Briggs & Stratton Generator System Installation and operation manual

Installation & Start-Up Manual
enerator System

Thank you for purchasing this quality-built Briggs & Stratton® home generator. We are pleased that you’ve placed your
confidence in the Briggs & Stratton brand. When operated and maintained according to the instructions in the operator’s
manual, your home generator will provide many years of dependable service.
This manual contains safety information to make you aware of the hazards and risks associated with residential generator
systems and how to avoid them. This generator system is designed and intended only for use as an optional home standby
system that provides an alternate source of electric power and to serve loads such as heating, refrigeration systems, and
communication systems that, when stopped during any power outage, could cause discomfort or inconvenience. Save these
original instructions for future reference.
This generator system requires professional installation before use. The installer should follow the instructions completely.
Where to Find Us
You never have to look far to find support and service for your generator. Consult your Yellow Pages. There are many
Briggs & Stratton authorized service dealers worldwide who provide quality service. You can also contact Briggs &
Stratton Customer Service by phone at 800-743-4115 between 8:00 AM and 5:00 PM CT., or click on Find a Dealer at
BRIGGSandSTRATTON.COM, which provides a list of authorized dealers.
For Future Reference
Please fill out the information below and keep with your receipt to assist in unit identification for future purchase issues.
Date of Purchase
enerator
Model Number
Model Revision
Serial Number
Engine
Model Number
Serial Number
Briggs & Stratton Power Products Group, LLC
P.O. Box 702
Milwaukee, WI 53201-0702
Copyright © 2013. All rights reserved. No part of this material
may be reproduced or transmitted in any form without the express
written permission of Briggs & Stratton Power Products Group, LLC.

3
Table of Contents
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . 4
Installation ....................................7
Owner Responsibilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing Dealer/Contractor Responsibilities . . . . . . . . . . . . . . . . . . . . . . . . 7
Cold Weather Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Unpacking Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Delivery Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Shipment Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Generator Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Placement of Standby Generator to REDUCE THE RISK OF CARBON MONOXIDE
POISONING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Other General Location Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Placement of Standby Generator to REDUCE THE RISK OF FIRE . . . . . . . 14
Electrical and Fuel Inlet Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Lifting the Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Concrete Anchoring of Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Access Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
The Gaseous Fuel System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Fuel Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fuel Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Power Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fuel Pipe Sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fuel Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
System Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Generator AC Connection System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Grounding the Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Utility Circuit Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Generator Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Transfer Switch Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
System Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Final Installation Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Initial Start-up (No Load) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Electronic Governor System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Installation Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Operation .................................... 34
Automatic Operation Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Setting Exercise Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Schematic / Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . 35

4
Save These Instructions
WARNIN Running engine gives off carbon monoxide,
an odorless, colorless, poison gas.
Breathing carbon monoxide could result
in death, serious injury, headache, fatigue,
dizziness, vomiting, confusion, seizures, nausea
or fainting.
tOperate this product ONLY outdoors in an area that will
not accumulate deadly exhaust gas.
tKeep exhaust gas away from any windows, doors,
ventilation intakes, soffit vents, crawl spaces, open garage
doors or other openings that can allow exhaust gas
to enter inside or be drawn into a potentially occupied
building or structure.
tCarbon monoxide detector(s) MUST be installed and
maintained indoors according to the manufacturer’s
instructions/recommendations. Smoke alarms cannot
detect carbon monoxide gas.
WARNIN Storage batteries give off explosive
hydrogen gas during recharging.
Slightest spark will ignite hydrogen
and cause explosion, resulting in
death or serious injury. Battery
electrolyte fluid contains acid and
is extremely caustic. Contact with battery contents could
cause severe chemical burns. A battery presents a risk of
electrical shock and high short circuit current.
tDO NOT dispose of battery in a fire. Recycle battery.
tDO NOT allow any open flame, spark, heat, or lit cigarette
during and for several minutes after charging a battery.
tDO NOT open or mutilate the battery.
tWear protective goggles, rubber apron, rubber boots and
rubber gloves.
tRemove watches, rings, or other metal objects.
tUse tools having insulated handles.
Important Safety Instructions
SAVE THESE INSTRUCTIONS - This manual contains
important instructions that should be followed during
installation and maintenance of the generator and batteries.
Safety Symbols and Meanings
The safety alert symbol indicates a potential personal
injury hazard. A signal word (DANGER, WARNING, or
CAUTION) is used with the alert symbol to designate a
degree or level of hazard seriousness. A safety symbol
may be used to represent the type of hazard. The signal
word NOTICE is used to address practices not related to
personal injury.
DAN ER indicates a hazard which, if not avoided, will
result in death or serious injury.
WARNIN indicates a hazard which, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazard which, if not avoided, could
result in minor or moderate injury.
N TICE addresses practices not related to personal injury.
The manufacturer cannot possibly anticipate every possible
circumstance that might involve a hazard. The warnings in
this manual, and the tags and decals affixed to the unit are,
therefore, not all-inclusive. If you use a procedure, work
method or operating technique that the manufacturer does
not specifically recommend, you must satisfy yourself that
it is safe for you and others. You must also make sure that
the procedure, work method or operating technique that you
choose does not render the generator system unsafe.
Explosion Fire Electrical Shock
Rotating Parts Hot Surface Toxic Fumes
Chemical BurnExplosive PressureAuto Start
Lift Hazard Read Manual
WARNIN The engine exhaust from this product
contains chemicals known to the State of California to
cause cancer, birth defects, or other reproductive harm.
WARNIN Certain components in this product and
related accessories contain chemicals known to the State
of California to cause cancer, birth defects, or other
reproductive harm. Wash hands after handling.

