Turbo Energy Lithium Series User manual

https://www.turbo-e.com/
Instruction
manual
Lithium Series 48V 5.1 kWh Battery

2
Read this manual before installing the battery and follow the instructions
carefully during the installation process.
Content
1. Scope ...................................................................................................................... 3
2. Specifications.......................................................................................................... 3
3. Battery Dimensions ................................................................................................. 4
4. Features................................................................................................................... 4
5. Operation................................................................................................................ 5
5.1. Battery front ...................................................................................................... 5
5.2. Battery back ..................................................................................................... 5
5.3. Assembly and connection ..............................................................................5
5.3.1. Configuration without communications..................................................7
5.3.2. Configuration with communications ....................................................... 8
5.4. On and Off ..................................................................................................... 10
5.5. LED display...................................................................................................... 10
5.6. Protection codes............................................................................................ 10
5.7. Error codes ...................................................................................................... 11
6. Appendix............................................................................................................... 12
6.1. Security instructions ........................................................................................ 12
6.2. Safety warnings .............................................................................................. 12
6.3. Environmental Protection .............................................................................. 13
6.4. Contact details .............................................................................................. 13

3
1. Scope
This document describes the basic operation of the Turbo Energy brand lithium-
ion rechargeable battery (Lithium Series 48V 5.1 kWh model). This manual
contains all the necessary details for understanding the operation of the
equipment and for its correct application.
2. Specifications
Electrical
Nominal Capacity
5.12 kWh
Usable Capacity
4.6 kWh
Depth of Discharge (DoD)
90%
Nominal Voltage
51.2V
Voltage operating range
48 –57.6V
Cycle Life
>= 6000
Physical
Weight
52 kg
Dimensions
475 x 446 x 200 mm
Protection class
IP20
Battery type
LiFePO4
Operation
Maximum charge/discharge current
50A (0.5 C)
Temperature operating range
0ºC…50ºC
Humidity
15% - 85%
Maximum operating altitude
< 3000 m
BMS
Energy consumption
<2 W running / <100mW at rest
Monitoring parameters
System voltage and current, Cell
voltage and temperature
Communication
Compatible CAN and RS-485

4
3. Battery Dimensions
4. Features
The Lithium Series 48V 5.1 kWh battery has the following features:
•Designed for use in photovoltaic applications.
•Battery Management System (BMS): The BMS system built into the battery
that monitors its operation and does not allow it to work outside the
bounds of the design regime (V, I).
•Expandability: The system's accumulation capacity can be expanded by
incorporating more batteries.
200

5
5. Operation
5.1. Battery front
5.2. Battery back
5.3. Assembly and connection
Batteries may be connected in parallel up to a maximum of 6. All batteries must
be grounded. It is suggested to connect the installation ground to the rack at the
same point as all battery lands.
•Connection between batteries:
Connect the power cord by plugging the connector behind the battery
module. Connect communication cable with the cable provided inside
the battery pack.
Puertode comunicaciones
Cable con conector25 mm2
InterruptorDIP
Communicagtion port
DIP switch
Connection cable 25 mm2
SOC: State of
Charge
ON/OFF

6
•Connection between battery and inverter:
25 mm2 power cable section.
Cable de
comunicaciones
entre baterías
CONEXIONADO DE TIERRAS
Battery connection
Inverter connection
Battery
communications
cable
Grounding connection

7
NOTE: Each power cord can carry a maximum of 100 A, so every two batteries
would need to connect a new cable to the inverter. However, if the inverter is 5
kW only with one cable it would be sufficient to be at the limit of the maximum
current recommended.
5.3.1. Configuration without communications
For those cases where the battery is intended to operate connected to an
inverter without communications, the recommended configuration parameters
are set in the following table:
Even if the system does not have Inverter-Battery communication, the batteries
need to be connected to each other via the communications cable.

