector4)intheevent
of an alarm
•24VDCoutput(0.1Amax)
connector3:clamps1+2
•CARDOPERATIONLED
Green ON = STARTvibrator
YellowON =TOPvibrator
RedON = alarmstart

20
Card “SE”
Fig.7
1 2
SE-03
Solenoid valve 24VDC
AUT alarm 24VAC (0,1A max)
ON - OFF vibrator card Outputs for enabling
NC
C
NC
C
NO
Vibrator block reset Vibrator block
Connector4
Input external enabling
Connector 5
Connector 3Connector 1
Connector 2
109 7654 213 324 18
PNPorNPN
sensor
Mechanical
sensor
AlarmONdelay
VibratorONdelay
VibratorOFFdelay
Sensortype
andfunction
Y2 T3 T2 T1
-
+
c
123 AY1 B
2 1
Vibrator ON LED
Vibrator OFF LED
Power supply
Alarm ON LED