5
WARNIN Generator produces hazardous voltage.
Failure to properly ground generator could result
inelectrocution.
Failure to isolate generator from utility power could
result in death or serious injury to electric utility
workers due to backfeed of electrical energy.
tWhen using generator for backup power, notify
utility company.
tDO NOT touch bare wires or bare receptacles.
tDO NOT use generator with electrical cords which are
worn, frayed, bare or otherwise damaged.
tDO NOT handle generator or electrical cords while
standing in water, while barefoot, or while hands or
feet are wet.
tIf you must work around a unit while it is operating,
stand on an insulated dry surface to reduce the risk of
a shock hazard.
tDO NOT allow unqualified persons or children to operate
or service generator.
tIn case of an accident caused by electrical shock,
immediately shut down the source of electrical power and
contact the local authorities. Avoid direct contact with
the victim.
tDespite the safe design of the generator, operating this
equipment imprudently, neglecting its maintenance or
being careless could cause possible injury or death.
tRemain alert at all times while working on this equipment.
Never work on the equipment when you are physically
or mentally fatigued.
tBefore performing any maintenance on the generator,
disconnect the battery cable indicated by a NE ATIVE,
NE or (-) first. When finished, reconnect that cable last.
tAfter your system is installed, the generator may crank
and start without warning any time there is a power
failure. To prevent possible injury, always set the
generator’s system switch to OFF, remove the service
disconnect from the disconnect box AND remove the
15 Amp fuse BEFORE working on the equipment.
WARNIN Propane and Natural Gas are extremely
flammable and explosive, which could cause
burns, fire or explosion resulting in death or
serious injury.
tInstall the fuel supply system according to NFPA 37 and
other applicable fuel-gas codes.
tBefore placing the generator into service, the fuel system
lines must be properly purged and leak tested.
tAfter the generator is installed, you should inspect the fuel
system periodically.
tNO leakage is permitted.
tDO NOT operate engine if smell of fuel is present or other
explosive conditions exist.
tDO NOT smoke around the generator. Wipe up any oil
spills immediately. Ensure that no combustible materials
are left in the generator compartment. Keep the area near
the generator clean and free of debris.
WARNIN Hazardous Voltage - Contact with power
lines could cause electric shock or burns,
resulting in death or serious injury.
Lifting Hazard / Heavy Object - Could result
in serious injury.
tIf lifting or hoisting equipment is used, DO NOT contact
any power lines.
tDO NOT lift or move generator without assistance.
tUse lifting pipes as described in Lifting the Generator.
tDO NOT lift unit by roof as damage to generator
will occur.