8
5.3.2. Configuration with communications
Communication cable: It will be configured one way or another depending on
the inverter used.
Cable configuration Hybrid Inverter Turbo Energy/
Goodwe/SMA
Inverter Turbo
Energy/Goodwe/ SMA
RJ45 connector
CN2
CN1
Lithium Series 48V 5,1 kWh
Battery RJ45 connector

9
DIP switch
•Each module has 4 DIP switches (Dual Inline Package) that will be
configured differently according to the system requirements, depending
basically on the brand of the inverter with which it is communicating.
Configuration Inverter Voltronic VMIII
DIP CONFIGURATION
(Master battery)
Important:
Connect the specific communication cable supplied by the provider.
Connect the communication cable between Batteries.
DIP CONFIGURATION
(Rest of the batteries).
1=ON
0=OFF
1
3
2
4
Configuration Hybrid Inverter Turbo Energy/Goodwe
1=ON
0=OFF
1
3
2
4
DIP CONFIGURATION
(Master battery)
DIP CONFIGURATION
(Rest of the batteries)
Important:
Connect the specific communication cable supplied by the provider.
Connect the communication cable between Batteries.

10
5.4. On and Off
To turn on, press the power button for 2-4 seconds. The BMS will start and the LCD
screen and the power button will also light up.
To turn off the batteries, press the power button for more than 5 seconds.
When the power button is pressed for <5 seconds while the battery is running, the
LCD will turn on for 30 seconds. When two or more batteries are used, the power
button should be pressed for 30 seconds to synchronize them. When the power
button is pressed for about 2 seconds, make sure that all batteries in a group are
turned on within the next 25 seconds.
5.5. LED display
The LED light on the front of the battery will indicate the State Of Charge (SOC)
as shown in the following table:
5.6. Protection codes
LED Alarm
Red light: 1 flicker
Green light:
N. º flickers = protection
code

11
5.7. Error codes
LED Alarm
Red light: 2 flickers
Green light: N. º flickers = error code

12
If the battery constantly runs for 30 days and its SOC has not been corrected,
the discharge function will not be available until the battery is fully charged at
least once and the SOC is corrected.
In case of parallel mode or work mode, if Protection 09 appears and the
power button is pressed 5 times within 10 seconds, the BMS will be forced to
turn on MOS of discharge so that the inverter can detect the battery voltage
and the battery can be charged.
6. Appendix
6.1. Security instructions
1. Please read the battery instructions before use.
2. Keep the battery away from high voltage and out of reach of children.
3. In operation, the battery should be kept in the set temperature ranges
(between -10ºC and 50ºC) and a humidity less than 80%.
4. During handling, be very careful to avoid bumps/falls of the battery.
5. Be careful not to touch the contacts at the same time.
6. The battery, at the end of its useful life, requires a recovery process, not
disassemble it.
7. Avoid locating batteries in damp places to avoid danger.
8. When not in use for a long time, store the battery intact and let the battery
be half charged. Wrap the battery with non-conductive material to avoid
direct contact of the metal. Store the battery in a cool, dry place.
9. Never expose the battery to fire or water.
6.2. Safety warnings
1. Do not disassemble the batteries. The inside of the battery has a protective
mechanism and a protective circuit to avoid danger. Improper
disassembly will damage the protection function permanently, leaving
the battery without safety conditions.
2. Never short-circuit the poles of the Battery. Avoid contact of positive and
negative poles with metals.
3. Keep the batteries away from fire and extreme temperatures. Monitor the
distance to thermal bulbs, stoves, etc.

13
4. Keep the battery away from the water. Always be careful that the battery
is not located in damp places where the dew point can be reached.
5. Do not use batteries that have physical damage that may be due to falls
or bumps.
6. Do not weld near the battery.
7. Overheating will result in the loss of the protective function of its life cycle,
even, it could render the battery useless and in extreme cases self-ignition
of the battery occurs.
8. Never connect this battery in series and connect it in parallel only with
identical batteries up to a maximum number of 6.
9. If the battery has liquid leakage, avoid contact with it completely. It can
be harmful to the skin, and if you touch the eyes, wash, and go to the
hospital immediately for treatment.
6.3. Environmental Protection
Turbo Energy's batteries comply with EU ROHS regulations.
6.4. Contact details
For any incident with the battery write, indicating your contact details, an email
to the address: [e-mail] and we will contact you as soon as possible.
