1. Scope
This document describes the basic operation of the Turbo Energy brand lithium-ion
rechargeable battery (Lithium Series Dual 48V 5.1 kWh model). This manual contains all
the necessary details for understanding the operation of the equipment and for its correct
application.
2. Specifications
Model Battery Lithium Series Dual 48V 5.1 kWh
Electrical
Nominal Capacity 5.12 kWh
Usable Capacity 4.8 kWh
Depth of Discharge (DoD) 90 %
Nominal Voltage 51.2 V
Voltage operating range 48 – 56 V
Connection type Series/Parallel
Cycle Life >=6000
Physical
Weight 45 kg
Dimensions 500 ×442 ×135 mm
Protection class IP20
Battery type LiFePO4
Operation
Maximum charge/discharge current 100 A (1 C)
Standard charge/discharge current 60 A (0,6 C)
Temperature operating range 0º C…50º C
Humidity < 60 %
Parallel Connection
Number of batteries 8
Serial Connection
Number of batteries 8
WiFi
Monitoring System Yes
APP Yes
Remote Updating Yes
BMS
Monitoring parameters System voltage and current, Cell voltage
and temperature
Comunicación Compatible CAN and RS-485

www.turbo-e.com
3. Battery Dimensions
4. Features
The Lithium Series Dual 48V 5.1 kWh battery has the following features:
• Designed for use in photovoltaic applications.
• Battery Management System (BMS): The BMS system built into the battery that monitors
its operation and does not allow it to work outside the bounds of the design regime (V, I).
• Expandability: The system’s accumulation capacity can be expanded by incorporating
more batteries.
• Can be connected in series and parallel connection.
• Wi-Fi module: The battery has a built-in Wi-Fi module, so you can see the battery
information and operate it remotely..

www.turbo-e.com
5. Operation
5.1. BATTERY ELEMENTS
Item Name Definition
1 SW1 DIP switch for CAN or RS485
2 SW2 Resistance for communication and for parallel or series
connection
3 SW3 Switch for battery’s address
4 SW4 & SW5 Communication interface for battery or master battery
5 Reset Restablecer la configuración del módulo WIFI
The standard packing list of Lithium Series Dual is as follows:
Part Name Description Quantity
Battery Lithium Series Dual 1
Data cable Communication cable 1
Power cable Positive and negative power cables 1

www.turbo-e.com
5.2. ASSEMBLY AND CONNECTION
5.2.1. PARALLEL CONNECTION
Batteries may be connected in parallel up to a maximum of 8. All batteries must be
grounded. It is suggested to connect the installation ground to the rack at the same point
as all battery lands.
Connection between batteries:
• Up to 8 batteries are allowed to be used in parallel.
• The batteries used in parallel must be the same batch of cases with the same SOC.
• The Voltage difference of batteries used in parallel must be within 1V.
• The dimensions of parallel cable must be the same.
Connection between battery and inverter:
Inverter connection Battery connection
• 2AWG power cable (35 mm2)

www.turbo-e.com
NOTE: Each power cord can carry a maximum of 200 A, so every two batteries
would need to connect a new cable to the inverter. However, if the inverter is 5 kW
only with one cable it would be enough to be at the limit of the maximum current
recommended.
Warning when doing a battery expansion: It is very important that in the case of
connecting batteries that are not new (for example, we add a new battery to an existing
system), we previously perform a voltage balancing (without load) between them to avoid
overcurrents that could damage the system. As an alternative to balancing voltages,
balancing can be done by equalizing the SOC of the batteries. In addition, when connecting
new batteries, we must take into account that the number of batteries at the time of
connection must be similar to the number of batteries that are already connected in the
system. For example, if we have five batteries installed and we want to connect a new one,
we must first connect the new battery with two of the five that were already in place to
balance them, and then connect these three with the other three remaining batteries in
the system. Batteries should always be connected in groups of similar numbers so that a
large group cannot damage a smaller group of batteries at the time of connection.

www.turbo-e.com
5.2.2. SERIE CONNECTION
Batteries may be connected in serie up to a maximum of 8. All batteries must be grounded.
It is suggested to connect the installation ground to the rack at the same point as all
battery lands.
Connection between batteries:
• Up to 8 batteries are allowed to be used in series.
• The batteries used in series must be the same batch of cases with the same SOC.
• The Voltage difference of batteries used in parallel must be within 0.1V.
• The dimensions of parallel cable must be the same.

www.turbo-e.com
For the serie connection of the batteries, we need yo modify the battery
cables first. These are designed so that the negative conector only fits
the negative terminal, the same with the positive one.
For the modification, we need to disassemble the head of the cable
we want to interchange of pole, to later assemble the one we need to
install.
We well require a M5 HEX wrench, a flat head screwdriver (optional),
and both cables
The proccess will be described in the followen steps:
1. Unlock the head
• We need to ensure that the head of the cable is in the unlock
position.
2. Withdraw the head of the connector
• We need to slightly move up both locking flange in order to unlock
the head piece.
3. Unscrew
• We will use the M5 HEX wrench to withdraw the screw which
ensures the head position of the cable.

www.turbo-e.com
4. Withdraw head
• We need to withdraw completely the head of the cable. Once done
that, we will interchange it by the analogue cable
5. Final assemble
• We preceed to assemble the heads of cables once we have
interchanged the head of the cables, following the previous steps
inversely.
5.2.3. CONFIGURATION WITHOUT COMMUNICATIONS
For those cases where the battery is intended to operate connected to an inverter without
communications, it’s not necessary to select a specific configuration of the DIP switches
and the batteries do not need to be connected each other with the communication cable.

www.turbo-e.com
5.2.4. DIP CONFIGURATION
Each module has 5 DIP switches (SW1, SW2, SW3, SW4 and SW5) that will be configured
differently according to the system requirements, the battery connection and the inverter.
SW1 is for communication protocol with inverter. If CAN protocol is used, 1 and 2 must be
ON. If 485 protocol is used, 3 and 4 must be ON.
SW4 and SW5 work to communicate with the inverter and depend on the communication
cable and the inverter protocol.
If using a pin-to-pin cable, the DIP configuration is as follows:
Protocolo/
Inversor
SW1 SW4 SW5
CAN
Turbo Energy,
Goodwe, Solis, Sofar,
Deye
1 2 3 4
1=ON
0=OFF
1 52 63 74 8 1 52 63 74 8
CAN
Victron Energy 1 2 3 4
1=ON
0=OFF
1 52 63 74 8 1 52 63 74 8
485
Voltronic 1 2 3 4
1=ON
0=OFF
1 52 63 74 8 1 52 63 74 8

www.turbo-e.com