6
WARNIN Starter and other rotating parts could
entangle hands, hair, clothing, or accessories
resulting in serious injury.
tNEVER operate generator without protective housings,
covers, or guards in place.
tDO NOT wear loose clothing, jewelry or anything that
could be caught in the starter or other rotating parts.
tTie up long hair and remove jewelry.
tBefore servicing, remove 15 Amp fuse from control panel
and disconnect Negative (NE or -) battery cable.
CAUTION Installing the 15A fuse could cause the
engine to start at any time without warning
resulting in minor or moderate injury.
tObserve that the 15 Amp fuse has been removed from the
control panel for shipping.
tDO NOT install this fuse until all plumbing and wiring has
been completed and inspected.
CAUTION Excessively high operating speeds could
result in minor injury and/or equipment damage,
Excessively low speeds impose a heavy load on generator.
tDO NOT tamper with governed speed. Generator supplies
correct rated frequency and voltage when running at
governed speed.
tDO NOT modify generator in any way.
N TICE Improper treatment of generator could damage it
and shorten its life.
tUse generator only for intended uses.
tIf you have questions about intended use, contact your
authorized dealer.
tOperate generator only on level surfaces.
tAdequate, unobstructed flow of cooling and ventilating air
is critical to correct generator operation.
tThe access panels/doors must be installed whenever the
unit is running.
tDO NOT expose generator to excessive moisture, dust,
dirt, or corrosive vapors.
tRemain alert at all times while working on this equipment.
Never work on the equipment when you are physically
or mentally fatigued.
tDO NOT start engine with air cleaner or air cleaner
cover removed.
tDO NOT insert any objects through cooling slots.
tDO NOT use the generator or any of its parts as a step.
Stepping on the unit could cause stress and break parts.
This may result in dangerous operating conditions from
leaking exhaust gases, fuel leakage, oil leakage, etc.
tIf connected devices overheat, turn them off and
disconnect them from generator.
Shut off generator
and contact an authorized deaker if
- electrical output is lost;
- equipment sparks, smokes, or emits flames;
- unit vibrates excessively;
- unit makes unusual noises.
WARNIN Exhaust heat/gases could ignite combustibles
or structures resulting in death or serious
injury. Contact with muffler area could cause
burns resulting in serious injury.
tDO NOT touch hot parts and AVOID hot exhaust gases.
tAllow equipment to cool before touching.
tExhaust outlet side of weatherproof enclosure must
have at least 5 ft. (1.5 m) minimum clearance from any
structure, shurbs, trees or any kind of vegetation.
tStandby generator weatherproof enclosure must be at
least 5 ft. (1.5 m) from windows, doors, any wall opening,
shrubs or vegetation over 12 inches (30.5 cm) in height.
tStandby generator weatherproof enclosure must have a
minimum of 5 ft. (1.5 m) overhead clearance from any
structure, overhang or trees.
tDO NOT place weatherproof enclosure under a deck or
other type of structure that may confine airflow.
tUse only flexible fuel line provided. Connect provided fuel
line to generator, DO NOT use with or substitute any other
flexible fuel line.
tSmoke detector(s) MUST be installed and maintained
indoors according to the manufacturer’s instructions/
recommendations. Carbon monoxide alarms cannot
detect smoke.
tKeep at least minimum distances shown in General
Location Guidelines to insure for proper generator cooling
and maintenance clearances.
tIt is a violation of California Public Resource Code,
Section 4442, to use or operate the engine on any forest-
covered, brush-covered, or grass-covered land unless
the exhaust system is equipped with a spark arrester, as
defined in Section 4442, maintained in effective working
order. Other states or federal jurisdictions may have
similar laws.
Contact the original equipment manufacturer, retailer, or
dealer to obtain a spark arrester designed for the exhaust
system installed on this engine.
tReplacement parts must be the same and installed in the
same position as the original parts.

7
Installation
Equipment Description
This product is only for use as an optional generator system
which provides an alternate source of electric power and
to serve loads such as heating, refrigeration systems, and
communication systems that, when stopped during any
power outage, could cause discomfort or inconvenience.
N TICE This product does NOT qualify for either an
emergency standby or legally required standby system as
defined by NFPA 70 (NEC).
t&NFSHFODZHFOFSBUPSTZTUFNTBSFJOUFOEFEUPautomatically supply illumination, power, or both, to
designated areas and equipment in the event of failure
of the normal supply. Emergency systems may also
provide power for such functions as ventilation where
essential to maintain life, where current interruption
of the normal supply would produce serious life
safety or health hazards.
t-FHBMMZ3FRVJSFETUBOECZHFOFSBUPSTZTUFNTBSFintended to automatically supply power to selected
loads in the event of failure of the normal source
which could create hazards or hamper rescue or fire-
fighting operations.
Every effort has been made to ensure that information in this
manual is accurate and current. However, we reserve the
right to change, alter, or otherwise improve the product and
this document at any time without prior notice.
Only current licensed electrical and plumbing professionals
should attempt home generator system installations.
Installations must strictly comply with all applicable codes,
industry standards, laws and regulations.
Owner Responsibilities
t3FBEBOEGPMMPXUIFJOTUSVDUJPOTHJWFOJOUIFoperator’smanual.
t'PMMPXBSFHVMBSTDIFEVMFJONBJOUBJOJOHDBSJOHGPSand using your generator, as specified in the operator’s
manual.
t$BSCPONPOPYJEFEFUFDUPST.645CFJOTUBMMFEBOEmaintained indoors according to the manufacturer’s
instructions/recommendations. Smoke alarms cannot
detect carbon monoxide gas.
t4NPLFEFUFDUPST.645CFJOTUBMMFEBOENBJOUBJOFEindoors according to the manufacturer’s instructions/
recommendations. Carbon monoxide alarms cannot
detect smoke.
If you have questions about intended use, ask your installer
or dealer or call 800-743-4115 between
8:00 AM and 5:00PM CT.
Installing Dealer/Contractor Responsibilities
t3FBEBOEPCTFSWFUIFTBGFUZSVMFTt*OTUBMMPOMZBO6-BQQSPWFEUSBOTGFSTXJUDIUIBUJTcompatible with the generator.
t3FBEBOEGPMMPXUIFJOTUSVDUJPOTHJWFOJOUIJTinstallation and start-up manual.
t*OTUBMMBUJPONVTUTUSJDUMZDPNQMZXJUIBMMBQQMJDBCMFcodes, industry standards, laws, and regulations.
t"MMPXTVGGJDJFOUSPPNPOBMMTJEFTPGUIFHFOFSBUPSGPSmaintenance and servicing.
Cold Weather Kit
If operating the generator below 30°F (-1°C), it is HI HLY
RECOMMENDED that a Model 6262 Cold Weather Kit
(includes two oil warmers and battery warmer) be installed
on the 8kW units and that a Model 6030A Cold Weather Kit
(includes oil warmer and battery warmer) be installed on the
10kW units.
These items are available at your local servicing dealer.
For cold weather areas (below 0°F (-18°C)) it is also
recommended that a BCI, Size 24F, wet lead-acid battery be
used of 800 CCA minimum.
If you need more information on this matter, please call
[phone], between 8:00 AM and 5:00 PM CT.
30°F (-1°C)

8
Unpacking Precautions
The unit is shipped ready for installation. Avoid damage from
dropping, bumping, collision, etc. Store and unpack carton
with the proper side up, as noted on the shipping carton.
Delivery Inspection
After removing the carton, carefully inspect the generator for
any damage that may have occurred during shipment.
If loss or damage is noted at time of delivery, have the
person(s) making delivery note all damage on the freight
bill and affix his signature under the consignor’s memo of
loss or damage. If loss or damage is noted after delivery,
separate the damaged materials and contact the carrier
for claim procedures. Parts damaged in shipping are not
warranted.
Shipment Contents
The home generator system is supplied with:
t0JM84ZOUIFUJDt'MFYJCMFTUFFMGVFMMJOFt*OTUBMMBUJPOBOETUBSUVQNBOVBMt0QFSBUPSTNBOVBMt4QBSFBDDFTTLFZTt4QBSF"NQ"50UZQFGVTFNot included:
t$BSCPONPOPYJEFEFUFDUPSTt4NPLFEFUFDUPSTt4UBSUJOHCBUUFSZt$POOFDUJOHXJSFBOEDPOEVJUt'VFMTVQQMZWBMWFTQMVNCJOHt$SBOFMJGUJOHTUSBQTDIBJOTPSDBCMFTt5XPwMFOHUITPGwOPNJOBMNJOJNVNTDIFEVMFE40 steel pipe (NOT conduit)
t5PSRVFTDSFXESJWFSUPJODIQPVOESBOHFt7PMUBHFGSFRVFODZNFUFSt3FNPUFXJSFMFTTNPOJUPS015*0/"-t"OUFOOB015*0/"-

9
Installation Checklist
Carbon Monoxide (CO) Detector
Carbon Monoxide (CO) detector installed and in working
order.
Smoke detector(s) installed and in working order.
Placement
Required permits have been obtained.
Generator placed in an area free from Carbon Monoxide
(CO) buildup. See Placement of Standby enerator to
Reduce the Risk of Carbon Monoxide Poisoning.
Generator placed in an area compliant to NFPA 37. See
Placement of Standby enerator to Reduce the Risk of
Fire.
Generator placed in an area free from water damage. See
Other eneral Location uidelines.
Generator placed in an area free from utiliity and other
home systems. See Other eneral Location uidelines.
Generator placed in a debris free zone. See Other eneral
Location uidelines.
Generator placed on flat ground with provisions for water
drainage. See Other eneral Location uidelines.
Fuel
Generator is connected to fuel source with flexible fuel line,
has no fuel leaks and conforms to local codes. See The
aseous Fuel System.
Proper fuel pressure has been measured with all gas
appliances operating. See The aseous Fuel System.
Fuel system has been configured for the proper fuel supply:
Natural gas (NG) or liquefied petroleum ( LP). See Fuel
Conversion.
Fuel type: (circle one) NG LP
'VFMQJQFTJ[FVTFEDJSDMFPOFwwwwSee NFPA 54, Chapter 6.
Fuel pressure at fuel inlet port with generator on and at
full load and all gas appliances turned on and operating
____________________.
Electrical
Generator neutral is connected to Automatic Transfer
Switch. See enerator AC Connection System.
Generator is grounded. See rounding the enerator and
NFPA 70,NEC, Article 250.35B.
Generator is connected to the transfer switch with the
specified wiring. See Utility Circuit Connection and
Transfer Switch Communication.
Generator is connected to the transfer switch with the
specified wiring. #18AWG twisted pair wiring from the
generator control panel to the transfer switch is installed
in a separate conduit from high voltage wires unless
the insulation rating on all wiring is rated for 600V. See
Transfer Switch Communication.
Dipswitches in most transfer switches must be set to
correspond to the wattage of the generator. See Transfer
Switch Operator/Installation Manual.
Operation
Cold weather kit is installed in temperatures below 30°F
(4°C). See Cold Weather Kit.
Correct battery type is installed and fully charged. See
Final Installation Considerations.
Generator engine oil level is at full mark. See Final
Installation Considerations.
Circuit breaker is in the ON position.
Utility was shut off to test the operation of generator
and transfer switch. Note any service codes and make
corrections as required.
AC Voltage Output___________________________.
Frequency Output___________________________.
Owner Information
Name: ___________________________________________
Address:__________________________________________
Phone/e-mail:______________________________________
Unit Information
Generator Model: ___________________________________
Generator Serial Number: ____________________________
Installing Contractor Information
Name: ___________________________________________
Address:__________________________________________
Phone/FAX: _______________________________________
Electrician: _______________________________________
Signature: ________________________________________
Plumber: _________________________________________
Signature: ________________________________________
Inspector Information
Name: ___________________________________________
Address:__________________________________________
_________________________________________________
Title:_____________________________________________
Inspection Date:____________________________________
This generator has been installed per the manufacturer’s
instructions:
Installing Contractor Signature: ____________________________
Date: _________________________________________________
Proper installation of the home generator requires the completion of the following tasks:

10
Intentionally Left Blank

11
enerator Placement
Before installing generator, consult with home owner and
convey the following requirements, which must be satisfied
before the installation is complete.
There are two equally important safety concerns in regards to
carbon monoxide poisoning and fire. There are also several
general location guidelines that must be met before the
installation in considered complete.
Exhaust Side of the enerator
A- Exhaust outlet side of weatherprooof enclosure
WARNIN Running engine gives off carbon monoxide,
an odorless, colorless, poison gas.
Breathing carbon monoxide could result in death
serious injury, headache, fatigue, dizziness,
vomiting, confusion, seizures, nausea or fainting.
tOperate this product ONLY outdoors in an area that wil
not accumulate deadly exhaust gas.
tKeep exhaust gas away from any windows, doors,
ventilation intakes, soffit vents, crawl spaces, open garage
doors or other openings that can allow exhaust gas
to enter inside or be drawn into a potentially occupied
building or structure.
tCarbon monoxide detector(s) MUST be installed and
maintained indoors according to the manufacturer’s
instructions/recommendations. Smoke alarms cannot
detect carbon monoxide gas.
A

12
All fossil fuel burning equipment, such as standby
generators, contains carbon monoxide (CO) gas in the
engine exhaust. CO gas is odorless, colorless and tasteless
and is unlikely to be noticed until a person is overcome.
CO gas can kill you so it is required that the following is
included as part of the installation:
t*OTUBMMHFOFSBUPSPVUEPPSTJOBOBSFBUIBUXJMMOPUaccumulate deadly exhaust gas.
t%0/05JOTUBMMHFOFSBUPSXIFSFFYIBVTUHBTDPVMEaccumulate and enter inside or be drawn into a
potentially occupied building or structure.
t#ZMBXJUJTSFRVJSFEJONBOZTUBUFTUPIBWFB$BSCPOMonoxide (CO) detector in operating condition in
your home. Carbon monoxide detector(s) (A) MUST
be installed and maintained indoors according to the
manufacturer’s instructions / recommendations. A CO
monitor is an electric device that detects hazardous
levels of CO. When there is a buildup of CO, the
monitor will alert the occupants by flashing visual
indicator light and alarm. Smoke alarms cannot detect
CO gas.
t:PVSOFJHICPSTIPNFNBZCFFYQPTFEUPUIFFOHJOFexhaust from your standby generator and must be
considered when installing your standby generator. t&OTVSFFYIBVTUHBTJTLFQUBXBZGSPNB- windows
C- doors
D- ventilation intakes
E- soffit vents
F- garage doors
- crawl spaces or other openings that can allow
exhaust gas to enter inside or be drawn into a
potentially occupied building or structure.
Placement of Standby enerator to REDUCE THE RISK OF CARBON MONOXIDE POISONIN
The arrows in the figure below point to POTENTIAL points of entry for Carbon Monoxide as.
A
FC
D
B
E
G
FC
D
B
E
NOTICE This Section is for Carbon Monoxide Hazard Safety Placement Only. Satisfying the standby generator placement, for
the Carbon Monoxide hazard, does not guarantee that Fire Safety Placement requirements are met. Please refer to Page 14 for
Fire Hazard Safety Placement requirements.

13
t%JSFDUUIFTUBOECZHFOFSBUPSFYIBVTUBXBZGSPNPSparallel to the building or structure. DO NOT direct
the generator exhaust towards a potentially occupied
building, structure, windows, doors, ventilation intakes,
soffit vents, crawl spaces, open garage doors or other
openings where exhaust gas could accumulate and
enter inside or be drawn into potentially occupied
building or structure.
t%0/05QMBDFTUBOECZHFOFSBUPSJOBOZBSFBXIFSFleaves or debris normally accumulates. Position
standby generator in an area where winds will carry
the exhaust gas away from any potentially occupied
building or structure.
Other eneral Location uidelines
t1MBDFUIFTUBOECZHFOFSBUPSJOBQSFQBSFEMPDBUJPOUIBUis flat and has provisions for water drainage.
t*OTUBMMUIFTUBOECZHFOFSBUPSJOBMPDBUJPOXIFSFTVNQpump discharge, rain gutter downspouts, roof run-off,
landscape irrigation, or water sprinklers will not flood
the unit or spray the enclosure and enter any air inlet or
outlet openings.
t*OTUBMMUIFTUBOECZHFOFSBUPSXIFSFJUXJMMOPUBGGFDUPSobstruct and services including covered, concealed and
underground, such as telephone, electric, fuel (natural
gas/ LPG vapor), irrigation, air conditioning, cable,
septic, sewer, well and so forth.
t*OTUBMMUIFTUBOECZHFOFSBUPSXIFSFMFBWFTHSBTTsnow, etc. will not obstruct air inlet and outlet
openings. If prevailing winds will cause blowing or
drifting, you may need to construct a windbreak to
protect the unit.
ENGINE
EXHAUST
STANDBY
GENERATOR

14
Placement of Standby enerator to REDUCE THE
RISK OF FIRE
NOTICE This Section is for Fire Hazard Safety Placement
Only. Satisfying the standby generator placement, for the Fire
Safety Hazard, does not guarantee that the Carbon Monoxide
Hazard Safety Placement requirements are met. Please refer
to Page 12 for Carbon Monoxide Hazard Safety Placement
requirements.
Requirements:
NFPA 37 2010, section 4. 1. 4, Engines Located Outdoors.
Engines, and their weatherproof housings if provided, that are
installed outdoors shall be located at least 1.5m (5 ft) from
openings in walls and at least 1.5 m (5 ft) from structures
having combustible walls. A minimum separation shall not be
required where either of the following conditions exist:
1. The adjacent wall of the structure has a fire resistance
rating of at least 1 hour.
2. The weatherproof enclosure is constructed
of noncombustible materials and it has been
demonstrated that a fire within the enclosure will not
ignite combustible materials outside the enclosure. *
Annex A Explanatory Material
A.4.1.4 (2) Means of demonstrating compliance are by
means of full-scale fire tests or by calculation procedures,
such as those given in NFPA 555, Guide on Methods for
Evaluating Potential for Room Flashover.
To comply with condition 2 above the weatherproof enclosure
has been constructed completely of non-combustible
materials and full-scale fire tests have been conducted to
demonstrate that a fire within the enclosure will not ignite
combustible materials outside the enclosure.
WARNIN Exhaust heat/gases could ignite combustibles
or structures resulting in death or serious injury.
tExhaust outlet side of weatherproof enclosure must have at least
5 ft. (1.5 m) minimum clearance from any structure, shrubs,
trees or any kind of vegetation.
tStandby generator weatherproof enclosure must be at least 5
ft. (1.5 m) from windows, doors, any wall opening, shrubs or
vegetation over 12 inches (30.5 cm) in height.
tStandby generator weatherproof enclosure must have a
minimum of 5 ft. (1.5 m) overhead clearance from any structure,
overhang or trees.
tDO NOT place weatherproof enclosure under a deck or other
type of structure that may confine airflow.
tUse only flexible fuel line provided. Connect provided fuel line to
generator, DO NOT use with or substitute any other flexible fuel
line.
tSmoke detector(s) MUST be installed and maintained indoors
according to the manufacturer’s instructions/recommendations.
Carbon monoxide alarms cannot detect smoke.
tDO NOT place weatherproof enclosure in manner other than
shown in illustrations.
Examples of standby generator locations to reduce the risk
of fire:
Vertical Clearances
Structure
Center of Exhaust Panel
Standby
Exhaust
Direction
5 ft
(1.5 m)
5 ft (1.5 m)
B
C
Legend for enerator Locations to reduce the risk of fire.
AStandby weatherproof enclosure must be at least 5
ft (1.5 m) from windows, doors, any wall opening,
shrubs or vegetation over 12 inches (30.5 cm) in
height.
BExhaust outlet side of weatherproof enclosure must
have at least 5 ft (1.5 m) minimum clearance from
any structure, shrubs, trees or any kind of vegetation.
CStandby weatherproof enclosure must have a
minimum of 5 feet (1.5 m) overhead clearance from
any structure, overhang or trees.
N TICE DO NOT place weatherproof enclosure under a deck
or other type of covered structure that may confine airflow.
B
C

15
AStandby weatherproof enclosure must be at least 5
ft (1.5 m) from windows, doors, any wall opening,
shrubs or vegetation over 12 inches (30.5 cm) in
height.
BExhaust outlet side of weatherproof enclosure must
have at least 5 ft (1.5 m) minimum clearance from
any structure, shrubs, trees or any kind of vegetation.
CStandby weatherproof enclosure must have a
minimum of 5 feet (1.5 m) overhead clearance from
any structure, overhang or trees.
N TICE DO NOT place weatherproof enclosure under a deck
or other type of covered structure that may confine airflow.
Legend for enerator Locations to reduce the risk of fire.
enerator Installations
AAA
A
A
A
A
Standby Standby
Standby
Standby
5 ft (1.5 m)
5 ft (1.5 m)
5 ft (1.5 m)
5 ft (1.5 m)
5 ft (1.5 m)
5 ft (1.5 m)
5 ft (1.5 m)
Exhaust
Direction
Exhaust
Direction
Exhaust
Direction
Exhaust
Direction
18 in. (45.7 cm) min.
18 in.
(45.7 cm) min.
B
B
B
B
18 in. (45.7 cm) min.
N TICE The figures below show the minimum installation distances allowed to structures and items listed in the legend.

16
Electrical and Fuel Inlet Locations
The 3/4 inch N.P.T. fuel inlet connector (A) and electrical inlet
location (B) is shown below.
A ½ inch knock-out is provided for the electrical inlet. This
inlet may be enlarged or supplemented to accommodate a
maximum conduit size of 1 ½ inches.
The generator is supplied with a base that, unless mandated
by local code, does not require a concrete slab.
A
B

17
Lifting the enerator
The generator weighs more than 330 pounds (150 kg).
Proper tools, equipment and qualified personnel should be
used in all phases of handling and moving the generator.
5XPwMFOHUITPGwOPNJOBMNJOJNVNTDIFEVMFEsteel pipe (A), supplied by the installer, are required to lift the
generator manually. Insert pipes through the lifting holes (B)
located near the unit’s base.
:PVNBZBMTPMJGUUIFVOJUVTJOHBiIPPLBOEIPJTUwNFUIPEattached to the lifting pipes, provided that you use a spreader
bar to ensure that the chains or cables DO NOT touch the
generator’s roof.
WARNIN Hazardous Voltage - Contact with power
lines could cause electric shock or burns,
resulting in death or serious injury.
Lifting Hazard / Heavy Object - Could result
in serious injury.
tIf lifting or hoisting equipment is used, DO NOT contact
any power lines.
tDO NOT lift or move generator without assistance.
tUse lifting pipes as described in Lifting the Generator.
tDO NOT lift unit by roof as damage to generator
will occur.
In areas determined to be hurricane prone, it is
recommended to anchor the standby generator to concrete.
The concrete anchors must be rated to hold 800 lbs ( kg).
There are three (C) 7/16 inch hole locations in the base of the
generator in which to anchor the unit.
Concrete Anchoring of Unit
N TICE Unless mandated by local or state code, a
concrete slab is not required.
C
C
C
A
B

18
Access Ports
The generator is equipped with an enclosure that has several
access panels, as shown.
N TICE The generator roof must be romoved to gain access
to the front panel.
(A) Front Panel that is used to access:
t#BUUFSZ$PNQBSUNFOUt&OHJOF0JM%SBJO)PTFt&OHJOF0JM'JMUFSt&OHJOF7BMWF$PWFSt4QBSL1MVHTEach generator is shipped with a set of identical keys.
A

19
To remove roof:
1. Remove the five screws (A) that secure the roof to the
unit.
2. Carefully lift and remove roof from unit.
To remove front panel:
1. Remove the two screws (B) that secure the panel to the
unit.
2. Lift and flex panel outward and off base. Use caution
not to damage the battery box (C).
To secure front panel:
1. Place panel in unit.
2. Secure the panel with two screws.
A
B
C

20
The aseous Fuel System
The information below is provided to assist gaseous
fuel system technicians in planning installations. In no
way should this information be interpreted to override
applicable fuel gas codes. Consult with your local fuel
supplier or Fire Marshall if questions or problems arise.
TO THE INSTALLER: Consult with the generator owner(s)
and convey any technical considerations that might
affect their installation plans before applying these
generalguidelines.
The following general rules apply to gaseous fuel
systempiping:
WARNIN Propane and Natural Gas are extremely flammable
and explosive, which could cause burns, fire or
explosion resulting in death or serious injury.
tBefore placing the generator into service, the fuel system lines
must be properly purged and leak tested.
tNo leakage is permitted.
N TICE The supplied flexible steel fuel line is not to be installed
underground or in contact with the ground.
tThe entire flexible steel fuel line must be visible for
periodic inspection and must not be concealed within
nor contact nor run through any wall, floor, or partition.
t5IFQJQJOHTIPVMECFPGBNBUFSJBMUIBUDPOGPSNTto federal and local codes, rigidly mounted and
protected against vibration.
t1JQJOHTIPVMECFQSPUFDUFEGSPNQIZTJDBMEBNBHFwhere it passes through flower beds, shrub beds, and
other cultivated areas where damage could occur.
N TICE The illustration is representative of a typical
installation. Your installation may differ.
t*OTUBMMUIF
flexible steel fuel line (B)(supplied) between
the generator fuel inlet port (A)and rigid piping
to prevent thermal expansion, contraction, or any
standby movement from causing excessive stress on
the piping material.
A
t"VOJPO(C)or flanged connection shall be provided
downstream to permit removal of standby.
t"NBOPNFUFSQPSUTIPVMECFQSPWJEFE(D). A digital
manometer, P/N 19495, is available at your Briggs &
Stratton service center. When the initial test runs are
completed, the manometer is removed and the port
is plugged. The manometer port permits temporary
installation of a manometer to ensure that the
engine receives the correct fuel pressure to operate
efficiently throughout its operatingrange.
t8IFSFUIFGPSNBUJPOPGIZESBUFTPSJDFJTLOPXOUPoccur, piping should be protected against freezing. The
termination of hard piping should include a sediment
trap (F)where condensate is not likely to freeze.
t"NJOJNVNPGPOFBDDFTTJCMFBQQSPWFENBOVBMshutoff valve (E) shall be installed in the fuel supply
line within 6 ft. (180 cm) of the home generator.
t"NBOVBMGVFMTIVUPGGWBMWFTIPVMECFJOTUBMMFEJOUIFinterior of the building.
t8IFSFMPDBMDPOEJUJPOTJODMVEFFBSUIRVBLFtornado, unstable ground, or flood hazards, special
consideration shall be given to increase strength and
GMFYJCJMJUZPGQJQJOHTVQQPSUTBOEDPOOFDUJPOTtPiping must be of the correct size to maintain the
required supply pressures and volume flow under
varying generator load conditions with all gas
appliances connected to the fuel system turned on
andoperating.
t6TFBQJQFTFBMBOUPSKPJOUDPNQPVOEBQQSPWFEGPSuse with NG/LPG on all threaded fittings to reduce the
possibility of leakage.
t*OTUBMMFEQJQJOHNVTUCFQSPQFSMZQVSHFEBOEleak tested, in accordance with applicable codes
andstandards.
WARNIN Propane and Natural Gas are extremely
flammable and explosive, which could cause
burns, fire or explosion resulting in death or
serious injury.
tLP gas is heavier than air and will settle in low areas.
tNatural gas is lighter than air and will collect in high
areas.
tThe slightest spark could ignite these fuels and cause an
explosion.
tDO NOT light a cigarette or smoke.
A
B
C
D
E
F
